DVD-R DRIVE UNIT SW-9501-S / SW-9501-T INSTRUCTION MANUAL Please read through these instructions before operating this unit. Interface : SCSI iii DVD-R DRIVE UNIT SW-9501-S / SW-9501-T INSTRUCTION MANUAL Please read through these instructions before operating this unit. Interface : SCSI TABLE OF CONTENTS IMPORTANT SAFETY NOTICE 1. PRECAUTIONS WHEN OPERATING ................................................................... A-6 1.1 PRECAUTIONS WHEN TRANSPORTING ...................................................... A-6 1.2 INSTALLATION LOCATION ............................................................................ A-6 1.3 PRECAUTIONS FOR USE .............................................................................. A-6 1.4 PRECAUTIONS FOR OPERATION ................................................................ A-6 1.5 PRECAUTIONS WHEN HANDLING DISCS .................................................... A-6 2. PARTS AND FUNCTIONS .................................................................................... A-8 2.1 FRONT VIEW ................................................................................................... A-8 2.2 REAR VIEW ..................................................................................................... A-9 3. CONNECTIONS ..................................................................................................... A-10 3.1 CONNECTING VIEW ....................................................................................... A-10 4. GUIDE TO OPERATION ....................................................................................... A-11 4.1 INSTALLATIONS ............................................................................................. A-11 5. GENERAL DESCRIPTION .................................................................................... A-12 5.1 FEATURE SUMMARY ..................................................................................... A-12 5.2 SYSTEM SET UP ............................................................................................ A-12 5.3 POWER SAVING ............................................................................................. A-12 6. SPECIFICATION SUMMARY ................................................................................ A-13 6.1 PERFORMANCE ............................................................................................. A-13 6.2 ERROR RATES ............................................................................................... A-14 6.3 GENERAL PERFORMANCE ........................................................................... A-14 6.4 ENVIRONMENTAL CONDITIONS ................................................................... A-14 6.5 PICK UP LASER .............................................................................................. A-14 7. BEFORE REQUESTING SERVICE ....................................................................... A-15 7.1 TROUBLESHOOTING ..................................................................................... A-15 iv IMPORTANT SAFETY NOTICE NOTICE (1) You may not reproduce or transcribe any part of this publication without permission. (2) We reserve the right to revise this document at any time without notice. (3) If you have any questions about this document, contact your sales representative. SAFETY NOTICE (1) To prevent fire or electric shock, do not expose this appliance to rain or moisture. (2) To avoid electric shock or damage to the eyes due to laser beam, do not attempt to disassemble the cabinet. FEDERAL COMMUNICATIONS COMMISSION (FCC) RADIO FREQUENCY INTERFERENCE STATEMENT Class B Computing Device NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - - Reorient or relocate the receiving antenna. - - Increase the separation between the equipment and receiver. - - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - - Consult the dealer or an experienced radio/TV technician for help. FCC WARNING : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION : Use shielded connecting cables in order to meet FCC emission limits and also to prevent interference to nearby radio and television reception. For USA (Model SW-9501-S only) A-1 LASER SAFETY INFORMATION Class 1 LASER Product This equipment is certified to comply with DHHS Rule 21 CFR Chapter 1, Subchapter J in effect as of date of manufacture. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN60825 for Class 1 laser products. Class 1 laser products are not considered to be hazardous. To ensure continued product safety, the following precautions should be heeded. Caution : (1) The use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. (2) Do not open the drive unit; no user adjustments or serviceable parts are inside. • This label is attached to the inner side of the rear wall on the Mechanism chassis in the built-in drive unit. Laser radiation when open. AVOID DI…

Text truncated - open the document above for the full version.

LPC AN8726FHQ 100pin MEC LDCDON SRF[1-3] DRC MN67792 80pin MEC FEP AN87115FHQ 100pin MEC GAIN EQOUT WBLPOL ASENV/BCA OFST BDO ADSC MN67EV704 144pin MEC XJGDRC TROK RDCLK,RDDT[0-3] HA AN8686 48pin MEC FO[1-2] TR[1-4] RFN,RFP WBLENV,WDO IDENV SPDO,SPCK FE,TE SVAS STMOUT ODFOFS TPSOUT SHP ENV VCD OFTR TOF1,TOF2,TBAL RFDCTE LPP WBL LPP_WBL LPP WBLIN LPP_BTM WBL_BTM TPSOFS WTGT TPSPD PD80 SDIO1,SCK1,CSDRC WBLOK SPMOK Inner SW SPMDRV AN8471SA 32pin MEC DMEC FG SPEN0 JMON SVASOFS SVFSTC ODFTR2 HBRDRV uPD16857 38pin NEC FOA+,FOA-,FOB+,FOB- CLK169 WPLLOK/XCLDCK BLKCLK RDCLK,RDDTA[0-3] XFMOK/IPFLG LWOFF SHPLRCK,SHPDATA XJG SUBC ODC LC897320 216pin SANYO XINTDSC SDI0,SDO0,SCK0 XENCIRC XINRSW CPU1 MN102H460B 128pin MEC TPSON WTMD WRDY1 XPPWR,XPPRD C2A[0-3],C2DT[0-7] XLDERR XLDCLR PWRMON XLDEND CPU2 HD64F2633 128pin HITACHI XBS2MD LDD AN8728FAP 32pin MEC PHOLD IPD BHOLD HFON INRD INPK1 INBS1,INBS2 Thermistor Flash ROM(4Mbit) MBM29LV400BC 48pin FUJITSU DT[0-15] ADR[0-18] CS BOSC XSRVRST XINT[0-1] Monitor WTDT WAIT LDMWP,LDMWN XCS E2PROM(4kbit) AK6440 8pin AKM Serial Enable Ready/Busy Reset SCSI ID(3) Option JP (2) XWR,XRD SYS_IRQ,SD_EVENT TxD3,RxD3,SCK3 FWE XSTBY,XRES FWE_EN,RSLT_FW CPU2_RDY LED LED DRAM (32Mbit) T2316162A45S 50pin TMTECK LVBIAS,PK1MDP,PK1MDN,BS1MDP,BS1MDN ROPC_RDY BLK_CP,SECT_CP ROPC_RST OPC ROPC TPS ENCODER XSPLDATA,ROPC_SH,XB_HLD,XPK_HLD E2PROM (2kbit) AK6420 8pin AKM (6) OPC_RST[1-2] RF_DC,RF_PEAK,RF_BTM ROPC_PK1,ROPC_PK2,ROPC_BTM TILTDRV BA6195FP 27pin ROHM TLT-LED,TLT_OUT,TLT_DRVEN,TLT_UDE TILT SWTLT_ULMT,TLT_LLMT TILT MotorTLM+,TLM- TILT Sensor TPDA,TPDB TPDCOM TLEDK Loading Motor Actuator (4) (6) (11)Spindle Motor WBLCLK/LRCK LEDK80 FOF1,FOF2,FBAL BRKMD SPMON TRD+,TRD- STPA+,STPA-,STPB+,STPB- XENSV TEMP SW-9501-S Block Diagram ENABLE SBCK LEDTPS Loading End SW Eject End SW Eject SW Traverse Motor LDMFW,LDMRV LDU(DVD) AD AD AD AD PWM DA DA DA AD AD DA AD AD BSDA AD BSDA AD AD DA DA DA AD BSDA 8 16 SCSI BUS 26.16MHz 16.93MHz Clock Line IC801 3.3V IC903,905 5V IC901 5V/3.3V IC2 3.3V 16.0MHz IC1 3.3V IC804 3.3V IC802 3.3V IC501 3.3V IC601 5V/3.3V IC301 3.3V IC401 5V/3.3V IC552 12V/5V IC551 12V/3.3V Pick Up PPN13KB00C8 NAMA LPF10RE04580 NIDEC COPAL MDN3BTCRA NAMA LMDRV LB1638M 10pin SANYO IC553 5V DC-DC Conv. M62270GP 5pin MITSUBISHI IC101 5V BSL5F01KA NAMA Power (+12V) Power (+5V) Power (+3.3V) Reset PST597I 5pin MITSUMI IC102 3.3V XRST33 TLT-A,TLT_B,TLT_SW TILT IC132 5V to IC501(ADSC) to IC501(ADSC) from IC501(ADSC) AD 400MHz typ.

Matsushita-Kotobuki Electronics Industries Ltd. Matsuyama Division Address: 2131-1 Minamikata, Kawauchi-cho, Onsen, Ehime 791 – 0395 Japan Tel: 089 - 966 - 2111 / Fax: 089 – 966 - 6006 March 30, 2000 Federal Communications Commission Office of Engineering and Technology Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Akzo Kashima Ltd. to act on our behalf in all matters relating to applications for the equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Akzo Kashima Ltd. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefit, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.862. This authorization expires one year from the current date. Sincerely yours, K. Matsugi Engineer Legal Affairs Sec. Matsuyama Division Matsushita-Kotobuki Electronics Ind.,Ltd.

MATSUSHITA-KOTOBUKI ELECTRONICS INDUSTRIES LTD. MATSUYAMA DIVISION 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan PHONE +81 89 966 2111 FAX +81 89 966 2123 Page 1 of 19 pages TEST REPORT REPORT NUMBER: MKM00F-004 APPLICANT: Matsushita-Kotobuki Electronics Industries, Ltd. MODEL NUMBER:SW-9501-S FCC ID:IUO9TB085CRS Regulation:FCC Part15B Class B Conducted Emission Test Radiated Emission Test Matsushita-Kotobuki Electronics Ind., Ltd. Matsuyama Division 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Tel.: +81 89 966 2111 Fax.: +81 89 966 5733 Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 2 of 19 pages TABLE OF CONTENTS Page SECTION1.TEST CERTIFICATION3 SECTION2.EQUIPMENT UNDER TEST5 SECTION3.SUPPORT EQUIPMENT USED6 SECTION4.CABLE(S) USED 7 SECTION5.CONSTRUCTION OF EQUIPMENT 8 SECTION6.OPERATING CONDITIONS9 SECTION7.TEST PROCEDURE(S)10 SECTION8.EVALUATION OF TEST RESULTS11 SECTION9.PHOTOGRAPHS OF TEST SET-UP17 SECTION10.INSTRUMENTS USED FOR TEST18 SECTION11.PRECISION19 SECTION12.VALIDITY OF TEST REPORT19 Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 3 of 19 pages SECTION 1. TEST CERTIFICATION APPLICANT INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Address: 8-1, Furujin-machi, Takamatsu-city, Kagawa-ken, 760-0025 Japan GRANTEE INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Division / Section: Matsuyama Division Legal Affairs Sec. Address: 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Telephone number: +81 89 966 2111 Fax number: +81 89 966 5733 Contact person: Kenji Matsugi DESCRIPTION OF TEST ITEM Kind of equipment: DVD-R Drive Trademark: Matsushita-Kotobuki FCC ID: IUO9TB085CRS Model number: SW-9501-S Serial number: SX0313000008 Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 4 of 19 pages TEST PERFORMED FCC Registration No.: 90793 Test started: March 30, 2000 Test completed: March 30, 2000 Purpose of test: FCC Docket 87-389 Regulation: FCC Part 15B Class B Unintentional Radiators Test setup: ANSI C63.4 -1992 Report file number: MKM00F-004 Report issue date: March 31, 2000 Test engineer: Shinji Yamauchi Report approved by : Hisayuki Honda [ Manager ] This equipment complies with above standard or regulation under the test condition or test configuration shown on this test report. Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 5 of 19 pages SECTION 2. EQUIPMENT UNDER TEST The equipment under test (EUT) consists of the following equipment. Indication in the following left side column corresponds to section 5. SymbolItemModel No. Serial No. FCC IDManufacturer A)DVD-RSW-9501-SSX0313000008IUO9TB085CRSMatsushita-Kotobuki DriveElectronics Ind., Ltd. Power ratings of EUT : AC 100-240V, 50/60Hz, 0.34-0.17A 2.1 Port(s) / Connector(s) : Port nameConnector typeConnector pinRemarks SCSIHalf pitch50 pin SCSIHalf pitch50 pin 2.2 Oscillator(s) / Crystal(s) : OscillatorOperatingBoard nameRemarks Frequency 16.00 MHz16.00 MHzMain PCBCPU2 26.16 MHz26.16 MHzMain PCBODC 16.93 MHz16.93 MHzMain PCBODC 400 MHz / typ.400 MHz / typ.Optical Pick UpHigh Frequency Module (Highest Frequency) Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 6 of 19 pages SECTION 3. SUPPORT EQUIPMENT USED The EUT has been supported by the following equipment during these tests. Indication in the following left side column corresponds to section 5. SymbolItemModel No.Serial No.FCC IDManufacturer B)Host ComputerOptiPlex GXaSPHWXDeclaration ofDELL DCSConformity C)CD-ROM3509-70723-ADGN1IUO9TB029CRSIBM Drive D)Color DisplayXC-1429C009133290BGB9J5XC-1429CMITSUBISHI E)ModemC202A010489BKM552C202AEPSON F)Printer3630A3219A17397BSD8533630AHEWLETT PACKARD G)KeyboardSK-1000REWM970911905GYUR36SKDELL H)AC AdapterH00CAA019592N.A.EPSON I )AC Adapter3301D91KZ41N.A.AT&T Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 7 of 19 pages SECTION 4. CABLE(S) USED The following cable(s) was used for testing. Indication number in the following left side column corresponds to section 5. NumberNameLengthShieldConnector 1)SCSI cable1.0 mYesMetal 2)SCSI cable0.9 mYesMetal 3)RS-232C cable1.2 mYesMetal 4)Centronics cable1.5 mYesMetal 5)Video cable1.4 mYesMetal 6)Keyboard cable1.9 mYesMetal 7)Power cord for EUT1.8 mNone 8)Power cord for Computer1.8 mNone 9)Power cord for CD-ROM Drive1.8 mNone 10)Power cord for Color Display1.5 mNone 11)Power cord for Modem1.9 mNone 12)Power cord for Printer2.0 mNone 13)Power cord for Printer2.0 mNone None : All cables are not attached ferrite core. Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 8 of 19 pages SECTION 5. CONSTRUCTION OF EQUIPMENT The construction of EUT during testing is as follows. System configuration * : EUT Symbol or numbers assigned to equipment or cables on this diagram are corresponded to the symbols or numbers assigned to equipment or cables on tables in Sections 2 to 4. G) Keyboard D) Color Display B) Host Computer * A) EUT C) CD-ROM Drive E) ModemF) Printer AC 120V 60Hz 5 6 I AC 120V 60Hz AC Adapter AC 120V 60Hz AC 120V 60Hz AC 120V 60Hz AC 120V 60Hz H AC Adapter 10 12 4 12 3 11 9 78 13 Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 9 of 19 pages SECTION 6. OPERATING CONDITIONS The EUT has been operated under the following conditions during the tests. 6.1 Operating condition The tests have been carried out under Read mode and Write mode. EUT was examined in the operating conditions that had maximum emissions. 6.2 Operation flow Following operations were performed continuously. 6.2.1 Read mode 6.2.2 Write mode The EUT reads the ‘H’ characters’ data from ROM Data Track The Computer sends the data to the Modem on loop back mode The Printer prints the data The Color Display displays the data The EUT play-back the data The EUT writes the ‘H’ characters’ data The Color Display displays the data Report No. MKM00F-004 FCC ID : IUO9TB085CRS Page 10 of 19 pages SECTION 7. TEST PROCEDURE(S) Tests have been carried out with the test procedure(s) drawn up by our laboratory which is in accordance with…
