DVD-ROM & CD-R/RW DRIVE UNIT SR-8571-B / SR-8571-C INSTRUCTION MANUAL Please read through these instructions before operating this unit. Interface : ATAPI iii ENGLISH DVD-ROM & CD-R/RW DRIVE UNIT CW-8571-B / CW-8571-C INSTRUCTION MANUAL Please read through these instructions before operating this unit. Interface : ATAPI TABLE OF CONTENTS IMPORTANT SAFETY NOTICE ................................................................................ iv LASER SAFETY INFORMATION ............................................................................. A-1 INTRODUCTION ........................................................................................................ A-4 1. PRECAUTIONS WHEN OPERATING ................................................................... A-5 1.1 PRECAUTIONS WHEN TRANSPORTING ...................................................... A-5 1.2 INSTALLATION LOCATION ............................................................................ A-5 1.3 PRECAUTIONS FOR USE .............................................................................. A-5 1.4 PRECAUTIONS FOR OPERATION ................................................................ A-5 1.5 PRECAUTIONS WHEN HANDLING DISCS .................................................... A-5 2. PARTS AND FUNCTIONS .................................................................................... A-7 2.1 FRONT VIEW ................................................................................................... A-7 2.2 REAR VIEW ..................................................................................................... A-7 3. CONNECTIONS ..................................................................................................... A-8 3.1 CONNECTING VIEW ....................................................................................... A-8 4. GUIDE TO OPERATION ....................................................................................... A-8 4.1 INSTALLATIONS ............................................................................................. A-8 5. GENERAL DESCRIPTION .................................................................................... A-9 5.1 FEATURE SUMMARY ..................................................................................... A-9 5.2 SYSTEM SET UP ............................................................................................ A-9 5.3 POWER SAVING ............................................................................................. A-9 6. SPECIFICATION SUMMARY ................................................................................ A-9 6.1 PERFORMANCE ............................................................................................. A-9 6.2 ERROR RATES ............................................................................................... A-10 6.3 AUDIO PERFORMANCE ................................................................................. A-10 6.4 GENERAL PERFORMANCE ........................................................................... A-11 6.5 ENVIRONMENTAL CONDITIONS ................................................................... A-11 6.6 PICK UP LASER .............................................................................................. A-11 7. BEFORE REQUESTING SERVICE ....................................................................... A-11 7.1 TROUBLESHOOTING ..................................................................................... A-11 iv IMPORTANT SAFETY NOTICE NOTICE (1) You may not reproduce or transcribe any part of this publication without permission. (2) We reserve the right to revise this document at any time without notice. (3) If you have any questions about this document, contact your sales representative. SAFETY NOTICE (1) To prevent fire or electric shock, do not expose this appliance to rain or moisture. (2) To avoid electric shock or damage to the eyes due to laser beam, do not attempt to disassemble the cabinet. FEDERAL COMMUNICATIONS COMMISSION (FCC) RADIO FREQUENCY INTERFERENCE STATEMENT Class B Computing Device NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - - Reorient or relocate the receiving antenna. - - Increase the separation between the equipment and receiver. - - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - - Consult the dealer or an experienced radio/TV technician for help. FCC WARNING : Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. For USA (Model CW-8571-B only) A-1 ENGLISH LASER SAFETY INFORMATION Class 1 LASER Product This equipment is certified to comply with DHHS Rule 21 CFR Chapter 1, Subchapter J in effect as of date of manufacture. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN60825 for Class 1 laser products. Class 1 laser products are not considered to be hazardous. To ensure continued product safety, the following precautions should be heeded. This equipment has the Optical Pickup which has the Dual Lasers (DVD & CD). Caution : (1…

Text truncated - open the document above for the full version.

Servo DSP MKE Front End LSI CD APC Serial I/F TE & FE detection RF & Dropout detection RF AMP AGC RF Equalizer Linear Driver Pick Up CD:300MHz(typ.) DVD:400MHz(typ.) Power (+5V) Line Out CONFIDENTIAL CW-8571-B FUNCTIONAL BLOCK DIAGRAM Micro Processor Optical Disc Controller Micro processor I/F ATAPI DRAM controller ECC processor Syndrome / CRC Chien search CD / DVD Formatter DRAM 16M bit IDE Bus 0.6V 0.6V DVD-RAM Play Power (+12V) 5V IC60112V / 5V IC602 12V IC701 5V / 3.3V IC201 3.3V IC101 5V / 3.3V / 1.8V 45.16MHz Regulator (+5v to +2.7V) Regulator & Reset IC (+5v to +3.3V) IC104 IC103 Serial I/F PWM output D/A Converter A/D Converter Servo processor Access Control CLV & CAV control Interpolation Digital Attenuation Digital Deemphasis Digital Filter DAC (MASH) CIRC Data Slice VCO PLL IC401 3.3V 45.16MHz 33.86MHz 33.86MHz 33.86MHz Control Signal Line Clock Line Regulator (+5v to +1.8V) IC102 Linear Driver IC603 5V Flash ROM IC202 3.3V Wobble detection ATIP Write Strategy CD Encoder DVD LPC OPC Disk Motor Spindle Motor Driver Traverse Motor Loading Motor Head-phone Amp. Head phone Out IC302 5V

MATSUSHITA-KOTOBUKI MATSUSHITA-KOTOBUKIMATSUSHITA-KOTOBUKI MATSUSHITA-KOTOBUKI ELECTRONICS INDUSTRIES LTD. ELECTRONICS INDUSTRIES LTD.ELECTRONICS INDUSTRIES LTD. ELECTRONICS INDUSTRIES LTD. MATSUYAMA DIVISION 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan PHONE +81 89 966 2111 FAX +81 89 966 2123 Page 1 of 18 pages TEST REPORT REPORT NUMBER: MKM01F-009 APPLICANT: Matsushita-Kotobuki Electronics Industries, Ltd. MODEL NUMBER: CW-8571-B FCC ID: IUO9TB091CRB Regulation: FCC Part15B Class B Conducted Emission Test Radiated Emission Test Matsushita-Kotobuki Electronics Ind., Ltd. Matsuyama Division 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Tel.: +81 89 966 2111 Fax.: +81 89 966 5733 Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 2 of 18 pages TABLE OF CONTENTS Page SECTION 1.TEST CERTIFICATION3 SECTION 2.EQUIPMENT UNDER TEST5 SECTION 3.SUPPORT EQUIPMENT USED6 SECTION 4.CABLE(S) USED 7 SECTION 5.CONSTRUCTION OF EQUIPMENT 9 SECTION 6.OPERATING CONDITIONS10 SECTION 7.TEST PROCEDURE(S)11 SECTION 8.EVALUATION OF TEST RESULTS12 SECTION 9.PHOTOGRAPHS OF TEST SET-UP16 SECTION 10. INSTRUMENTS USED FOR TEST17 SECTION 11. PRECISION18 SECTION 12. VALIDITY OF TEST REPORT18 Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 3 of 18 pages SECTION 1. TEST CERTIFICATION APPLICANT INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Address: 8-1, Furujin-machi, Takamatsu-city, Kagawa-ken, 760-0025 Japan GRANTEE INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Division / Section: Matsuyama Division Legal Affairs Sec. Address: 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Telephone number: +81 89 966 2111 Fax number: +81 89 966 5733 Contact person: Kenji Matsugi DESCRIPTION OF TEST ITEM Kind of equipment: DVD-ROM & CD-R/RW Drive Trademark: Matsushita-Kotobuki FCC ID: IUO9TB091CRB Model number: CW-8571-B Serial number: 1116XXA00010 Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 4 of 18 pages TEST PERFORMED FCC Registration No.: 90793 Test started: February 15, 2001 Test completed: February 15, 2001 Purpose of test: FCC Docket 87-389 Regulation: FCC Part 15B Class B Unintentional Radiators Test setup: ANSI C63.4 -1992 Report file number: MKM01F-009 Report issue date: February 15, 2001 Test engineer: Shinji Yamauchi Report approved by : Hisayuki Honda [ Manager ] This equipment complies with above standard or regulation under the test condition or test configuration shown on this test report. Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 5 of 18 pages SECTION 2. EQUIPMENT UNDER TEST The equipment under test (EUT) consists of the following equipment. Indication in the following left side column corresponds to section 5. SymbolItemModel No. Serial No. FCC IDManufacturer A) DVD-ROM CW-8571-B 1116XXA00010IUO9TB091CRBMatsushita-Kotobuki & CD-R/RW Drive Electronics Ind., Ltd. Power ratings of EUT : +5V DC, 1.0A / +12V DC, 2.0A 2.1 Port(s) / Connector(s) : IDE Bus Connector(40pin), Head Phone Jack(Stereo Mini Plug), Audio Out Connector(4pin), Digital Audio Out Connector(2pin), DC IN Connector(4pin) 2.2 Oscillator(s) / Crystal(s) : OscillatorOperatingBoard nameRemarks Frequency 33.86 MHz45.16 MHzMain PCBOptical Disc Controller 33.86 MHz45.16 MHzMain PCBCPU 300 MHz / typ.300 MHz / typ.Pick UpHigh Frequency Module (CD) 400 MHz / typ.400 MHz / typ.Pick UpHigh Frequency Module (DVD) Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 6 of 18 pages SECTION 3. SUPPORT EQUIPMENT USED The EUT has been supported by the following equipment during these tests. Indication in the following left side column corresponds to section 5. SymbolItemModel No.Serial No.FCC IDManufacturer B) Interface Card LMEP0345ANoneIUO9TB035CRIMatsushita- Kotobuki C) Host Computer OptiPlex GXaSPHWXDeclaration ofDELL DCSConformity D) Head PhoneRP-HT28NoneN.A.Panasonic E) Stereo RadioRX-F5NoneACJ9TBRX-F5Panasonic Cassette Recorder F) KeyboardSK-1000REWM970911905GYUR36SKDELL G) Color Display14MVX5103ABL9679001CDHITACHI H) Printer3630A3219A17397BSD8533630AHEWLETT PACKARD I ) ModemC202A010489BKM552C202AEPSON J ) MouseM-S34-6MDID75BCIF1MONDZL211029COMPAQ Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 7 of 18 pages SECTION 4. CABLE(S) USED The following cable(s) was used for testing. Indication number in the following left side column corresponds to section 5. NumberNameLengthShieldFromTo 1)40Pin Flat cable0.4 mNoneDVD-ROM DriveHost Computer Plastic connector 2)Audio cable0.4 mNoneDVD-ROM DriveInterface Card Plastic connector 3)Digital Audio cable0.4 mNoneDVD-ROM DriveInterface Card Plastic connector 4)DC Power cable0.4 mNoneDVD-ROM DriveHost Computer 5)Head Phone cable1.5 mNoneDVD-ROM DriveHead Phone Plastic connector 6)Audio cable1.0 mNoneInterface CardStereo Radio Cassette Recorder 7)Audio cable1.0 mNoneInterface CardStereo Radio Cassette Recorder 8)Keyboard I/F cable1.9 mYesHost ComputerKeyboard Metal connector 9)Video Signal1.4 mYesHost ComputerColor Display I/F cableMetal connector None : All cables are not attached ferrite core. Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 8 of 18 pages The following cable(s) was used for testing. Indication number in the following left side column corresponds to section 5. NumberNameLengthShieldFromTo 10)Mouse cable1.8 mNoneHost ComputerMouse Metal connector 11)Parallel I/F cable1.5 mYesHost ComputerPrinter Metal connector 12)RS-232C I/F cable1.1 mYesHost ComputerModem Metal connector 13)Power cord for1.9 mYesHost ComputerPower Source Host Computer 14)Power cord for Stereo1.9 mNoneStereo RadioPower Source Radio Cassette RecorderCassette Recorder 15)Power cord for1.9 mNoneColor DisplayPower Source Color Display 16)Power cord for Printer2.0 mNonePrinterAC Adapter 17)Power cord for Printer2.0 mNoneAC AdapterPower Source 18)Power cord for Modem1.9 mNoneModemPower Source None : All cables are not attached ferrite core. Report No. MKM01F-009 FCC ID : IUO9TB091CRB Page 9 of 18 pages SECTION 5. CONSTRUCTION OF EQ…
