J2LLUFXLimited Modular Transmitter

5About Consumables 5.1Available Consumables.................................................................... 72 5.2EP Cartridge .................................................................................... 74 5.3Fuser Unit ........................................................................................ 77 5.4Transfer Roll Cartridge ..................................................................... 81 5.5Feed Roll.......................................................................................... 85 Lupin_IOT.book Page 71 Monday, February 24, 2003 10:23 AM 72 5 About Consumables 5.1 Available Consumables The following consumables are available for this printer. To order these, contact our Printer Support Desk. EP cartridge The EP cartridge includes the toner and the photosensitive drum. If the toner in the EP cartridge is insufficient, the printout will become light and blurred. If it is time for replacement, replace with a new EP cartridge. The following types of EP cartridge are available: z 6 Kpv: can print approximately 6,000 pages z 10 Kpv: can print approximately 10,000 pages z 15 Kpv: can print approximately 15,000 pages The possible number of pages that can be printed is based on A4 size paper with a print ratio of 5% and the default density setting using one EP cartridge. The number of pages that can be actually printed varies according to the conditions of use. Use of EP cartridges not recommended by our company may impair print quality or printer performance. Use only EP cartridges recommended by our company on this printer. “5.2 EP Cartridge” for details on how to replace the EP cartridge. Lupin_IOT.book Page 72 Monday, February 24, 2003 10:23 AM 5.1 Available Consumables 73 5 About Consumables Regular replacement parts Regular replacement parts packaged together include the fuser unit, the transfer roll cartridge, and the feed roll. About 100,000 pages for a fuser unit and about 200,000 pages for a transfer roll cartridge and a feed roll can be printed. When these parts have reached this limit, replace them with new ones. The possible number of pages that can be printed is based on A4 size paper with a print ratio of 5% and the default density setting. The number of pages that can be actually printed varies according to the conditions of use. z “5.3 Fuser Unit” for details on how to replace the fuser unit. z “5.4 Transfer Roll Cartridge” for details on how to replace the transfer roll cartridge. z “5.5 Feed Roll” for details on how to replace the feed roll. Fuser unit Transfer roll cartridge Feed roll Lupin_IOT.book Page 73 Monday, February 24, 2003 10:23 AM 74 5 About Consumables 5.2 EP Cartridge This section explains about the EP cartridge. 5.2.1Cautions on Handling the EP Cartridge When handling the EP cartridge, take note of the following points: z Do not subject it to direct sunlight or strong light. z When installing the EP cartridge, select a location not subject to strong light and try to finish the installation within 5 minutes. z Do not touch the surface of the photosensitive drum. Do not let the EP cartridge stand or place it upside down. The drum might get damaged. z A drum shutter protects the photosensitive drum from light. Do not open the drum shutter. z Although the toner is not harmful to the body, wash it off immediately if your hands or clothes are stained with it. z It is recommended to use up the EP cartridge within 1 year after opening it. 5.2.2Replacing the EP Cartridge Procedure 1 Switch off the power of the printer. Never throw an EP cartridge into an open flame. It can cause an explosion and you can get burnt. Lupin_IOT.book Page 74 Monday, February 24, 2003 10:23 AM 5.2 EP Cartridge 75 5 About Consumables 2 Remove any paper in the center output tray. 3 Open the top cover. Do not touch any parts inside the printer. 4 Hold the EP cartridge by the grip and pull it out slowly. To prevent the toner from dirtying the floor, lay a piece of paper on the floor first before putting the EP cartridge down. 5 Take the new EP cartridge out of the box and shake it 7 to 8 times in the manner as shown in the diagram. z If the toner is not evenly spread out, the print quality may drop. Also, if you did not shake the EP cartridge well, there may be operating noise or the interior of the EP cartridge may be damaged during operation. z Do not touch the surface of the photosensitive drum. Lupin_IOT.book Page 75 Monday, February 24, 2003 10:23 AM 5.2 EP Cartridge 76 5 About Consumables 6 Place the EP cartridge on a flat surface and pull out the seal horizontally. z When pulling out the seal, pull it out horizontally. The tape might break if it is pulled out diagonally. z After the seal has been pulled out, do not shake or dump the EP cartridge. 7 Hold the EP cartridge by the grip and insert it into the slot inside the printer. z Do not touch any parts inside the printer. z Ensure that the EP cartridge is firmly set. 8 Close the top cover securely. Lupin_IOT.book Page 76 Monday, February 24, 2003 10:23 AM 77 5 About Consumables 5.3 Fuser Unit This section explains about the fuser unit. 5.3.1Caution on Handling the Fuser Unit The fuser unit is included as one of the regular replacement parts. Before replacing the fuser unit, open the box of the regular replacement parts and get the new fuser unit ready. When handling the fuser unit, take note of the following points: z Do not replace the fuser unit immediately after using the printer. You may get burnt. z Never touch a labeled area found on or near the heat roller. You can get burnt. If a sheet of paper is wrapped around the heat roller, do not try to remove it by yourself to avoid injuries or burns. Switch off the machine immediately, and contact our Printer Support Desk. z Be sure to switch off and unplug the machine before accessing the interior of the machine for cleaning, maintenance, or fault clearance. Access to a live machine’s interior can cause electric shock. Lupin_IOT.book Page 77 Mond…

Text truncated - open the document above for the full version.

5About Consumables 5.1Available Consumables.................................................................... 72 5.2EP Cartridge .................................................................................... 74 5.3Fuser Unit ........................................................................................ 77 5.4Transfer Roll Cartridge ..................................................................... 81 5.5Feed Roll.......................................................................................... 85 Lupin_IOT.book Page 71 Monday, February 24, 2003 10:23 AM 72 5 About Consumables 5.1 Available Consumables The following consumables are available for this printer. To order these, contact our Printer Support Desk. EP cartridge The EP cartridge includes the toner and the photosensitive drum. If the toner in the EP cartridge is insufficient, the printout will become light and blurred. If it is time for replacement, replace with a new EP cartridge. The following types of EP cartridge are available: z 6 Kpv: can print approximately 6,000 pages z 10 Kpv: can print approximately 10,000 pages z 15 Kpv: can print approximately 15,000 pages The possible number of pages that can be printed is based on A4 size paper with a print ratio of 5% and the default density setting using one EP cartridge. The number of pages that can be actually printed varies according to the conditions of use. Use of EP cartridges not recommended by our company may impair print quality or printer performance. Use only EP cartridges recommended by our company on this printer. “5.2 EP Cartridge” for details on how to replace the EP cartridge. Lupin_IOT.book Page 72 Monday, February 24, 2003 10:23 AM 5.1 Available Consumables 73 5 About Consumables Regular replacement parts Regular replacement parts packaged together include the fuser unit, the transfer roll cartridge, and the feed roll. About 100,000 pages for a fuser unit and about 200,000 pages for a transfer roll cartridge and a feed roll can be printed. When these parts have reached this limit, replace them with new ones. The possible number of pages that can be printed is based on A4 size paper with a print ratio of 5% and the default density setting. The number of pages that can be actually printed varies according to the conditions of use. z “5.3 Fuser Unit” for details on how to replace the fuser unit. z “5.4 Transfer Roll Cartridge” for details on how to replace the transfer roll cartridge. z “5.5 Feed Roll” for details on how to replace the feed roll. Fuser unit Transfer roll cartridge Feed roll Lupin_IOT.book Page 73 Monday, February 24, 2003 10:23 AM 74 5 About Consumables 5.2 EP Cartridge This section explains about the EP cartridge. 5.2.1Cautions on Handling the EP Cartridge When handling the EP cartridge, take note of the following points: z Do not subject it to direct sunlight or strong light. z When installing the EP cartridge, select a location not subject to strong light and try to finish the installation within 5 minutes. z Do not touch the surface of the photosensitive drum. Do not let the EP cartridge stand or place it upside down. The drum might get damaged. z A drum shutter protects the photosensitive drum from light. Do not open the drum shutter. z Although the toner is not harmful to the body, wash it off immediately if your hands or clothes are stained with it. z It is recommended to use up the EP cartridge within 1 year after opening it. 5.2.2Replacing the EP Cartridge Procedure 1 Switch off the power of the printer. Never throw an EP cartridge into an open flame. It can cause an explosion and you can get burnt. Lupin_IOT.book Page 74 Monday, February 24, 2003 10:23 AM 5.2 EP Cartridge 75 5 About Consumables 2 Remove any paper in the center output tray. 3 Open the top cover. Do not touch any parts inside the printer. 4 Hold the EP cartridge by the grip and pull it out slowly. To prevent the toner from dirtying the floor, lay a piece of paper on the floor first before putting the EP cartridge down. 5 Take the new EP cartridge out of the box and shake it 7 to 8 times in the manner as shown in the diagram. z If the toner is not evenly spread out, the print quality may drop. Also, if you did not shake the EP cartridge well, there may be operating noise or the interior of the EP cartridge may be damaged during operation. z Do not touch the surface of the photosensitive drum. Lupin_IOT.book Page 75 Monday, February 24, 2003 10:23 AM 5.2 EP Cartridge 76 5 About Consumables 6 Place the EP cartridge on a flat surface and pull out the seal horizontally. z When pulling out the seal, pull it out horizontally. The tape might break if it is pulled out diagonally. z After the seal has been pulled out, do not shake or dump the EP cartridge. 7 Hold the EP cartridge by the grip and insert it into the slot inside the printer. z Do not touch any parts inside the printer. z Ensure that the EP cartridge is firmly set. 8 Close the top cover securely. Lupin_IOT.book Page 76 Monday, February 24, 2003 10:23 AM 77 5 About Consumables 5.3 Fuser Unit This section explains about the fuser unit. 5.3.1Caution on Handling the Fuser Unit The fuser unit is included as one of the regular replacement parts. Before replacing the fuser unit, open the box of the regular replacement parts and get the new fuser unit ready. When handling the fuser unit, take note of the following points: z Do not replace the fuser unit immediately after using the printer. You may get burnt. z Never touch a labeled area found on or near the heat roller. You can get burnt. If a sheet of paper is wrapped around the heat roller, do not try to remove it by yourself to avoid injuries or burns. Switch off the machine immediately, and contact our Printer Support Desk. z Be sure to switch off and unplug the machine before accessing the interior of the machine for cleaning, maintenance, or fault clearance. Access to a live machine’s interior can cause electric shock. Lupin_IOT.book Page 77 Mond…

Text truncated - open the document above for the full version.

April 17, 2003 14085 Howard Rd Dayton, MD 21036 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21036 Re: FCC ID:J2LLUFX Gentlemen: Submitted herewith is an application for a low frequency transmitter module to be used in a series of printers having essentially same form factor. In accordance with the requirements set forth in DA 00-1407 Released: June 26, 2000, this device incorporates the design features as described and listed below for Part 15 limited modular transmitter approval: 1. The modular transmitter has its own RF shielding. As can be seen from the test site photos, the device was tested outside the host equipment that provided data and power to the unit. The PC board with the RF circuit incorporated is contained within the internal shield as shown in the photo. This basic pc board assembly is host to the RF transmitter circuit and is used across many printers comprising a family of products using the LUFX board that have the same basic mechanical and electrical specifications. 2. This modular transmitter only has data inputs from the basic printer and toner cartridge assembly thus ensuring that the module will continue to comply with Part 15 requirements and no conditions of excessive data rates or over-modulation can occur. 3. This modular transmitter receives its DC power from a regulated supply providing power to the main PC board. The design of the power supply circuitry in the printers into which the PC board is installed requires a regulated supply voltage at a fixed level to the PC board thus ensuring the modular transmitter will always receive the correct regulated voltage. 4. The modular transmitter complies with the antenna requirements of Section 15.203 and 15.204(c) and is a small multi-turn inductively coupled loop antenna that couples to the toner cartridge. 5. This modular transmitter was tested in a stand-alone configuration outside the host device during testing. The host device is an ac-powered unit intended to be used as an office/business printer. No modifications were made to the host device. 6. This modular transmitter is labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed will also display a label referring to the enclosed module. This exterior label will use this wording: “Contains FCC ID: J2LLUFX”. 7. This modular transmitter complies with all operating requirements applicable to the transmitter. 8. This modular transmitter complies with applicable RF exposure requirements. Its measured field strength level is 1.9 uV/m at 300 meters when extrapolated using inverse linear method from measurements made at 3 meters. This is very conservative and the level would be much lower. Further, the module is intended to be installed inside a host device which provides additional isolation from the user. Specific installation and operating instructions for users are not required as the only user installed portion of this system is replacement toner cartridges that have very fixed installation procedures. If there are any additional questions, please contact me at 410-531-3439. Sincerely yours, Phillip Inglis TRP/Cetecom bvba

April 17, 2003 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Fuji Xerox Co., Ltd. application for Spread Spectrum System, FCC ID: J2LLUFX Gentlemen: Fuji Xerox Co., Ltd, 7-1, Funai 3-Chome Iwatsuki-shi, Saitama 339-8509, Japan herein submits an Application for Equipment Authorization for certification of a spread spectrum transmitter under FCC Rules Part 15. Fuji Xerox Co., Ltd., requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the item during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as attachment: "schematics”. 2. Block diagram submitted as attachment “block diagram”. 3. Theory of operation submitted as attachment “operational description”. 4. Parts list submitted as attachment “parts list”. Specifically, these exhibits contain information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that Fuji Xerox does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by phone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Regards, (signed) Phillip Inglis, TRP/Cetecom b.v.b.a. 14085 Howard Rd. Dayton, MD. 21036

CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 17 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX Photograph no.: 1 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 18 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX Photograph no.: 2

Label for FCC ID: J2LRFHIFX to be placed on bottom of unit it is installed within. This devices contains FCC ID:J2LLUFX IC:4423A-LUFX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Bottom of unit. Label Loc.

CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 21 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-A Photograph no.: 5 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 22 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-A Photograph no.: 6 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 23 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-T Photograph no.: 7 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 24 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-T Photograph no.: 8

CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 19 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-C Photograph no.: 3 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 20 (24) PHOTOGRAPHS OF THE EQUIPMENT LUFX-C Photograph no.:4

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC14issue test report consist of 24 PagesPage 1 (24) Recognized by the Federal Communications Commission FCC–Identification Number: 90462 TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 2-3163-01-03/03 FCC Part 15.209 LUFX FCC ID: J2LLUFX CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 9075 BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 2 (24) Table of contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test specifications 2 Technical test 2.1 Summary of test results 2.2 Test report CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 3 (24) 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2003-02-27RSC - 8411Berg M. DateSectionNameSignature Technical responsibility for area of testing: 2003-02-27RSC - 8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 4 (24) 1.2 Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 0 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory Accredited by: Regulierungsbehörde für Telekommunikation und Post (RegTP) Listed by: Federal Communications Commission (FCC) AuthorityIdentification/Registration No. RegTPTTI-P-G 166/98-30 FCC90462 1.3Details of applicant Name :FUJI XEROX CO., LTD Street :3-7-1, Funai, Iwatsuki-shi City :Saitama 339-8509 Country :Japan Telephone:+81-48-798-5111 Telex :+81-48-790-1930 E-mail :[email protected] Contact person: Name : Mr. Tsuneo Imada Telephone : +81-48-798-5111 Telex : +81-48-790-1930 E-mail : 1.4Application details Date of receipt of test item : 2003-01-20 Date of test: 2003-01-20 Person(s) who have been : Mr. Masayuki Hirata present during the test: [email protected] CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 5 (24) 1.5Test item Type of equipment : Paasiv transponder reader for toner cartridges Type designation:LUFX (Part composition: LUFX-C, LUFX-A, LUFX-T) Manufacturer:Same as applicant Street: City: Country: Serial number:- / - Additional information : Frequency:125 kHz Channel spacing:-.- Number of channels :1 Antenna:Integral antenna ERP:65.6 dBμV/m in 3m distance or 25.6 dBμV/m in 300m distance Power supply:3.3V DC ext. Temperature range :0°C - +55°C FCC ID :J2LLUFX 1.6Test specifications: FCC Part 15 §15.209 CANADA RSS-210 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 6 (24) 2 Technical test 2.1 Summary of test results The radiated measurements are performed in vertical and horizontal plane in the frequency range from 9 kHz to 20 GHz in semi-anechoic chambers. The EUT is positioned on a non- conductive support with a height of 0.80 m above a conductive ground plane that covers the whole chamber. The receiving antennas are conform with specifications ANSI C63.2-1987 clause 15 and ANSI C63.4-1992 clause 4.1.5. These antennas can be moved over the height range between 1.0 m and 4.0 m in order to search for maximum field strength emitted from EUT. The measurement distances between EUT and receiving antennas are indicated in the test set-ups for the various frequency ranges. For each measurement, the EUT is rotated in all three axes until the maximum field strength is received. The wanted and unwanted emissions are received by spectrum analysers where the detector modes and resolution bandwidths over various frequency ranges are set according to requirement ANSI C63-4-1992 clause 4.2. Antennas are conform with ANSI C63.2-1996 item 15. 150 kHz - 30 MHz: Quasi Peak measurement, 9kHz Bandwidth, passive loop antenna . 30 MHz - 200 MHz: Quasi Peak measurement, 120KHz Bandwidth, biconical antenna 200MHz - 1GHz: Quasi Peak measurement, 120KHz Bandwidth, log periodic antenna >1GHz: Average, RBW 1MHz, VBW 10 Hz, wave guide horn All measurement settings are according to FCC 15.35, 15.209. The product fulfils also the requirements for CANADA RSS-210 No deviations from the technical specification(s) were ascertained in the course of the tests performed. FINAL VERDICT : PASS CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 7 (24) 2.2Test report TEST REPORT Test report no: 2-3163-01-03/03 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 8 (24) LIST OF MEASUREMENTS. The list of measured parameters is given below. Clause Page number Transmitter parameters § 15.209Effective radiated RF power9 § 15.209Spurious radiations – Radiated10 Test equipment listing14 Photographs of the equipment16 CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 9 (24) Equipment under test : LUFX Ambient temperature : 23° °° °C Relative humidity : 33% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see tes…

Text truncated - open the document above for the full version.

FUJI XEROX CO., LTD Environmental and Product Safety Department 2274, Hongo Ebina-shi, Kanagawa 243-0494, Japan Name of the standard document; EMC TEST REPORT Form or Standard Number: EPS25-F001 Form revision: k1 Page:22 of 57 Test plan Number: EPS-2002-025 Produced © by FUJI XEROX CO., LTD. Test Data

CETECOM ICT Services GmbH Test report no.:2-3163-01-03/03Issue date: 2003-02-26 Page 16 (24) Photographs of the equipment Test site
