JBQCDR017Internal CD-RW Drive

1998.11.24 FCC ID : JBQCDR017 MODEL CRD-RW1 BLOCK DIAGRAM A ctuator Optical Electric ICLaser Diode SpindleSledTray Actuator Driver Sample & Hold RF Amplifier A uto Power Control* Stepping Driver Motor Driver Micro Processor H8(128Kflash) 20MHZ Matrix Amplifier A uto Adjust* Digital-Servo DSP 33.86MHZ Wobble Demodulator Strategy IC SANYO Encoder/Decoder SANYO 17.2872MHZ DRAM 2MB SCSI CONNECTOR AUDIO Line Out Spindle Driver A CTIVE TERMINATOR LED READ  WRIT ID SELECT EJECT SWITCH HEADPHONE JACK V OLUME POWER CONNECTOR 5V 12V D/D CONVERTER MOTOR 12V DRIVER 5V MAIN 5V A NALOG 3.3V    7  RW1      AC INLET DC Cable M ain Board Power Supply SCSI ConnectorAudio SCSI Internal DC CableInternal CableCable  CRD-RW1    h ones Connector Volume

ZACTA TECHNOLOGY CORPORATION December 8, 1998 Yonezawa Testing Center 4149-7 Hachimanpara 5-Chome Yonezawa-shi Yamagata 992-1128 Japan Tel:+81-238-28-2880 FAX:+81-238-28-2888 ATTN: FEDERAL COMMUNICATION COMMISSION Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 USA RE: FCC Part 15 Certification CD-RW drive JBP-Computing Device Peripheral File # : Z02C-98355 APPLICANT : Sanyo Electric Co., Ltd. FCC ID : JBQCDR017 Gentlemen: Please find the attached exhibits listed below; Block Diagram External Photos ID Label / Location Info Internal Photos Operational description Test Report Test Setup Photos User Manual Your prompt attention to this matter would be highly appreciated. If there are any questions or if further information is needed, please contact our USA point of Contact as follows: Zacta International Corporation 21220 Devonshire street, Suite 201 Chatsworth CA. 91311 Contact Name: Yoshi Namiki / Consultant Tel: 818-727-1740 Fax: 818-727-7938 E-mail: [email protected] We also hereby certify that no party to this application is subject to denial of benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 853(a). Sincerely yours, Akemi Suzuki [email protected] Filling Coordinator of ZACTA TECHNOLOGY CORPORATION

Master: ktlPT15BR Date: October 8, 1998 KTL Test Report:8R00987 Applicant:VTECH Engineering Canada Ltd. 200-7671 Alderbridge Way Richmond, B.C. V6X 1Z9 Equipment Under Test:Sony SPP-900 (E.U.T.)Analog 900 MHz Cordless Telephone In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: _____________________________________ W. Waterhouse, RF Engineering Lab Manager Date:_____________________________________ Total Number of Pages:30 KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 2 of 30 TABLE OF CONTENTS Section 1. Summary of Test Results General Summary of Tests Section 2. Equipment Under Test (E.U.T.) Equipment Details Description of E.U.T. Modifications Incorporated in E.U.T. Theory of Operation Justification Exercise Program Section 3. Equipment Configuration Equipment Configuration List Inter-connection Cables Configuration of the Equipment Under Test (E.U.T.) Block Diagram Section 4. Receiver Antenna Conducted Emissions Test Conditions Test Results Receiver Antenna Conducted Plots Section 5. Radiated Emissions Test Conditions Test Results Test Data-Radiated Emissions Radiated Photographs Radiated Emissions Plots Section 6. Powerline Conducted Emissions Test Conditions Test Results Powerline Conducted Photographs Powerline Conducted Plots KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 3 of 30 TABLE OF CONTENTS, continued Section 7. Sample Calculations Conducted Emissions Radiated Emissions Section 8. Block Diagrams Conducted Emissions Radiated Emissions Section 9. Test Equipment List Equipment List - Powerline Conducted Emissions Equipment List - Radiated Emissions KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 4 of 30 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. Abstract: Name Of TestPara. No.Results Antenna Conducted Emissions15.111Not Applicable Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Complies THIS REPORT APPLIES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. None NVLAP Lab Code: 100351-0 It is recommended that the margin of compliance be improved to allow for manufacturing tolerances. TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist TECHNICAL REVIEW: ____________________________ DATE: ___________________ Tom Tidwell, Wireless Group Manager KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 5 of 30 Section 2.Equipment Under Test (E.U.T.) Manufacturer:VTECH Engineering Canada Ltd. Model No.:Sony SPP-900, MK2A and MK2B Serial No.:None Class IINewProductionPre-ProductionEquipment Code Permissive ChangeSubmissionUnitUnit Equipment Details Base Handset Frequency Range:923.10 – 927.75 MHz902.3 – 906.65 MHz Number of Channels:3030 Operating Frequency(ies) of Sample:923.10, 925.05 MHz905.00, 905.15 MHz Crystal Frequency(ies):Not ApplicableNot Applicable Primary Power Requirement:9 Vdc via 120 VAC, 60 Hz (AC Adapter) 3.6 Vdc (NICD Battery) Bandwidth and Emission Designator:165KF1D165KF1D Intermediate Frequency(ies):10.7 MHz10.7 MHz KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 6 of 30 Description of E.U.T. The E.U.T. is a 30 channel analog cordless telephone. Modifications Incorporated in E.U.T. The EUT has not been modified from what is described by the brand name and unique type identification stated above. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 7 of 30 Theory of Operation The Sony SPP-900 is a basic analog cordless telephone. It has 30-channel operation which is operator controllable. It is intended to be compatible with most types of central office equipment in Canada, the United States and South America. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 8 of 30 Justification The E.U.T. was configured for testing as per typical installation. Position and bundling of cables were investigated to establish maximum amplitude of emissions. The following combinations were investigated to establish worst case configuration: BASE: 3-Orthagonal Orientations (1) Lying flat on the table, antenna pointing up. (2) Lying flat on the table, antenna pointing straight back. (3) Vertically mounted, antenna pointing up. HANDSET: 3-Orthagonal Orientations (1) Lying flat on its back. (2) Vertical (3) Lying on its side. Exercise Program The E.U.T. exercise program used during radiated and conducted testing was designed to exercise the various system components in a manner similar to typical use. Exercise mode: (1) Off hook, loaded telephone line, carrier enabled. KTL…
