JBQCDR028CD-RW Drive
Sanyo Electric Co Ltd
Click to zoom
Application Details
- Equipment Class
- JBP - Part 15 Class B Computing Device Peripheral
- Date of Grant
- Jun 30, 2002
- Application Purpose
- Original Equipment
- Date of Application
- Jun 30, 2002
- Equipment Note
- CD-RW Drive
- Company
- Sanyo Electric Co Ltd
- Country
- Japan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Block Diagram
FCC ID: JBQCDR028 CRD-BP1800P BlockDiagram PickUP 290MHz25% ACT SPDL MOTOR LC898095 AK8569B SLMOTOR D8 AC INLET DC Cable Main Board Power Supply Audio Internal Cable IDE Connector DC Cable IDE Internal Cable 8 HzHz Phones Connector Volume
External Photos
Sanyo Electric Co., Ltd. CD-RW Drive JBQCDR028
ID Label/Location Info
MODEL No. CRD-BP1800P Label goes here
Internal Photos
Sanyo Electric Co., Ltd. CD-RW Drive JBQCDR028
Test Report
Report No.:Z01C-02181 Page 2 of 15 ZACTA Technology Corp. FCC ID: JBQCDR028 FCC Certification Rev.3.0 Table of contents Page 1. Equipment description..............................................................................................................................3 1.1 EUT information....................................................................................................................................................................................3 1.2 Operating flow........................................................................................................................................................................................3 2. Configuration information........................................................................................................................4 2.1 Peripheral(s) information........................................................................................................................................................................4 2.2 Cable(s) information...............................................................................................................................................................................4 2.3 System configuration..............................................................................................................................................................................5 3. Test procedure..........................................................................................................................................6 3.1 Description of Conducted Emission testing............................................................................................................................................6 3.2 Test equipment for Conducted emission.................................................................................................................................................6 3.3 Description of Radiated emission testing................................................................................................................................................7 3.4 Test equipment for Radiated emission....................................................................................................................................................8 4. Laboratory description..............................................................................................................................9 4.1 Description for Test Site..........................................................................................................................................................................9 4.2 Uncertainty...........................................................................................................................................................................................10 5. Results of the measurements...................................................................................................................11 5.1 Results of the measurements.................................................................................................................................................................11 5.2 Deviation from the standard..................................................................................................................................................................11 5.3 Sample of field strength calculation......................................................................................................................................................11 6. Test Data................................................................................................................................................12 Report No.:Z01C-02181 Page 3 of 15 ZACTA Technology Corp. FCC ID: JBQCDR028 FCC Certification Rev.3.0 1. Equipment description 1.1 EUT information No. EUT Company Model No. Serial No. FCC ID/DoC Comment 1 CD-RW Drive SANYO CRD-BP1800P 1800PL149 JBQCDR028 - Max. used frequency : 290.00MHz (±25%) Oscillator(s)/Crystal(s) Operating frequency : 33.86MHz, 290.00MHz (±25%) Power ratings : DC +5V, +12V [EUT is powered from Host PC. Power supply for Host PC in testing was AC 120V 60Hz.] Port(s) : Headphones jack Audio connector IDE connector DC connector (DC input) Size : (W) 146 x (D) 188.5 x (H) 41.3 mm Operating mode : CD Read mode CD Write mode Variation of model(s) : Not applicable 1.2 Operating flow <CD Read > <CD Write > END EUT reads CD data and output data to PC. START END EUT writes data from PC on the CD. START Report No.:Z01C-02181 Page 4 of 15 ZACTA Technology Corp. FCC ID: JBQCDR028 FCC Certification Rev.3.0 2. Configuration information 2.1 Peripheral(s) information No. Equipment Company Model No. Serial No. DoC / FCC ID Comment 2 Main board COMPAQ N/A N/A N/A - 3 Personal Computer COMPAQ Prosig 320 C500/ M1 JPN2 7016 CZHP0116 DoC - 4 Headphone FISHER N/A N/A N/A - 5 Speaker Panasonic RP-SP30 N/A N/A - 6 Printer HP C4555A US6BC212N B94C4555X - 7 Display Goldstar Studio Works 56i 15005G004960 BEJCS585 - 8 Modem US Robotics 839 000839032BK6YV4J DoC - 9 AC adapter for Modem US Robotics N/A N/A N/A - 10 Keyboard COMPAQ KB-9965 B13B00WBUJ6150 DoC - 11 Mouse COMPAQ Intelli Mouse 0805393-5 DoC - 2.2 Cable(s) information No. Cable Length [m] Shield Connector From To Comment a IDE cable 0.4 Unshielded Plastic EUT Main board - b Audio cable 0.5 Unshielded Plastic EUT Main board - c DC cable 0.2 Unshielded Plastic EUT Power supply - d Headphone cable 1.0 Unshielded Metal EUT Headphone - e Speaker cable 1.0 Unshielded Metal PC Speaker - f Centronics cable 1.2 Shielded Metal PC Printer - g AC power cord for Printer 2.7 Unshielded Plastic Printer AC outlet - h RGB cable 1.5 Shielded Metal PC Display With one ferrite core Bundled excess cable. i AC power cord for Display 2.2 Unshielded Plastic Display AC outlet - j RS232C cable 1.4 Shielded Metal PC Modem Bundled excess cable.…
Text truncated - open the document above for the full version.
Test Setup Photos
Sanyo Electric Co., Ltd. CD-RW Drive JBQCDR028 Conduction Radiation Connectors
Contact Information
Applicant
Ryuichi Matsunae(Manager)
Technical Contact
PCTEST Engineering Lab., Inc.Randy Ortanez
[email protected]410-290-6652
6660-B Dobbin Road · Columbia, Maryland · United States
Test Firm
TUV SUD Zacta Ltd.Katsumi Sumiyoshi
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | - | - |
