JHITXRXPC Transceiver or Repeater or Wall Buster

1100 Falcon Ave.Tele:320-864-4444 Glencoe, MN 55336Fax: 320-864-6611 “Your Agent to Product Certifications and Licenses Throughout the World” To:Jaunice GreenAugust 2, 2002 From: Duane R. Bagdons Applicant: Graco Inc. Correspondence Reference Number: 23532 731 Confirmation Number: EA675138 Please disregard the following two files that were submitted on July 26 for this project: "FCC Label" and "FCC Label Location" and replace them with the single file just submitted in "add attachments" called "FCC Label and Location.pdf" Thank you Duane R. Bagdons INTERNATIONAL CERTIFICATION SERVICES INC.

1100 Falcon Ave.Tele:320-864-4444 Glencoe, MN 55336Fax: 320-864-6611 “Your Agent to Product Certifications and Licenses Throughout the World” To:FCCAugust 12, 2002 From: Duane R. Bagdons Form 731 Confirmation Number: EA675138 FCC ID: JHITXRX Cover Letter: On the Form 731 that was submitted on July 26 the name in Item 4: was listed as: Larry LunzerProject Manager. This has since been changed by Graco with the CORES Register FRN: 0007452931 on July 25 as: Mr. Douglas A. Rivord Tele: 612-623-6366 Fax: 612-623-6273 Email: [email protected] Graco Inc. & Subsidaries 88 11 th Ave N.E. Minneapolis, MN 55413-1894 Please make these changes to the form 731 submitted on July 26. Thank you Duane R. Bagdons INTERNATIONAL CERTIFICATION SERVICES INC.

1100 Falcon Ave.Tele:320-864-4444 Glencoe, MN 55336Fax: 320-864-6611 “Your Agent to Product Certifications and Licenses Throughout the World” July 5, 2002 Graco Inc. & Subsidiaries Product: Matrix PC TRANSCEIVER AND REPEATER P/N’s: 117256 and 117257 EXTERNAL PHOTOS TOP VIEW: INTERNATIONAL CERTIFICATION SERVICES INC. International Certification Services, Inc. [email protected] FRONT VIEW: International Certification Services, Inc. [email protected] TOP LABEL VIEW:

1100 Falcon Ave.Tele:320-864-4444 Glencoe, MN 55336Fax: 320-864-6611 “Your Agent to Product Certifications and Licenses Throughout the World” August 2, 2002 Graco Inc. & Subsidiaries Product: Matrix PC TRANSCEIVER REPEATER, and WALL BUSTER: P/N’s: 117256, 117257 and 117258 FCC LABEL LOCATION INTERNATIONAL CERTIFICATION SERVICES INC. FCC LABEL International Certification Services, Inc. [email protected] FCC LABEL TRANSCEIVER P/N: 117256 JHI TXRX 117256 International Certification Services, Inc. [email protected] FCC LABEL REPEATER P/N: 117257 JHI TXRX 117257 International Certification Services, Inc. [email protected] FCC LABEL WALL BUSTER P/N: 117258 JHI TXRX 117258

1100 Falcon Ave.Tele:320-864-4444 Glencoe, MN 55336Fax: 320-864-6611 “Your Agent to Product Certifications and Licenses Throughout the World” July 5, 2002 Graco Inc. & Subsidiaries Product: Matrix PC TRANSCEIVER AND REPEATER P/N’s: 117256 and 117257 INTERNAL PHOTOS INTERNAL CONSTRUCTION VIEW: INTERNATIONAL CERTIFICATION SERVICES INC. International Certification Services, Inc. [email protected] PC BOARD ASSEMBLY COMPONENT VIEW: International Certification Services, Inc. [email protected] FIXED BUILT IN RECEIVING ANTENNA: RECEIVING ANTENNA International Certification Services, Inc. [email protected] CLOSE UP OF THE TRANSMITTING ANTENNA: TRANSMITTING ANTENNA PC FOIL

TEST REPORT #180702 STANDARD: FCC PART 15 SUBPART C--INTENTIONAL RADIATORS SECTION 15.249 OPERATION WITHIN THE BANDS 902-928 MHZ, 2400-2483.5 MHZ, 5725-5875 MHZ, AND 24.0-24.25 GHZ. EQUIPMENT TESTED: GRACO INC. & SUBSIDIARIES MODEL: MATRIX PC TRANSCEIVER, REPEATER AND WALL BUSTER P/N: 117256, 117257 and 117258 TEST DATE: 18 JULY 2002 INTERNATIONAL CERTIFICATION SERVICES, INC. 1100 Falcon Avenue Glencoe, MN 55336 Tele: 320-864-4444 Fax: 320-864-6611 INTERNATIONAL CERTIFICATION SERVICES, INC. Prepared for: Test agent: Test location: Prepared by: . Graco Inc. & Subsidiaries PO Box 1441 Minneapolis, MN 55440-1441 International Certification Services, Inc. 1100 Falcon Avenue Glencoe, MN 55336 Tele: 320-864-4444 Fax: 320-864-6611 International Certification Services, Inc. 1100 Falcon Avenue Glencoe, MN 55336 Tele: 320-864-4444 Fax: 320-864-6611 International Certification Services, Inc. 1100 Falcon Avenue Glencoe, MN 55336 International Certification Services represents to the client that testing is done in accordance with standard procedures applicable and that reported test results are accurate within generally accepted commercial ranges of accuracy. This report only applies to the specific samples tested under stated test conditions. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. International Certification Services shall have no liability for any deductions, inferences or generalizations drawn by the client or others from this report. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. INTERNATIONAL CERTIFICATION SERVICES, INC. 1.0 TEST SUMMARY TEST REPORT: #180702 COMPANY: AGENT:International Certification Services, Inc. PHONE:320-864-4444 TEST DATE: EQUIPMENT UNDER TEST: GENERAL TEST SUMMARY: VERIFICATION / CERTIFICATION STATUS: MODIFICATIONS NECESSARY: TESTED BYWRITTEN BY Duane R. BagdonsDuane R. Bagdons Graco Inc. & Subsidiaries 18 July, 2002 Matrix PC Transceiver, Repeater and Wall Buster, P/N’s: 117256, 117257, and 117258 The testing was performed at International Certification Services, Inc. at 1100 Falcon Ave, Glencoe, MN 55336 The Matrix PC Transceiver, Repeater and Wall Buster, P/N’s: 117256, 117257, and 117258 were found to be in compliance with the FCC Part 15 Subpart C, Section 15.249 requirements. None INTERNATIONAL CERTIFICATION SERVICES, INC. Applicable Standards 47 CFR Ch.1 (10-1-98 Edition) FCC Part 15Radio Frequency Devices Subpart CIntentional Radiators Section 15.249Operation within the Bands 902-928 Mhz, 2400- 2483.5 Mhz, 5725-5875 Mhz, and 24.0-24.25 Ghz 2.1Referenced Standards ANSI C63.4-1992Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 Khz to 40 Ghz. 2.2 Equipment Units Tested The equipment tested was a wireless transceiver. The Three products (PC Transceiver, Repeater, and Wall Buster) are all identical except for internal firmware. Only the PC transceiver was tested as a typical sample of each of these products. This EUT is a stand alone device powered from a wall mounted transformer power supply that plugs into the 120 VAC, 60 Hz Mains. A serial cable connects this device to a computer for downloading information (both ways). The Receiver portion of the circuit is an integrated chip (Melixis TH71112 (868-915 Mhz FSK/FMIASK Receiver) which is preceded by a SAW filter. The Transmitter portion of the circuit is also a Melxis chip Type (TH71081 868-915 ASK Transmitter / LO Source). Information is received either from the attached computer and transmitted to the EUT or it is received on the internal wireless receiver from a remote device and sent to the computer on the serial cable connection. Information is sent in a serial data stream from the EUT. When transmitting from the wireless transmitter link, the data is sent out in a serial data stream and pulse modulates the transmitter chip. The maximum transmitted burst is 83 ms worst case limited by the internal data buffer in the circuit. Each cell time is 832 uS long and the worst case duty cycle is 50%. The minimum spacing between the data bursts is 1.5 seconds. 2.3 Equipment and Cable Configuration See photos of the EUT PC board and schematic and test configuration setup in Attachment A 2.4 List of Test Equipment Test Equipment Spectrum Analyzer Preamp Log Periodic Antenna (200-1000 MHz) Horn Antenna (1-18 Ghz) Model Hewlett-Packard 8566B MiniCircuits ZKL-2R7 EMCO 3146 EMCO 3115 S/N 2421A00458 N/A 9101-2991 5697 Last Calibration Date 08/27/01 11/21/01 12/17/01 12/17/01 INTERNATIONAL CERTIFICATION SERVICES, INC. Measurement cable losses, and antenna correction factors are included in the Corrected Data column of the data sheet. Quasi Peak Detection was used for measuring the Fundamental frequency signal and Average detection method was used to measure the Harmonics since they were all above 1000 Mhz. The Resolution BW was set at 1 Mhz and the Video BW was set at 1 Hz with a Span of 0 Hz to perform the correct average detected measurements. 2.5 Units of Measurement. All measurements were taken in dBuV/m with the antenna located at 3 meters distance from the EUT. Frequency measurements are recorded in Mhz. Input power to the intentional radiator was not recorded---only the radiated emissions with the internal transmitting antenna were recorded. 2.6 Location of Test Site The open area test site (OATS) and conducted measurement facility used to collect the data was International Certification Services, Inc. at 1100 Falcon Ave. in Glencoe, MN 55336. This site has been certified to be in compliance with the normalized site attenuation section of CISPR 16-1. (See FCC Registration number: 91103 and Industry Canada File number: IC 3701.) 2.7 Measurement Procedures The …
