JI5-D3GN4Wireless Gateway

Administrator Manual SMCD3GNV4 / SMCD3GNV4E Administrator Manual Wireless EMTA Gateway FastFind Links Getting to Know Your Gateway Installing Your Gateway Preparing to Configure Your Gateway Configuring the Gateway SMC Networks 20 Mason Irvine, CA 92618 U.S.A. Copyright © 2012 SMC Networks All Rights Reserved Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or stored in a database or retrieval system for any purpose without the express written permission of SMC. Microsoft and Windows are registered trademarks of Microsoft Corporation. Apple and Macintosh are registered trademarks of Apple, Inc. All other brands, product names, trademarks, or service marks are property of their respective owners. GPL/LGPL Licenses Statement This product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL used in this product, are available to you at http://gpl.smc.com/. The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL Code and LGPL Code for this product and the terms of the GPL and LGPL SMCD3GNV4 and SMCD3GNV4E Wireless EMTA Gateway Administrator Manual March 30, 2012 iii SMCD3GNV4 and SMCD3GNV4E Wireless EMTA Gateway Administrator Manual Safety This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment to ensure the safe use of the equipment. Safety Instructions Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. y Turning Off the Product Before Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. y Caution for Plug as Disconnecting Device When connecting power to the power supply unit, install the power supply unit before connecting the power cord to the AC power outlet. When disconnecting, unplug the power cord before removing the power supply unit from the computer. y Caution for Accessibility Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. When you need to disconnect power to the equipment, be sure to unplug the power cord from the electrical outlet. iv SMCD3GNV4 and SMCD3GNV4E Wireless EMTA Gateway Administrator Manual Warning y Do not use this product near water. y Do not place this product on an unstable cart, stand, or table. If the product falls, it could be seriously damaged. y Slots and openings on the product are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. y Never push objects of any kind into this product through cabinet slots, as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquids of any kind onto or into the product. y To avoid damage of internal components, do not place the product on a vibrating surface. Using Electrical Power y This product should be operated from the type of power indicated on the marking label. y Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the cord. y If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating. y Do not overload a power outlet, strip or receptacle by plugging in too many devices. v SMCD3GNV4 and SMCD3GNV4E Wireless EMTA Gateway Administrator Manual Contents Safety ....................................................................................................................... iii Safety Instructions ........................................................................................................ iii Warning ......................................................................................................................... iv Using Electrical Power .................................................................................................. iv Contents ................................................................................................................... v Preface ..................................................................................................................... ix Key Features .................................................................................................................. x Document Organization ................................................................................................ xi Document Conventions ............................................................................................... xii 1 Getting to Know Your Gateway ........................................................................... 1 Unpacking Package Contents ....................................................................................…

Text truncated - open the document above for the full version.

Date: April 2 nd , 2012 Confidentiality Request FCC ID: JI5-D3GN4 Federal Communications Commission Authorization and Evaluation Division To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below:  Schematics  Block Diagram  Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you. Sincerely yours, ------------------------------------ Name/ Job Title: Chooi Sim/ PM SMC Networks, Inc. Tel.: +1 (949) 679-8034 Fax.: + 1 (949) 502-3415 E-mail: [email protected]

To whom it may concern: We, the undersigned SMC Networks, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C/E and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don't hesitate to contact us. Thank you! Sincerely yours,

Report No.: 120314E09A-1 1 Report Format Version 4.2.0 Report No.:120327E09 CONSTRUCTION PHOTOS OF EUT Report No.: 120314E09A-1 2 Report Format Version 4.2.0 Report No.:120327E09 MODEL NO.: ADS0271-W 120200 Report No.: 120314E09A-1 3 Report Format Version 4.2.0 Report No.:120327E09 Report No.: 120314E09A-1 4 Report Format Version 4.2.0 Report No.:120327E09 MODEL NO.: SYS1428-2412-W2 Report No.: 120314E09A-1 5 Report Format Version 4.2.0 Report No.:120327E09

FCC ID： JI5-D3GN4 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label Here

Report No.: 120314E09A-1 1 Report Format Version 4.2.0 Report No.:120327E09 CONSTRUCTION PHOTOS OF EUT Report No.: 120314E09A-1 2 Report Format Version 4.2.0 Report No.:120327E09 Report No.: 120314E09A-1 3 Report Format Version 4.2.0 Report No.:120327E09 Report No.: 120314E09A-1 4 Report Format Version 4.2.0 Report No.:120327E09

Report No.: SA120314E09A 1 Report Format Version 4.0.0 Report No.:120327E09 RF EXPOSURE REPORT REPORT NO.: SA120314E09A MODEL NO.: SMCD3GN4xxxxx (x =0-9, A-Z, a-z, “-“, “.”, or blank for marketing purpose only) FCC ID: JI5-D3GN4 RECEIVED: Mar. 27, 2012 TESTED: Apr. 12, 2012 ISSUED: June 12, 2012 APPLICANT: SMC Networks Inc. ADDRESS: 20 Mason, Irvine, CA 92618, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This test report consists of 9 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA120314E09A 2 Report Format Version 4.0.0 Report No.:120327E09 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA120314E09A 3 Report Format Version 4.0.0 Report No.:120327E09 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120314E09A Original release June 12, 2012 Report No.: SA120314E09A 4 Report Format Version 4.0.0 Report No.:120327E09 1. CERTIFICATION PRODUCT: Wireless Gateway BRAND NAME: SMC MODEL NO.: SMCD3GN4xxxxx (x =0-9, A-Z, a-z, “-“, “.”, or blank for marketing purpose only) TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: SMC Networks Inc. TESTED: Apr. 12, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: SMCD3GN4) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: June 12, 2012 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: June 12, 2012 ( May Chen, Deputy Manager ) Report No.: SA120314E09A 5 Report Format Version 4.0.0 Report No.:120327E09 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120314E09A 6 Report Format Version 4.0.0 Report No.:120327E09 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: For 2.4GHz Transmitter Circuit Brand Model Peak Gain (dBi) Antenna Type Connecter Type Chain (0) Wanshih SI6WFI0094 2.39 PIFA U.FL Chain (1) Wanshih SI6WFI0094 2.46 PIFA U.FL For 5GHz Transmitter Circuit Brand Model Peak Gain (dBi) Antenna Type Connecter Type Chain (0) Wanshih SI6WFI0094 6.41 PIFA U.FL Chain (1) Wanshih SI6WFI0094 4.22 PIFA U.FL Report No.: SA120314E09A 7 Report Format Version 4.0.0 Report No.:120327E09 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): 802.11b: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 34.674 2.46 20 0.012 1.00 802.11g: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 933.254 2.46 20 0.327 1.00 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 957.514 2.46 20 0.336 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2422-2452 991.491 2.46 20 0.348 1.00 Report No.: SA120314E09A 8 Report Format Version 4.0.0 Report No.:120327E09 For 15.247(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 851.138 6.41 20 0.741 1.00 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 863.096 6.41 20 0.751 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5755 ~ 5795 833.960 6.41 20 0.726 1.00 Report No.: SA120314E09A 9 Report Format Version 4.0.0 Report No.:120327E09 For 15.407(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 31.623 6.41 20 0.028 1.00 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POW…

Text truncated - open the document above for the full version.

Report No.:RF120314E09A 1 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: RF120314E09Adated Apr. 10, 2012 FCC TEST REPORT (15.247) REPORT NO.: RF120314E09A MODEL NO.: SMCD3GN4xxxxx (x =0-9, A-Z, a-z, “-“, “.”, or blank for marketing purpose only) FCC ID: JI5-D3GN4 RECEIVED: Mar. 27, 2012 TESTED: Mar. 28 to Apr. 12, 2012 ISSUED: June 12, 2012 APPLICANT: SMC Networks Inc. ADDRESS: 20 Mason, Irvine, CA 92618, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This test report consists of 93 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.:RF120314E09A 2 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: RF120314E09Adated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 8 3. GENERAL INFORMATION ..................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 9 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 18 4. TEST TYPES AND RESULTS (FOR 2.4GHZ, 2400 ~ 2483.5MHZ BAND) ........... 20 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 20 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 20 4.1.2 TEST INSTRUMENTS .......................................................................................... 20 4.1.3 TEST PROCEDURES .......................................................................................... 21 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 21 4.1.5 TEST SETUP ....................................................................................................... 22 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 22 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 23 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 25 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 27 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 27 4.2.2 TEST INSTRUMENTS .......................................................................................... 28 4.2.3 TEST PROCEDURES .......................................................................................... 29 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 29 4.2.5 TEST SETUP ....................................................................................................... 30 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 30 4.2.7 TEST RESULTS ................................................................................................... 31 4.3 6DB BANDWIDTH MEASUREMENT ................................................................... 44 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ................................................. 44 4.3.2 TEST INSTRUMENTS .......................................................................................... 44 4.3.3 TEST PROCEDURE ............................................................................................. 44 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 44 4.3.5 TEST SETUP ....................................................................................................... 44 4.3.6 EUT OPERATING CONDITIONS ......................................................................... 45 4.3.7 TEST RESULTS ................................................................................................... 46 4.4 CONDUCTED OUTPUT POWER ......................................................................... 48 4.4.1 LIMITS OF CONDUCTED OUTPUT POWER MEASUREMENT .......................... 48 4.4.2 INSTRUMENTS .................................................................................................... 48 Report No.:RF120314E09A 3 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: RF120314E09Adated Apr. 10, 2012 4.4.3 TEST PROCEDURES .......................................................................................... 48 4.4.4 DEVIATION FROM …

Text truncated - open the document above for the full version.

Report No.: RF120314E09A-1 1 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 FCC TEST REPORT (15.407) REPORT NO.: RF120314E09A-1 MODEL NO.: SMCD3GN4xxxxx (x =0-9, A-Z, a-z, “-“, “.”, or blank for marketing purpose only) FCC ID: JI5-D3GN4 RECEIVED: Mar. 27, 2012 TESTED: Mar. 28 to Apr. 12, 2012 ISSUED: June 12, 2012 APPLICANT: SMC Networks Inc. ADDRESS: 20 Mason, Irvine, CA 92618, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This test report consists of 61 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF120314E09A-1 2 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 14 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 15 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 16 4. TEST TYPES AND RESULTS .............................................................................. 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 21 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 23 4.2 RADIATED EMISSION MEASUREMENT ............................................................. 25 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ........................................... 25 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 26 4.2.3 TEST INSTRUMENTS .......................................................................................... 27 4.2.4 TEST PROCEDURES .......................................................................................... 28 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 28 4.2.6 TEST SETUP ....................................................................................................... 29 4.2.7 EUT OPERATING CONDITION ............................................................................ 29 4.2.8 TEST RESULTS ................................................................................................... 30 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 39 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 39 4.3.2 TEST INSTRUMENTS .......................................................................................... 39 4.3.3 TEST PROCEDURE ............................................................................................. 40 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 40 4.3.5 TEST SETUP ....................................................................................................... 40 4.3.6 EUT OPERATING CONDITIONS ......................................................................... 41 Report No.: RF120314E09A-1 3 Report Format Version 4.2.0 Report No.:120327E09 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 4.3.7 TEST RESULTS ................................................................................................... 42 4.4 PEAK POWER SPECTRAL DENSITY MEASUREMENT ..................................... 44 4.4.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT ................... 44 4.4.2 TEST INSTRUMEN…

Text truncated - open the document above for the full version.

Report No.:120314E09A 1 Report Format Version 4.2.0 Report No.:120327E09 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (MODE 1) Report No.:120314E09A 2 Report Format Version 4.2.0 Report No.:120327E09 CONDUCTED EMISSION TEST (MODE 2) Report No.:120314E09A 3 Report Format Version 4.2.0 Report No.:120327E09 RADIATED EMISSION TEST (Below 1GHz) Report No.:120314E09A 4 Report Format Version 4.2.0 Report No.:120327E09 RADIATED EMISSION TEST (Above 1GHz)
