JUP-029A-SN450Ruggedized Data Modem for GPS

F Part Number 45423-00-ENG Revision A October 2001 SiteNet ™ 450 Operation Manual SN450.book Page 1 Friday, October 5, 2001 5:01 PM Corporate Office Trimble Navigation Limited Engineering and Construction 5475 Kellenburger Road Dayton, Ohio 45424-1099 U.S.A. Phone: +1-937-233-8921 Toll free:+1-800-538-7800 Fax: +1-937-233-9441 www.trimble.com Copyright and Trademarks © 2001, Trimble Navigation Limited. All rights reserved. The Globe & Triangle logo, Trimble, 4700, 4800, 5700, MS750, MS850, MS860, SiteNet, SiteVision, TRIMCOMM, TRIMMARK, TRIMTALK, and WinFLASH are trademarks of Trimble Navigation Limited. The Sextant logo with Trimble and BladePro 3D are trademarks of Trimble Navigation Limited, registered in the United States Patent and Trademark Office. All other trademarks are the property of their respective owners. Release Notice This is the October 2001 release (Revision A) of the SiteNet 450 Operation Manual, part number 45423-00-ENG. The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction. Hardware Limited Warranty Trimble warrants that this Trimble hardware product (the “Product”) shall be free from defects in materials and workmanship and will substantially conform to Trimble’s applicable published specifications for the Product for a period of one (1) year, starting from the date of delivery. The warranty set forth in this paragraph shall not apply to software/firmware products. Software and Firmware License, Limited Warranty This Trimble software and/or firmware product (the “Software”) is licensed and not sold. Its use is governed by the provisions of the applicable End User License Agreement (“EULA”), if any, included with the Software. In the absence of a separate EULA included with the Software providing different limited warranty terms, exclusions, and limitations, the following terms and conditions shall apply. Trimble warrants that this Trimble Software product will substantially conform to Trimble’s applicable published specifications for the Software for a period of ninety (90) days, starting from the date of delivery. Warranty Remedies Trimble's sole liability and your exclusive remedy under the warranties set forth above shall be, at Trimble’s option, to repair or replace any Product or Software that fails to conform to such warranty (“Nonconforming Product”), or refund the purchase price paid by you for any such Nonconforming Product, upon your return of any Nonconforming Product to Trimble in accordance with Trimble’s standard return material authorization procedures. SN450.book Page 2 Friday, October 5, 2001 5:01 PM Warranty Exclusions and Disclaimer These warranties shall be applied only in the event and to the extent that: (i) the Products and Software are properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble’s relevant operator's manual and specifications, and; (ii) the Products and Software are not modified or misused. The preceding warranties shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product or Software with products, information, data, systems or devices not made, supplied or specified by Trimble; (ii) the operation of the Product or Software under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized modification or use of the Product or Software; (iv) damage caused by accident, lightning or other electrical discharge, fresh or salt water immersion or spray; or (v) normal wear and tear on consumable parts (e.g., batteries). THE WARRANTIES ABOVE STATE TRIMBLE'S ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATING TO PERFORMANCE OF THE PRODUCTS AND SOFTWARE. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE PRODUCTS, SOFTWARE, AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, INSTALLATION, OR DISTRIBUTION, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF TRIMBLE ARISING OUT OF, OR IN CONNECTION WITH, ANY PRODUCTS OR SOFTWARE. SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. TRIMBLE NAVIGATION LIMITED IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF GPS SATELLITES OR THE AVAILABILITY OF GPS SATELLITE SIGNALS. Limitation of Liability TRIMBLE’S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SHALL BE LIMITED TO THE GREATER OF THE AMOUNT PAID BY YOU FOR THE PRODUCT OR SOFTWARE LICENSE OR U.S.$25.00. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TRIMBLE OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANY WAY TO THE PRODUCTS, SOFTWARE, AND ACCOMPANYING DOCUMENTATION AND MATERIALS, (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS), REGARDLESS OF WHETHER TRIMBLE HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE COURSE OF DEALING WHICH DEVELOPS OR HAS DEVELOPED BETWEEN YOU AND TRIMBLE. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. SN450.book Page 3 Friday, October 5, 2001 5:01 PM Notices Class B Statement – Notice to Users. This equipment has been tested and found to comply with the limits for a Class B digit…

Text truncated - open the document above for the full version.

TCB RF Exposure Review Procedure Statement FCC ID: JUP-029A-SN450 Transmitter Category Device Type Product Category Approval and Review Procedures Used Specific Procedures: VII Part 90 Mobil Transmitter TNB Section D SP(1), SP(3), SP(5), SP(6), SP(7), SP(8) and SP(9) Grant Condition : The antenna installation and operating configurations of this transmitter, including antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of 2.1091. The antenna(s) used forthis transmitter must be installed to provide a separation distance of at least 24 cm from all persons and mustnot be co-located or operating in conjunction with and other antenna or transmitter. Users and installers must beprovided with antenna installation instructions and transmitter operating conditions for satisfying RF exposurecompliance. SP 1 Output power: Verified on page 7 of test report 28.2 dBm at 450 MHz (12.5 kHz channel) 27.9 dBm at 450 MHz (25 kHz channel ) Antenna Gain: The Integral antenna is 0dBi The Whip antenna is 5 dBiCable Loss: Any cable attached will reduce output powerAntenna Installation Instructions: See page 39 of SN450 Operation ManualDuty Cycle: Not taken into account in determining MPE SP 3 See Chapter 4 SN450 Operation Manual SP 5 Per 90.210 operates within 421 – 512 MHz Frequency Range. Device operates between430 – 470 MHz SP 7 See Chapter 3 SN450 Operation Manual SP 8 Page 39, Chapter 4 SN450 SP 9 Grant condition has been verified. Reviewed by Barbara L. JudgeCompliance Certification ServicesNovember 19, 2001

tel: 650-726-1263 fax: 650-726-1252 internet: [email protected] Thomas N. Cokenias EMC & Radio Type Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 28 September 2001 FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner Reviewing Engineer Re: Request for confidentiality per Section 0.459 of FCC Rules Applicant: Trimble Navigation Ltd. FCC ID: JUP-029A-SN450 To whom it may concern, Request is hereby submitted, on behalf of my client Trimble Navigation, to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Schematics Block diagrams Theory of operation Rationale for request for confidentiality: Trimble Navigation has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. The $135 fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, THOMAS N. COKENIAS EMC Consultant/Agent for Trimble Navigation. tel: 650-726-1263 fax: 650-726-1252 internet: [email protected]

Trimble Navigation Ltd. FCC ID: JUP-029A-SN450 FCC ID Label Location

Level,Agile Class,Part Number,Rev,Part Description,Item Nbr,Qty,Ref Des,BOM Notes, 0,Part,38219-10-D,,+BD ASSY SN450 DIG,,,,, .1,Part,38219-D,D,BOARD BLANK TC900,1,1,,, .1,Part,20020,0,RES CHP KOHM 82.5 1% .1W 0805,2,1,R452,, .1,Part,12218,0,CAP CH UF .1 10% 1H X7 1206,5,1,C56,, .1,Part,12219,0,CAP CH UF .01 10% 2A X7 1206,10,2,C312, C341,, .1,Part,13410,0,CAP CH PF 22 5% 2A CG 805,15,2,C386, C387,, .1,Part,13414,0,CAP CH PF 100 5% 1H CG 805,20,1,C489,, .1,Part,14757,0,CAP CH UF .1 80% 1H Y5 805,25,21,C9, C11, C12, C300, C301, C303, C306, C309, C315, C317, C319, C322, C323, C339, C348, C349, C371, C394, C420, C443, C488,, .1,Part,14827,0,CAP CH UF .01 10% 1H X7 0805,30,30,C302, C304, C305, C308, C310, C311, C313, C314, C318, C321, C324, C325, C328, C338, C342, C344, C345, C350-C352, C372, C383, C410, C425, C477, C485, C487, C491, C540, C952,, .1,Part,33626,0,CAP CH UF .01 10% 1H X7 0603,32,2,C340, C353,, .1,Part,17648,0,CAP CHP UF 1 20% 50V TAN C,35,1,C452,, .1,Part,20151,0,CAP CH UF .33 10% 1H X7 1812,40,1,C421,, .1,Part,23089,0,FLTR EMI SUPP 360PF 50V SMD,45,4,C1-C4,, .1,Part,23249,0,CAP CHP UF 10 10% 10V TAN B,50,4,C307, C316, C320, C347,, .1,Part,26897,0,CAP CHP UF 100 10% 16V TAN E,55,9,C401, C422, C423, C483, C484, C486, C490, C495, C520,, .1,Part,29114,0,CAP CHP UF 6.8 20% 50V TAN X,60,11,C400, C404-C409, C438, C439, C457, C458,, .1,Part,30548,0,FLT EMI SUPP 4000PF 5A SMD,65,1,C8,, .1,Part,31809,0,CAP CH UF .01 10% 2A X7 1206,70,1,C51,, .1,Part,32548,0,CAP CH PF 22 10% 2D CG 0805,75,4,C430-C433,, .1,Part,32630,0,CAP CH UF .1 10% 1C X7 0603,80,8,C203, C204, C373, C395-C399,, .1,Part,33628,0,CAP CHP UF 4.7 10% 10V TAN A,85,1,C107,, .1,Part,36750,0,CAP CH PF 56 5% 1H CG 0603,95,9,C601-C603, C621, C628, C640, C652, C653, C692,, .1,Part,83077,0,CAP CH UF 1 10% X5R 0805,100,1,C530,, .1,Part,86477,0,CAP CHP UF 4.7 10% 25V TAN C,105,1,C424,, .1,Part,12295,0,DIO SW MMBD914 70V 3PZ,110,2,D412, D496,, .1,Part,17479,0,DIO TVS 30V .6KW SMBJ30A 2DZ,115,1,D16,, .1,Part,17871,0,RECT SCH 40V MBRS140 1A 2DZ,120,3,D401, D413, D466,, .1,Part,17873,0,DIO ZEN 15V MMBZ5245B 3PZ,125,3,D12, D13, D497,, .1,Part,26466,0,DIO TVS 18V .6KW BIDIR 2DZ,130,5,D1, D3, D4, D311, D312,, .1,Part,31731,0,DIO TVS 40V .6KW BIDIR 2DZ,135,1,D2,, .1,Part,31821,0,LED GRN 20MCD@10MA SMD,140,1,D5,, .1,Part,31855,0,LED YEL HLMP6405 10MA20Mcd SMD,145,1,D6,, .1,Part,34164,0,RECT CT SCH DUPLICATE OF 86523,150,1,D400,, .1,Part,36470,0,DIO ZEN 6.2V 1SMB5920BT3 2DZ,155,1,D25,, .1,Part,86366,0,DIO ZEN 4.7V MMBZ5230B 3PZ,160,1,D18,, .1,Part,30541,0,CONN 24P 2X12 HDR ST .05 SMD,165,1,JP2,, .1,Part,31409-00,A,ASSY CONN BP BULKHD SEALED,170,1,JP1,, ..2,Part,31409,A,CONN 8P BULKHEAD JAM NUT,10,1,,, ..2,Part,16403,0,RTV CLR NON-CORROSIVE DOW 3140,20,0.01,,, ..2,Document,31409-00-AD,A,ASSY CONN 8P BULKHD SEALED,9500,0,,, .1,Part,13422,0,IND CHP UH 22 10%.18A 1210,175,1,L301,, .1,Part,24044,0,IND CHP UH 150 20% .72A 4545,180,2,L408, L409,, .1,Part,26898,0,IND CHP UH 20 20% 2.1A 4545,185,2,L400, L403,, .1,Part,36522,0,FLTR EMI FER 30 OHM@100MHZ SMD,190,2,L100, L101,, .1,Part,22193,0,TRAN PCH MFET SI9430 20V 8AZ,195,1,Q300,, .1,Part,22773,0,TRAN NCH MFET SI9410 30V 8AZ,200,2,Q410, Q411,, .1,Part,26650,0,TRAN PCH MFET SI9407 60V 8AZ,205,1,Q496,, .1,Part,36437,0,TRAN NCH MFET MTB10N40E 3LZ,210,1,Q6,, .1,Part,36548,0,TRAN NPN MMBTA42 300V .5A 3PZ,215,1,Q7,, .1,Part,38017,0,TRAN NCH MFET MMBF170 MOT ONLY,220,3,Q3, Q4, Q301,, .1,Part,13159,0,RES CHP OHM 51.1 1% 1/8 1206,225,1,R307,, .1,Part,13170,0,RES CHP KOHM 10 1% 1/8 1206,230,1,R333,, .1,Part,13370,0,RES CHP KOHM 68.1 1% 1/8 1206,235,1,R491,, .1,Part,13579,0,RES CHP OHM 511 1% 1/8 1206,240,1,R301,, .1,Part,13617,0,RES CHP KOHM 464 1% 1/8 1206,245,1,R489,, .1,Part,14773,0,RES CHP KOHM 4.7 5%.1W 805,255,4,R311, R338, R339, R342,, .1,Part,14775,0,RES CHP KOHM 10 5% .1W 805,260,10,R331, R332, R335, R336, R390, R392, R393, R902, R903, R935,, .1,Part,16771,0,RES CHP OHM 0.0 JUMPER 0805,265,23,C343, C346, R41, R312, R353, R370, R380, R391, R400, R501-R503, R535, R549, R601, R602, R605, R606, R609, R610, R901, R958, R959,, .1,Part,19968,0,RES CHP OHM 464 1% .1W 0805,270,2,R11, R13,, .1,Part,20000,0,RES CHP KOHM 12.1 1% .1W 0805,275,1,R70,, .1,Part,20015,0,RES CHP KOHM 51.1 1% .1W 0805,280,1,R66,, .1,Part,20021,0,RES CHP KOHM 90.9 1% .1W 0805,285,1,R540,, .1,Part,20032,0,RES CHP KOHM 237 1% .1W 0805,295,1,R541,, .1,Part,20047,0,RES CHP MOHM 1 1%.1W 0805,300,5,R10, R12, R401, R441, R444,, .1,Part,45176,0,RES PTC 33V 1.5A SMD,305,2,R6, R7,, .1,Part,26914,0,RES CHP OHM 0.03 5% 1W 2512,310,1,R440,, .1,Part,28025,0,RES CHP OHM 1.96 1%.1W 0805,315,1,R302,, .1,Part,30549,0,RES NET KOHM 10 5% ISO SMD,320,5,R303-R306, R308,, .1,Part,30846,0,RES NET KOHM X41K 5% ISO SMD,325,1,R300,, .1,Part,32523,0,RES CHP KOHM 10 5%1W 2512,330,1,R118,, .1,Part,32525,0,RES CHP KOHM 150 5% .1W 0805,335,1,R451,, .1,Part,35418,0,RES CHP KOHM 2.21 1%.1W 0603,340,3,R200, R206, R208,, .1,Part,35423,0,RES CHP KOHM 26.7 1% .1W 0603,345,1,R201,, .1,Part,35743,0,RES CHP KOHM 1 1%.1W 0603,350,3,R203, R204, R394,, .1,Part,35745,0,RES CHP KOHM 4.22 1%.1W 0603,355,2,R205, R207,, .1,Part,36822,0,RES CHP KOHM 2.21 1% 1W 2512,360,1,R116,, .1,Part,38758,0,RES CHP KOHM 100 5% 1W 2512,365,1,R64,, .1,Part,38324,0,SWITCH MINI KEY SPST MOMEN SMT,380,1,SW1,, .1,Part,14224,0,IC CMOS 74ACT 32 Q 2I OR CAI,385,1,U905,, .1,Part,17553,0,IC CMOS 74ACT 04 HEX INV CAI,390,1,U111,, .1,Part,19573,0,IC CMOS 74ACT 08 Q 2I AND CAI,400,1,U300,, .1,Part,23123,0,IC SRAM 128KX8 CMS 70NS K9I,405,1,U303,, .1,Part,23124,0,IC SRAM 128KX8 CMS 70NS KEI,410,1,U304,, .1,Part,26900,0,IC VR MAX797 SW DC/DC CTRL DAI,415,1,U408,, .1,Part,28827,0,IC FPLD EP8452A-4 RFI,420,1,U305,, .1,Part,29130,0,IC INTF MAX707 PRCSR SVPV 8AI,425,1,U306,, .1,Part,29930,0,IC VR LM2937 +5V .5A 3ZZ,430,1,U409,, .1,Part,31082,0,IC INTF MIC5018 HISIDE DRV 4QI,435,1,U35,, .1,Part,32680,0,IC INTF PCA82C251 CAN XCVR 8AZ,440,1,U328,, .1,Part,38084,0,IC INTF 82527 SER CTRLR MMZ,445,1,U329,, .1,Part,38085,A,IC P…

Text truncated - open the document above for the full version.

Level Agile Class Part Number Rev Part Description Item Nbr Qty Ref Des BOM Notes 0 Part 43633-00-C +BD ASSY SITENET450 .1 Part 43633-C C +BD BLANK SITENET 450 1 1 .1 Part 13410 0 CAP CH PF 22 5% 2A CG 805 5 1 C1 .1 Part 32630 0 CAP CH UF .1 10% 1C X7 0603 10 3 C7, C10, C48 .1 Part 14827 0 CAP CH UF .01 10% 1H X7 0805 15 10 C3, C4, C8, C9, C11, C12, C15, C16, C18, C52 .1 Part 13439 0 CAP CHP UF 10 20% 25V TAN D 20 2 C13, C17 .1 Part 23434 0 CAP CHP UF 1.0 10% 16V TAN A 25 1 C44 .1 Part 13629 0 CAP CHP UF 47 20% 10V TAN D 30 2 C45, C46 .1 Part 13645 0 CAP CH PF 150 5% 1H CG 805 35 2 C47, C51 .1 Part 13438 0 CAP CHP UF 2.2 20% 35V TAN C 40 1 C49 .1 Part 80427 0 CAP CH UF .47 10% 2A X7 2225 45 1 C50 .1 Part 16453 0 CAP CH UF 1 80% 1H Y5 1812 50 2 C53, C56 .1 Part 23433 0 CAP CH PF 100 5% 1H CG 0603 55 3 C54, C59, C60 .1 Part 36750 0 CAP CH PF 56 5% 1H CG 0603 60 2 C55, C57 .1 Part 23249 0 CAP CHP UF 10 10% 10V TAN B 65 1 C58 .1 Part 13550 0 CAP CH PF 470 5% 1H CG 805 70 1 C6 .1 Part 22003 0 FLTR EMI SUPP 1000PF "T"2A SMD 75 1 F1 .1 Part 30539 0 CONN 24S RECPT 2X12 ST .05 SMD 80 1 J1 .1 Part 17104 0 TRAN NCH MFET MMBF170 60V 3PZ 85 1 Q603 .1 Part 20022 0 RES CHP KOHM 100 1% .1W 0805 90 3 R1, R42, R48 .1 Part 35738 0 RES CHP OHM 0.0 JUMPER 0603 95 7 R15, R17, R60, R62, R63, R66, R93 .1 Part 35421 0 RES CHP KOHM 10 1% .1W 0603 100 11 R2, R3, R5, R8, R18, R44-R46, R49, R68, R90 .1 Part 20128 0 RES CHP KOHM 21.5 1% .1W 0805 105 1 R43 .1 Part 20013 0 RES CHP KOHM 42.2 1% .1W 0805 110 1 R52 .1 Part 18110 0 RES CHP KOHM 26.7 1% 1/8 1206 115 1 R53 .1 Part 20004 0 RES CHP KOHM 17.8 1% .1W 0805 120 1 R7 .1 Part 35416 0 RES CHP OHM 200 1%.1W 0603 125 1 R95 .1 Part 44635 0 SHLD EMI SMT 1.03 SQ 130 1 SH1 .1 Part 31349 0 IC INTF MX589 MODEM HEI 135 1 U1 .1 Part 31692 0 IC INTF X9241 DIGPOT Q 50K FBI 140 1 U10 .1 Part 29930 0 IC VR LM2937 +5V .5A 3ZZ 145 1 U11 .1 Part 43406 0 IC CMOS 74VHC1614B BIN CTR DAI 150 1 U13 .1 Part 44616 0 IC CMOS 74AC153 D 4IN MPLX DBZ 155 1 U14 .1 Part 17329 0 IC CMOS 7SU04 SINGLE INV 5CI 160 1 U15 .1 Part 40818 0 IC CMOS 74HC589 8B SH REG DEI 165 1 U16 .1 Part 14295 0 IC CMOS 74HC 02 Q 2I NOR CAI 170 1 U17 .1 Part 40562 0 IC CMOS 74VHC595 SH REG DEI 175 2 U2, U3 .1 Part 19211 0 IC OP AMP LM224 QUAD CAZ 180 1 U5 .1 Part 44627 0 OSC MHZ 24.576 100PPM IND T 190 1 Y1 .1 Part 35420 0 RES CHP OHM 100 1% .1W 0603 195 3 R6, R92, R94 .1 Part 17910 0 LABEL BARCODE SERIALIZED PCB 8900 1 .1 Document 43633-XX-AD-C C +ASSY DWG SITENE 450 9500 0 .1 Document 43633-XX-SD-C C +SCHEM DWG SITENE 450 9510 0 .1 Part NO-LOAD 0 NO LOAD REFERENCE DESIGNATORS 9990 6 R10, R61, R64, R65, R67, R91 ̋

Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 1 of 31 pages FCC CERTIFICATION INFORMATION The following information is in accordance with FCC Rules, 47CFR Part 2, Subpart J, sections 2.1031 - 2.1057. 2.1033(c)1Applicant:Trimble Navigation Ltd. 645 N. Mary Avenue Sunnyvale, CA 94086 2.1033(c)2FCC ID: JUP-029A-SN450 2.1033(c)3Installation and operating instructions are in separate documentation. 2.1033(c)4Types of emission: 1. 4800 baud GMSK(.5), 3.5 kHz deviation20 kHz auth BW: 20K0G1D 2. 8000 baud GMSK(.5), 2.6 kHz deviation20 kHz auth BW: 20K0G1D 3. 9600 baud GMSK(.5), 2.4 kHz deviation20 kHz auth BW: 20K0G1D 4. 4800 baud GMSK(.5) 1.2 kHz deviation11.25 kHz auth BW: 11K25G1D 5. 8000 baud GMSK(.3) 1.5 kHz deviation11.25 kHz auth BW: 11K25G1D 2.1033(c)5Frequency range: 430-470 MHz 2.1033(c)6Range of operating power: 27 dBm (0.5 watt) design. Power set at factory. 2.1033(c)7Maximum output power: 28.2 dBm (12.5 kHz) 2.1033(c)8Applied DC voltages and currents to final amplifier: Refer to schematic 2.1033(c)9Tune-up procedure Refer to user manual 2.1033(c)10 Schematic, Block Diagram, and Theory of Operation Refer to separate exhibits. Confidentiality is requested for these items. 2.1033(c)11 Drawing or photograph of FCC ID label Refer to separate exhibits 2.1033(c)12 Types of equipment: Refer to separate exhibits. 2.1033(c)13 Desciption of digital modulation: refer to Theory of Operation. Power Requirements: 10.5 - 20.0 VDC unconditioned Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 2 of 31 pages 2.1091 Radio frequency radiation exposure evaluation: mobile devices The SiteNET 450 radio meets the requirements of a mobile device, as it is designed to be used as a GPS data receiver in other than fixed locations, and is generally used at a separation distance of at least 20 cm between the antenna and the body of the user or nearby persons. The SiteNET 450 radio has a design nominal output of 27 dBm (0.5 watts). Test sample measurement yielded a maximum power output of 28.2 dBm (0.661 watt). Antennas sold for this product are a 0 dBi integral and a 5 dBi whip antenna. Worst case MPE is for 5 dBi antenna at 430 MHz (lowest frequency, lowest exposure level): RF Hazard Distance Calculation mW/cm2 from Table1:0.29 Max RF PowerTX AntennaMPE P, dBmG, dBiSafe Distance, cm 28.25.023.9 Basis of Calculations: E^2/3770 = S, mW/cm2 E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less The user manual cautions users to maintain at least 2 ft. (60 cm) from the antenna during normal operation. ERP for this radio is (5 dBi -2.15 dB) + 28.2 dBm = 31.05 dBm EIRP = 1.27 watts ERP. The SiteNET 450 meets the requirements for exclusion from routine environmental investigation. Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 3 of 31 pages Spectral Efficiency per Section 90.203 CERTIFICATE: Trimble Navigation Ltd. certifies that, per the requirements of 90.203(j)3, that the reference radio, FCC ID: JUP-029A-SN450, meets the spectrum efficiency channel of one voice channel bandwidth per 12.5 kHz of channel bandwidth. Channel bandwidth is calculated as the bandwidth containing 99% of the energy of the emission, or the 20 dB bandwidth. Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 4 of 31 pages Report of Measurements All tests except for transmitter mask measurements were performed by Compliance Certification Services. Antenna conducted measurements were performed at Trimble Navigation's facility in Sunnyvale, CA. Radiated emissions tests were performed at a CCS open air test site in Sunnyvale, CA. Emissions mask measurements were performed at Trimble in Sunnyvale. Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 5 of 31 pages Standard Test Conditions The transmitter was tested under the following conditions: Room Temperature: 20 - 23 °C Relative Humidity: 35 - 50% DC Supply Voltage: 12.6 VDC The transmitter was aligned and tuned up according to manufacturer’s alignment procedure, prior to testing. All data presented represents the worst case parameter being measured. Section 2.1046 RF Power Output Test Set-up spectrum analyzerEUT DC supply attenuator controller pc Measurement Equipment Used: HP 8561 Spectrum Analyzer Weinschel model 401034 attenuator, 50 watt 90.205 Power and Antenna Height Limits Test Results Maximum Output Power: 28.2 dBm at 450 MHz (12.5 kHz channel) 27.9 dBm at 450 MHz (25 kHz channel) Design Output Power: 27 dBm Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 6 of 31 pages Section 2.1049 Occupied Bandwidth Test Set-up spectrum analyzerEUT DC supply attenuator controller pc Measurement Equipment Used: HP 8561 Spectrum Analyzer Weinschel model 401034 attenuator, 50 watt Data on the bandwidth occupied by this transmitter is presented in graphical form using spectrum analyzer plots. A separate spectrum plot is supplied for each modulation type. 90.209 Bandwidth limitations 90.210(b) Emission mask B : 25 kHz channel (20 kHz authorized BW) Any emission must be attenuated below the power (P) of the highest emission contained within the authorized bandwidth as follows: 1. On any frequency removed from the assigned frequency by more than 50 percent but less than 100 percent: at least 25 dB 2. On any frequency removed from the assigned frequency by more than 100 percent but less than 250 percent: at least 35 dB 3. On any frequency removed from the center of the authorized bandwidth by a displacement frequency (fd in kHz) of more than 250 percent: At least 43 + 10 log(P) dB Trimble Navigation Ltd.FCC ID: JUP-029A-SN450 7 of 31 pages 90.210(d) Emission mask D: 12.5 kHz channel bandwidth (11.25 kHz authorized BW) Any emission must be attenuated below the power (P) of the highest emission contained within the authorized bandwidth as follows: 1. On any frequency from the center of the authorized bandwidth fo to 5.625 kHz removed from …

Text truncated - open the document above for the full version.
