JUP-55800Bluetooth Device

Trimble Navigation January 3, 2006 Gerardo Torres Addendum to Draft of Trimble SPSx50 User Manual 1. RSS-310, RSS-Gen and RSS-210 statements regarding antennas: for 450 MHz radio This device has been designed to operate with the antennas listed below, and having a maximum gain of 5 dBi. Antennas not included in this list or having a gain greater than 3 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. The antennas to be used with this radio device are 0 dBi, 3 dBi and 5 dBi whip antennas. for license-free 900 MHz and Bluetooth radios: To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. 2. RF exposure warning statements : for 450 MHz radio Safety. Exposure to RF energy is an important safety consideration. The FCC has adopted a safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated equipment as a result of its actions in General Docket 79-144 on March 13, 1986. Proper use of this radio modem results in exposure below government limits. The following precautions are recommended: DO NOT operate the transmitter when someone is within two feet (0.6 meter) of the antenna. DO NOT operate the transmitter unless all RF connectors are secure and any open connectors are properly terminated. DO NOT operate the equipment near electrical blasting caps or in an explosive atmosphere. All equipment must be properly grounded according to Trimble installation instructions for safe operation. All equipment should be serviced only by a qualified technician. for license-free 900 MHz radio: CAUTION – For your own safety, and in terms of the RF Exposure requirements of the FCC, always observe the precautions listed here. Trimble Navigation January 3, 2006 Gerardo Torres - Always maintain a minimum separation distance of 21 cm (approximately 8 inches) between yourself and the radiating antenna on the SPSx50 radio- modem. - Do not co-locate the antenna with any other transmitting device. - For mobile operation, do not allow the maximum gain of the antenna to exceed 5 dBi. 3. General RSS-310 compliance statement : This apparatus complies with Canadian RSS-310. Cet appareil est conforme à la norme CNR-310 du Canada. 4. Other regulatory information to be amended in the next version: On p. 108 under "Certification" it says "Class B, Part 15, 22, 24, FCC certification." It should say "FCC Certification to Part 15 (Class B device) and Part 90." On p. 108 under "Certification" it says "Canadian FCC." It should say "Industry Canada Certification to RSS-119, RSS-210, RSS-310 and RSS-Gen."

Version 1.0 Revision A February 2006 F USER GUIDE Trimble ® SPSx50 Modular GPS Receiver Corporate Office Trimbl e Nav i gation Limit ed 935 Stewart Drive Sunnyvale, CA 94085 USA www.trimble.com Trimbl e Nav i gation Limit ed Construction Business Area 5475 Kellenburger Road Dayton, Ohio 45424-1099 USA 800-538-7800 (toll free in USA) +1-937-245-5600 Phone +1-937-233-9004 Fax www.trimble.com E-mail: [email protected] Legal Notices © 2006, Trimble Navigation Limited. All rights reserved. Trimble, the Globe & Triangle logo, and <list Trimble registered marks used in the text (alphabetically, numbers first)> are trademarks of Trimble Navigation Limited, registered in the United States Patent and Trademark Office and in other countries. <List Trimble trademarks used in the text (alphabetically, numbers first)> are trademarks of Trimble Navigation Limited. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Trimble Navigation Limited is under license. If the product uses a ™ or ® Microsoft product, bug the text and insert this statement here: Microsoft and <***> are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Release Notice This is the February 2006 release (Revision A) of the SPSx50 Modular GPS Receiver User Guide. It applies to version 1.0 of the SPSx50 Modular GPS receiver. Limited Warranty Terms and Conditions Product Limited Warranty Subject to the terms and conditions set forth herein, Trimble Navigation Limited (“Trimble”) warrants that for a period of (1) year from date of purchase this Trimble product (the “Product”) will substantially conform to Trimble's publicly available specifications for the Product and that the hardware and any storage media components of the Product will be substantially free from defects in materials and workmanship. Product Software Product software, whether built into hardware circuitry as firmware, provided as a standalone computer software product, embedded in flash memory, or stored on magnetic or other media, is licensed and not sold. If accompanied by a separate end user license agreement, use of any such software will be subject to the terms of such end user license agreement (including any differing limited warranty terms, exclusions and limitations), which shall control over the terms and conditions set forth in this limited warranty). Software Updates During the limited warranty period you will be entitled to receive such Fix Updates and Minor Updates to the Product software that Trimble releases and makes commercially available and for which it does not charge separately, subject to the procedures for delivery to purchasers of Trimble products generally. If you have purchased the Product from an authorized Trimble distributor rather than from Trimble directly, Trimble may, at its option, forward the software Fix Update or Minor Update to the Trimble distributor for final distribution to you. Major Upgrades, new products, or substantially new software releases, as identified by Trimble are expressly excluded from this update process and limited warranty. Receipt of software updates shall not serve to extend the limited warranty period. For purposes of this warranty the following definitions shall apply: (1) “Fix Update” means an error correction or other update created to fix a previous software version that does not substantially conform to its published specifications; (2) “Minor Update” occurs when enhancements are made to current features in a software program; and (3) “Major Upgrade” occurs when significant new features are added to software, or when a new product containing new features replaces the further development of a current product line. Trimble reserves the right to determine, in its sole discretion, what constitutes a significant new feature and Major Upgrade. Warranty Remedies If the Trimble Product fails during the warranty period for reasons covered by this Limited Warranty and you notify Trimble of such failure during the warranty period, Trimble at its option will repair OR replace the nonconforming Product, OR refund the purchase price paid by you for the Product, upon your return of the Product to Trimble in accordance with Trimble's standard return material authorization procedures. How to Obtain Warranty Service To obtain warranty service for the Product, please contact your Trimble dealer. Alternatively, you may contact Trimble to request warranty service at +1-408-481-6940 (24 hours a day) or e-mail your request to [email protected]. Please be prepared to provide: – your name, address, and telephone numbers – proof of purchase –this Trimble warranty card – a description of the nonconforming Product including the model number – an explanation of the problem. The customer service representative may need additional information from you depending on the nature of the problem. Warranty Exclusions and Disclaimer This Product limited warranty shall only apply in the event and to the extent that (i) the Product is properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's applicable operator's manual and specifications, and; (ii) the Product is not modified or misused. This Product limited warranty shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product with hardware or software products, information, data, systems, interfaces or devices not made, supplied or specified by Trimble; (ii) the operation of the Product under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized, installation, modification, or use of the Product; (iv) damage caused by: accident, lightning or other electrical discharge, fresh …

Text truncated - open the document above for the full version.

SPSx50 Modular GPS Receiver User Guide 81 Configuring the Receiver Settings 7 Configuring the SPSx50 Receiver Using a Web Browser The SPSx50 receiver can be configured using the keypad and display, Trimble SCS900 Site Controller software, or a web browser. This section provides an overview of how to set up the receiver using a web browser. For more information, select the Help link from the web page. Supported browsers The following browsers are supported: •Mozilla Firefox version 1.07 or later (version 1.50 is recommended for Windows, Machintosh, and Linux) •Microsoft Internet Explorer version 6.00 or later for Windows To connect to the receiver using a web browser, enter the IP address of the receiver into the address bar of the web browser as shown: 1.If security is enabled on the receiver, the web browser prompts you to enter a username and password. The default login values for the SPSx50 receiver are: –User Name: admin –Password: password If the password for the root account has been changed or a different account is being used, contact the receiver administrator for the appropriate login information. 7 Configuring the Receiver Settings 82 SPSx50 Modular GPS Receiver User Guide Once you are logged in, the following web page is displayed that lets you configure the settings of the receiver : The web interface to the SPSx50 receiver is available in the following languages: To display the web interface in the desired language, click the corresponding country flag. The web interface to the SPSx50 receiver uses a frame type structure to view and configure the settings of the receiver. The receiver has several configuration menus on the left of the browser window. The image below shows the configuration menus. Note – The configuration menus available vary based on the version SPSx50 receiver. Each configuration menu contains related submenus for configuring the receiver and monitoring receiver performance. A summary of each configuration menu is provided. For more detailed information about each of the receiver settings, select the Help menu on the web page. •English•Italian •Chinese•Japanese •French•Russian •German•Spanish Model name of receiver Serial number of receiver Menus Available languages SPSx50 Modular GPS Receiver User Guide 83 Configuring the Receiver Settings 7 Receiver Status menu The Receiver Status menu provides a quick link to review the receiver’s available options, current firmware version, IP address, temperature, runtime, satellites tracked, current outputs, available memory, position information and more. The image below shows the Receiver Status / Identity screen. 7 Configuring the Receiver Settings 84 SPSx50 Modular GPS Receiver User Guide Satellites menu Use the Satellites menu to view satellite tracking details and enable/disable GPS, GLONASS, and SBAS (WAAS/EGNOS and MSAS) satellites. Note – To configure the receiver for OmniSTAR, use the OmniSTAR menu. See page 90. The image below shows the Satellite / Tracking (Sky Plot) screen. SPSx50 Modular GPS Receiver User Guide 85 Configuring the Receiver Settings 7 Data Logging menu Use the Data Logging menu to set up the SPSx50 receiver to log static GPS data. This menu is only available if the receiver has the data logging option enabled. You can also configure settings such as observable rate, position rate, continuous logging, continuous logging rate, and whether to auto delete old files if memory is low. The image below shows the Data Logging / Configuration screen. 7 Configuring the Receiver Settings 86 SPSx50 Modular GPS Receiver User Guide Receiver Configuration menu Use the Receiver Configuration menu to configure such settings as elevation and PDOP mask, the antenna type and height, the reference station position, and the reference station name and code. The image below shows the Receiver Configuration / Summary screen. SPSx50 Modular GPS Receiver User Guide 87 Configuring the Receiver Settings 7 I/O Configuration menu Use the I/O Configuration menu to set up all outputs of the SPSx50 receiver. The receiver can output CMR, RTCM, NMEA, GSOF, RT17, or BINEX messages. These messages can be output on TCP/IP, UDP, serial, Bluetooth, or radio ports. The image below shows the I/O Configuration / Port Summary screen: 7 Configuring the Receiver Settings 88 SPSx50 Modular GPS Receiver User Guide Bluetooth menu Use the Bluetooth menu to configure the receiver to connect to other Trimble devices that use Bluetooth wireless technology. These devices can be used to configure the receiver, and generate or receive corrections. The following Trimble devices can be connected to the SPSx50 receiver using Bluetooth wireless technology: •TSC2 controller •TCU controller •TSCe controller •ACU controller •SNB900 radio-modem •Other Bluetooth-enabled SPS GPS receivers The image below shows the Bluetooth / Info screen. SPSx50 Modular GPS Receiver User Guide 89 Configuring the Receiver Settings 7 Radio menu Use the Radio menu to configure the internal radio of the receiver, if available. The SPSx50 receivers are available with 410–430 MHz, 430–450 MHz, 450–470 MHz, or 900 MHz radios. The SPS550H receiver is not available with an internal radio. The image below shows the Radio Configuration screen. 7 Configuring the Receiver Settings 90 SPSx50 Modular GPS Receiver User Guide OmniSTAR menu All SPSx50 receivers, except the SPS550H, are capable of receiving OmniSTAR corrections. By default, OmniSTAR tracking is turned on in the receiver. For the receiver to receive the OmniSTAR corrections, you must set it to track OmniSTAR satellites and it must have a valid OmniSTAR subscription. The receiver is capable of positioning with OmniSTAR XP or HP. To purchase a subscription for your receiver, contact OmniSTAR at: www.OmniSTAR.com North & South America, 1-888-883-8476 or 1-713-785-5850 Europe & Northern Africa, 31-70-317-0900 Australia & Asia, 61-8-9322 5295 Southern Africa, 27 21 552 0535 The image below shows the OmniSTAR / Configuration scree…

Text truncated - open the document above for the full version.

March 8, 2006 American TCB 6731 Whittier Ave. Suite C110 McLean VA. 22101 Reference: FCC ID: JUP-55800 and Industry Canada: 1756A-55800 Gentlemen: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Industry Canada RSS 210 and Subpart C of Part 15 of FCC Rules (CFR 47) regarding intentional radiators. Data within this report demonstrates that the equipment tested complies with the FCC and Industry Canada limits for intentional radiators and receivers. The scope of the certification is for the Trimble part number 55800-00 (a GPS receiver unit with Bluetooth transceiver) sold under the Trimble model numbers SPS850, SPS750 and SPS550. The different model numbers refer to software-enabled options related to GPS positioning that allow access to features such as different GPS bands, data logging capabilities and CMR (GPS data packet) input and output. Note that the base unit is also sold with an optional 400 MHz licensed transceiver installed in the device. The model numbers for the options are 55800-62, 55800-64, and 55800-66, all three available are available in the US and only the first and last are available in Canada. As the optional transceiver has modular approval from both FCC and Industry Canada, and is being used within the scope of its approval, this application for the Bluetooth transceiver does not address the 400 MHz transceiver operation. Although the Bluetooth transceiver has FCC modular approval (FCC ID: Q23 31307), Trimble are using an antenna that is not included in the scope of that modular approval . For this reason the application for FCC ID JUP-55800 includes assessment of both Bluetooth and 900 MHz frequency hopping operation. Compliance of the Bluetooth transceiver is to be demonstrated using the original grant covering modular approval plus a test report covering all aspects of the device operation with the Trimble antenna. This test report covers testing with the device tested as a module, outside of a host enclosure. Cover Letter JUP-55800 and Industry Canada: 1756A-55800 Page 2 of 3 As the quantity of files to support this application is large, they are listed here. Letters Cover Letter for BT.pdf FCC Agent Authorization_SPSx50.pdf IC Listing acknowledgement_Trimble SPSx50.pdf MDS TRM450 IC Grant.pdf IC cert for 400MHz TRX 1756A-55800 Model Names2.pdf Clarification of model names and similarities ATCB Response 022706.doc Response to first series of questions raised by ATCB ATCB Response 030606.doc Response to second series of questions raised by ATCB SPSx50 & NetR5 Models and Part Numbers.doc Clarification of model names and similarities Letter of Confidentiality.pdf Forms ATCB Agreement form_Trimble SPSx50.pdf IC Application UPN 1756A-55800.pdf Contains the correct model number to be listed ATCB Form 731 55800.doc Reports Bluetooth report.pdf Test report for Bluetooth module with Trimble 4dBi antenna R61810 _IC only_revised.pdf Report for GPS and Bluetooth receiver Test Photographs Bluetooth Test Photos.pdf Tests et up for the bluetooth module Test Configuration Photographs.Pdf AC conducted emissions set-up for complete device External Photos External pics.pdf Internal Photos Bluetooth 1 of 3.jpg Bluetooth 2 of 3.jpg Bluetooth 3 of 3.jpg SPSx50 55800-90 back panel.jpg SPSx50 front panel assembly.JPG SPSx50 Main Board back.jpg SPSx50 Main Board front.jpg Block Diagrams Infineone PBA 31307 Bluetooth Module Block Diagram.pdf Bluetooth block diagram Main System Blk Diagram.pdf Main block diagram, including GPS receiver Label Information 55800-00 Label.pdf Label for base system (Bluetooth TRX) 55800-6X Label.pdf Label for models with optional 400 MHz TRX module installed Cover Letter JUP-55800 and Industry Canada: 1756A-55800 Page 3 of 3 RF Exposure Information MPE Calculation BT only.pdf RSS102 form.pdf MDS TRM450 RSS 102 RF Hazard Eval.pdf RSS 102 form for 400MHz TRX Schematics SPSx50 Schematics main board 55212-XX- SD-B-R4.pdf Includes Bluetooth module Manuals SPSx50 User Manual Addendum.pdf SPSx50_ModularGPSRcvr_UserGuide pt 1 of 2.pdf SPSx50_ModularGPSRcvr_UserGuide pt 2 of 2.pdf Operational Descriptions Infineone PBA 31307 Bluetooth Module Product Spec.pdf Infineone PBA 31307 Bluetooth Module Product Specification sheet Note that a separate application will be submitted for both Industry Canada and FCC certification for part number 55800-90 (the base unit with Bluetooth transceiver and an optional 900 MHz FHSS transceiver) under FCC ID JUP-5580090 and IC # 1756A-5580090. Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, Mark Briggs Principal Engineer

Trimble Navigation Gerardo Torres February 15, 2006 SPSx50 & NetR5 Models and Part Numbers All of the following models use the same Main Board (P/N 55212-XX-SD-B). Tested Products (Tested at Elliott Labs, August 29 2005 to December 9 20005) 55800-66 SPS850 GPS Receiver with Bluetooth and 450 MHz Radio Transceiver This is the assembly line P/N. The final label and configured P/N is 58805-66. 55800-90 SPS850 GPS Receiver with Bluetooth and 900 MHz Radio Transceiver This is the assembly line P/N. The final label and configured P/N is 58805-90-10. Derivative Products (Not tested, but conforming due to similarity to tested products) 55800-00 SPSx50 GPS Receiver with Bluetooth This product does not contain a 450 MHz or 900 MHz radio transceiver. This is the assembly line P/N. 5880x-00 SPSx50 GPS Receiver with Bluetooth This product does not contain a 450 MHz or 900 MHz radio transceiver. This P/N is the final label and configured P/N. The value of ‘x’ (1-5) indicates whether the product is configured as SPS550, SPS550H, SPS750 or SPS850. 62800-00 NetR5 GPS Receiver with Bluetooth This product does not contain a 450 MHz or 900 MHz radio transceiver. This product is configured as a Reference Station. This is both the assembly line and final label and configured P/N. 55800-62 SPSx50 GPS Receiver with Bluetooth and 450 MHz Radio Transceiver Similar to 55800-66, but the 450 MHz radio transceiver has a center frequency around 420 MHz. This is the assembly line P/N. 5880x-62 SPSx50 GPS Receiver with Bluetooth and 450 MHz Radio Transceiver Similar to 55800-66, but the 450 MHz radio transceiver has a center frequency around 420 MHz. This is the final label and configured P/N. The value of ‘x’ (1-5) indicates whether the product is configured as SPS550, SPS550H, SPS750 or SPS850. 55800-64 SPSx50 GPS Receiver with Bluetooth and 450 MHz Radio Transceiver Similar to 55800-66, but the 450 MHz radio transceiver has a center frequency around 440 MHz. This is the assembly line P/N. Trimble Navigation Gerardo Torres February 15, 2006 5880x-64 SPSx50 GPS Receiver with Bluetooth and 450 MHz Radio Transceiver Similar to 55800-66, but the 450 MHz radio transceiver has a center frequency around 440 MHz. This is the final label and configured P/N. The value of ‘x’ (1-5) indicates whether the product is configured as SPS550, SPS550H, SPS750 or SPS850. 5880x-90-y0 SPSx50 GPS Receiver with Bluetooth and 900 MHz Radio Transceiver Similar to 55800-90, but the value of ‘y’ (1-3) indicates whether the 900 MHz FHSS radio transceiver is configured for operation in the USA, Australia or New Zealand. This is the final label and configured P/N. The value of ‘x’ (1-5) indicates whether the product is configured as SPS550, SPS550H, SPS750 or SPS850. Referenced Document Part Number SPSx50 & NetR5 GPS Main Board Schematic: ‘55212-XX-SD-B-R4.tif’ 55212-XX-SD-B SPSx50 900 MHz Radio Board Schematic: ‘53195-XX-SD-B+01.tif’ 53195-XX-SD-B SPSx50 450 MHz Radio Board Schematic: ‘48483-XX-SD-B-A.tif’ 48483-XX-SD-B SPSx50 & NetR5 Assembly Diagram: ‘55800-00-AD+1.pdf’ 55800-00-AD SPSx50 GPS Receiver with 450 MHz Radio Assembly Diagram: ‘55800-00-AD+1.pdf’ 55800-6x-AD SPSx50 GPS Receiver with 900 MHz Radio Assembly Diagram: ‘55800-00-AD+1.pdf’ 55800-90-AD SPSx50 GPS Receiver BOM: 55800-00 NetR5 GPS Receiver BOM: 62800-00 SPSx50 GPS Receiver with 450 MHz Radio BOM: 55800-6x SPSx50 GPS Receiver with 900 MHz Radio BOM: 55800-90 Trimble Navigation Gerardo Torres February 15, 2006 P/N List Configured & labelled receiver Label Line 1 Label Line 2 Label Line 3 Label Line 4 A ssembly line p/n's SPS550 58800-00 SPS550 58800-00 barcode 55800-00 58800-62 SPS550 58800-62 barcode 55800-62 58800-64 SPS550 58800-64 barcode 55800-64 58800-66 SPS550 58800-66 barcode 55800-66 58800-90-10 SPS550 58800-90 -10 barcode 55800-90 58800-90-20 SPS550 58800-90 -20 barcode 55800-90 58800-90-30 SPS550 58800-90 -30 barcode 55800-90 SPS550H 58801-00 SPS550H 58801-00 barcode 55800-00 SPS750 Basic Base 58802-00 SPS750 Basic Base 58802-00 barcode 55800-00 58802-62 SPS750 Basic Base 58802-62 barcode 55800-62 58802-64 SPS750 Basic Base 58802-64 barcode 55800-64 58802-66 SPS750 Basic Base 58802-66 barcode 55800-66 58802-90-10 SPS750 Basic Base 58802-90-10 barcode 55800-90 58802-90-20 SPS750 Basic Base 58802-90-20 barcode 55800-90 58802-90-30 SPS750 Basic Base 58802-90-30 barcode 55800-90 SPS750 Basic Rover 58803-00 SPS750 Basic Rover 58803-00 barcode 55800-00 58803-62 SPS750 Basic Rover 58803-62 barcode 55800-62 58803-64 SPS750 Basic Rover 58803-64 barcode 55800-64 58803-66 SPS750 Basic Rover 58803-66 barcode 55800-66 58803-90-10 SPS750 Basic Rover 58803-90-10 barcode 55800-90 58803-90-20 SPS750 Basic Rover 58803-90-20 barcode 55800-90 58803-90-30 SPS750 Basic Rover 58803-90-30 barcode 55800-90 Trimble Navigation Gerardo Torres February 15, 2006 SPS750 Max 58804-00 SPS750 Max 58804-00 barcode 55800-00 58804-62 SPS750 Max 58804-62 barcode 55800-62 58804-64 SPS750 Max 58804-64 barcode 55800-64 58804-66 SPS750 Max 58804-66 barcode 55800-66 58804-90-10 SPS750 Max 58804- 90-10 barcode 55800-90 58804-90-20 SPS750 Max 58804- 90-20 barcode 55800-90 58804-90-30 SPS750 Max 58804- 90-30 barcode 55800-90 SPS850 Extreme 58805-00 SPS850 Extreme 5880 5-00 barcode 55800-00 58805-62 SPS850 Extreme 5880 5-62 barcode 55800-62 58805-64 SPS850 Extreme 5880 5-64 barcode 55800-64 58805-66 SPS850 Extreme 5880 5-66 barcode 55800-66 58805-90-10 SPS850 Extreme 5880 5-90-10 barcode 55800-90 58805-90-20 SPS850 Extreme 5880 5-90-20 barcode 55800-90 58805-90-30 SPS850 Extreme 5880 5-90-30 barcode 55800-90

MPE Calculations The device is not a portable device (i.e. intended to be worn on the body or be hand- held), so it is classified as being either a mobile device or a fixed mounted device. The user’s manual specifies a minimum separation distance of at least 20cm, consistent with this classification. FCC part 1.1310, Table 1 limits the power density for uncontrolled exposure. The power density, P d (mW/cm 2 ) calculated from the maximum EIRP, P t (mW) and the distance, d (m), between the transmitting antenna and the closest person, can be calculated using: P d = P t /(4 πd 2 ) Frequency MPE Limit (mW/cm 2 ) Output Power (mW) Max. Antenna Gain (dBi) EIRP (mW) Pd at 20cm (mW/cm 2 ) Distance where Pd = limit (cm) 2402 to 2480 MHz 1.00 2.5 4.1 6.5 0.001 0.7 At 20cm from the device the contribution from the Bluetooth device is well below the limit. Note that as the device is below the 60/f(GHz) threshold power of 25mW for a 2.4 GHz device, it is not restricted to mobile use but could be classified as a portable device when no other transceivers are installed in the base device.

TTI-P-G 081/94-A0 Accredited according to ISO/IEC 17025 Bluetooth Qualification Test Facility (BQTF) FCC listed # 101450 IC recognized # 3925 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V1.1 2003-03-01 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test Report FCC Part 15.247 for FHSS systems/ CANADA RSS-210 FOR: MODEL #: R8-Model 2, SPS880 TRIMBLE NAVIGATION LTD., 935 STEWART DR. P.O BOX 3642 SUNNYVALE, CA 94088-3642 U.S.A FCC ID: Q23 31307 / 09EQ2426-SK IC ID: 1756A-50158 TEST REPORT #: EMC_1098_2005_BLUETOOTH DATE: DECEMBER 05, 2005 Test Report #: EMC_1098_2005_BLUETOOTH Date of Report: 2005-12-05 Page 2 of 81 TABLE OF CONTENTS 1 Assessment_____________________________________________________________________ 4 2 Administrative Data _____________________________________________________________ 5 2.1 Identification of the Testing Laboratory Issuing the EMC Test Report _____________________ 5 2.2 Identification of the Client __________________________________________________________ 5 2.3 Identification of the Manufacturer ___________________________________________________ 5 3 Equipment under Test (EUT) ______________________________________________________ 6 3.1 Identification of the Equipment under Test____________________________________________ 6 4 Subject Of Investigation __________________________________________________________ 7 5 Measurements For Bluetooth Module _______________________________________________ 8 5.1 MAXIMUM PEAK OUTPUT POWER § 15.247 (RADIATED) ___________________________ 8 5.1.1 LIMIT SUB CLAUSE § 15.247 (b) (1) (2) (3) (4)_______________________________________________ 8 5.1.2 RESULTS: _____________________________________________________________________________ 8 5.2 MAXIMUM PEAK OUTPUT POWER § 15.247 (CONDUCTED) ________________________ 12 5.2.1 LIMIT SUB CLAUSE § 15.247 (b) (1) ______________________________________________________ 12 5.2.2 RESULTS: ____________________________________________________________________________ 12 5.3 20dB BANDWIDTH ______________________________________________________________ 16 5.3.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 16 5.3.2 RESULTS: ____________________________________________________________________________ 16 5.4 CARRIER FREQUENCY SEPARATION____________________________________________ 20 5.4.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 20 5.4.2 RESULTS: ____________________________________________________________________________ 20 5.5 NUMBER OF HOPPING CHANNELS ______________________________________________ 22 5.5.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (iii)___________________________________________________ 22 5.5.2 RESULTS: ____________________________________________________________________________ 22 5.6 TIME OF OCCUPANCY (DWELL TIME)___________________________________________ 27 5.6.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 27 5.6.2 RESULTS: ____________________________________________________________________________ 27 5.7 CONDUCTED SPURIOUS EMISSIONS_____________________________________________ 31 5.7.1 LIMIT SUB CLAUSE § 15.247 (d) _________________________________________________________ 31 5.7.2 RESULTS __________________________________________________________________…

Text truncated - open the document above for the full version.
