JUP-9414-450GPS data transciever

Trimble, Inc.

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Mar 28, 2000
Application Purpose: Original Equipment
Date of Application: Jan 09, 2000
Equipment Note: GPS data transciever
Frequency Range: 410.00000000 - 470.00000000
Company: Trimble, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

– DRAFT – TRIMMARK III Operation Manual Part Number: XXXXX-00 Revision: A Date: November 1999 Trimble Navigation Limited Surveying & Mapping Division 645 North Mary Avenue Post Office Box 3642 Sunnyvale, CA 94088-3642 U.S.A. 1-800-827-8000 in North America +1-408-481-8000 International Fax: +1-408-481-7744 www.trimble.com – DRAFT – Trimble Navigation Europe Limited Trimble House, Meridian Office Park Osborn Way, Hook Hampshire RG27 9HX ENGLAND +44-1256-760-150 Fax: +44-1256-760-148 Voicemail: +44-1256-761-130 Trimble Navigation Singapore PTE Limited 79 Anson Road # 05-02 Singapore 079906 SINGAPORE +65-325-5668 Fax: +65-225-9989 Voicemail: +65-325-5668 Trimble Japan K.K. Sumitomo Hamamatsu-cho, Building 10F 1-18-16 Hamamatsu-cho Minato-ku Tokyo 105 JAPAN +81-3-5472-0880 Fax: +81-3-5472-2326 Trimble Navigation New Zealand Limited 11 Birmingham Drive P.O. Box 8729 Riccarton Christchurch NEW ZEALAND +64-3-339-1400 Fax: +64-3-339-1417 Copyright © 1999 Trimble Navigation Limited. All rights reserved. No part of this manual may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine- readable form without prior written consent from Trimble Navigation Limited. Printed in the United States of America. Printed on recycled paper. – DRAFT – Revision Notice This is the November 1999 release (Revision A) of the TRIMMARK III Operation Manual, part number XXXXX-00. Trademarks TRIMTALK 450S, TRIMTALK 900, RTK, OSM2, 4000Si, 4000SSi, 4600LS, 4700, 4800, 7400MSi, and GPS Total Station are trademarks of Trimble Navigation Limited. IBM is a registered trademark of International Business Machines, Inc. MS-DOS and Windows are trademarks of Microsoft Corporation. Intel is a trademark of Intel Corporation. All other brand names are trademarks of their respective holders. Notices Safety. Exposure to RF energy is an important safety consideration. The FCC has adopted a safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated equipment as a result of its actions in General Docket 79-144 on March 13, 1986. Proper use of this radio modem results in exposure below government limits. The following precautions are recommended: DO NOT operate the transmitter when someone is within two feet (0.6 meter) of the antenna. DO NOT operate the transmitter unless all RF connectors are secure and any open connectors are properly terminated. DO NOT operate the equipment near electrical blasting caps or in an explosive atmosphere. All equipment must be properly grounded according to Trimble installation instructions for safe operation. All equipment should be serviced only by a qualified technician. Class A Computing Device—Information to User. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. – DRAFT – Disclaimer of Warranty E XCEPT AS INDICATED IN “LIMITED WARRANTY” HEREIN, TRIMBLE HARDWARE, SOFTWARE, F IRMWARE AND DOCUMENTATION IS PROVIDED “AS IS” AND WITHOUT EXPRESS OR LIMITED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, OR DISTRIBUTION INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK, AS TO THE QUALITY AND PERFORMANCE OF THE TRIMBLE H ARDWARE, SOFTWARE, FIRMWARE AND DOCUMENTATION, IS WITH YOU. SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU. Limitation of Liability IN NO EVENT WILL TRIMBLE OR ANY PERSON INVOLVED IN THE CREATION, PRODUCTION, OR DISTRIBUTION OF THE TRIMBLE PRODUCT BE LIABLE TO YOU ON ACCOUNT OF ANY CLAIM FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES, INCLUDING BUT NOT LIMITED TO ANY DAMAGES ASSESSED AGAINST OR PAID BY YOU TO ANY THIRD PARTY, RISING OUT OF THE USE, LIABILITY TO USE, QUALITY OR PERFORMANCE OF SUCH TRIMBLE PRODUCT INCLUDING HARDWARE, SOFTWARE, FIRMWARE AND DOCUMENTATION, EVEN IF TRIMBLE OR ANY SUCH PERSON OR ENTITY HAS BEEN ADVISED OF THE POSSIBILITY OF DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. SOME STATES DO NOT ALLOW THE LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. Software and Firmware Limited Warranty Trimble Navigation Limited warrants that Software and Firmware products will substantially conform to the published specifications provided it is used with the Trimble products, computer products, and operating system for which it was designed. For a period of ninety (90) days, commencing thirty (30) days after shipment from Trimble, Trimble also warrants that the magnetic media on which Software and Firmware are distributed and the documentation are free from defects in materials and workmanship. During the ninety (90) day warranty period, Trimble will replace defective media or documentation, or correct substantial program errors at no charge. If Trimble is unable to replace defective media or documentation, or correct program errors, Trimble will refund the price paid for The Software. These are your sole remedies for any breach in warranty. – DRAFT – Hardware Limited Warranty Trimble Navigation Limited products are warranted against defects in material and workmanship for a period of one year. The warranty period shall commence thirty (30) days aft…

Text truncated - open the document above for the full version.

Cover Letter(s)

tel: 650-726-1263 fax: 650-726-1252 internet: [email protected] Thomas N. CokeniasEMC & Radio Type Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 21 January 2000 FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner Reviewing Engineer Re: Request for confidentiality per Section 0.459 of FCC Rules Applicant: Trimble Navigation Ltd. FCC ID: JUP-9414-450 To whom it may concern, Request is hereby submitted, on behalf of my client Trimble Navigation, to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Schematics Block diagrams Theory of operation Rationale for request for confidentiality: Trimble Navigation has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. The $135 fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, THOMAS N. COKENIAS EMC Consultant/Agent for Trimble Navigation. tel: 650-726-1263 fax: 650-726-1252 internet: [email protected]

Cover Letter(s)

ID Label/Location Info

DESIGNER: PROJECT: PROJECT MANAGER: INDUSTRIAL DESIGN 623 11.16.99 TRIMMARK III BOTTOM LABEL JACK WARNER SKIP ANDERSON CONFIDENTIAL SEE OPERATION MANUAL FOR SERVICE INFORMATION & OTHER WARNINGS CAUTION. HOT SURFACE. DURING OPERATION AVOID CONTACT WITH FINS. Made in USA FOR USE WITH 12.6 VDC 7 amps MAX OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, & (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES MODEL SN PN FCC ID: JUP-9414-450 CANADA FREQ TRIMBLE NAVIGATION LTD.

ID Label/Location Info

Test Report

Trimble Navigation Ltd.FCC ID: JUP-9414-450 1 of 31 pages EXHIBITS EXHIBIT 1:Letter Requesting Confidentiality under Sec. 0.457(d) EXHIBIT 2:Information for which Confidentiality is Requested Schematics Block Diagrams Theory of Operations EXHIBIT 3:Product Photographs EXHIBIT 4:Parts List of Active Devices EXHIBIT 5:User Manual and FCC ID Label EXHIBIT 6:Spectral Efficiency Per Section 90.203 EXHIBIT 7: Report of Measurements EXHIBIT 8: Data Graphs - Occupied Bandwidth EXHIBIT 9: Data Graphs - Out of Band Emissions EXHIBIT 10:Data Graphs - Modulation Limiting and Transient Response EXHIBIT 11:Data Sheets - Frequency Stability Trimble Navigation Ltd.FCC ID: JUP-9414-450 2 of 31 pages EXHIBIT 1:Letter Requesting Confidentiality under Sec. 0.457(d) - see separate attachment TM3conf.doc Trimble Navigation Ltd.FCC ID: JUP-9414-450 3 of 31 pages EXHIBIT 2:Information for which Confidentiality is Requested Schematics Theory of Operation Block Diagrams Trimble Navigation Ltd.FCC ID: JUP-9414-450 4 of 31 pages EXHIBIT 3: Product Photographs - See separately submitted .jpg photograph files Trimble Navigation Ltd.FCC ID: JUP-9414-450 5 of 31 pages EXHIBIT 4:Parts List of Active Devices - refer to schematics, block diagrams, and theory of operation Trimble Navigation Ltd.FCC ID: JUP-9414-450 6 of 31 pages EXHIBIT 5:User Manual and FCC ID Label - See separate attachments USERMAN.pdf and TRIM3FCCID.pdf Trimble Navigation Ltd.FCC ID: JUP-9414-450 7 of 31 pages EXHIBIT 6: Spectral Efficiency per Section 90.203 CERTIFICATE: Trimble Navigation Ltd. certifies that, per the requirements of 90.203(j)3, that the reference radio, FCC ID: JUP-9414-450, meets the spectrum efficiency channel of one voice channel bandwidth per 12.5 kHz of channel bandwidth. Furthermore, the reference device is capable of transmitting data and is capable of supporting a data rate of 4800 bits per second per 6.25 kHz of bandwidth. Channel bandwidth is calculated as the bandwidth containing 99% of the energy of the emission, or the 20 dB bandwidth. Trimble Navigation Ltd.FCC ID: JUP-9414-450 8 of 31 pages EXHIBIT 7:Report of Measurements Trimble Navigation Ltd.FCC ID: JUP-9414-450 9 of 31 pages FCC CERTIFICATION INFORMATION The following information is in accordance with FCC Rules, 47CFR Part 2, Subpart J, sections 2.1031 - 2.1057. 2.1033(c)1Applicant:Trimble Navigation Ltd. 645 N. Mary Avenue Sunnyvale, CA 94086 2.1033(c)2FCC ID: JUP-9414-450 2.1033(c)3Installation and operating instructions are in separate documentation. 2.1033(c)4Types of emission: 1. 4800 baud GMSK(.5), 3.5 kHz deviation20 kHz auth BW: 20K0G1D 2. 9600 baud GMSK(.5), 3.5 kHz deviation20 kHz auth BW: 20K0G1D 3. 4800 baud GMSK(.5), 2.4 kHz deviation20 kHz auth BW: 20K0G1D 4. 4800 baud GMSK(.5) 1.2 kHz deviation11.25 kHz auth BW: 11K25G1D 5. 9600 baud GMSK(.3) 1.5 kHz deviation11.25 kHz auth BW: 11K25G1D 6. 9600 baud GMSK(.5) 4.8 kHz deviation20 kHz auth BW: 20K0G1D 7. 19200baud GMSK(.3) 4.0 kHz deviation20 kHz auth BW: 20K0G1D 8. 9600 baud 4FSK 4 kHz deviation11.25 kHz auth BW: 11K25G1D 9. 19200 baud 4FSK 4.8 kHz deviation20 kHz auth BW: 20K0G1D 2.1033(c)5Frequency range: 410-470 MHz 2.1033(c)6Range of operating power: 2 watts or 25 watts programmable 2.1033(c)7Maximum output power: 25 watts design (26.6 watts measured, +0.3 dB) 2.1033(c)8Applied DC voltages and currents to final amplifier: Refer to schematic 2.1033(c)9Tune-up procedure Refer to user manual USERMAN.pdf 2.1033(c)10 Schematic, Block Diagram, and Theory of Operation Trimble Navigation Ltd.FCC ID: JUP-9414-450 10 of 31 pages Refer to Exhibit 2. Confidentiality is requested for these items. 2.1033(c)11 Drawing or photograph of FCC ID label Refer to Exhibit 5. 2.1033(c)12 Types of equipment: Refer to separate .jpg product photographs 2.1033(c)13 Desciption of digital modulation: See 2.1033(c) above and Exhibit 2 Trimble Navigation Ltd.FCC ID: JUP-9414-450 11 of 31 pages Standard Test Conditions The transmitter was tested under the following conditions: Room Temperature: 20 - 23 °C Relative Humidity: 35 - 50% DC Supply Voltage: 12.6 VDC The transmitter was aligned and tuned up according to manufacturer’s alignment procedure, prior to testing. All data presented represents the worst case parameter being measured. Section 2.1046 RF Power Output Test Set-up power meter power sensor EUT DC supply attenuator controller pc Measurement Equipment Used: HP 437B Power Meter HP 8482A Power Sensor Weinschel model 401034 attenuator, 50 watt 90.205 Power and Antenna Height Limits Test Results Trimble Navigation Ltd.FCC ID: JUP-9414-450 12 of 31 pages Maximum Output Power: 26.6 Watts @ 450 MHz Trimble Navigation Ltd.FCC ID: JUP-9414-450 13 of 31 pages Section 2.1049 Occupied Bandwidth Test Set-up spectrum analyzerEUT DC supply attenuator controller p Measurement Equipment Used: HP 8561 Spectrum Analyzer Weinschel model 401034 attenuator, 50 watt Data on the bandwidth occupied by this transmitter is presented in graphical form using spectrum analyzer plots. A separate spectrum plot is supplied for each modulation type. 90.209 Bandwidth limitations 90.210(b) Emission mask B: 25 kHz channel (20 kHz authorized BW) Any emission must be attenuated below the power (P) of the highest emission contained within the authorized bandwidth as follows: 1. On any frequency removed from the assigned frequency by more than 50 percent but less than 100 percent: at least 25 dB Trimble Navigation Ltd.FCC ID: JUP-9414-450 14 of 31 pages 2. On any frequency removed from the assigned frequency by more than 100 percent but less than 250 percent: at least 35 dB 3. On any frequency removed from the center of the authorized bandwidth by a displacement frequency (fd in kHz) of more than 250 percent: At least 43 + 10 log(P) dB 90.210(d) Emission mask D: 12.5 kHz channel bandwidth (11.25 kHz authorized BW) Any emission must be attenuated below the power (P) of the highest emission contained within the authorized bandwidth as follows: 1. On any frequen…

Text truncated - open the document above for the full version.

Test Report

T, ° °° °CStability, ppm -30-1.1 -20-1.0 -10-0.8 0-1.1 10-0.8 200 30-0.2 40-0.4 50-0.5 Italics: temperature stability data from Trimble, 8 March 2000 Normal type: from manufacturer's test data sheet, submitted with application Tests performed in Trimble temperature chamber. Freq. v Supply Voltage: TX set to 460 MHz Nominal: 12.6 VDC f = 459.999861 MHz (-149 Hz) 115% Nominal: 14.5 VDC f = 459.999854 MHz (-146 Hz) 85% Nominal: . 10.8 VDCf = 459.999853 MHz (-157 Hz) 10.65 VDC: LO BATT warning NOTE: The power supply variation data was submitted previously - see p 14 of test report, and is being reproduced here for convenience. Frequency Stability Data FCC ID: JUP-9414-450
