JUP-TVG850EVDOTelematics Platforms

TVG-850 - Installation Instructions Trimble Mobile Resource Management. Jun 16, 2010 Revision 02 Trimble TVG-850 68008-XX-IM Installation Instructions Revision: 02 Jun 16, 2010 © Copyright 2009, Trimble Navigation Limited. All rights reserved. The Sextant Logo with Trimble, the Globe & Triangle logo with Trimble, Telvisant, IQEvent Engine, CrossCheck, TVG-850 and iDT are trademarks of Trimble Navigation Limited registered in the United States Patent and Trademark Office. TrimFleet, TrimWeb, TrimView, and TrimTrac are trademarks of Trimble Navigation Limited. All other trademarks are the property of their respective owners. TVG-850 - Installation Instructions Trimble Mobile Resource Management Jun 16, 2010 Revision 02 ii Trimble Navigation Limited 935 Stewart Drive Sunnyvale, California 94085 Phone: (408) 481-8000 www.trimble.com Software License, Limited Warranty This Trimble software product, whether provided as a stand-alone computer software product, built into hardware circuitry as firmware, embedded in flash memory, or stored on magnetic or other media, (the “Software”) is licensed and not sold, and its use is governed by the terms of the relevant End User License Agreement (“EULA”) included with the Software. In the absence of a separate EULA included with the Software providing different limited warranty terms, exclusions and limitations, the following terms and conditions shall apply. Trimble warrants that this Trimble Software product will substantially conform to Trimble’s applicable published specifications for the Software for a period of ninety (90) days, starting from the date of delivery. Warranty Remedies Trimble's sole liability and your exclusive remedy under the warranties set forth above shall be, at Trimble’s option, to repair or replace any Product or Software that fails to conform to such warranty ("Nonconforming Product") or refund the purchase price paid by you for any such Nonconforming Product, upon your return of any Nonconforming Product to Trimble in accordance with Trimble’s standard return material authorization procedures. Warranty Exclusions and Disclaimer These warranties shall be applied only in the event and to the extent that the Products and Software are (i) properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's relevant operator's manual and specifications, and; (ii) the Products and Software are not modified or misused. The preceding warranties shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product or Software with hardware or software products, information, data, systems, interfacing or devices not made, supplied or specified by Trimble; (ii) the operation of the Product or Software under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized modification or use of the Product or Software; (iv) damage caused by accident, lightning or other electrical discharge, fresh or salt water immersion or spray; or (v) normal wear and tear on consumable parts (e.g., batteries). Trimble does not warrant or guarantee the results obtained through the use of the Product. THE WARRANTIES ABOVE STATE TRIMBLE'S ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATING TO PERFORMANCE OF THE PRODUCTS AND SOFTWARE. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE PRODUCTS, SOFTWARE, AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, INSTALLATION, OR DISTRIBUTION INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF TRIMBLE ARISING OUT OF, OR IN CONNECTION WITH, ANY PRODUCTS OR SOFTWARE. SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. TRIMBLE NAVIGATION LIMITED IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF GPS SATELLITES OR THE AVAILABILITY OF GPS SATELLITE SIGNALS. Limitation of Liability TRIMBLE’S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SHALL BE LIMITED TO THE AMOUNT PAID BY YOU FOR THE PRODUCT OR SOFTWARE LICENSE. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TRIMBLE OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANY WAY TO THE PRODUCTS, SOFTWARE AND ACCOMPANYING DOCUMENTATION AND MATERIALS, (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS), REGARDLESS WHETHER TRIMBLE HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE COURSE OF DEALING WHICH DEVELOPS OR HAS DEVELOPED BETWEEN YOU AND TRIMBLE. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. NOT WITHSTANDING THE ABOVE, IF YOU PURCHASED THIS PRODUCT OR SOFTWARE IN THE EUROPEAN UNION, THE ABOVE WARRANTY PROVISIONS MAY NOT APPLY. PLEASE CONTACT YOUR DEALER FOR APPLICABLE WARRANTY INFORMATION. TVG-850 - Installation Instructions Trimble Mobile Solutions, Inc. Jun 16, 2010 Revision 02 iii FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Note: This equipment has been tested and found to comply wit…

Text truncated - open the document above for the full version.

TVG-850 - Installation Instructions Trimble Mobile Resource Management. July 20, 2010 Revision 03 Trimble TVG-850 68008-XX-IM Installation Instructions Revision: 03 July 20, 2010 © Copyright 2009, Trimble Navigation Limited. All rights reserved. The Sextant Logo with Trimble, the Globe & Triangle logo with Trimble, Telvisant, IQEvent Engine, CrossCheck, TVG-850 and iDT are trademarks of Trimble Navigation Limited registered in the United States Patent and Trademark Office. TrimFleet, TrimWeb, TrimView, and TrimTrac are trademarks of Trimble Navigation Limited. All other trademarks are the property of their respective owners. TVG-850 - Installation Instructions Trimble Mobile Resource Management July 20, 2010 Revision 03 ii Trimble Navigation Limited 935 Stewart Drive Sunnyvale, California 94085 Phone: (408) 481-8000 www.trimble.com Software License, Limited Warranty This Trimble software product, whether provided as a stand-alone computer software product, built into hardware circuitry as firmware, embedded in flash memory, or stored on magnetic or other media, (the “Software”) is licensed and not sold, and its use is governed by the terms of the relevant End User License Agreement (“EULA”) included with the Software. In the absence of a separate EULA included with the Software providing different limited warranty terms, exclusions and limitations, the following terms and conditions shall apply. Trimble warrants that this Trimble Software product will substantially conform to Trimble’s applicable published specifications for the Software for a period of ninety (90) days, starting from the date of delivery. Warranty Remedies Trimble's sole liability and your exclusive remedy under the warranties set forth above shall be, at Trimble’s option, to repair or replace any Product or Software that fails to conform to such warranty ("Nonconforming Product") or refund the purchase price paid by you for any such Nonconforming Product, upon your return of any Nonconforming Product to Trimble in accordance with Trimble’s standard return material authorization procedures. Warranty Exclusions and Disclaimer These warranties shall be applied only in the event and to the extent that the Products and Software are (i) properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's relevant operator's manual and specifications, and; (ii) the Products and Software are not modified or misused. The preceding warranties shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product or Software with hardware or software products, information, data, systems, interfacing or devices not made, supplied or specified by Trimble; (ii) the operation of the Product or Software under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized modification or use of the Product or Software; (iv) damage caused by accident, lightning or other electrical discharge, fresh or salt water immersion or spray; or (v) normal wear and tear on consumable parts (e.g., batteries). Trimble does not warrant or guarantee the results obtained through the use of the Product. THE WARRANTIES ABOVE STATE TRIMBLE'S ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATING TO PERFORMANCE OF THE PRODUCTS AND SOFTWARE. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE PRODUCTS, SOFTWARE, AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, INSTALLATION, OR DISTRIBUTION INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF TRIMBLE ARISING OUT OF, OR IN CONNECTION WITH, ANY PRODUCTS OR SOFTWARE. SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. TRIMBLE NAVIGATION LIMITED IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF GPS SATELLITES OR THE AVAILABILITY OF GPS SATELLITE SIGNALS. Limitation of Liability TRIMBLE’S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SHALL BE LIMITED TO THE AMOUNT PAID BY YOU FOR THE PRODUCT OR SOFTWARE LICENSE. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TRIMBLE OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANY WAY TO THE PRODUCTS, SOFTWARE AND ACCOMPANYING DOCUMENTATION AND MATERIALS, (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS), REGARDLESS WHETHER TRIMBLE HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE COURSE OF DEALING WHICH DEVELOPS OR HAS DEVELOPED BETWEEN YOU AND TRIMBLE. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. NOT WITHSTANDING THE ABOVE, IF YOU PURCHASED THIS PRODUCT OR SOFTWARE IN THE EUROPEAN UNION, THE ABOVE WARRANTY PROVISIONS MAY NOT APPLY. PLEASE CONTACT YOUR DEALER FOR APPLICABLE WARRANTY INFORMATION. TVG-850 - Installation Instructions Trimble Mobile Solutions, Inc. July 20, 2010 Revision 03 iii FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Note: This equipment has been tested and found to comply…

Text truncated - open the document above for the full version.

s ilex tec hnol o gy silex technology america, Inc. www. silexamerica. com June 24,2010 157 West 7065 Sou t h Sa lt Lake City, UT 84047 Ph one. 801-748-1199 Fax.801 - 748-0 730 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Authorization to utilize certification test report on identical unit ­ per section 2.908 To whom it may concern, Please be advised that Silex Technology. Inc. authorizes Trimble MRM and UL Compliance Certification Services to utilize compliance data from Part 22/24 RF conducted test report of the Silex Technology, Inc. model No:SX­ 10WAG, FCC ID: N6C-SX10WAG to demonstrate compliance for the Trimble MRM Model No: TVG-850 EVDO, FCC ID: JUP-TVG850EVDO. The FCC Part 15.247 RF conducted test data is referenced to report no: 26GE0351-HO-A-1. Cordially, ( David N. Smith COO & Vice President International Business Silex Technology, Inc.

888 Tasman Drive, Milpitas, CA 95035 TVG-850 EVDO External Photos 1 TVG-850 EVDO external (a) Front view, (b) top view, (c) Rear view (a) (b) (c) USB Ethernet VB SER 2 SER 1 DIG PWR 888 Tasman Drive, Milpitas, CA 95035 TVG-850 EVDO External Photos 2 TVG-850 EVDO – Bottom View TVG-850 EVDO With Antennas

PRODUCT: LABEL, TVG-850, TOP SPRINT/VZW DATE DRAWN: 28 June 2010 DRAWN BY: John Koehler PAGE: 1 OF 1 SCALE: N/A SIZE: A PART NUMBER: 80490 THIS DOCUMENT CONTAINS CONFIDENTIAL AND PROPRIETARY INFORMATION. THE RECIPIENT SHALL NOT USE, REPRODUCE, OR DISCLOSE ITS CONTENTS IN WHOLE OR IN PART WITHOUT THE PRIOR WRITTEN CONSENT OF TRIMBLE MOBILE SOLUTIONS, INCORPORATED. FULL FILENAME: CHECKED BY:APPROVAL: REV DESCRIPTION APPROVAL / DATE 01 Created 02 Rev was incorrectly listed as A. Updated FCC and IC info. Added EVDO to product name DC BA 4 3 2 1 DC BA 4 3 2 1 Notes:1. 300LSE(2mil version) Adhesive, or equivalent2. Material to be 0.002 White Mylar, suitable for thermal transfer printing. 3. This part will be RoHS compliant.4. Unless otherwise specified dimensions are in inc hes. 2.30 1.50 Mobile Resource Management R 0.15" 3.80 0.12 0.68 1.18 1.68 0.17 0.45 FCC ID: JUP-TVG850EVDOIC: 1756A- TVG850EVDO This device complies with part 15 of the FCC Rules. Operation is subject to the following two co nditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference receiv ed, including interference that may cause undesired ope ration. This Class B digital apparatus complies with Canadi an ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Assembled in Taiwan Arial 4pt. Arial 4pt.Arial 8pt. Arial 18pt. Arial 4pt. 80490 Label PN Arial 6pt. .34" 1.67"

888 Tasman Drive, Milpitas, CA 95035 TVG-850 EVDO Internal Photos 1 TVG-850 EVDO Internal (a) PCB Top (b) PCB Bottom (a) (b)

MPE RF exposure calculations for TVG-850 EVDO with collocated antennas The following RF exposure calculations have been made for the TVG-850 EVDO (FCC ID: JUP-TVG850EVDO) which incorporates the following devices and antennas: • Sierra Wireless EVDO card, model: MC5728V FCC ID: N7N-MC5728 • Silex 802.11 b/g card, model: SX-10WAG FCC ID: N6C-SX-10WAG • Mobile Mark antenna (cellular, GPS and 802.11) model number: SMW-UMB This device will only be used with a separation of 20 cm or greater between the antennas and the user or nearby person. This device will be considered as a mobile transmitter per 47 CFR 2.1091(b) and therefore has to comply with Maximum Permissible Exposure (MPE) limits. Limits Applicable to the TVG-850 EVDO For mobile radio equipment operating in the cellular phone band, the lowest power density limit is calculated using the lowest frequency as 824 MHz / 1500 = 0.55mW/c,^2 and 824 MHz / 150 = 5.5 W/m^2 For operation in the PCS band and the 2.4 GHz band, from FCC 1.1310 Table 1 (B), the maximum values of S = 1.0 mW/cm^2 and from IC Safety Code, Section 2.2 Table 5 Column 4, S = 10W/m^2. Co-location results for Simultaneous Operation in the Cellular Band and 2.4 GHz band Band Mode Separation Distance (m) Output Power (dBm) Antenna gain with cable loss (dBi) Duty Cycle (%) IC Power Density (W/m^2) 850 MHz Cell 29.82 -0.25 100 2.4 GHz WLAN 16.45 1.7 100 Combined 0.20 1.93 The co-located Power Density is less than 5.5 W/m^2 which is the most stringent of the limits for each separate transmitter (5.5 W/m^2 and 10 W/m^2 for the WAN and WLAN respectively). Co-located results for simultaneous operation in the PCS band and the 2.4 GHz band Band Mode Separation Distance (m) Output Power (dBm) Antenna gain with cable loss (dBi) Duty Cycle (%) IC Power Density (W/m^2) 1900 MHz PCS 29.10 1.70 100 2.4 GHz WLAN 16.45 1.70 100 Combined 0.20 2.52 The co-located Power Density is less than 10W/m^2 which is the limits for each separate transmitter. Conclusion The TVG-850 EVDO is in compliance with FCC MPE limits for General Population / Uncontrolled Exposure as a mobile device with a distance of greater than 20 cm from the co-located antennas.

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 7 CERTIFICATION TEST REPORT FOR TELEMATICS PLATFORMS (GPS+WWAN (CDMA2000 EV-DO/1xRTT) +WLAN (802.11a/b/g) + BLUETOOOTH (Ver.2.0)) MODEL NUMBER: TVG-850 EVDO FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO REPORT NUMBER: 10U13184-4 ISSUE DATE: JUNE 18, 2010 Prepared for TRIMBLE MRM 888 TASMAN ROAD MILPITAS, CA 95035, U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 2 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 06/18/10 Initial Issue T. Chan REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 3 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS.................................................................................... 4 2. TEST METHODOLOGY ........................................................................................................ 5 3. FACILITIES AND ACCREDITATION.................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .................................................................................. 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................... 5 4.2. SAMPLE CALCULATION.............................................................................................. 5 4.3. MEASUREMENT UNCERTAINTY................................................................................ 5 5. EQUIPMENT UNDER TEST ................................................................................................. 6 5.1. DESCRIPTION OF EUT................................................................................................ 6 5.2. DESCRIPTION OF AVAILABLE ANTENNAS............................................................... 6 5.3. SOFTWARE AND FIRMWARE..................................................................................... 6 5.4. WORST-CASE CONFIGURATION AND MODE .......................................................... 6 5.5. DESCRIPTION OF TEST SETUP................................................................................. 7 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................... 9 7. RADIATED TEST RESULTS .............................................................................................. 10 7.1. LIMITS AND PROCEDURE ........................................................................................ 10 7.2. TRANSMITTER ABOVE 1 GHz .................................................................................. 11 7.2.1. TRANSMITTER ABOVE 1 GHz FOR 802.11b MODE IN THE 2.4 GHz BAND .. 11 7.2.2. TRANSMITTER ABOVE 1 GHz FOR 802.11g MODE IN THE 2.4 GHz BAND .. 20 7.3. RECEIVER ABOVE 1 GHz ......................................................................................... 29 7.4. WORST-CASE BELOW 1 GHz................................................................................... 30 7.5. DIGITAL DEVICE BELOW 1 GHz............................................................................... 33 8. REQUIREMENTS - LIMITATION OF EXPOSURE ............................................................. 36 8.1. LIMITS.........................................................................................................................36 8.2. EQUATIONS ............................................................................................................... 38 8.3. RESULTS.................................................................................................................... 39 8.3.1. CO-LOCATED RESULTS FOR SIMULTANEOUS OPERATION IN THE CELLULAR BAND AND 2.4 GHz BAND ............................................................................. 39 8.3.2. CO-LOCATED RESULTS FOR SIMULTANEOUS OPERATION IN THE PCS BAND AND 2.4 GHz BAND ................................................................................................. 39 9. SETUP PHOTOS................................................................................................................. 40 REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 4 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: TRIMBLE MRM 888 TASMAN ROAD, MILPITAS, CA 95035, U.S.A. EUT DESCRIPTION: TELEMATICS PLATFORM Contains: GPS+WWAN (CDMA2000 EV-DO/1xRTT) +WLAN (802.11a/b/g) + BLUETOOOTH (Ver.2.0) MODEL: TVG-850 EVDO SERIAL NUMBER: 38 DATE TESTED: APRIL 27 – JUNE 16, 2010 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass INDUSTRY CANADA RSS-210 Issue 7 Annex 8 Pass INDUSTRY CANADA RSS-GEN Issue 2 Pass Compliance Certification Services, Inc. (CCS) tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by CCS based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as document…

Text truncated - open the document above for the full version.

Test report No. : 26GE0351-HO-A-1 Page : 1 of 80 Issued date : June 8, 2006 Revised date : July 8, 2006 FCC ID : N6C-SX10WAG UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(14.06.06) EMI TEST REPORT Test Report No. : 26GE0351-HO-A-1 Applicant : silex technology, Inc. Type of Equipment : MiniPCI Wireless LAN Board Model No. : SX-10WAG Test standard : FCC Part 15 Subpart C Section 15.207, Section 15.247: 2006 FCC ID : N6C-SX10WAG Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Apex Co., Ltd. 2. The results in this report apply only to the sample tested. 3. This equipment is in compliance with above regulation. We hereby certify that the data contain a true representation of the EMC profile. 4. The test results in this report are traceable to the national or international standards. Date of test: ____________________________ Tested by: ______________________________ ______________________________ Hiroka Umeyama EMC Services Norihisa Hashimoto EMC Services Approved by : ______________________________ Naoki Sakamoto Group Leader of EMC Services May 11 to July 8, 2006 NVLAP LAB CODE: 200572-0 This laboratory is accredited by the NVLAP LAB CODE 200572-0, U.S.A. The tests reported herein have been performed in accordance with its terms of accreditation. *As for the range of Accreditation in NVLAP, you may refer to the WEB address, http://ulapex.jp/emc/nvlap.htm Test report No. : 26GE0351-HO-A-1 Page : 2 of 80 Issued date : June 8, 2006 Revised date : July 8, 2006 FCC ID : N6C-SX10WAG UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(14.06.06) CONTENTS PAGE SECTION 1: Client information...................................................................................................3 SECTION 2: Equipment under test (E.U.T.)................................................................................3 SECTION 3: Test specification, procedures & results..................................................................4 SECTION 4: Operation of E.U.T. during testing..........................................................................7 SECTION 5: Conducted Emission................................................................................................9 SECTION 6: Spurious Emission.................................................................................................10 SECTION 7: Bandwidth.............................................................................................................11 SECTION 8: Maximum Peak Output Power..............................................................................11 SECTION 9: Peak Power Density...............................................................................................11 APPENDIX 1: Photographs of test setup....................................................................................12 Conducted Emission................................................................................................................12 Spurious Emission (Radiated).................................................................................................13 Worst Case Position (X-axis:Horizontal / Y-axis:Vertical)......................................................14 APPENDIX 2:Test instruments...................................................................................................15 APPENDIX 3: Data of EMI test...................................................................................................17 Conducted Emission................................................................................................................17 6dB Bandwidth.......................................................................................................................28 Maximum Peak Output Power................................................................................................33 Radiated Spurious Emission...................................................................................................40 Conducted Spurious Emission.................................................................................................58 Conducted emission Band Edge compliance............................................................................71 Power Density.........................................................................................................................73 99%Occupied Bandwidth.......................................................................................................78 Test report No. : 26GE0351-HO-A-1 Page : 3 of 80 Issued date : June 8, 2006 Revised date : July 8, 2006 FCC ID : N6C-SX10WAG UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(14.06.06) SECTION 1: Client information Company Name : silex technology, Inc. Address : 15-15 Takaida higashiosaka Osaka Japan Telephone Number : +81-6-6784-3758 Facsimile Number : +81-6-6784-3750 Contact Person : Toshiro Kometani SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : MiniPCI Wireless LAN Board Model No. : SX-10WAG Serial : ES0002 / 0080923A9A29 Rating : DC3.3V, 0.54A Country of Manufacture : Japan Receipt Date of Sample : April 14, 2006 Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No modification by the test lab. 2.2 Product Description Model: SX-10WAG is the MiniPCI Wireless LAN Board. Equipment Type : Transceiver Clock frequency : 40MHz Method of Frequency Generation : Crystal Operating voltage (inner) : DC3.3V +/-10% IEEE802.11b IEEE802.11g IEEE802.11a Frequency of operation 2412-2462MHz 2412-2462MHz …

Text truncated - open the document above for the full version.

REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 40 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 9. SETUP PHOTOS RADIATED RF MEASUREMENT SETUP RADIATED FRONT PHOTO RADIATED BACK PHOTO REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 41 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED CLOSE UP FRONT PHOTO RADIATED CLOSE UP BACK PHOTO REPORT NO: 10U13184-4 ATE: JUNE 18, 2010 FCC ID: JUP-TVG850EVDO IC: 1756A-TVG850EVDO Page 42 of 43 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-100…

Text truncated - open the document above for the full version.
