JUP66430PDA

USER GUIDE Juno ® SA handheld Version 1.00 Revision A January 2011 F USER GUIDE Juno ® SA handheld 4 Juno SA handheld User Guide Trimble Navigation Limited 10355 Westmoor Drive Suite #100 Westminster, CO 80021 USA www.trimble.com Legal Notices Copyright and Trademarks © 2011, Trimble Navigation Limited. All rights reserved. Trimble, the Globe & Triangle logo, GPS Pathfinder, and Juno are trademarks of Trimble Navigation Limited, registered in the United States and in other countries. GPS Analyst, GPScorrect, and TerraSync are trademarks of Trimble Navigation Limited. Microsoft, ActiveSync, Outlook, Windows, Windows Live, Windows Media, Windows Mobile, Windows Vista, and the Windows Start logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Release Notice This is the January 2011 release (Revision A) of the Juno SA handheld User Guide. The Juno SA handheld’s operating system is based on the Microsoft Windows Mobile version 6.1 Classic operating system (5.2.20269). Limited Warranty Terms and Conditions Product Limited Warranty Subject to the terms and conditions set forth herein, Trimble Navigation Limited (“Trimble”) warrants that for a period of (1) year from date of purchase this Trimble product (the “Product”) will substantially conform to Trimble's publicly available specifications for the Product and that the hardware and any storage media components of the Product will be substantially free from defects in materials and workmanship. Product Software Product software, whether built into hardware circuitry as firmware, provided as a standalone computer software product, embedded in flash memory, or stored on magnetic or other media, is licensed solely for use with or as an integral part of the Product and is not sold. The terms of the end user license agreement, as included below, govern the use of the Product Software, including any differing limited warranty terms, exclusions and limitations, which shall control over the terms and conditions set forth in the limited Product warranty. Warranty Remedies If the Trimble Product fails during the warranty period for reasons covered by this limited warranty and you notify Trimble of such failure during the warranty period, Trimble will repair OR replace the nonconforming Product with new, equivalent to new, or reconditioned parts or Product, OR refund the Product purchase price paid by you, at Trimble’s option, upon your return of the Product in accordance with Trimble's product return procedures then in effect. How to Obtain Warranty Service To obtain warranty service for the Product, please contact your Trimble dealer. Alternatively, you may contact Trimble to request warranty service at +1-408-481-6940 (24 hours a day) or email your request to [email protected]. Please be prepared to provide: – your name, address, and telephone numbers; – proof of purchase; – a copy of this Trimble warranty – a description of the nonconforming Product including the model number; and – an explanation of the problem. The customer service representative may need additional information from you depending on the nature of the problem. Warranty Exclusions and Disclaimer This Product limited warranty shall only apply in the event and to the extent that (i) the Product is properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's applicable operator's manual and specifications, and; (ii) the Product is not modified or misused. This Product limited warranty shall not apply to, and Trimble shall not be responsible for, defects or performance problems resulting from (i) the combination or utilization of the Product with hardware or software products, information, data, systems, interfaces, or devices not made, supplied, or specified by Trimble; (ii) the operation of the Product under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized installation, modification, or use of the Product; (iv) damage caused by: accident, lightning or other electrical discharge, fresh or salt water immersion or spray (outside of Product specifications); or exposure to environmental conditions for which the Product is not intended; (v) normal wear and tear on consumable parts (e.g., batteries); or (vi) cosmetic damage. Trimble does not warrant or guarantee the results obtained through the use of the Product or Software, or that software components will operate error free. NOTICE REGARDING PRODUCTS EQUIPPED WITH TECHNOLOGY CAPABLE OF TRACKING SATELLITE SIGNALS FROM SATELLITE BASED AUGMENTATION SYSTEMS (SBAS) (WAAS/EGNOS, AND MSAS), OMNISTAR, GPS, MODERNIZED GPS OR GLONASS SATELLITES, OR FROM IALA BEACON SOURCES:TRIMBLE IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF ANY SATELLITE BASED POSITIONING SYSTEM OR THE AVAILABILITY OF ANY SATELLITE BASED POSITIONING SIGNALS. THE FOREGOING LIMITED WARRANTY TERMS STATE TRIMBLE’S ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATING TO THE TRIMBLE PRODUCT. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE PRODUCT, AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND, BY EITHER TRIMBLE OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, INSTALLATION, OR DISTRIBUTION, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF TRIMBLE ARISING OUT OF, OR IN CONNECTION WITH, ANY PRODUCT. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. Limitation of Liability TRIMBLE'S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN S…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 December 16, 2010 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Sporton International Inc. December 16, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _Sporton International Inc._hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: PDA Model name: Juno SA We affirm that between SIEMIC and __Sporton Internationl Inc.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Roy Wu Contact information / address: No.52, HwaYa 1st Rd., Kwei-Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C.

Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 1 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 1. External Photograph of EUT Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 2 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 720510 Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 3 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 List of Accessory: Specification of Accessory USB Cable Signal Line Type 1.1 meter shielded cable with ferrite core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 4 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 720510

Note: 1. Material: Polyester (#75) 2. The Manufacturing process of handling of this material may require special health and/or safety precaution. 3. The adhesive base should be acrylic. coating thickness:0.022mm 4. The material color (background color): Silver, The printing color (words color): Black. 5. According to Official journal of EU releases RoHS (2002/95/CE). Abate/ Reduce Hazardous Substance in Components 1 ABCDEFG 2 3 4 5 1 2 3 4 5 RANGE A( ) B( ) C( ) EXTRA 0 - 10 ±0.05 ±0.1 ±0.2 10 -50 ±0.10 ±0.15 ±0.5 50 -100 ±0.15 ±0.2 ±1.0 100 - ±0.2 ±0.25 ±2.0 DIMENSION TOLERANCE HOLE : ±0.05 ANGLES : ±0.5° DESCRIPTION Label,Device,PET,42.5*64*t0.2,WWE,TN600 ZONEREVDATE MODELTN600 Polyester (#75)Chris Huang 610-00014-00A M74-GOT01-082 Chris Huang MATERIAL SCALE UNITS Q'TY DESIGNER CHECKER APP'D ABO PN GT PN NOTE mm 1:1 WWEv0520101201 √ Fonts are 6.5P Fonts are 4.7P/ Vertical 90% TTTTTYYWWXXXXX (D)(C)(B)(A) S/N Barcode: total is 14 numbers，code128 (A) TTTTT: Customer’s P/N last 5 No.，Juno SA: 66430-00 → 43000 (B) YY: Year, ext: 2008→08, 2009→09........... . (C) WW: Manufacture week. (D) Serial No.: From 00001~99999 TTTTTYYWWXXXXX S/N: 10 2200 Model No. : Juno SA Part No. : 66430-00 FCC ID : JUP66430 Input : DC 5V 2.6A (2600mA) TN 600 Device Label - WWE 42.5 mm R1 64 mm 10 mm 39.5 mm Made in Taiwan This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. N324

FCC ID:JUP66430 Label Location The Battery and PDA are packed separated in the box, when user is taking the PDA, the FCC ID label will be visible. Rear side of EUT FCC Label Battery compartment

Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 5 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 3. Internal Photograph of EUT Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 6 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 7 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 8 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 Photographs of EUT Report No.: EP8O1703-03 Brand Name: Trimble / Model Name: Juno SA SPORTON INTERNATIONAL INC. Page Number : 9 of 9 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 720510 GPS Antenna (Rx Only)

SPORTON INTERNATIONAL INC. Page Number : 1 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 FCC Test Report APPLICANT : Trimble Navigation Ltd. EQUIPMENT : PDA BRAND NAME : Trimble MODEL NAME : Juno SA FCC ID : JUP66430 STANDARD : FCC 47 CFR FCC Part 15 Subpart B CLASSIFICATION : Certification The product was received on Nov. 19, 2010 and completely tested on Dec. 01, 2010. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.4-2003 and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Anderson Chiu / Deputy Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1. GENERAL DESCRIPTION .......................................................................................................................... 5 1.1. Applicant ............................................................................................................................................ 5 1.2. Manufacturer ..................................................................................................................................... 5 1.3. Feature of Equipment Under Test ..................................................................................................... 5 1.4. Test Site ............................................................................................................................................ 6 1.5. Applied Standards ............................................................................................................................. 6 1.6. Ancillary Equipment List .................................................................................................................... 6 2. TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1. Test Mode ......................................................................................................................................... 7 2.2. Connection Diagram of Test System ................................................................................................ 8 2.3. Test Software .................................................................................................................................... 8 3. TEST RESULT ............................................................................................................................................. 9 3.1. Test of AC Conducted Emission Measurement ................................................................................ 9 3.2. Test of Radiated Emission Measurement ....................................................................................... 13 4. LIST OF MEASURING EQUIPMENT ........................................................................................................ 17 5. UNCERTAINTY OF EVALUATION ........................................................................................................... 18 APPENDIX A. PHOTOGRAPHS OF EUT APPENDIX B. SETUP PHOTOGRAPHS SPORTON INTERNATIONAL INC. Page Number : 3 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FC8O1703-03 Rev. 01 Initial issue of report Dec. 06, 2010 SPORTON INTERNATIONAL INC. Page Number : 4 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 SUMMARY OF TEST RESULT Report Section FCC Rule IC Rule Description Limit Result Remark 3.1 15.107 7.2.2 AC Conducted Emission < 15.107 limits < RSS-Gen table 2 limits PASS Under limit 7.4 dB at 0.422 MHz 3.2 15.109 7.2.3.2 Radiated Emission < 15.109 limits or < RSS-Gen table 1 limits (Section 6) PASS Under limit 3.46 dB at 300.00 MHz SPORTON INTERNATIONAL INC. Page Number : 5 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 1. General Description 1.1. Applicant Trimble Navigation Ltd. No. 935, Stewart Drive, Sunnyvale, CA94088-3642, U.S.A. 1.2. Manufacturer GOLDTEK Technology Co., Ltd. 3F., No. 3, Ln. 768, Sec. 4, Pateh Rd., Taipei 115, Taiwan, R.O.C. 1.3. Feature of Equipment Under Test Product Feature & Specification Equipment PDA Brand Name Trimble Model Name Juno SA FCC ID JUP66430 Rx Frequency Range 1.57542 GHz Antenna Type Fixed Internal Antenna HW Version 1.0 SW Version 1.0 Type of Modulation BPSK EUT Stage Production Unit Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. SPORTON INTERNATIONAL INC. Page Number : 6 of 19 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 1.4. Test Site Test Site SPORTON INTERNAT…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : B1 of B2 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 Appendix B. Setup Photographs <Conducted Emission> SPORTON INTERNATIONAL INC. Page Number : B2 of B2 TEL : 886-3-327-3456 Report Issued Date : Dec. 06, 2010 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : JUP66430 FCC Test Report Report No. : FC8O1703-03 <Radiated Emission>
