JUP98850TRIMBLE PRO SERIES RECEIVER

Version 1.00 Revision A March 2012 F USER GUIDE Trimble ® Pro Series Receivers Safety Introduction Parts of the receiver Charging the battery Turning on and turning off the receiver Connecting to a field computer Deactivating and reactivating the Bluetooth radio Additional receiver options Using the receiver with a backpack or range pole Caring for and storing the receiver 2 Pro Series Receivers User Guide Trimble Navigation Limited 10355 Westmoor Drive Suite #100 Westminster, CO 80021 USA www.trimble.com Legal Notices Copyright and Trademarks © 2012, Trimble Navigation Limited. All rights reserved. Trimble and the Globe and Triangle logo are trademarks of Trimble Navigation Limited, registered in the United States and in other countries. Floodlight, Tempest, and Tornado are trademarks of Trimbl e Nav i gation Limit ed . All other trademarks are the property of their respective owners. Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Trimble Navigation Limited is under license. Release Notice This is the March 2012 release (Revision A) of the Trimble Pro Series Receivers User Guide. It applies to version 1.00 of the Trimble Pro series receiver (Pro 6H and Pro 6T receivers), model / 型号: 98850. Limited Warranty Terms and Conditions Product Limited Warranty Subject to the terms and conditions set forth herein, Trimble Navigation Limited (“Trimble”) warrants that for a period of (1) year from date of purchase this Trimble product (the “Product”) will substantially conform to Trimble's publicly available specifications for the Product and that the hardware and any storage media components of the Product will be substantially free from defects in materials and workmanship. Product Software Product software, whether built into hardware circuitry as firmware, provided as a standalone computer software product, embedded in flash memory, or stored on magnetic or other media, is licensed solely for use with or as an integral part of the Product and is not sold. The terms of the end user license agreement, as included below, govern the use of the Product Software, including any differing limited warranty terms, exclusions and limitations, which shall control over the terms and conditions set forth in the limited Product warranty. Warranty Remedies If the Trimble Product fails during the warranty period for reasons covered by this limited warranty and you notify Trimble of such failure during the warranty period, Trimble will repair OR replace the nonconforming Product with new, equivalent to new, or reconditioned parts or Product, OR refund the Product purchase price paid by you, at Trimble’s option, upon your return of the Product in accordance with Trimble's product return procedures then in effect. How to Obtain Warranty Service To obtain warranty service for the Product, please contact your Trimble dealer. Alternatively, you may contact Trimble to request warranty service at +1-408-481-6940 (24 hours a day) or email your request to [email protected]. Please be prepared to provide: – your name, address, and telephone numbers; – proof of purchase; – a copy of this Trimble warranty – a description of the nonconforming Product including the model number; and – an explanation of the problem. The customer service representative may need additional information from you depending on the nature of the problem. Warranty Exclusions and Disclaimer This Product limited warranty shall only apply in the event and to the extent that (i) the Product is properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's applicable operator's manual and specifications, and; (ii) the Product is not modified or misused. This Product limited warranty shall not apply to, and Trimble shall not be responsible for, defects or performance problems resulting from (i) the combination or utilization of the Product with hardware or software products, information, data, systems, interfaces, or devices not made, supplied, or specified by Trimble; (ii) the operation of the Product under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized installation, modification, or use of the Product; (iv) damage caused by: accident, lightning or other electrical discharge, fresh or salt water immersion or spray (outside of Product specifications); or exposure to environmental conditions for which the Product is not intended; (v) normal wear and tear on consumable parts (e.g., batteries); or (vi) cosmetic damage. Trimble does not warrant or guarantee the results obtained through the use of the Product or Software, or that software components will operate error free. NOTICE REGARDING PRODUCTS EQUIPPED WITH TECHNOLOGY CAPABLE OF TRACKING SATELLITE SIGNALS FROM SATELLITE BASED AUGMENTATION SYSTEMS (SBAS) (WAAS, EGNOS, AND MSAS), OMNISTAR, GPS, MODERNIZED GPS OR GLONASS SATELLITES, OR FROM IALA BEACON SOURCES:TRIMBLE IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF ANY SATELLITE BASED POSITIONING SYSTEM OR THE AVAILABILITY OF ANY SATELLITE BASED POSITIONING SIGNALS. THE FOREGOING LIMITED WARRANTY TERMS STATE TRIMBLE’S ENTIRE LIABILITY, AND YOUR EXCLUSIVE REMEDIES, RELATING TO THE TRIMBLE PRODUCT. EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE PRODUCT, AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND, BY EITHER TRIMBLE OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION, INSTALLATION, OR DISTRIBUTION, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITI…

Text truncated - open the document above for the full version.

Battery CAUTION: Please read the full user manual including all safety warnings, before operating this product. Trimble ® Pro series receiver (Model / 型号: 98850) ©2012. Trimble Navigation Limited. All rights reserved. This product is protected by US and international copyright, trademark, and patent law as described in "Legal Notices" in the Trimble Pro Series User Guide. PN 98845-00-ENG, Revision A (02/2012) Trimble Navigation Limited 10355 Westmoor Drive Suite #100 Westminster, CO 80021 USA www.trimble.com 98845-00-ENG Antenna Pole Mounting Trimble Support S U P P O R T T R I M B L E http://www.trimble.com/locator/locator.aspx Trimble Pro SerieS receiver Quick STarT Guide 41 PDF *98845-00* 1 2 5 h Trimble Pro SerieS receiver On/Off USB RS-232 Bluetooth 23 PDF ? PDF ? PDF ? Pro###...

Trimble Navigation Limited 935 Stewart Drive Sunnyvale, California 94085 +1 408 481 8000 Phone +1 408-481-6885 Fax Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 10 th February 2012 Re: Permanent Confidentiality Request for FCC ID: JUP98850 Certification Application Dear FCC Examiner, Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Trimble Navigation Limited requests that the following information accompanying this application be held permanently confidential: 1) Block Diagram Block-Diagram_98850 2) All Schematics 3) Parts List BOM 98800-01 4) Operational Description The above exhibits contain Trimble Navigation Ltd trade secrets and proprietary information that could be of benefit to competitors regarding the design of the device. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Bruce Maule GIS Data Collection Division - Compliance Company: Trimble Navigation Limited Address: 935 Stewart Drive, Sunnyvale California, CA 94085 Phone: +1 (408) 481-8000 Fax: +1 (408) 481-7781 Email: [email protected]

Trimble Navigation Limited 935 Stewart Drive Sunnyvale, California 94085 +1 408 481 8000 Phone +1 408-481-6885 Fax Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 10 th February 2012 Re: Temporary Confidentiality Request for FCC ID: JUP98850 Certification Application Dear FCC Examiner, Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Trimble Navigation Limited requests that the following information accompanying this application be held temporarily confidential for 45 days from the date of the Grant of Equipment Authorization : 1) External Photos 2) Internal Photos 3) Users Manual 4) Test Setup Photos The above exhibits contain technical information that Trimble Navigation Limited deems to be trade secrets and proprietary. If made public, the information could be used to the benefit of competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Bruce Maule GIS Data Collection Division - Compliance Company: Trimble Navigation Limited Address: 935 Stewart Drive, Sunnyvale California, CA 94085 Phone: +1 (408) 481-8000 Fax: +1 (408) 481-7781 Email: [email protected]

Project #: EMC_Trimb_083_1101_Photos_External FCC ID: JUP98850 Date: 2012-03-14 IC ID: 1756A-98850 EUT Rear EUT Top Project #: EMC_Trimb_083_1101_Photos_External FCC ID: JUP98850 Date: 2012-03-14 IC ID: 1756A-98850 EUT Front EUT Bottom Project #: EMC_Trimb_083_1101_Photos_External FCC ID: JUP98850 Date: 2012-03-14 IC ID: 1756A-98850 EUT Battery Top EUT Battery Front Project #: EMC_Trimb_083_1101_Photos_External FCC ID: JUP98850 Date: 2012-03-14 IC ID: 1756A-98850 EUT Battery Side EUT Battery Bottom

B 98822-01 LBL, Vanguard Compliance NOTES: 1). Material: 0.20mm Lexan (No surface texture). 2). Adhesive: Nitto 500 or 3M equivalent. 3). Colours: White symbols on Black background. 4). Overall dimensions: 85.52mm x 41.40mm ± 0.20mm. 5). Completed label must comply with EU directive 2002/95/EC (RoHS, Restriction of Hazardous Substances) 6). Packaging to be labeled with Part number, Revision and Quantity. 墨西哥组装 ASSEMBLED IN MEXICO Trimble Navigation Limited Rating / 输入: 15V 1A OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, & (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. CMIIT ID: 2012DJ0945 Bluetooth QD ID B016326 IC: 1756A-98850FCC ID JUP98850 KCC-CMM-TNZ-98850 202WWSM11569471 R T D 11-0025 202 0682 10 ML05 N324 PLACE BARCODED SERIAL NUMBER LABEL HERE PN: 98800-01 GPS Pathfinder Pro Series ® 系列 Model / 型号: 98850 16NOV11AGILE PRODUCTION RELEASEA C51071 16NOV11DESIGN UPDATES02 01NOV11INITIAL DESIGN01 C53939 BADD “FCC” AND “SRRC” INFORMATION23MAR12 22JUL11Paul Taylor Title Drawing NumberRevision Drawn ByDate Approved ByDate Trimble Navigation Limited Proprietry & Confidential ECNREVDATE APPROVED DESCRIPTION L UNCONTROLLED COPY DRAFT ONLY, MUST NOT BE USED FOR PRODUCTION

Images for: Model 98850 FCC ID JUP98850 IC: 1756A-98850 Note: This product shares the same main board with another similar product. Hence some items shown in the images are not utilised in this product because the Model 98850 does not support the attendant functionality, eg. the only radio transceiver technology supported is Bluetooth. Main Board top (with Shields) Main Board reverse (with Shields) Main Board top (no Shields) Main Board reverse (no Shields) User Interface (UI) board top User Interface (UI) board reverse Low Noise Amplifier (LNA) board top Low Noise Amplifier (LNA) board reverse (with Shield) Low Noise Amplifier (LNA) board reverse (no Shield) Keypad, Serial Port and Sensor Boards top Keypad, Serial Port and Sensor Boards reverse

RF Exposure Evaluation Report FOR: Model Number: 98850 Trimble Pro Series Receivers with high-performance GNSS integrated antenna and receiver, user-removable battery, and Bluetooth® wireless technology for connectivity with field computers. FCC ID: JUP98850 IC ID: 1756A-98850 References: 1. FCC OET Bulletin 65 Supplement C 2. FCC CFR Part 2 3. RSS-102- Radio Frequency Exposure Compliance of Radiocommunication Apparatus Issue 4 March 2010 Test Report #: EMC_TRIMB_083_11001_MPE FCC ID: JUP98850 Date of Report : 2012-03-14 IC ID: 1756A-98850 Feb 2012. Rev 1.0 Page 2 of 8 1 Administrative Data 1.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Address: 411 Dixon Landing Road Milpitas, CA 95035 U.S.A. Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Test Lab Director: Heiko Strehlow Responsible Project Leader: Sajay Jose 1.2 Identification of the Client Applicant’s Name: Trimble Navigation New Zealand Street Address: 11 Birmingham Drive P.O. Box 8729 City/Zip Code Christchurch Country New Zealand Contact Person: Bruce Maule Phone No. +64 3.963.5628 Fax: +1 408.481.6885 e-mail: [email protected] 1.3 Identification of the Manufacturer Same as above. Test Report #: EMC_TRIMB_083_11001_MPE FCC ID: JUP98850 Date of Report : 2012-03-14 IC ID: 1756A-98850 Feb 2012. Rev 1.0 Page 3 of 8 2 Equipment under Test (EUT) 2.1 Specification of the Equipment under Test Model No: 98850 HW Revision/ SW Revision: 98850-XX / 98850-0X 00, [Build 1.0.X] FCC-ID/ IC-ID: JUP98850 / 1756A-98850 Product Description: Trimble Pro Series Receivers with high-performance GNSS integrated antenna and receiver, user-removable battery, and Bluetooth® wireless technology for connectivity with field computers. Frequency Range: Bluetooth: 2402 - 2480 MHz Antenna Type and Gain: (As stated by manufacturer) Reported Antenna gain at: 2402 MHz: 0.7dBi 2441 MHz: 1.7dBi 2481 MHz: 0.7dBi Co-located Transmitters/ Antennas? No Power supply: Rechargeable Lithium Ion Battery: 11.1VDC, 2.5Ah Operating temperature range: -20 ̊C to +60 ̊C Prototype / Production unit: Production Device Category:  Fixed Installation  Mobile  Portable Exposure Category:  Occupational/ Controlled General Population/ Uncontrolled Test Report #: EMC_TRIMB_083_11001_MPE FCC ID: JUP98850 Date of Report : 2012-03-14 IC ID: 1756A-98850 Feb 2012. Rev 1.0 Page 4 of 8 3 Assessment This report serves as the Technical Information regarding RF Exposure evaluation against the requirements in 47 CFR 2.1091and as the RF Exposure Technical Brief according to RSS-102 Ch. 2.2. The following device has been evaluated and meets/is exempt from the RF Exposure Limits defined in 47 CFR 1.310 and RSS-102 Issue 4 Ch. 4. Company Description Model # Trimble Navigation Trimble Pro Series Receivers with high- performance GNSS integrated antenna and receiver, user-removable battery, and Bluetooth® wireless technology for connectivity with field computers. 98850 2012-03-14 Compliance Tunji Yusuf (EMC Engineer) Date Section Name Signature Test Report #: EMC_TRIMB_083_11001_MPE FCC ID: JUP98850 Date of Report : 2012-03-14 IC ID: 1756A-98850 Feb 2012. Rev 1.0 Page 5 of 8 4 RF Exposure Evaluation Requirements 4.1 FCC: Calculations can be made to predict RF field strength and power density levels around typical RF sources using the general equations (3) and (4) on page 19 of the following FCC document: “OET Bulletin 65, Edition 97-01 - Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields”. The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100.000 1.0 30 Using the equation from page 19 of OET Bulletin 65, Edition 97-01: 2 4R PG S   where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Note: 1. This device is to be used only for fixed and mobile applications. 2. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Additionally, according to § 2.1091: The limit for <1.5 GHz mobile operations where no routine evaluation is required is: 1.5W ERP The limit for >1.5 GHz mobile operations where no routine evaluation is required is: 3W ERP 4.2 IC: RSS-102 Section 2.5.2 RF exposure evaluation is required if the separation distance between the user and the device's radiating element is greater than 20 cm, except when the device operates as follows:  below 1.5 GHz and the maximum EIRP of the device is equal to or less than 2.5 W;  at or above 1.5 GHz and the maximum EIRP of the device is equal to or less than 5 W. RSS-102 4.2: RF Field strength limits for devices used by the General Public (Uncontrolled Environment): Power density 300MHz- 1500 MHz= f/150 W/m 2 1500 MHz- 1500000 MHz= 10 W/m 2 Test Report #: EMC_TRIMB_083_11001_MPE FCC ID: JUP98850 Date of Report : 2012-03-14 IC ID: 1756A-98850 Feb 2012. Rev 1.0 Page 6 of 8 5 Measurement procedure: 5.1 Radiated power measurement- ERP/EIRP- 1. Connect the equipment as shown in the above diagram with the EUT’s antenna in center of the turn table. 2. Adjust the settings of the Digital Radio Communication Tester (DRT) to set the EUT to its maximum power at the required channel. 3. Set the spectrum analyzer to the channel frequency. Set the analyzer to measure peak hold with the required settings. 4. Rotate the EUT 360. Record the peak level in dBm (LVL). 5. Replace the EUT with a vertically polarized …
