JUPCCKCDPD46707-00 Crosscheck CDPD

 Part Number 46750-00-ENG PRELIMINARY - Revision A January 2002 CrossCheck ® CDPD Mobile Unit Manual Corporate Office Trimble Navigation Limited 645 North Mary Avenue Post Office Box 3642 Sunnyvale, CA 94088-3642 U.S.A. Phone: +1-408-481-8940, 1-800-545-7762 www.trimble.com Copyright and Trademarks © 1997–2002, Trimble Navigation Limited. All rights reserved. Printed in the United States of America. Printed on recycled paper. The Globe & Triangle, Trimble, Colossus, Echo LDX , and FirstGPS are trademarks of Trimble Navigation Limited. The Sextant logo with Trimble and CrossCheck are trademarks of Trimble Navigation Limited, registered in the United States Patent and Trademark Office. All other trademarks are the property of their respective owners. Release Notice This is January 2002 release (PRELIMINARY - Revision A) of the CrossCheck ® CDPD Mobile Unit Manual , Part Number 46750-00-ENG. Use this manual with the Echo LDX Message Terminal for CrossCheck CDPD and CrossCheck GPRS Installation and User’s Manual , Trimble part number 46667-00-ENG. The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction.The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction. Hardware Limited Warranty Trimble warrants that this Trimble hardware product (the “Product”) shall be free from defects in materials and workmanship and will substantially conform to Trimble’s applicable published specifications for the Product for a period of one (1) year, starting from the date of delivery. The warranty set forth in this paragraph shall not apply to software/firmware products. Software and Firmware License, Limited Warranty This Trimble software and/or firmware product (the “Software”) is licensed and not sold. Its use is governed by the provisions of the applicable End User License Agreement (“EULA”), if any, included with the Software. In the absence of a separate EULA included with the Software providing different limited warranty terms, exclusions, and limitations, the following terms and conditions shall apply. Trimble warrants that this Trimble Software product will substantially conform to Trimble’s applicable published specifications for the Software for a period of ninety (90) days, starting from the date of delivery. Warranty Remedies Trimble's sole liability and your exclusive remedy under the warranties set forth above shall be, at Trimble’s option, to repair or replace any Product or Software that fails to conform to such warranty (“Nonconforming Product”), or refund the purchase price paid by you for any such Nonconforming Product, upon your return of any Nonconforming Product to Trimble in accordance with Trimble’s standard return material authorization procedures. Warranty Exclusions and Disclaimer These warranties shall be applied only in the event and to the extent that: (i) the Products and Software are properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's relevant operator's manual and specifications, and; (ii) the Products and Software are not modified or misused. The preceding warranties shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product or Software with products, information, data, systems or devices not made, supplied or specified by Trimble; (ii) the operation of the Product or Software under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized modification or use of the Product or Software; (iv) damage caused by accident, lightning or other electrical discharge, fresh or salt water immersion or spray; or (v) normal wear and tear on consumable parts (e.g., batteries). T HE WARRANTIES ABOVE STATE T RIMBLE ' S ENTIRE LIABILITY , AND YOUR EXCLUSIVE REMEDIES , RELATING TO PERFORMANCE OF THE PRODUCTS AND SOFTWARE . EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN , THE PRODUCTS , SOFTWARE , AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “ AS - IS ” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION , PRODUCTION , INSTALLATION , OR DISTRIBUTION INCLUDING , BUT NOT LIMITED TO , THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE , TITLE , AND NONINFRINGEMENT . THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF T RIMBLE ARISING OUT OF , OR IN CONNECTION WITH , ANY PRODUCTS OR SOFTWARE . SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY , SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU . TRIMBLE NAVIGATION LIMITED IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF GPS SATELLITES OR THE AVAILABILITY OF GPS SATELLITE SIGNALS. Limitation of Liability T RIMBLE ’ S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SHALL BE LIMITED TO THE GREATER OF THE AMOUNT PAID BY YOU FOR THE PRODUCT OR SOFTWARE LICENSE OR U.S.$25.00. T O THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW , IN NO EVENT SHALL TRIMBLE OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT , SPECIAL , INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING IN ANY WAY TO THE PRODUCTS , SOFTWARE AND ACCOMPANYING DOCUMENTATION AND MATERIALS , ( INCLUDING , WITHOUT LIMITATION , DAMAGES FOR LOSS OF BUSINESS PROFITS , BUSINESS INTERRUPTION , LOSS OF BUSINESS INFORMATION , OR ANY OTHER PECUNIARY LOSS ), REGARDLESS WHETHER TRIMBLE HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE COURSE OF DEALING WHICH DEVELOPS OR HAS DEVELOPED BETWEEN YOU AND TRIMBLE . B ECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCID…

Text truncated - open the document above for the full version.

F Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Trimble Navigation LTD. would like the following documents regarding this submission for FCC ID: JUPCCKCDPD to be kept confidential. 1. Document titled “Confidential schematic 39661 pg 1 of 4.pdf” 2. Document titled “Confidential schematic 39661 pg 2 of 4.pdf” 3. Document titled “Confidential schematic 39661 pg 3 of 4.pdf” 4. Document titled “Confidential schematic 39661 pg 4 of 4.pdf” 5. Document titled “Confidential schematic 46401 pg 1 of 1.pdf” 6. Document titled “Confidential CrossCheck CDPD Block Diagram.pdf” 7. Document titled “Confidential description of equipment.pdf” The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Jorge Heraud Engineering Manager

F Label is placed in the bottom of CrossCheck CDPD as shown

F Sample FCC ID label CrossCheck CDPD. Material: 0.002” white mylar base with 0.001” 3M 467 or equivalent adhesive Dimensions: 3.10” x 2.25” 1.5” 0.45” 2.25” 3.1”

Page 1 of 22 Report No.: FC02-004 TRIMBLE NAVIGATION LTD. TEST REPORT FOR THE 46707-00 CROSSCHECK CDPD FCC PART 15 SUBPART B SECTION 15.109 CLASS B COMPLIANCE DATE OF ISSUE: JANUARY 3, 2002 PREPARED FOR: Trimble Navigation Ltd. 485 Potrero Ave., B1 Sunnyvale, CA 94086 PREPARED BY: Joyce Walker CKC Laboratories, Inc. 5473A Clouds Rest Mariposa, CA 95338 P.O. No.: E2N104243 W.O. No.: 78104 Date of test: December 18, 2001 Report No.: FC02-004 This report contains a total of 22 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Page 2 of 22 Report No.: FC02-004 TABLE OF CONTENTS Administrative Information ............................................................................................. 3 Summary of Results......................................................................................................... 4 Required EUT Changes To Comply................................................................................ 4 Approvals......................................................................................................................... 4 Equipment Under Test (EUT) Description...................................................................... 5 Equipment Under Test..................................................................................................... 5 Peripheral Devices ........................................................................................................... 5 Specifications and Requirements..................................................................................... 6 Report of Measurements.................................................................................................. 7 Table 1: Six Highest Radiated Emission Levels ................................................. 7 Measurement Uncertainty................................................................................................ 8 Testing ............................................................................................................................. 8 Emissions......................................................................................................................... 8 Correction Factors ............................................................................................... 9 Table A: Sample Calculations ................................................................. 9 Test Instrumentation and Analyzer Settings........................................................ 9 Table B: Analyzer Bandwidth Settings Per Frequency Range................ 9 Spectrum Analyzer Detector Functions............................................................... 10 Peak ......................................................................................................... 10 Quasi-Peak............................................................................................... 10 Average.................................................................................................... 10 Radiated Emissions ............................................................................................. 11 Appendix A: Information About The Equipment Under Test......................................... 12 I/O Ports............................................................................................................... 13 Crystal Oscillators ............................................................................................... 13 Printed Circuit Boards ......................................................................................... 13 Cable Information................................................................................................ 14 Test Connection Diagram .................................................................................... 16 Photograph Showing Radiated Emissions ........................................................... 17 Photograph Showing Radiated Emissions ........................................................... 18 Appendix B: Test Equipment List ................................................................................... 19 Appendix C: Measurement Data Sheets .......................................................................... 20 Page 3 of 22 Report No.: FC02-004 CKC Laboratories, Inc. has received Certificates of Accreditation from the following agencies: A2LA (USA); DATech (Germany); BSMI (Taiwan); Nemko (Norway); and GOST (Russia). CKC Laboratories, Inc has received test site Registration Acceptance from the following agencies: FCC (USA); VCCI (Japan); and Industry Canada. CKC Laboratories, Inc. has received Letters of Acceptance through an MRA for the following agencies: ACA/NATA (Australia); SABS (South Africa); SWEDAC (Sweden); Radio Communications Agency (RA); HOKLAS (Hong Kong); Bakom (Swiss); BIPT (Belgium); Denmark Telestyrelsen; RvA (Netherlands); SEE (Luxembourg) SITTEL (Bolivia); and UKAS (UK). ADMINISTRATIVE INFORMATION DATE OF TEST: December 18, 2001 DATE OF RECEIPT: December 18, 2001 PURPOSE OF TEST: To demonstrate the compliance of the 46707-00 CrossCheck CDPD with the requirements for FCC Part 15 Subpart B Section 15.109 Class B devices. TEST METHOD: ANSI C63.4 (1992) FREQUENCY RANGE TESTED: 30 - 1000 MHz MANUFACTURER: Trimble Navigation Ltd. 485 Potrero Ave., B1 Sunnyvale, CA 94086 REPRESENTATIVE: Jorge Heraud TEST LOCATION: CKC Laboratories, Inc. 480 Los Viboras Road Hollister, CA 95023 Page 4 of 22 Report No.: FC02-004 SUMMARY OF RESULTS As received, the Trimble Navigation Ltd. 46707-00 CrossCheck CDPD was found to be fully compliant with the following standards and specifications: United States ! FCC Part 15 Subpart B Section 15.109 Class B ! ANSI C63.4 (1992) method Canada ICES-003 Class B using: ! ANSI C63.4 (1992) method Industry of Canada File No. IC 3171-D The results in this report apply only to the items tested, as identified herein. REQUIRED EUT CHANG…

Text truncated - open the document above for the full version.

PHOTOGRAPH SHOWING RADIATED EMISSIONS Radiated Emissions - Front View PHOTOGRAPH SHOWING RADIATED EMISSIONS Radiated Emissions - Back View
