JUPCCKGPRS19Resource Management System

F Part Number 47770-00-ENG Revision A August 2002 CrossCheck ® GPRS 1900 Installation Manual Corporate Office Trimble Navigation Limited 645 North Mary Avenue Post Office Box 3642 Sunnyvale, CA 94088-3642 U.S.A. Phone: 1-408-481-8940, 1-800-545-7762 www.trimble.com Copyright and Trademarks © 1997–2002, Trimble Navigation Limited. All rights reserved. Printed in the United States of America. Printed on recycled paper. The Globe & Triangle, Trimble, Colossus, EchoLDX, FirstGPS, IQEventEngine, and Telvisant are trademarks of Trimble Navigation Limited. The Sextant logo with Trimble and CrossCheck are trademarks of Trimble Navigation Limited, registered in the United States Patent and Trademark Office. All other trademarks are the property of their respective owners. Release Notice This is August 2002 release (Revision A) of the CrossCheck® GPRS 1900 Installation Manual, Part Number 47770-00-ENG. Use this manual with the EchoLDX Message Terminal Installation and User’s Manual, Trimble part number 46667- 00-ENG. The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction.The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction. Hardware Limited Warranty Trimble Navigation Limited products are warranted against defects in material and workmanship for a period of one year. The warranty period shall commence thirty (30) days after shipment from Trimble's factory. Warranty service will be provided at a designated Trimble Service Center. Trimble at its option will replace or repair products that prove to be defective. Customer shall pay all shipping charges for products returned to Trimble for warranty service. Trimble will not be responsible for uninstall and install cost charges. Trimble shall pay all shipping charges for return of products to the Customer. The above warranty shall not apply to defects resulting from: 1. Improper or inadequate maintenance by the buyer 2. Buyer-supplied software or interfacing 3. Unauthorized modifications or misuse 4. Operation outside of the environmental specifications of the product 5. Improper installation, where applicable 6. Lightning or other electrical discharge 7. Fresh or salt water immersion or spray 8. Normal wear and tear on consumable parts (for example cables, mounting hardware, antennas fuses, batteries) No other warranty is expressed or implied. Trimble Navigation Limited specifically disclaims the implied warranties of fitness for a particular purpose and merchantability. Software and Firmware License, Limited Warranty This Trimble software and/or firmware product (the “Software”) is licensed and not sold. Its use is governed by the provisions of the applicable End User License Agreement (“EULA”), if any, included with the Software. In the absence of a separate EULA included with the Software providing different limited warranty terms, exclusions, and limitations, the following terms and conditions shall apply. Trimble warrants that this Trimble Software product will substantially conform to Trimble’s applicable published specifications for the Software for a period of ninety (90) days, starting from the date of delivery. Warranty Remedies Trimble's sole liability and your exclusive remedy under the warranties set forth above shall be, at Trimble’s option, to repair or replace any Product or Software that fails to conform to such warranty (“Nonconforming Product”), or refund the purchase price paid by you for any such Nonconforming Product, upon your return of any Nonconforming Product to Trimble in accordance with Trimble’s standard return material authorization procedures. Warranty Exclusions and Disclaimer These warranties shall be applied only in the event and to the extent that: (i) the Products and Software are properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Trimble's relevant operator's manual and specifications, and; (ii) the Products and Software are not modified or misused. The preceding warranties shall not apply to, and Trimble shall not be responsible for defects or performance problems resulting from (i) the combination or utilization of the Product or Software with products, information, data, systems or devices not made, supplied or specified by Trimble; (ii) the operation of the Product or Software under any specification other than, or in addition to, Trimble's standard specifications for its products; (iii) the unauthorized modification or use of the Product or Software; (iv) damage caused by accident, lightning or other electrical discharge, fresh or salt water immersion or spray; or (v) normal wear and tear on consumable parts (e.g., batteries). T HE WARRANTIES ABOVE STATE T RIMBLE ' S ENTIRE LIABILITY , AND YOUR EXCLUSIVE REMEDIES , RELATING TO PERFORMANCE OF THE PRODUCTS AND SOFTWARE . EXCEPT AS OTHERWISE EXPRESSLY PROVIDED HEREIN , THE PRODUCTS , SOFTWARE , AND ACCOMPANYING DOCUMENTATION AND MATERIALS ARE PROVIDED “ AS - IS ” AND WITHOUT EXPRESS OR IMPLIED WARRANTY OF ANY KIND BY EITHER TRIMBLE NAVIGATION LIMITED OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION , PRODUCTION , INSTALLATION , OR DISTRIBUTION INCLUDING , BUT NOT LIMITED TO , THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE , TITLE , AND NONINFRINGEMENT . THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL OBLIGATIONS OR LIABILITIES ON THE PART OF T RIMBLE ARISING OUT OF , OR IN CONNECTION WITH , ANY PRODUCTS OR SOFTWARE . SOME STATES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION OF AN IMPLIED WARRANTY , SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. TRIMBLE NAVIGATION LIMITED IS NOT RESPONSIBLE FOR THE OPERATION OR FAILURE OF OPERATION OF GPS SATELLITES OR THE AVAILABILITY OF GPS SATELLITE SIGNALS. Limitation of Liability T RIMBLE ’ S ENTIRE LIABILITY UNDER ANY PROVISION HEREIN SH…

Text truncated - open the document above for the full version.

Trimble Navigation 645 North Mary Av., PO Box 3648 Sunnyvale, CA 94088 3642 Jul 19, 2002 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Trimble Navigation LTD. would like the following documents regarding this submission for FCC ID: JUPCCKGPRS19 to be kept confidential. 1. Document titled “Schematics.pdf” 2. Document titled “Block Diagram.pdf” 3. Document titled “Operational description.pdf” The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Jorge Heraud Engineering Manager Trimble Navigation

-ETS- DR. Genz GmbH, GermanyReference number: G0M20207-6900-T-51Annex I, page 1 of 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Annex I: Photos of the EUT -ETS- DR. Genz GmbH, GermanyReference number: G0M20207-6900-T-51Annex I, page 2 of 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH -ETS- DR. Genz GmbH, GermanyReference number: G0M20207-6900-T-51Annex I, page 3 of 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH

-ETS- DR. Genz GmbH, GermanyReference number:G0M20207-6900-T-51Annex I, page 1 of 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Annex I: Photos of the EUT -ETS- DR. Genz GmbH, GermanyReference number:G0M20207-6900-T-51Annex I, page 2 of 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH

LevelPart NumberPart DescriptionRevQtyRef DesSrc CodeLifecycle PhaseItem NbrOp SeqBOM Notes 046122-01+ASSY CHIRON GPRS 19005 139661-20-EBD ASSY CHIRONE51BProduction50 143054-00ASSY CCK GSM TOP COVERA1BProduction150 146268BATTERY LI 560MAHR W CLIPS01PProduction180 146376BOTTOM SHEETMETAL CHIRONA1PPProduction200 147005CBL ASSY BKHD TNC-SL RG188 2.1A1BProduction400 139816CHIP GSM SIM CARRIER01PProduction450 146274MODULE WMO 2C2 900/190001PProduction500 143239INSULATOR WISMO GSMA1BProduction550 140478SPACER CROSSCHECK AMPSB1BProduction600 143032STANDOFF, NYLON PCB 1/4" HIGH01PProduction650 120270STDF M-F 3/16HX 440X3/16ST02FProduction700 117818SCR 4-40X1/4 PHILLIPS TYPE 1A05FProduction750 134696SCR M2.5X18MM PH PL WSHR01FProduction800 110364RTV CLR NON-CORROSIVE GE 12800,01PProduction850 147691LBL REMOVABLE CCK GPRS 1900A1BProduction1000 147692LBL HANDSET CON COVER GPRSA1BProduction1050 146122-XX-CEPH TEST RPT CHIRON GPRS??0Place-Holder95150 146122-XX-TFTEST FIXTR DOC CHIRON GPRS10Engineering95200 146122-XX-TPTEST PROC CHIRON GPRS10Engineering95250 146766-01-MDMSTR DSK TSTR CH GPRS10Engineering95350 146122-01-ADASSY DWG CCK GPRS20Engineering95400 146122-01-CLPH CHG LOG CCK GPRS??0Place-Holder95450 146122-01-DCPH DEC OF CONF CCK GPRS??0Place-Holder95500 146122-XX-SFSPEC FILE TSTR CHIRON GPRS10Engineering95550 147668-10PH FW BOOT XCGPRS VX.XX??0ZPlace-Holder95600

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH TEST - REPORT FCC RULES PART 24 Test report no.: G0M20207-6900-T-47 FCC ELECTRONIC TECHNOLOGY SYSTEMSSTORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBHPHONE +49-33631-888 00 FAX +49-33631-888 66 ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 1 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1General information 1.1Notes 1.2Testing laboratory 1.3Details of approval holder 1.4Application details 1.5Test item 1.6Test standards 2Technical test 2.1Summary of test results 2.2Test environment 2.3Test equipment utilized 3 Test Results 4 RF Power Output, FCC 2.1046 4.1 Test Procedure 4.2 Test Results 5 Radiated Power, FCC 24.232 5.1 Test Procedure 5.2 Test Results 6 Occupied Bandwidth, FCC 2.1049 6.1 Test Procedure 6.2 Test Results 7 Spurious Radiations, FCC 2.1053, 24.238(a) 7.1 Test Procedure 7.2 Test Results 8 Line Conducted Emissions, FCC 15.107 8.1 Test Procedure 8.2 Test Results 9 Frequency Stability vs Temperature, FCC 2.1055, 24.235 9.1 Test Procedure 9.2 Test Results 10 Frequency Stability vs Voltage, FCC 2.1055, 24.235 10.1 Test Procedure 10.2 Test Equipment ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 2 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1General Information 1.1Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Futhermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample posseses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extractes from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 14.08.2002F. Walter DateETS-Lab.NameSignature Technical responsibility for area of testing: 14.08.2002Dr. Genz DateETSNameSignature ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 3 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2Details of accreditation status ACCREDITED TESTING LABORATORY Accredited by: Bundesamt für Post und Telekommunikation (BAPT) DAR-REGISTRATION NUMBER: TTI-P-G 126/96-30 ACCREDITED COMPETENT BODY Accredited by: Bundesamt für Post und Telekommunikation (BAPT) DAR-REGISTRATION NUMBER: BPT-ZE-026/96-00 FCC FILED TEST LABORATORY REG. NO. 96970 Bluetooth Qualification Test Facility (BQTF) Accredited by Bluetooth Qualification Review Board INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 1.3Details of approval holder Name: Trimble Navigation Limited Street: 645 North Mary Avenue Post Office Box 3642 Town: Sunnyvale, CA94088-3642 Country: USA Telephone: 001 408 481 8853 Fax: 001 408 481 2020 Contact: Mr. Jorge Heraud Telephone: 001 408 481 8853 ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 4 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4Application details Date of receipt of application: 15.07.2002 Date of receipt of test item: 15.07.2002 Date of test: 24.06.2002-19.07.2002; 16.08.2002 1.5Test item Description of test item: Mobile Resource Management System Type identification: Crosscheck GPRS 1900 Serial number: Test model without serial number. Photos: See annex Technical data Frequency range: 1850-1910 MHz; 1930-1990 MHz Antenna transmitter: integral (internal antenna) Antenna receiver: integral (internal antenna) Power supply : 12 V DC Operating mode:duplex Type of modulation:TDMA Manufacturer: (if applicable) Name: Street: Town: Country: Additional information: none ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 5 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6Test standards Technical standard : FCC Parts 24 2Technical test 2.1Summary of test results No deviations from the technical specification(s) were ascertained in the course ý of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests ̈ performed. 2.2Test environment Temperature: 23 o C Relative humidity content: 20 ...75 % Air pressure: 86 ...103 kPa Extreme temperature: -10 / 55°C ETS Dr. Genz GmbH, GermanyRegistration number: G0M20207-6900-T-47Page 6 of 22 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 2.3Test equipment utilized No.Measurement device:Type:Manufacturer: ETS 0001Test receiverESHS 10Rohde&Schwarz ETS 0002Test receiverESVPRohde&Schwarz ETS 0003Test receiverESVS 10Rohde&Schwarz ETS 0004Spektrum- and Network-AnalyzerFSMS 26Rohde&Schwarz ETS 0005Test receiverSMV 11MEB ETS 0006Test receiver systemSME 12MEB ETS 0007Spectrum analyzerPSA-65AAvcom ETS 0008AntennaLoop antennaSiemens ETS 0009AntennaLoop antennaMEB ETS 0010AntennaLoop antennaMEB ETS 0011Antennavan Veen/ FrameETS ETS 0012AntennaHK 116Rohde&Schwarz ETS 0013AntennaHL 223Rohde&Schwarz ETS 0014AntennaHL 025Rohde&Schwarz ETS 0015AntennaHL 025Rohde&Schwarz ETS 0016AntennaVHAPSchwarzbeck ETS 0017AntennaVHAPSchwarzbeck ETS 0018AntennaUHAPSchwarzbeck ETS 0019AntennaUHAPSchwarzbeck ETS 0020AntennaDP 21MEB ETS 0021AntennaDP 3MEB ETS 0022AntennaSAS-200/ 521A.H. Systeme / USA ETS 0023AntennaDP 1MEB ETS 0024Antenna mastAF 2MEB ETS 0025Antenna mastAF 2MEB ETS 0026TripodHeinrich Deisel…

Text truncated - open the document above for the full version.
