KENWOOD CORPORATION COMMUNICATION EQUIPMENT DIVISION SCANNING RECEIVER (As PC peripheral) FCC ID : K4428871110 Z02C-98265 October, 1998 ZACTA TECHNOLOGY CORPORATION 4149-7 Hachimanpara 5-chome Yonezawa-shi Yamagata 992-11 Japan TABLE OF CONTENTS CERTIFICATE COMPLIANCE ..................................... 3 TECHNICHAL INFORMATION ..................................... 4 DESCRIPTION FOR TEST SITE ...................................................... 4 FCC PART 15 SUBPART B CERTIFICATION REPORT Z02C-98265 Page 2/18 FCC ID: K4428871110 Zacta Technology Corp. DESCRIPTION OF RADIATED EMISSION TESTING ....................................... 5 DESCRIPTION OF CONDUCTED EMISSION TESTING ...................................... 6 TEST EQUIPMENT ................................................................. 7 SAMPLE OF FIELD STRENGTH CALCULATION ........................................... 9 LABORATORY MEASUREMENTS ................................... 9 JUSTIFICATION / ENGINEERING COMMENT ........................................... 10 SMMURY OF TEST DATA ........................................................... 11 TEST SITE CONDITION ........................................................... 12 INSTRUMENTATION USED .......................................................... 12 CONFIGURATION INFORMATION .................................................... 14 SYSTEM CONFIGURATION .......................................................... 16 Z02C-98265 Page 3/18 FCC ID: K4428871110 Zacta Technology Corp. CERTIFICATE COMPLIANCE ZACTA TECHNOLOGY CORPORATION YONEZAWA TESTING CENTER 4149-7 Hachimanpara 5-chome Yonezawa-shi Yamagata 992-1128 Japan This device was measured pursuant to ANSI C63.4-1992 by Zacta Technology Corporation. The data in this application complies with the applicable technical standards as indicated in the measurements report and FCC Part 15 Class B limits. The EUT complies with section 15.37 βTransition provision for compliance with the rulesβ. APPLICANT : KENWOOD CORPORATION COMMUNICATION EQUIPMENT DIVISION FCC ID : K4428871110 FCC RULE PART : FCC Part 15 Subpart B, Docket 87-389 EQUIPMENT CLASS : Class B EUT TYPE : SCANNING RECEIVER / Peripheral FREQ. RANGE : VHF 118MHz β 173.995MHz UHF 400MHz β 469.995MHz DATE OF TEST : September 9, 14, 1998 MEASUREMENT : ANSI C63.4-1992 TEST RESULT : PASS REPORT NO. : Z02C-98265 REMARKS : No modification was made during testing. EUT is powered from battery Zacta Technology Corporation certifies that no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21U.S.C. 853(a). Authorized by : Shin-ichi Abe General Manager, Zacta Technology Corporation Yonezawa Testing Center The results in this test report apply only to the samples tested. This report shall not be re-product except in full without the written approval of Zacta Technology Corporation. Z02C-98265 Page 4/18 FCC ID: K4428871110 Zacta Technology Corp. TECHNICHAL INFORMATION DESCRIPTION FOR TEST SITE 1. LOCATION: ZACTA TECHNOLOGY CORPORATION YONEZAWA TESTING CENTER 4149-7 Hachimanpara 5-chome, Yonezawa-shi Yamagata 992- 1128 Japan Phone: +81-238-28-2880 Fax: +81-238-28-2888 2. THE NUMBER OF SITE: Total: 4 sites #1 site #2 site #3 site #4 site 3. THE TYPE OF SITE : Weather protected site 4. TEST TYPE : All site could perform as follows tests: 1) 3/10m Radiated emission test 2) Conducted emission test 5. NORMALIZED SITE ATTENUATION GRAPH β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’β’ 6. FACILITY FILING INFORMATION ANSI Site Attenuation SITE3 3m VER` -30.0 -25.0 -20.0 -15.0 -10.0 -5.0 0.0 5.0 10.0 15.0 20.0 30.0 60.0 120.0 175.0 400.0 900.0 FREQUENCY [M H z] SITE ATTENUATI O ANSI Site A ttenuation SITE3 3m HOR` -30.0 -20.0 -10.0 0.0 10.0 20.0 30.0 60.0 120.0 175.0 400.0 900.0 FREQUENCY [M H z] SITE ATTENUATI O Z02C-98265 Page 5/18 FCC ID: K4428871110 Zacta Technology Corp. FCC FINAL SITE FILING: January 29, 1997 (Final date) Β§2.948 Pursuant to ANSI C63.4-1992 #1 site #2 site #3 site β’ #4 site (Final date: June 18, 1998) *3m/10m Radiated emission test & Conducted emission test could be performed on each site VCCI FINAL SITE FILING: April 1, 1997 (Final date) Vβ5/97.04 Pursuant to VCCI Regulations for Registration of measurement facilities #1 site R β 136 C - 132 #2 site R β 137 C - 133 #3 site R β 138 C - 134 #4 site R β 752 C β 775 (Final date: June 23, 1998) NVLAP ACCREDITION : NVLAP CODE: 200306-0 NVLAP INFORMATION NVLAP accreditation does not constitute any product endorsement by NVLAP or any agent of the U.S. Government DESCRIPTION OF RADIATED EMISSION TESTING Measurements: were made at 3 meter using broadband antenna (Biconical Antenna and log-periodic antenna) & Test receiver. Frequency Range : 30MHz β 1GHz was scanned and investigated using receiver. Six highest emissions(Min.) was reported. The test results represents the worst case Z02C-98265 Page 6/18 FCC ID: K4428871110 Zacta Technology Corp. emissions for each emission with manipulating the EUT, support equipment and interconnecting cables maximize the worst emissions in this test report. Condition: The detector function of the test receiver was set to CISPR Quasi-peak mode and the bandwidth was set to 120kHz. Sufficient time for the EUT, support equipment, and test equipment were allowed in order for them to warm up to their normal operating condition. The EUT and support equipment were placed on a top of a 0.8 meter height wooden table. For Floor-Standing devices, the EUT and all cables were installed on electrical insulating material. The antenna height was varied 1 to 4 meters and stopped at height producing the maximum emission. The turntable was rotated by 360 degrees and stopped at azimuth of producing the maximum emission. Interconnecting cables which are connected to a peripheral was bundled in center, and its length was not exceed 1 meter. Each emission was maximized by: varying the mode of operation; clock or data exchange speed; scrolling Hβ¦
Text truncated - open the document above for the full version.
= FCC PARTl5B class B 3m RADIATED DATA SHEET = DATE OF TESTS: 98/09/09 SITE: 3 CHART NO.Sheet NO. 1 COMPANY NAME: KENWOOID MODEL: TH-D7A MODE COMMENT: Without core on PC cable POL. FREQ. READ. FACTOR NET LIMITS MARGIN H/V [MHz] [dBuV] [dB] [dBuV/m] [dBuV/m] [dB] V 40.00 44.5 -l2.3 32.2 40.0 -7.8 H 40.00 47.4 -12.3 35.1 40.0 -4.9 * H 143.95 36.9 -l3.3 23.6 43.5 -l9.9 H 207.92 34.8 -ll.3 23.5 43.5 -20.0 V 375.85 38.5 -ll.7 26.8 46.0 -l9.2 H 383.86 37.3 -ll.6 25_7 46.0 -20.3 V 383.86 43.7 -ll.6 32.1 46.0 -l3.9 V 735.70 30.7 -3.1 27.6 46.0 -l8.4 = FCC PARTl5B class B LINE CONDUCTED DATA SHEET = DATE OF TESTS : 98/09/09 SITE.. 3 CHART NO. SHEET NO. 2 COMPANY NAME : KENWOOD MODEL: TH-D7A MODE: COMMENT: Without core on PC cable FREQ. READ.A READ.B FACTOR NETA NET B LIMITS MARGIN COMMENT [MHz] [dBuV] [dBuV] [dB] [dBuV][dBuV] [dBuV] [dB] 0.523 23.9 35.6 0.1 24.0 35.7 48.0 -l2.3 * 0.601 2l.2 23.1 0.1 2l.3 23.2 48.0 -24.8 0.670 18.6 26.1 0.1 l8.7 26.2 48.0 -2l.8 0.753 20.3 2l.9 0.1 20.4 22.0 48.0 -26.0 0.829 24.1 26.3 0.1 24.2 26.4 48.0 -21.6 0.90l l9.4 14.0 0.1 l9.5 14.1 48.0 -28.5 FCC PART15B class B 3m = FCC PARTl5B class B 3m RADIATED DATA SHEET = DATE OF TESTS: 98/09/14 SITE: 3 CHART NO. SHEET NO. 3 COMPANY NAME: KENWOOD MODEL: TH-D7A MODE: COMMENT: With core on PC cable POL. FREQ. READ. FACTOR NET LIMITS MARGIN H/V [MHz] [dBuV] [dB] [dBuV/m] [dBuV/m] [dB] V 40.00 42.5 -l2.3 30.2 40.0 -9.8 H 40.00 46.3 -l2.3 34.0 40.0 -6.0 * H l43.96 40.4 -l3.3 27.1 43.5 -16.4 H 207.92 34.6 -l1.3 23.3 43.5 -20.2 V 375.85 38.1 -11.7 26.4 46.0 -l9.6 H 383.85 35.8 -l1.6 24.2 46.0 -2l.8 V 383.85 44.6 -ll.6 33.0 46.0 -13.0 V 735.70 34.4 -3.1 3l.3 46.0 -14.7 = FCC PART15B class B LINE CONDUCTED DATA SHEET = DATE OF TESTS : 98/09/14 SITE: 3 CHART NO. SHEET NO. 4 COMPANY NAME : KENWOOD MODEL: TH-D7A MODE: COMMENT: With core on PC cable FREQ. READ.A READ.B FACTOR NET A NET B LIMITS MARGIN COMMENT [MHz] [dBuV] [dBuV] [dB] [dBuV] [dBuV] [dBuV] [dB] 0.525 23.6 35.1 0.1 23.7 35.2 48.0 -12.8 * 0.603 22.0 23.8 0.1 22.1 23.9 48.0 -24.1 0.670 22.3 27.4 0.1 22.4 27.5 48.0 -20.5 0.752 20.5 22.3 0.1 20.6 22.4 48.0 -25.6 0.829 23.7 25.6 0.1 23.8 25.7 48.0 -22.3 0.901 19.7 14.5 0.1 19.8 14.6 48.0 -28.2
