K44407100HF/50MHz All Mode Transceiver Model: TS-590S

July 9th, 2010 Letter of Attestation Model: TS-590S Scanning receiver (FCC ID: K44407100) This letter attests to the fact that Kenwood scanning receiver model TS-590S meets the requirements of the FCC Rules, 15.121(a). Compliance is achieved through the following method(s): (1). The Microprocessor employed has internal flash memory, however the programming information cannot be read out from the Microprocessor, therefore it has same means of protection as a masked Microprocessor . (2). The Microprocessor is not to accept programming, selection, scanning or direct entry of Cellular band frequencies. (3). Filtering precludes reception of mixer images or harmonics of Cellular band frequencies. (4). Subminiature SMD assembly and inaccessible multiplayer PCB construction all but precludes attempts at circuit hardware modifications. ___________________________________ Tamaki Shimamura Communication Equipment Division Kenwood Corporation

July 9th 2010 MET Laboratories 914 West Patapsco Ave. Baltimore MD 21230 Attn: Reviewing Engineer RE: CONFIDENTIALITY REQUEST FOR MODEL: TS-590S, FCC ID: K44407100 To whom it may concern: This letter serves as an official request for permanent confidentiality pursuant to 47 CFR Section 0.459 of the Commission Rules. We have requested that the Block Diagram, Schematic Diagrams and Circuit Description required to be submitted with this application be withheld from public review. The documents are company proprietary information that could never get into the possession of our competition. Please contact me if you require any additional information. Sincerely, Tamaki Shimamura Communications Equipment Division Kenwood Corporation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

Aug. 17th, 2009 MET Laboratories 914 West Patapsco Ave. Baltimore MD 21230 Attn: Reviewing Engineer RE: LETTER OF AGENT AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize Sae Hagino of Intertek Japan K.K. to act on our behalf in all matters relating to this application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. This agreement expires one year from the current date. Sincerely, Tamaki Shimamura Communications Equipment Division Kenwood Corporation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

July 9th, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer RE: SHORT TERM CONFIDENTIALITY REQUEST FOR MODEL: TS-590S, FCC ID: K44407100. To Whom It May Concern: This letter serves as an official request for short term confidentiality pursuant to 47 CFR Section 0.459 of the Commission Rules. We have requested that the Internal Photos, User’s Manual, External Photos and Test Set-up Photos required to be submitted with this application be withheld from public review. The documents are company proprietary information that could never get into the possession of our competition before product launch . Please contact me if you require any additional information. Sincerely, Tamaki Shimamura Communications Equipment Division Kenwood Corporation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

TS-590S FCC ID: K44407100 IC: 282F-407100 Front View Rear View TS-590S FCC ID: K44407100 IC: 282F-407100 Top View Bottom View TS-590S FCC ID: K44407100 IC: 282F-407100 Right View Left View

TS-590S FCC ID: K44407100 IC: 282F-407100

TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 Front View Rear View TS-590S FCC ID: K44407100 IC: 282F-407100 Rear View TS-590S FCC ID: K44407100 IC: 282F-407100 Rear View TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100 TS-590S FCC ID: K44407100 IC: 282F-407100

Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 1 of 23 FJP-EM001 Version2.1 TEST REPORT STANDARD : FCC Part15B Class B -Peripherals- Applicant Testing Laboratory Kenwood Corporation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan Tel. +81 45 939 6254 Intertek Japan K.K. Tochigi Laboratory URL: http://www.japan.intertek-etlsemko.com 870, Nakaawano, Kanuma-shi, Tochigi-ken 322-0306 Japan Tel. +81 289 86 7121 Equipment Type HF/50MHz ALL MODE TRANSCEIVER Trademark KENWOOD Model(s) TS-590S Serial No. None Equipment Authorization Certification (FCC ID : K44407100) Test Result Complied Report Number JT10070002 Report Issue Date July 16, 2010 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Approved by Tested by Kazuo Gokita [Manager] Atsuyuki Morishima VLAC-008-5 Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 2 of 23 FJP-EM001 Version2.1 TABLE OF CONTENTS Page SECTION 1. GENERAL INFORMATION .................................................................................................. 3 SECTION 2. SUMMARY OF TEST RESULTS ......................................................................................... 4 SECTION 3. EQUIPMENT UNDER TEST ................................................................................................ 5 SECTION 4. SUPPORT EQUIPMENT...................................................................................................... 7 SECTION 5. USED CABLE(S).................................................................................................................. 8 SECTION 6. TEST CONFIGURATION ..................................................................................................... 9 SECTION 7. OPERATING CONDITION ................................................................................................. 10 SECTION 8. TEST PROCEDURE(S) ......................................................................................................11 SECTION 9. MEASUREMENT UNCERTAINTY ..................................................................................... 13 SECTION 10. EVALUATION OF TEST RESULTS ................................................................................. 14 SECTION 11. LIST OF MEASURING INSTRUMENTS .......................................................................... 23 Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 3 of 23 FJP-EM001 Version2.1 SECTION 1. GENERAL INFORMATION TEST PERFORMED Location Tochigi No.2 Test Site EUT Received June 22, 2010 Date of Test From July 2, 2010 to July 6, 2010 Standard Applied FCC Part15B Class B -Peripherals- Measurement methods ANSI C63.4-2003 Test Procedure Document number : RJP-EM001, RJP-EM003 Deviation from Standard(s) None QUALIFICATIONS OF TESTING LABORATORY ACCREDITATION SCOPE LAB. CODE Remarks VLAC EMC Testing VLAC-008-5 JAPAN BSMI EMC Testing SL2-IN-E-6017, SL2-AI-E-6017 TAIWAN FILING VCCI EMC Testing R-257, C-260, C-284, T-1736, T-1737, G-124 R-258, C-261, C-285, T-1738, T-1739 R-259, C-262, T-1740, G-125 JAPAN FCC EMC Testing Designation Number : JP0011 USA IC EMC Testing 2042P-1, 2042P-2 CANADA SAUDI ARABIA EMC Testing N/A ABBREVIATIONS EUT Equipment Under Test DoC Declaration of Conformity AMN Artificial Mains Network ISN Impedance Stabilization Network LISN Line Impedance Stabilization Network Q-P Quasi-peak AMP Amplifier AVG Average ATT Attenuator PK Peak ANT Antenna Cal Calibration BBA Broadband Antenna N/A Not applicable or Not available DIP Dipole Antenna LCD Liquid-Crystal Display AE Associated Equipment VFO Variable Frequency Oscillator Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 4 of 23 FJP-EM001 Version2.1 SECTION 2. SUMMARY OF TEST RESULTS The minimum margins to the limits are as follows: Conducted disturbance at mains terminals RX mode(0.03MHz:ANT 1) 13.5 dB (3.7933 MHz) AVG RX mode(60.000MHz:ANT 1) 13.5 dB (3.9980 MHz) AVG Radiated disturbance RX mode(30.000MHz:ANT 1) 2.6 dB (412.37 MHz) Note : 1. See Section 10 for details. < Measurement data correction > * Conducted disturbance at mains terminals Emission Level [dBμV] = Meter Reading [dBμV] + Factor [dB] Margin [dB] = Limit [dBμV] - Emission Level [dBμV] *Factor = LISN Factor + Cable Loss + ATT * Radiated disturbance Emission Level [dBμV/m] = Meter Reading [dBμV] + Factor [dB/m] Margin [dB] = Limit [dBμV/m] - Emission Level [dBμV/m] * Factor = Antenna Factor + Cable Loss - Amplifier Gain + ATT ( – Distance Conversion Factor) Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 5 of 23 FJP-EM001 Version2.1 SECTION 3. EQUIPMENT UNDER TEST The equipment under test (EUT) consisted of the following apparatus. 3.1 System Configuration Symbol Item Model No. Serial No. ManufacturerRemarks FCC ID A HF/50MHz ALL MODE TRANSCEIVER TS-590S None KENWOOD EUT K44407100 Rated Power : DC13.8 V ± 15% 1.5 A max. Supplied Power : DC13.8 V Condition of Equipment Prototype Type Tabletop Suppression Devices No Modifications by the laboratory were made to the device 3.2 Overview of EUT Frequency Ranges 0.030 – 60.000 MHz Receiver Type Double or Triple…

Text truncated - open the document above for the full version.

Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 1 of 54 FJP-EM001 Version2.1 TEST REPORT STANDARD : FCC Part 15B-Scanning Receiver : Industry Canada RSS-215 Issue 2 Applicant Testing Laboratory Kenwood Corporation 1-16-2,Hakusan,Modori-ku,Yokohama-shi Kanagawa, 226-8525 Japan Tel.: +81 45 939 6254 Fax.:+81 45 939 7097 Intertek Japan K.K. Tochigi Laboratory 870, Nakaawano, Kanuma-shi, Tochigi-ken 322-0306 Japan Tel. : +81 289 86 7121 URL: http://www.japan.intertek-etlsemko.com Equipment Type HF/50MHz ALL MODE TRANSCEIVER Category Scanning Receiver Trademark KENWOOD Model(s) TS-590S Serial No. None Equipment Authorization Certification (FCC ID : K44407100, IC : 282F-407100) Test Result Complied Report Number JT10070001 Report Issue Date July 16, 2010 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Approved by Tested by Kazuo Gokita [Manager] Atsuyuki Morishima VLAC-008-5 Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 2 of 54 FJP-EM001 Version2.1 TABLE OF CONTENTS Page SECTION 1. GENERAL INFORMATION .................................................................................................. 3 SECTION 2. SUMMARY OF TEST RESULTS ......................................................................................... 4 SECTION 3. EQUIPMENT UNDER TEST ................................................................................................ 5 SECTION 4. SUPPORT EQUIPMENT...................................................................................................... 7 SECTION 5. USED CABLE(S).................................................................................................................. 8 SECTION 6. TEST CONFIGURATION ..................................................................................................... 9 SECTION 7. OPERATING CONDITION ..................................................................................................11 SECTION 8. TEST PROCEDURE(S) ..................................................................................................... 12 SECTION 9. MEASUREMENT UNCERTAINTY ..................................................................................... 16 SECTION 10. EVALUATION OF TEST RESULTS ................................................................................. 17 SECTION 11. LIST OF MEASURING INSTRUMENTS .......................................................................... 53 Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 3 of 54 FJP-EM001 Version2.1 SECTION 1. GENERAL INFORMATION TEST PERFORMED Location Tochigi No.2 Test Site EUT Received June 22, 2010 Date of Test From Jun 30, 2010 to July 6, 2010 Standard Applied FCC Part15B – Scanning Receiver Industry Canada RSS-215 Issue 2 * * It is not covered by accredited scope of VLAC. Measurement methods ANSI C63.4-2003 / RSS-GEN Issue2 4.10 Test Procedure Document number : RJP-EM001, RJP-EM003 Deviation from Standard(s) None Note : As for the ICES-003 “Digital Apparatus”, the EUT has been measured. Refer to report No.“JT10070003”. As for the FCC Part15B Class B “Peripherals”, the EUT has been measured. Refer to report No.“JT10070002”. QUALIFICATIONS OF TESTING LABORATORY ACCREDITATION SCOPE LAB. CODE Remarks VLAC EMC Testing VLAC-008-5 JAPAN BSMI EMC Testing SL2-IN-E-6017, SL2-A-E-6017 TAIWAN FILING VCCI EMC Testing R-257, C-260, C-284, T-1736, T-1737, G-124 R-258, C-261, C-285, T-1738, T-1739 R-259, C-262, T-1740, G-125 JAPAN FCC EMC Testing Designation Number : JP0011 USA IC EMC Testing 2042P-1, 2042P-2 CANADA SAUDI ARABIA EMC Testing N/A ABBREVIATIONS EUT Equipment Under Test DoC Declaration of Conformity AMN Artificial Mains Network ISN Impedance Stabilization Network LISN Line Impedance Stabilization Network Q-P Quasi-peak AMP Amplifier AVG Average ATT Attenuator PK Peak ANT Antenna Cal Calibration BBA Broadband Antenna N/A Not applicable or Not available DIP Dipole Antenna LCD Liquid-Crystal Display AE Associated Equipment VFO Variable Frequency Oscillator Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 4 of 54 FJP-EM001 Version2.1 SECTION 2. SUMMARY OF TEST RESULTS The minimum margins to the limits are as follows: Conducted disturbance at mains terminals RX mode(0.03MHz:ANT 1) 13.5 dB (3.7933 MHz) AVG RX mode(60.000MHz:ANT 1) 13.5 dB (3.9980 MHz) AVG Radiated disturbance RX mode(30.000MHz:ANT 1) 2.6 dB (412.37 MHz) Conducted Power on Antenna Port (15.111) / (RSS-215 5.1) VFO A SCAN( ANT 2 ) mode 12.8 dB (80.00 MHz) 38dB Rejection Test (15.121(b)) No frequency of response was detected – Passed- Note : See Section 10 for details. < Measurement data correction > * Conducted disturbance at mains terminals Emission Level [dBμV] = Meter Reading [dBμV] + Factor [dB] Margin [dB] = Limit [dBμV] - Emission Level [dBμV] * Factor = LISN Factor + Cable Loss + ATT * Radiated disturbance Emission Level [dBμV/m] = Meter Reading [dBμV] + Factor [dB/m] Margin [dB] = Limit [dBμV/m] - Emission Level [dBμV/m] * Factor = Antenna Factor + Cable Loss - Amplifier Gai…

Text truncated - open the document above for the full version.

Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 1 of 5 FJP-EM001 Version2.1 Annex A Photographs Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 2 of 5 FJP-EM001 Version2.1 PHOTOGRAPHS OF MAXIMUM EMISSION SET-UP 1 Conducted disturbance at main terminals Note : Maintaining 10cm spacing between all the equipment cabinets. Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 3 of 5 FJP-EM001 Version2.1 2 Radiated disturbance Note : Maintaining 10cm spacing between all the equipment cabinets. Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 4 of 5 FJP-EM001 Version2.1 3 Conducted Power on Antenna Port (15.111) Report No. JT10070001 FCC ID : K44407100 / IC : 282F-407100 © Intertek Japan K.K. Page 5 of 5 FJP-EM001 Version2.1 4 38dB Rejection (15.121(b))

Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 1 of 3 FJP-EM001 Version2.1 Annex A Photographs Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 2 of 3 FJP-EM001 Version2.1 PHOTOGRAPHS OF MAXIMUM EMISSION SET-UP 1 Conducted disturbance at mains terminals Note : Maintaining 10cm spacing between all the equipment cabinets. EUT Report No. JT10070002 FCC ID : K44407100 © Intertek Japan K.K. Page 3 of 3 FJP-EM001 Version2.1 2 Radiated disturbance Note : Maintaining 10cm spacing between all the equipment cabinets.
