NX-720 Series NX-820 Series VHF DIGITAL TRANSCEIVER UHF DIGITAL TRANSCEIVER INSTRUCTION MANUAL ÉMETTEUR-RÉCEPTEUR NUMÉRIQUE VHF ÉMETTEUR-RÉCEPTEUR NUMÉRIQUE UHF MODE D’EMPLOI TRANSCEPTOR DIGITAL VHF TRANSCEPTOR DIGITAL UHF MANUAL DE INSTRUCCIONES © B62-2421-00 (K) 09 08 07 06 05 04 03 02 01 00 VHF DIGITAL TRANSCEIVER UHF DIGITAL TRANSCEIVER NX-700 Series NX-800 Series INSTRUCTION MANUAL ENGLISH Terminal Descriptions ACC (D-SUB 15 Pin Connector) Pin No.NameI/ODescriptionSpecification 1SBODC Power (Switched B) Output13.6 V ±15% Max. 2 A 2IGNIIgintion Signal Input Min. Input: 10.8 V Max. Input: 16.0 V 3SP2OLoudspeaker Output4 Ω 4DETOORX Detected Audio Output280 mV p-p (typ.) 5DATAIITX Data Input100 kΩ 6FNC1/ TXDI/OProgrammable/ PC Serial Data from RadioHigh Impedance 7FNC1/ RXDI/OProgrammable/ PC Serial Data to RadioHigh Impedance 8FNC3I/OProgrammableHigh Impedance 9FNC4I/OProgrammableHigh Impedance 10FNC5I/OProgrammableHigh Impedance 11FNC6I/OProgrammableHigh Impedance 1250MCODC Power Output5 V, Max 100 mA 13HR1OHorn Alert Signal OutputMax 3 A 14HR2OHorn Alert Signal OutputMax 3 A 15GND—GroundGround Speaker Jack (3.5 mm Phone Jack) 4 W/ 4 Ω Pin No.NameI/ODescriptionSpecification 1SPOOExternal Speaker Output4 Ω 3GND—GroundGround DC Input Connector Pin No.NameI/ODescriptionSpecification RedBIDC Power Input13.6 V ±15% BlackGNDIGroundGround Microphone Jack Pin No.NameI/ODescriptionSpecification 1BLCOBacklight ControlHigh Impedance 2SBODC Power (Switched B) Output13.6 V ±15% 3GND—GroundGround 4PTT/ TXD I/OPTT/ PC Serial Data from RadioHigh Impedance 5ME—Mic GroundGround 6MICIMic Signal Input600 Ω 7HOOK/ RXD IHook/ PC Serial Data to RadioHigh Impedance 8DMI/OMic Data DetectionHigh Impedance Antenna Terminal 50 Ω impedance GPS Terminal <GPS model olny> 50 Ω impedance i One or more of the following statements may be applicable: FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer for technical assistance. THANK YOU We are grateful you have chosen KENWOOD for your personal mobile applications. This instruction manual covers only the basic operations of your mobile radio. Ask your dealer for information on any customized features they may have added to your radio. NOTICES TO THE USER ◆ Government law prohibits the operation of unlicensed transmitters within the territories under government control. ◆ Illegal operation is punishable by fine and/or imprisonment. ◆ Refer service to qualified technicians only. SAFETY: It is important that the operator is aware of, and understands, hazards common to the operation of any transceiver. ◆ EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.) Turn OFF your transceiver while taking on fuel or while parked in gasoline service stations. Do not carry spare fuel containers in the trunk of your vehicle if your transceiver is mounted in the trunk area. ◆ INJURY FROM RADIO FREQUENCY TRANSMISSIONS Do not operate your transceiver when somebody is either standing near to or touching the antenna, to avoid the possibility of radio frequency burns or related physical injury. ◆ DYNAMITE BLASTING CAPS Operating the transceiver within 500 feet (150 m) of dynamite blasting caps may cause them to explode. Turn OFF your transceiver when in an area where blasting is in progress, or where “TURN OFF TWO-WAY RADIO” signs have been posted. If you are transporting blasting caps in your vehicle, make sure they are carried in a closed metal box with a padded interior. Do not transmit while the caps are being placed into or removed from the container. ii CONTENTS GETTING STARTED ...................................................................................... 1 GETTING ACQUAINTED ............................................................................... 3 PROGRAMMABLE FUNCTIONS ................................................................... 5 BASIC OPERATIONS .................................................................................... 6 SCAN.............................................................................................................. 8 FleetSync: ALPHANUMERIC 2-WAY PAGING FUNCTION ........................ 10 TRUNKING CALLS (ANALOG) .................................................................... 12 ADVANCED OPERATIONS ......................................................................... 13 BACKGROUND OPERATIONS ................................................................... 17 PRECAUTIONS Observe the following precautions to prevent fire, personal injury, and transceiver damage. • Do not attempt to configure the transceiver while driving; it is too dangerous. • Do not disassemble or modify the transceiver fo…

Text truncated - open the document above for the full version.

July 20th, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer RE: LETTER OF AGENT AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize any individual within Intertek Japan K.K. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. This agreement expires one year from the current date. Sincerely, Tamaki Shimamura Communications Equipment Division 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

July 2nd 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer RE: CONFIDENTIALITY REQUEST FOR MODEL: NX-720H-K, NX-720HG-K FCC ID: K44431100. To whom it may concern: This letter serves as an official request for permanent confidentiality pursuant to 47 CFR Section 0.459 of the Commission Rules. We have requested that the Block Diagram, Schematic Diagrams, Circuit Description, Parts List, Active Devices and Tuning Procedure required to be submitted with this application be withheld from public review. The documents are company proprietary information that could never get into the possession of our competition. Please contact me if you require any additional information. Sincerely, Tamaki Shimamura Communications Equipment Division 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

July 2nd, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer Subject: Justify Extended Frequency Range for MODEL: NX-720H-K, NX-720HG-K, FCC ID: K44431100. To Whom It May Concern: This letter serves justification for extended frequencies This device has design capability to operate in the frequency band 150 to 174 MHz and complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Please note that Licensed End Users do not have access to any external controls that will allow them to program the equipment. Equipment programming is the responsibility of Kenwood approved Service Agents. In addition to Parts 90 usage, this device is utilized in systems such as Federal and Public Safety agencies, e.g. police, fire, and emergency medical, etc. as indicated in the following table: Freq. Range (MHz) Part 90 Federal Customers 150.0000-150.8000 x 150.8000-156.2475 x 156.2475-157.0375 x 157.0375-161.5750 x 161.5750-161.7750 x 161.7750-173.4000 x 173.4000-174.0000 x T able 1 – Frequency Range and Rule Parts - (47 CFR Part 2.106) It is understood that a grant note code may be added to the grant which indicates this required operation. In addition, we acknowledge that it is a violation of FCC rules if the device operates on unauthorized frequencies. Please cont act me if you require any additional information. Sincerely, Tamaki Shimamura Communications Equipment Division JVC KENWOOD Corporation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

NX-720H-K, NX-720HG-K FCC ID: K44431 100 IC: 282F-431100 NX-720 H-K NX-720H-K, NX-720HG-K FCC ID: K44431100 IC: 282F-431100 NX-720 HG-K

NX-720H-K, NX-720HG-K FCC ID: K44431100 IC: 282F-431100 NX-720H-K, NX-720HG-K FCC ID: K44431100 IC: 282F-431100 NX-720H-K, NX-720HG-K FCC ID: K44431100 IC: 282F-431100

MANDATORY SAFETY INSTRUCTIONS TO INSTALLERS AND USERS • Use only manufacturer or dealer supplied antennas. • A ntenna Minimum Safe Distance: 40 cm (16 inches), 50% duty Cycle. • Antenna Gain: 0 dBd referenced to a dipole. The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits. • Antenna Mounting: The antenna supplied by the manufacturer or radio dealer must not be mounted at a location such that during radio transmission, any person or persons can come closer than the above indicated minimum safe distance to the antenna, i.e. 40 cm (16 inches) , 50% duty Cycle. • To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding t he minimum safe distance shown above, and in accordance with the requirements of the antenna manufacturer or supplier. • Vehicle installation: The antenna can be mounted at the center of a vehicle metal roof or trunk lid, if the minimum safe distance is observed. • Base S tation Installation: The antenna should be fixed-mounted on an outdoor permanent structure. RF Exposure compliance must be addressed at the time of installation. Antenna substitution: Do not substitute any antenna for the one supplied or recommended by the manufacturer or radio dealer. You may be exposing person or persons to excess radio frequency radiation. You may contact your radio dealer or the manufacturer f or further instructions. Maintain a separation distance from the antenna to person(s) of at least 40 cm (16 inches), 50% duty Cycle. “This transmitter is authorized to operate with a maximum duty factor of 50%, in typical push-to-talk mode, for satisfying FCC RF exposure compliance requirements.” You, as the qualified end-user of this radio device must control the exposure conditions of bystanders to ensure the minimum separation distance (above) is maintained between the antenna and nearby persons for satisfying RF Exposure compliance. The operation of this transmitter must satisfy the requirements of Occupational/Controlled Exposure Environment, for work-related use, transmit only when person(s) are at least the minimum distance from the properly installed, externally mounted antenna. Transmit only when people outside the vehicle are at least the recommended minimum lateral distance away from the antenna/vehicle. B59-2723-00

p1280009_FCC_Part 1.1310_Rev 2.0 Page 1 of 6 Test Report Prepared for: JVC Kenwood Corporation Model: NX-720H-K / NX-720HG-K Description: VHF Digital Transceiver To FCC Part 1.1310 Date of Issue: August 24, 2012 On the behalf of the applicant: JVC Kenwood Corporation 1-16-2, Hakusan Midori-ku Yokohama, Kanagawa 226-8525 Attention of: Tamaki Shimamura, Manager Ph: +81 45 939 6254 E-Mail: [email protected] Prepared By Compliance Testing, LLC 3356 N San Marcos Pl, Suite 107 Chandler, AZ 85225-7176 (866) 311-3268 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1280009 John Erhard Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1280009_FCC_Part 1.1310_Rev 2.0 Page 2 of 6 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 August 24, 2012 John Erhard Original Document 2.0 September 6, 2012 John Erhard Clarify the test report detailing how the 50% duty factor was applied. Edit antenna information. p1280009_FCC_Part 1.1310_Rev 2.0 Page 3 of 6 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC OATS Reg, #933597 IC Reg. #2044A-1 Non-accredited tests contained in this report: N/A p1280009_FCC_Part 1.1310_Rev 2.0 Page 4 of 6 Measurement Description The EUT was placed inside an anechoic chamber at a height of 1.2 meters to simulate being mounted on a vehicle. The isotropic probe was placed a distance of 40 cm from the EUT and the power density was measured at 0.2m increments from 0.2m to 2.0m with the peak value from each location being recorded in the corresponding data tables. The general population limit of 0.2 mW/cm 2 was applied to all measurements. The EUT is a PTT radio for mobile application with a peak power of 50W. By allowing for an operational 50% duty factor the power was reduced to 25W for testing purposes yet transmitted continuously during the test. A 0 dBd antenna was utilized for testing. Measurement Result 138 MHz Probe Height (m) Peak Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Result 0.2 0.03 0.2 Pass 0.4 0.02 0.2 Pass 0.6 0.01 0.2 Pass 0.8 0.02 0.2 Pass 1.0 0.05 0.2 Pass 1.2 0.07 0.2 Pass 1.4 0.08 0.2 Pass 1.6 0.09 0.2 Pass 1.8 0.10 0.2 Pass 2.0 0.07 0.2 Pass 150 MHz Probe Height (m) Peak Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Result 0.2 0.01 0.2 Pass 0.4 0.01 0.2 Pass 0.6 0.01 0.2 Pass 0.8 0.01 0.2 Pass 1.0 0.03 0.2 Pass 1.2 0.05 0.2 Pass 1.4 0.06 0.2 Pass 1.6 0.05 0.2 Pass 1.8 0.03 0.2 Pass 2.0 0.02 0.2 Pass p1280009_FCC_Part 1.1310_Rev 2.0 Page 5 of 6 162 MHz Probe Height (m) Peak Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Result 0.2 0.01 0.2 Pass 0.4 0.01 0.2 Pass 0.6 0.01 0.2 Pass 0.8 0.03 0.2 Pass 1.0 0.07 0.2 Pass 1.2 0.10 0.2 Pass 1.4 0.10 0.2 Pass 1.6 0.10 0.2 Pass 1.8 0.08 0.2 Pass 2.0 0.06 0.2 Pass 174 MHz Probe Height (m) Peak Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Result 0.2 0.01 0.2 Pass 0.4 0.01 0.2 Pass 0.6 0.01 0.2 Pass 0.8 0.02 0.2 Pass 1.0 0.03 0.2 Pass 1.2 0.04 0.2 Pass 1.4 0.04 0.2 Pass 1.6 0.04 0.2 Pass 1.8 0.03 0.2 Pass 2.0 0.02 0.2 Pass p1280009_FCC_Part 1.1310_Rev 2.0 Page 6 of 6 Test Equipment Utilized Description Manufacturer Model # CT Asset # Last Cal Date Cal Due Date Power Supply HP 6673A i00191 Verified on: 8/23/12 Semi-Anechoic Chamber CT N/A i00276 8/31/11 8/31/12 Isotropic E Field Probe ETS Lindgren HI 6005 i00300 8/02/12 8/02/13 END OF TEST REPORT

Report No :JK12070002 FCC ID :K44431100 IC CN :282F-431100 TRUE FALSE 3 REGULATION :FCC Part 2, 90 RSS-119 Issue 11 JVC KENWOOD CorporationIntertek Japan K. K. Kashima Laboratory 1-16-2, Hakusan, Midori-ku, Yokohama-shi3-2, Sunayama, Kamisu-shi, Ibaraki-ken Kanagawa, 226-8525 Japan314-0255 Japan Tel.: +81 45 939 6254Tel.: +81 479 40 1097 Fax.: +81 45 939 6261 Intertek Japan K. K. Matsuda Laboratory 1283 Yadoriki, Matsuda-machi, Ashigarakami-gun, Kanagawa-ken, 258-0001 Japan Tel.: +81 465 89 2316 Equipment typeVHF DIGTAL TRANSCEIVER TrademarkKENWOOD Model(s)NX-720H-K, NX-720HG-K Serial No. FCC ID K44431100 IC CN and UPN 282F-431100 Test ResultComplied Report NumberJK12070002 Report issue date Approved byTested by Kazuo GokitaKoichi Wagatsuma [Manager] This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Applicant TEST REPORT Testing Laboratory July 10, 2012 None Intertek Japan K.K.Page 1 of 61 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :JK12070002 FCC ID :K44431100 IC CN :282F-431100 In Accordance with FCC Rules and Regulations, Volume II, Part 2 and 90 Sub-part 2.1033 (c)(1) Applicant and Manufacture Information APPLICANT Company:JVC KENWOOD Corporation Address:1-16-2, Hakusan, Midori-ku, Yokohama-shi Kanagawa, 226-8525 Japan Contact Person:Tamaki Shimamura Manager, Communications Equipment Division MANUFACTURER Company:JVC KENWOOD Corporation Address:1-16-2, Hakusan, Midori-ku, Yokohama-shi Kanagawa, 226-8525 Japan (c)(2) FCC ID FCC ID:K44431100 Model number:NX-720H-K, NX-720HG-K Serial number:None (c)(3) Instruction Manual(S) Instruction manual(s) :Please refer to attached Exhibits F (c)(4) Type of Emission Emission Designation :16K0F3E(Wide)* / 11K0F3E(Narrow) * 16K0F3E(Wide) is RSS Only 8K30F1E(Narrow) / 8K30F1D(Narrow) / 8K30F7W(Narrow) 4K00F1E(Very Narrow) / 4K00F1D(Very Narrow) / 4K00F7W(Very Narrow) 4K00F2D(Very Narrow) (c)(5) Frequency range Frequency Range:150 to 174 MHz(FCC) , 138 to 144 MHz and 148 to 174 (RSS) (c)(6) Power Rating Output Power:5 to 50 W Type:Continuously Variable (c)(7) Maximum Power Rating Output Power:50W Collector Current, A:12.0 amps (Maximum) Collector Voltage, Vdc :13.6 Vdc Supply Voltage, Vdc:13.6 Vdc Other Information Number of Channel:260 channels Maximum Deviation:5kHz* , 2.5kHz* 5kHz is RSS Only Frequency Stability:1.0 ppm : Antenna Impedance:50 Ω Norminal Note including final transistor or solid-state device (c)(8): Voltages & currents in all elements in final RF stage, Intertek Japan K.K.Page 2 of 61 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :JK12070002 FCC ID :K44431100 IC CN :282F-431100 TABLE OF CONTENTS Page SECTION 1. GENERAL INFORMATION4 SECTION 2. SUMMARY OF TEST RESULT5 SECTION 3. TEST AND MEASUREMENT DATA6 SECTION 4. INFORMATION ABOUT EUT AND SUPPORT EQUIPMENT(S)7 SECTION 5. SUPPORT EQUIPMENT8 SECTION 6. USED CABLE(S)9 SECTION 7. TEST CONFIGURATION10 SECTION 8. OPERATING CONDITION11 SECTION 9. MEASUREMENT UNCERTAINTY12 SECTION 10. TEST DATA 10.1Carrier Output Power (Conducted)13 10.2Unwanted Emissions (Transmitter Conducted)15 10.3Field Strength of Spurious Radiation18 10.4Emission Masks (Occupied Bandwidth)24 10.5Transient Frequency Behavior34 10.6Audio Frequency Response / Audio Low Pass Filter (Voice Input)43 10.7Modulation Limiting46 10.8Frequency Stability (Temperature Variation)51 10.9Frequency Stability (Voltage Variation)55 10.10Receiver Spurious Emissions(Radiated)57 10.11Necessary Bandwidth and Emission Bandwidth61 APPENDIXPHOTOGRAPHS Intertek Japan K.K.Page 3 of 61 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :JK12070002 FCC ID :K44431100 IC CN :282F-431100 SECTION 1. GENERAL INFORMATION TEST PERFORMED LocationKashima No.1 Test Site, Matsuda No.2 Test Site , No.3 Test Site EUT Received Date of Testto Standard AppliedFCC Part 2, 90 RSS-119 Issue 11 Measurement Method Deviation from Standard(s)Not applicable QUALIFICATIONS OF TESTING LABORATORY(Kashima Lab.) ACCREDITATIONSCOPELAB. CODERemarks NVLAPEMC Testing100290-0USA VLACEMC TestingVLAC-008-1JAPAN BSMIEMC TestingSL2-IN-E-6008TAIWAN FILING VCCIEMC TestingJAPAN FCCEMC TestingDesignation Number:JP0008 ICEMC TestingIC-2042K-1, IC-2042K-3, , IC-2042Q-12CANADA CB-SchemeEMC TestingTL222IECEE SAUDI ARABIAEMC TestingN/A QUALIFICATIONS OF TESTING LABORATORY(Matsuda Lab.) ACCREDITATIONSCOPELAB. CODERemarks VLACEMC TestingVLAC-008-3JAPAN BSMIEMC TestingSL2-IN-E-6009TAIWAN FILING VCCIEMC TestingJAPAN FCCEMC TestingDesignation Number:JP0009USA ICEMC TestingCANADA CB-SchemeEMC TestingTL223IECEE SAUDI ARABIAEMC TestingN/A ABBREVIATIONS EUTDoC AMNISN LISNQ-P AMPAVG ATTPK ANTCal BBAN/A DIPLCD AEAssociated Equipment4LEVEL FSK 4LEVEL Frequency Shift Key GMSKCW ID FMC4FM PTTPush to TalkAFC Gaussian Maximum Shift Key Frequency ModulationConstant envelope 4 Level FM Continuously Repeating bit stream Automatic frequency control Dipole AntennaLiquid-Crystal Display Not applicable or Not available June 13, 2012July 06, 2012 Attenuator Antenna Broadband Antenna June 13, 2012 Peak Declaration of Conformity Calibration Impedance Stabilization Network R-252, C-287, C-255, T-1723 R-253, C-288, C-256, T-1724 R-254, C-289,…
