K44478500700/800MHz DIGITAL TRANSCEIVER with Bluetooth

B5A-0056-10 (K) USER GUIDE GUIDE DE L'UTILISATEUR GUÍA DEL USUARIO NX-5000 series The illustration shows the model with an operation panel attached. L’illustration représente le modèle avec un panneau de commande fi xé. La ilustración muestra el modelo con un panel de operaciones adjunto. USER GUIDE VHF DIGITAL TRANSCEIVER NX-5700 NX-5700(B) UHF DIGITAL TRANSCEIVER NX-5800 NX-5800(B) 700/800MHz DIGITAL TRANSCEIVER NX-5900 NX-5900(B) Firmware Copyrights The title to and ownership of copyrights for firmware embedded in KENWOOD product memories are reserved for JVC KENWOOD Corporation. The AMBE+2 TM voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to extract, remove, decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human-readable form. U.S. Patent Nos. #6,199,037, #6,912,495, #8,200,497, #7,970,606, and #8,359,197 • SD TM and microSD TM are trademarks of SD-3C, LLC in the United States. and/ or other countries. • The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners. 2 THANK YOU We are grateful you have chosen KENWOOD for your Digital Transceiver applications. This User Guide covers only the basic operations of your radio. Ask your dealer for information on anycustomized features they may have added to your radio. For using details instruction manual, refer to the following URL. http://manual2.jvckenwood.com/en_contents/search/ CONTENTS NOTICES TO THE USER ..........................................................................3 PRECAUTIONS ....................................................................................4 TERMINAL DESCRIPTIONS .....................................................................5 UNPACKING AND CHECKING EQUIPMENT ....................................................6 SUPPLIED ACCESSORIES ......................................................................................... 6 PREPARATION ....................................................................................7 ORIENTATION .....................................................................................9 OPERATION PANEL (ATTACHED PANEL OR KCH-19) ............................................... 9 DISPLAY ................................................................................................................. 10 BASIC OPERATION ............................................................................. 13 SWITCHING POWER ON/ OFF ................................................................................. 13 ADJUSTING THE VOLUME ...................................................................................... 13 SELECTING A ZONE AND CHANNEL ....................................................................... 13 TRANSMITTING ...................................................................................................... 13 RECEIVING .............................................................................................................. 13 3 NOTICES TO THE USER • Government law prohibits the operation of unlicensed radio transmitters within the territories under government control. • Illegal operation is punishable by fi ne and/or imprisonment. • Refer service to qualifi ed technicians only. Safety: It is important that the operator is aware of, and understands, hazards common to the operation of any transceiver. • EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.) Turn OFF your transceiver while taking on fuel or while parked in gasoline service stations. Do not carry spare fuel containers in the trunk of your vehicle if your transceiver is mounted in the trunk area. • INJURY FROM RADIO FREQUENCY TRANSMISSIONS Do not operate your transceiver when somebody is either standing near to or touching the antenna, to avoid the possibility of radio frequency burns or related physical injury. • DYNAMITE BLASTING CAPS Operating the transceiver within 500 feet (150 m) of dynamite blasting caps may cause them to explode. Turn OFF your transceiver when in an area where blasting is in progress, or where “TURN OFF TWO-WAY RADIO” signs have been posted. If you are transporting blasting caps in your vehicle, make sure they are carried in a closed metal box with a padded interior. Do not transmit while the caps are being placed into or removed from the container. One or more of the following statements may be applicable: FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved by the party responsible/ JVC KENWOOD. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by on…

Text truncated - open the document above for the full version.

MANDATORY SAFETY INSTRUCTIONS TO INSTALLERS AND USERS • Use only manufacturer or dealer supplied antennas. • Antenna Minimum Safe Distance: 40 cm (16 inches), 50% duty Cycle. • Antenna Gain: 0 dBd referenced to a dipole. The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits. • Antenna Mounting: The antenna supplied by the manufacturer or radio dealer must not be mounted at a location such that during radio transmission, any person or persons can come closer than the above indicated minimum safe distance to the antenna, i.e. 40 cm (16 inches) , 50% duty Cycle. • To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding the minimum safe distance shown above, and in accordance with the requirements of the antenna manufacturer or supplier. • Vehicle installation: The antenna can be mounted at the center of a vehicle metal roof or trunk lid, if the minimum safe distance is observed. • Base Station Installation: The antenna should be fixed-mounted on an outdoor permanent structure. RF Exposure compliance must be addressed at the time of installation. Antenna substitution: Do not substitute any antenna for the one supplied or recommended by the manufacturer or radio dealer. You may be exposing person or persons to excess radio frequency radiation. You may contact your radio dealer or the manufacturer for further instructions. Maintain a separation distance from the antenna to person(s) of at least 40 cm (16 inches), 50% duty Cycle. “This transmitter is authorized to operate with a maximum duty factor of 50%, in typical push-to-talk mode, for satisfying FCC RF exposure compliance requirements.” You, as the qualified end-user of this radio device must control the exposure conditions of bystanders to ensure the minimum separation distance (above) is maintained between the antenna and nearby persons for satisfying RF Exposure compliance. The operation of this transmitter must satisfy the requirements of Occupational/Controlled Exposure Environment, for work-related use, transmit only when person(s) are at least the minimum distance from the properly installed, externally mounted antenna. Transmit only when people outside the vehicle are at least the recommended minimum lateral distance away from the antenna/vehicle. B59-2723-00

July 9th 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer RE: CONFIDENTIALITY REQUEST FOR MODEL: NX-5900-K,NX-5900-F, FCC ID: K44478500. To whom it may concern: This letter serves as an official request for permanent confidentiality pursuant to 47 CFR Section 0.459 of the Commission Rules. We have requested that the Block Diagram, Schematic Diagrams, Circuit Description, Parts List, Active Devices and Tuning Procedure required to be submitted with this application be withheld from public review. The documents are company proprietary information that could never get into the possession of our competition. Please contact me if you require any additional information. Sincerely, Tamaki Shimamura Communications Systems Business Operation 1-16-2, Hakusan, Midori-ku, Yokohama-shi, Kanagawa, 226-8525 Japan

NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 Front View Rear View Right View Left View NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 Top View Bottom View

NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500

NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 Internal View NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500 NX-5900-K/-F FCC ID: K44478500 NX-5900-K IC: 282F-478500

Report No :15060364JKA-003 FCC ID:K44478500 IC CN UPN :282F-478500 TRUE FALSE 3 REGULATION :FCC Part 2, 90 RSS-119 Issue 12 JVC KENWOOD CorporationIntertek Japan K.K. Kashima Laboratory URL: http://www.japan.intertek-etlsemko.com 1-16-2, Hakusan, Midori-ku, Yokohama-shi(Anechoic chamber) Kanagawa, 226-8525 Japan 298-6 Sada, Kashima, Ibaraki Tel.: +81 45 939 6254 314-0027 Japan Fax.: +81 45 939 6261 Tel. +81 299 82 8464 (Open area test site) 3-2 Sunayama, Kamisu, Ibaraki 314-0255 Japan Tel. +81 479 40 1097 Equipment type700/800MHz DIGITAL TRANSCEIVER TrademarkKENWOOD FCC Model(s)NX-5900-K, NX-5900-F IC Model(s)NX-5900-K Serial No. FCC ID K44478500 IC CN and UPN 282F-478500 Test ResultComplied Report Number15060364JKA-003 Original Issue Date Approved byTested by Hideaki KosemuraKoichi Wagatsuma [Technical Dept. Manager][Engineer] Katsuya Uchida [Engineer] This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Applicant TEST REPORT Testing Laboratory 90-No.1 July 31, 2015 Intertek Japan K.K.Page 1 of 139 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :15060364JKA-003 FCC ID:K44478500 IC CN UPN :282F-478500 In Accordance with FCC Rules and Regulations, Volume II, Part 2 and 90 Sub-part 2.1033 Applicant and Manufacture Information APPLICANT Company:JVC KENWOOD Corporation Address:1-16-2, Hakusan, Midori-ku, Yokohama-shi Kanagawa, 226-8525 Japan Contact Person:Tamaki Shimamura Manager, Communications Systems Business Operation MANUFACTURER Company:JVC KENWOOD Corporation Address:1-16-2, Hakusan, Midori-ku, Yokohama-shi Kanagawa, 226-8525 Japan (c)(2) FCC ID FCC ID:K44478500 Model number:NX-5900-K, NX-5900-F Serial number:90-No.1 Instruction Manual(S) Instruction manual(s):Please refer to attached Exhibits F Type of Emission Emission Designation :16K0F3E(Wide), 14K0F3E(Wide) 11K0F3E(Narrow) 8K10F1E(Narrow) / 8K10F1D(Narrow) / 8K10F1W(Narrow) 8K30F1E(Narrow) / 8K30F1D(Narrow) / 8K30F7W(Narrow) 4K00F1E(Very Narrow) / 4K00F1D(Very Narrow) / 4K00F7W(Very Narrow) 4K00F2D(Very Narrow) Frequency range Frequency Range:FCC: 769 to 775 MHz, 799 to 805 MHz, 806 to 824 MHz and 851 to 869 MHz IC: 768 to 776 MHz, 798 to 806 MHz, 806 to 824 MHz and 851 to 869 MHz Power Rating Output Power:2 to 30 W (768 to 806MHz), 2 to 35 W (806 to 869MHz) Type:Continuously Variable Maximum Power Rating Output Power:30 W (768 to 806MHz), 35 W (806 to 869MHz) Collector Current, A:13.0 A Maximum Collector Voltage, Vdc :13.6 Vdc Supply Voltage, Vdc:13.6 Vdc Other Information Number of Channel:Zone 128max. Cannels 512 max.(per Zone) Maximum Deviation:± 5 kHz (16K0F3E), ± 4 kHz (14K0F3E), ± 2.5 kHz (11K0F3E) Frequency Stability: 1 ppm (768 to 776 MHz, 798 to 806 MHz) / 0.4 ppm with AFC (798 to 806 MHz) :1 ppm (806 to 824 MHz, 851 to 869 MHz) Antenna Impedance:50  Norminal Note including final transistor or solid-state device Voltages & currents in all elements in final RF stage, Intertek Japan K.K.Page 2 of 139 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :15060364JKA-003 FCC ID:K44478500 IC CN UPN :282F-478500 TABLE OF CONTENTS Page SECTION 1. GENERAL INFORMATION4 SECTION 2. SUMMARY OF TEST RESULT5 SECTION 3. TEST AND MEASUREMENT DATA6 SECTION 4. INFORMATION ABOUT EUT AND SUPPORT EQUIPMENT(S)7 SECTION 5. SUPPORT EQUIPMENT8 SECTION 6. USED CABLE(S)9 SECTION 7. TEST CONFIGURATION10 SECTION 8. OPERATING CONDITION11 SECTION 9. MEASUREMENT UNCERTAINTY12 SECTION 10. TEST DATA 10.1 Carrier Output Power (Conducted)13 10.2 Unwanted Emissions (Transmitter Conducted)16 10.3 Field Strength of Spurious Radiation19 10.4 Emission Masks (Occupied Bandwidth)25 10.5 Audio Frequency Response / Audio Low Pass Filter (Voice Input)59 10.6 Modulation Limiting68 10.7 Frequency Stability (Temperature Variation)82 10.8 Frequency Stability (Voltage Variation)88 10.9Frequency Stability (Temperature Variation) AFC 90 10.10Frequency Stability (Voltage Variation) AFC 93 10.11Emission Limitations 95 10.12 Receiver Spurious Emissions(Radiated)125 10.13 Necessary Bandwidth and Emission Bandwidth129 10.1499% Occupied Bandwidth130 APPENDIXPHOTOGRAPHS Intertek Japan K.K.Page 3 of 139 FJP-TE031 Ver.1.0 Effective Date:January 4, 2011 Report No :15060364JKA-003 FCC ID:K44478500 IC CN UPN :282F-478500 SECTION 1. GENERAL INFORMATION TEST PERFORMED LocationKashima No.1 Test Site and No.12 Test Site EUT Received Date of Testto Standard AppliedFCC Part 2, 90 RSS-119 Issue 12 Measurement Method Deviation from Standard(s)Not applicable QUALIFICATIONS OF TESTING LABORATORY(Kashima Lab.) ACCREDITATIONSCOPELAB. CODERemarks VLACEMC TestingVLAC-008-1JAPAN BSMIEMC TestingSL2-IN-E-6008TAIWAN FILING VCCIEMC TestingA-0126JAPAN FCCEMC TestingJP0008 ICEMC TestingIC-2042K-3, IC-2042Q-12CANADA CB-SchemeEMC TestingTL222IECEE ABBREVIATIONS EUTDoC AMNISN LISNQ-P AMPAVG ATTPK ANTCal BBAN/A DIPLCD AEAssociated Equipment4LEVEL FSK 4LEVEL Frequency Shift Key GMSKCW ID FMC4FM PTTPush to TalkAFC Revision Summary June 30, 2015July 24, 2015 Attenuator AntennaCalibration Peak ANSI/TIA-603-D-2010 / RSS-119 Issue 12(2015), RSS-Gen Issue 4(2014) Impedance Stabilization Network Declaration of Conformity Not applicable or Not availableBroad…
