K6610353030VHF Transceiver

VX-4100 SERIES OPERATING MANUAL VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. VERTEX STANDARD HK LTD. Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong P2P1 TX/BUSY A 12 3 4 Congratulations! You now have at your fingertips a valuable communications tool: a VERTEX STAN- DARD two-way radio! Rugged, reliable and easy to use, your VERTEX STANDARD radio will keep you in constant touch with your colleagues for years to come, with negligible maintenance downtime. Please take a few minutes to read this manual carefully. The information presented here will allow you to derive maximum performance from your radio, in case ques- tions arise later on. We’re glad you joined the VERTEX STANDARD team. Call on us anytime, because communications is our business. Let us help you get your message across. NOTICE ! There are no owner-serviceable parts inside the transceiver. All service jobs must be referred to an authorized VERTEX STANDARD Service Represen- tative. Consult your Authorized VERTEX STANDARD Dealer for installa- tion of optional accessories. SAFETY/WARNING INFORMATION WARNING - DO NOT operate the VX-4100 radio when any person(s) (by- standers) outside the vehicle are within the distances shown in the chart at the bottom of this section. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd. The radio must be used in vehicle-mount configurations with a maximum op- erating duty factor not exceeding 50%, in typical Push-to-Talk configurations. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure condi- tions of its passengers and bystanders by maintaining the minimum separa- tion distance shown below. Failure to observe these restrictions will result in exceeding the FCC RF ex- posure limits. Antenna Installation: For rear deck trunk installation, the antenna must be located at least the fol- lowing distance away from rear-seat passengers in order to comply with the FCC RF exposure requirements. For roof top installations, the antenna must be placed in the center of the roof. 1.97 Feet ( 0.60 m ) Unsafe Radiation Distance VX-4101 VX-4100 SERIES OPERATING MANUAL1 INTRODUCTION The VX-4100 Series are full-featured FM transceiver designed for flexible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide vari- ety of applications with a wide range of operating capability provided by their lead- ing-edge design. Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VER- TEX STANDARD VPL-1 Programming Cable and CE59 Software. The pages which follow will detail the many advanced features provided on the VX- 4100 Series transceiver. After reading this manual, you may wish to consult with your Network Administrator regarding precise details of the configuration of this equipment for use in your application P2P1 TX/BUSY A 12 3 4 VX-4100 SERIES OPERATING MANUAL2 P2P1 TX/BUSY A 12 3 4 CONTROLS & CONNECTORS Front Panel Important! - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below discribe a typically-con- figured radio.
VOL Knob Turn this control clockwise to increase the volume.  Microphone Jack Connect the microphone plug to this jack.  Emergency Microphone The emergency microphone is located behind this small slit. When the emer- gency feature is activated, this microphone is enabled.  [ MON ], [ A ], [
] Buttons (Programmable Function Buttons) These buttons can be set up for special applications, such as High/Low power selection, Monitor, Talk-Around, etc., as determined by your network require- ments and programmed by your VERTEX STANDARD dealer.  ( POWER ) Button Press and hold in this button for 2 seconds to toggle the transceiver’s power “on” and “off.”
 VX-4100 SERIES OPERATING MANUAL3  TX/BUSY Indicator Indicates the transceiver’s Transmit/Receive Status. Steady Red: Transmitting in progress Steady Green: Signaling Off Blinking Green: Busy Channel/Squelch Off  Channel Number Indicator Indicates the operating channel.  Transceiver Status Indicator The “P1” and “P2” indicators show current transceiver status, which can be customized via programming by your VERTEX STANDARD dealer to meet your communications/network requirements. The possible “P1” and “P2” dis- plays are explained below. CONTROLS & CONNECTORS MONI SCAN Channel +4 CH LOW TA ( Talk Around ) Encryption Disable ( Requires optional Unit ) Emergency HOME Horn Alert Public Adress Key Lock EXT ACC REC/PLAY INDICATOR P1P2 This indicator blinks when CTCSS- or DCS- controlled squelch is disabled. The indicator is Illuminated constantly while the audio is pass- ing normally. Illuminates the indicator when the operating channel is selected on the SCAN channel. Illuminates the indicator when the radio recalls the alternate channel list. Illuminates the indicator when the radio’s trans- mitter is set to the “Low Power” mode. Illuminates the indicator when the “Talk Around” function is activated. Illuminates the indicator when the “Voice Scrambler” function is disabled temporarily. Illuminates the indicator when the “Emergency” feature is activated. Illuminates the indicator when you recall the Home group/channel. Illuminates the indicator when the “Horn Alert” feature is activated. Illuminates the indicator when the radio is turned …

Text truncated - open the document above for the full version.

November 13, 2004 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-4101-0-10/VX-4201-0-10 (FCC ID: K6610353030) Gentlemen: Part 15.19 Compliance Statement is placed on the bottom of case. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

November 13, 2004 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-4101-0-10/VX-4201-0-10 (FCC ID: K6610353030) Gentlemen: A. Part 15.21 Compliance Statement Drawing: B. Part 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on inside back cover) Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device. 20mm 97mm

November 13, 2004 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-4101-0-10/VX-4201-0-10 (FCC ID: K6610353030) Gentlemen: The equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. Programming of this product’s transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personal. The operator cannot be program transmit frequencies using the equipment’s external operation controls. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Front view (FRONT-C-UNIT (for VX-4101)) Front view (FRONT-D-UNIT (for VX-4201)) FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Rear view Left view FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Right view Top view FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Bottom view Microphone FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. DC Power Cable

VX-4101-0-10 / VX-4201-0-10VX-4101-0-10 / VX-4201-0-10 LABEL DRAWINGLABEL DRAWING Vertex Standard Co., Ltd.Vertex Standard Co., Ltd. ID / Part 15.19 and CAUTION drawings ID drawing Part 15.19 and CAUTION drawings Label location VX-4101-0-10 VERTEX STANDARD CO., LTD. MADE IN JAPAN IC: 511B-10353030 FCC ID: K6610353030 4909959000000 SER NO. 00000000 ! ! Device restricted to occupational use to satisfy FCC RF exposure compliance. See owner's manual for specific operating requirement CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. VX-4201-0-10 VERTEX STANDARD CO., LTD. MADE IN JAPAN IC: 511B-10353030 FCC ID: K6610353030 4909959000000 SER NO. 00000000

FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Removed top cover Inside of EUT with shield case FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Inside of EUT without shield case Side-A of RF-UNIT FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Side-B of RF-UNIT with shield case Side-B of RF-UNIT without shield case FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Inside of front panel with PWB (FRONT-D-UNIT) Inside of front panel with PWB (FRONT-C-UNIT) FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Side-A of FRONT-D-UNIT with LCD Side-A of FRONT-D-UNIT without LCD FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Side-B of FRONT-D-UNIT Front of LCD FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Back of LCD Side-A of FRONT-C-UNIT FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Side-B of FRONT-C-UNIT Inside of front panel (for FRONT-D-UNIT) FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Inside of front panel (for FRONT-C-UNIT) Inside of chassis FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Inside of top case Inside of top cover FCC ID: K6610353030/IC ID: 511B-10353030 Vertex Standard Co., Ltd. Inside of microphone

VX-4100 SERIES OPERATING MANUAL VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. VERTEX STANDARD HK LTD. Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong P2P1 TX/BUSY A 12 3 4 Congratulations! You now have at your fingertips a valuable communications tool: a VERTEX STAN- DARD two-way radio! Rugged, reliable and easy to use, your VERTEX STANDARD radio will keep you in constant touch with your colleagues for years to come, with negligible maintenance downtime. Please take a few minutes to read this manual carefully. The information presented here will allow you to derive maximum performance from your radio, in case ques- tions arise later on. We’re glad you joined the VERTEX STANDARD team. Call on us anytime, because communications is our business. Let us help you get your message across. NOTICE ! There are no owner-serviceable parts inside the transceiver. All service jobs must be referred to an authorized VERTEX STANDARD Service Represen- tative. Consult your Authorized VERTEX STANDARD Dealer for installa- tion of optional accessories. SAFETY/WARNING INFORMATION WARNING - DO NOT operate the VX-4100 radio when any person(s) (by- standers) outside the vehicle are within the distances shown in the chart at the bottom of this section. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd. The radio must be used in vehicle-mount configurations with a maximum op- erating duty factor not exceeding 50%, in typical Push-to-Talk configurations. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure condi- tions of its passengers and bystanders by maintaining the minimum separa- tion distance shown below. Failure to observe these restrictions will result in exceeding the FCC RF ex- posure limits. Antenna Installation: For rear deck trunk installation, the antenna must be located at least the fol- lowing distance away from rear-seat passengers in order to comply with the FCC RF exposure requirements. For roof top installations, the antenna must be placed in the center of the roof. 1.97 Feet ( 0.60 m ) Unsafe Radiation Distance VX-4101 VX-4100 SERIES OPERATING MANUAL1 INTRODUCTION The VX-4100 Series are full-featured FM transceiver designed for flexible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide vari- ety of applications with a wide range of operating capability provided by their lead- ing-edge design. Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VER- TEX STANDARD VPL-1 Programming Cable and CE59 Software. The pages which follow will detail the many advanced features provided on the VX- 4100 Series transceiver. After reading this manual, you may wish to consult with your Network Administrator regarding precise details of the configuration of this equipment for use in your application P2P1 TX/BUSY A 12 3 4 VX-4100 SERIES OPERATING MANUAL2 P2P1 TX/BUSY A 12 3 4 CONTROLS & CONNECTORS Front Panel Important! - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below discribe a typically-con- figured radio.
VOL Knob Turn this control clockwise to increase the volume.  Microphone Jack Connect the microphone plug to this jack.  Emergency Microphone The emergency microphone is located behind this small slit. When the emer- gency feature is activated, this microphone is enabled.  [ MON ], [ A ], [
] Buttons (Programmable Function Buttons) These buttons can be set up for special applications, such as High/Low power selection, Monitor, Talk-Around, etc., as determined by your network require- ments and programmed by your VERTEX STANDARD dealer.  ( POWER ) Button Press and hold in this button for 2 seconds to toggle the transceiver’s power “on” and “off.”
 VX-4100 SERIES OPERATING MANUAL3  TX/BUSY Indicator Indicates the transceiver’s Transmit/Receive Status. Steady Red: Transmitting in progress Steady Green: Signaling Off Blinking Green: Busy Channel/Squelch Off  Channel Number Indicator Indicates the operating channel.  Transceiver Status Indicator The “P1” and “P2” indicators show current transceiver status, which can be customized via programming by your VERTEX STANDARD dealer to meet your communications/network requirements. The possible “P1” and “P2” dis- plays are explained below. CONTROLS & CONNECTORS MONI SCAN Channel +4 CH LOW TA ( Talk Around ) Encryption Disable ( Requires optional Unit ) Emergency HOME Horn Alert Public Adress Key Lock EXT ACC REC/PLAY INDICATOR P1P2 This indicator blinks when CTCSS- or DCS- controlled squelch is disabled. The indicator is Illuminated constantly while the audio is pass- ing normally. Illuminates the indicator when the operating channel is selected on the SCAN channel. Illuminates the indicator when the radio recalls the alternate channel list. Illuminates the indicator when the radio’s trans- mitter is set to the “Low Power” mode. Illuminates the indicator when the “Talk Around” function is activated. Illuminates the indicator when the “Voice Scrambler” function is disabled temporarily. Illuminates the indicator when the “Emergency” feature is activated. Illuminates the indicator when you recall the Home group/channel. Illuminates the indicator when the “Horn Alert” feature is activated. Illuminates the indicator when the radio is turned …

Text truncated - open the document above for the full version.

1/3 FCC ID: K6610353030/IC ID: 511B-10353030 VX-4101-0-10/VX-4201-0-10Component Applications Address Device nameDescriptionApplication [RF-UNIT] Q 1001 TransisterDTC114TEDTMF DEC INPUT SW Q 1002 Transister2SC5226-4/5TX Buff AMP Q 1004 ICNJM7808DL1A8V Regurator Q 1005 ICTDA1519CTHAF Power AMP Q 1006 FETRTQ030P02DC SW Q 1007 TransisterDTA144EEDC SW Q 1008 Dual TransisterXP1501TX8V DC SW Q 1009 TransisterDTC144EEAF AMP MUTE SW Q 1010 TransisterCPH6102TX8V DC SW Q 1011 TransisterDTC114TEDC SW Q 1012 TransisterDTC144EEIGN SENS DC SW Q 1013 Dual TransisterUMG2NTRX SW Q 1014 ICNJU4053BVFRONT/EXT MIC SW/Normal/Flat SW/ADJ AF/DTMF SW Q 1015 FETRTQ030P02DC SW Q 1016 ICNJU4053BVPre-Emphasis SW/EXT AF OUT Normal/Flat Select SW/PA SW Q 1017 TransisterUN911FRX5V DC SW Q 1018 TransisterDTC144EETX8V Protection Q 1019 TransisterDTC114TERX5V Protection Q 1020 Transister2SA1774Q1022 Bias Q 1021 ICLA8630MCompand/Expand IC Q 1022 Transister2SC3357RF AMP Q 1023 TransisterDTC144EEDC SW Q 1024 TransisterDTC144EECompand/Expand ON/OFF SW Q 1025 Transister2SC4617HOOK/FLASH Write Select SW Q 1026 Transister2SC4617C_DATA/FLASH Write Select SW Q 1027 Transister2SC4617PTT/FLASH Write Select SW Q 1028 FETRA13H1317MTX Power Amp Q 1029 ICM62364FPD/A Q 1030 TransisterDTC144EECLONE SW Q 1031 TransisterDTA124EECLONE SW Q 1032 TransisterDTC144EERX Emphasis SW Q 1033 TransisterDTC144EEPower OFF SW Q 1034 ICBD6111FV-5V Regurator Q 1035 ICSPM5001Mixer IC Q 1036 ICNJM2125F-VCV Control Q 1037 ICAK2345Base Band IC Q 1038 Transister2SC5226-4VCO Buff AMP Q 1039 Dual TransisterUMC5NRX VCO SW Q 1044 Transister2SA1774Ripple Filter Q 1045 TransisterDTC114TEClock Shift Q 1046 Transister2SC3357-T2 RFIF AMP Q 1047 TransisterDTC144EEVCO Buff AMP SW Q 1049 Transister2SC5226-4VCO Buff AMP Q 1051 TransisterDTC144EERevers Tone SW Q 1053 TransisterDTC144EERX VCO SW Q 1054 FET2SK508RX VCO OSC Q 1055 TransisterDTC144EEBuff AMP SW Q 1056 TransisterDTC114TETX VCO SW Q 1057 Transister2SC5226-4Buff AMP Q 1058 Transister2SC3356TX VCO OSC Q 1059 Transister2SC5226-4IF AMP Q 1060 ICTK71735SCL3.5V Regurator Q 1061 Dual TransisterXN1501CONT5V AVR Q 1062 Transister2SB1201SCONT5V AVR Q 1063 ICBU4066BCFVOPTION SW/DTMF DEC INPUT SW/De-emphasis SW Q 1064 ICLC73881MDTMF DEC IC Q 1065 ICS-80835CNMC-B8URESET IC Q 1066 Quadruple OP-AMPNJM12902VEXT MIC AMP/WXT AF AMP/EXT RSSI AMP/FRONT MIC AMP Q 1067 Transister2SC4617Ripple Filter Q 1068 ICBU4066BCFVEXT MIC GAIN Select SW/Compand SW/ AF MUTE/De-emphasi s Q 1072 Transister2SC4617RESET Q 1073 TransisterDTC144EEACC4 OUTPUT SW Q 1074 Quadruple OP-AMPNJM12902VVCO MOD AMP/REF MOD AMP/RX TUNE DC AMP/BIAS Q 1075 TransisterDTC114TEClock Shift Q 1076 Quadruple OP-AMPNJM12902V5TONE DEC/DCS DEC Q 1077 TransisterDTC144EEACC3 INPUT SW Q 1078 FET2SK880GRVCV Buff AMP Q 1079 ICTA31136FNIF System IC Q 1080 ICBR93L66RFVMEEPROM Q 1081 TransisterDTC144EEACC3 OUTPUT SW Q 1082 TransisterDTC144EEACC2 INPUT SW Q 1083 ICLC87F74C8ACPU Q 1084 TransisterDTC144EEACC2 OUTPUT SW Q 1085 ICSA7025DKPLL IC Vertex Standard Co., Ltd. 2/3 FCC ID: K6610353030/IC ID: 511B-10353030 VX-4101-0-10/VX-4201-0-10Component Applications Address Device nameDescriptionApplication Q 1086 TransisterDTC144EEACC1 OUTPUT SW Q 1087 TransisterDTC144EEACC1 INPUT SW Q 1088 Quadruple OP-AMPNJM12902VMIC AMP/RX AF buff AMP/Freq Cntl DC AMP Q 1089 Quadruple OP-AMPNJM12902VReverceTone/DCS/Reverce Tone DEC Q 1090 Dual OP-AMPNJM12904VAPC Q 1091 Transister2SC4617SQL Noise AMP Q 1092 TransisterDTC144EEW/N SW Q 1093 TransisterDTC144EEW/N SW D 1001 DiodeUM9957FANT SW D 1002 Surge AbsorberP6KE18ASurge Protector D 1003 Varactor Diode1SV279RX tune D 1004 Varactor Diode1SV279RX tune D 1006 DiodeUM9957FANT SW D 1007 Diode1SS400Surge Protector D 1008 Varactor Diode1SV279RX tune D 1009 Varactor Diode1SV279RX tune D 1010 Varactor Diode1SV279RX tune D 1011 Diode1SS400Surge Protector D 1012 Varactor Diode1SV279RX tune D 1013 Dual DiodeHSM88ASAPC Voltage Detect D 1014 Dual DiodeHSM88ASAPC Voltage Detect D 1015 Diode1SS400Surge Protector D 1016 Diode1SS400Reverse Protection D 1017 Diode1SS400Reverse Protection D 1018 Diode1SS400Reverse Protection D 1020 Diode1SS400Reverse Protection D 1021 Dual DiodeDA221Protector D 1022 Dual DiodeDAN222TX/RX SW D 1023 Diode1SS400Current Steering D 1024 Dual DiodeDA221Limitter D 1029 Dual DiodeDA221Limitter D 1030 Varactor DiodeHVC383BModulator D 1031 Diode1SS400Reverse Protection D 1032 Diode1SS400Reverse Protection D 1033 Diode1SS400Reverse Protection D 1034 Dual DiodeDA221Limitter D 1035 Varactor Diode1SV282RX VCO Freq Cont D 1036 Varactor Diode1SV282RX VCO Freq Cont D 1037 Varactor Diode1SV282RX VCO Freq Cont D 1038 Dual DiodeDA221Limitter D 1039 Varactor Diode1SV282RX VCO Freq Cont D 1040 Diode1SS400Current Steering D 1041 Varactor DiodeHVC383BTX VCO Freq Cont D 1042 Varactor DiodeHVC383BTX VCO Freq Cont D 1043 Varactor DiodeHVC383BTX VCO Freq Cont D 1044 Dual DiodeDA221RESET D 1045 Dual DiodeDAN222MAIN/SUB BAND SW D 1046 Varactor DiodeHVC383BTX VCO Freq Cont D 1047 Zener DiodeUDZSSurge Protector D 1048 Dual DiodeDAN222MAIN/SUB BAND SW D 1049 Diode1SS400Reverse Protection D 1050 Zener DiodeUDZSSurge Protector D 1051 Diode1SS400UL DET D 1052 Dual DiodeDAN222W/N SW D 1053 Zener DiodeUDZSSurge Protector D 1054 Dual DiodeDAN222W/N SW D 1055 Zener DiodeUDZSSurge Protector D 1056 Dual DiodeDA221Surge Protector D 1057 Dual DiodeDA221Surge Protector D 1058 Dual DiodeDA221Surge Protector D 1059 Dual DiodeDA221SQL Noise DET D 1060 Dual DiodeDA221Surge Protector D 1061 Dual DiodeDA221SQL Noise DET D 1062 Zener DiodeUDZSSurge Protector D 1063 Zener DiodeUDZSSurge Protector D 1064 Zener DiodeUDZSSurge Protector D 1065 Zener DiodeUDZSSurge Protector D 1066 Zener DiodeUDZSSurge Protector D 1067 Dual DiodeDA221Noise Detection D 1068Diode1SS400Reverse Protection [FRONT-C-UNIT] Q 4001 TransisterDTC144EETX LED SW Q 4002 ICTC4S66FEmergency MIC SW Q 4003 TransisterDTC144EEBUSY LED SW Q 4004 ICBU4094BCFVPANEL Control Vertex Standard Co., Ltd. 3/3 FCC ID: K6610353030/IC ID: 511B-1035…

Text truncated - open the document above for the full version.

VX-4101/4201-D0-10 RF Exposure Calculations 1) Calculation/10 W A: Frequency Band 150 MHz B: RF Exposure Limit 0.2 mW/cm 2 = 2 W/m 2 C: RF Power Output 10 W D: Antenna Gain 0 dBd (numeric gain of 1.64) E: Duty Cycle 50 % = 0.5 Safe Distance = SQRT (C x D x E/4π x B) (@ Above condition) = SQRT (10 x 1 x 0.5/4π x 2) = 0.57 m 2) Safe Distance (@ VX-4204-D0-50 (50W), Test Report [MFA p0340005, d0350004]) F: Safe Distance = 0.6 m 3) RF Exposure (@ F, 0.6 m) G: RF Exposure = C x D x E/4π x F 2 = 10 x 1.64 x 0.5/4π x 0.6 2 = 1.11 W/m 2 = 0.18 mW/cm 2 Therefore, G < B

Page 1 of 48 REPORT ON Radio testing of the VERTEX STANDARD VX-4201-0-10 In accordance with ANSI/TIA/EIA-603, RSS-119 November 2004Report number TA000171 Vertex Standard Co., Ltd. GENERAL INFORMATION TRANSMITTERS Switchable x Variable N/A RＥＣＥＩＶERS This report was prepared by Vertex Standard Co., Ltd. 13.6[V] Collector Current:2.7[A] MANUFACTURER:Vertex Standard Co., Ltd. NUMBER OF CHANNELS: FCC ID/IC ID: TRADE NAME: VHF FM Transceiver 4M000001 TYPE OF EMISSION: FREQUENCY RANGE: RSS-119 VOLTAGE RQUIREMENTS: SERIAL NUMBER: SPECIFICATION ARE REFERENCED: POWER OUTPUT RATING: 134 2 174to to10 [MHz] [W] 16K0F3E , 11K0F3E [MHz] [W] [Ω] [Ω] 50[Ω] [MHz] [kHz] 50.85 450 1st 2nd [W]AUDIO OUTPUT POWER: OUTPUT IMPEDANCE (SP):[Ω]4 12 Report number TA000171 Page 2 of 48 EUT DESCRIPTION: 13.6[V] VX-4201-0-10 K6610353030/511B-1353030 VERTEX STANDARD MODEL NAME: INPUT IMPEDANCE (MIC): MAXIMUM POWER RATING: INPUT IMPEDANCE (RF): INTERMEDIATE FREQUENCIES: FREQUENCY RANGE: OUTPUT IMPEDANCE (RF): Collector Voltage: Date 10 / November /2004 Test performed by N.Tamakoshi 174to134 50 600 300 DC 501 ANSI/TIA/EIA-603 Vertex Standard Co., Ltd. Report number TA000171Page 3 of 48 VX-4201-0-10 Channel Settings HighLow 1134_WH134.000134.00025k10W 2154_WH154.000154.00025k10W 3174_WH174.000174.00025k10W 4134_NH134.000134.00012.5k10W 5154_NH154.000154.00012.5k10W 6174_NH174.000174.00012.5k10W 7134_WL134.000134.00025k2W 8154_WL154.000154.00025k2W 9174_WL174.000174.00025k2W 10134_NL134.000134.00012.5k2W 11154_NL154.000154.00012.5k2W 12174_NL174.000174.00012.5k2W 13 14 15 16 17 18 19 20 Power Transmit Frequency [MHz] CH No. Receive Frequency [MHz] CH SpacingShown on LCD Vertex Standard Co., Ltd. NAME OF TEST:R.F. Power Output (Conducted) SPECIFICATION: 47 CFR 2.1046 (a) GUIDE: ANSI/TIA/EIA-603, Paragraph 2.2.1 TEST EQUIPMENT: As per attached page The EUT was connected to a resistive coaxial attenuator of normal load impedance, and the modulated output powerwas measured by means of an R.F. power meter. Measurement accuracy is ± 4% Report number TA000171 Page 4 of 48 MEASUREMENT PROCEDURE 11.000 10.7502.270 2.150 2.300154.000 174.000 2 3 1. 2. MEASUREMENT RESULTS 134.000 CHANNEL R.F. POWER, WATTS NOMINAL, MHz 110.410 HIGHLOW Vertex Standard Co., Ltd. (2)(3)(4) Serial NumberDescription (5) Report number TA000171 Page 5 of 48 TRANSMITTER POWER CONDUCTED MEASUREMENTS TEST 1: R.F. POWER OUTPUT TEST 2: FREQUENCY STABILITY Power Supply Instruments Test Sample (1) (5) FREQUENCY COUNTER Agilent 8901B FREQUENCY MODE*** *** *** *** Agilent 8901B POWER MODE*** WEINSCHELL 49-10-43 (2) RF COUPLERADVANTEST TR4153 (3) POWER SENSORAgilent 8482B (1) COAXUAL ATTENUATOR (4) POWER METER Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) SPECIFICATION: 47 CFR 2.1051 GUIDE: ANSI/TIA/EIA-603, Paragraph 2.2.13 TEST EQUIPMENT: As per attached page The emissions were measured for the worst case as follows: (a): within a band of frequencies defined by the carrier frequency plus and minus one channel. (b): from the lowest frequency generated in the EUT and to at least the 10th harmonic of the carrier frequency, or 40GHz, whichever is lower. The magnitude of spurious emissions that are attenuated more than 20dB below the permissible value need not be specified. MEASUREMENT RESULTS: FREQUENCY OF CARRIER, MHz=,, SPECTRUM SEARCHED, GHz=0 to 10 x Fc MAXIMUM RESPONSE, Hz= ALL OTHER EMISSIONS=>= 20dB BELOW LIMIT MEASUREMENT PROCEDURE 3. 1. 2. 134154174 Report number TA000171 Page 6 of 48 2600 Vertex Standard Co., Ltd. (2) COAXUAL ATTENUATORAgilent 8498A*** (3) SPECTRUM ANALYZERADVANTEST TR4173*** (1) *** (3) Serial Number (2) COAXUAL ATTENUATORWEINSCHELL 49-10-43 TEST 2: OUT-OF-BAND SPURIOUS TRANSMITTER SPURIOUS EMISSION TEST 1: OCCUPIED BANDWIDTH (IN-BAND SPURIOUS) Test Sample (2) InstrumentsDescription Power Supply Report number TA000171 Page 7 of 48 (1) AUDIO GENERATORAgilent 8903B*** Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(50+10xLOG(P)) =(Watts ) -(50+10xLOG(P)) =(Watts ) High Power 9.4-29.4-69.4 MARGIN, dBmdBcdB LEVEL,LEVEL, -532 FREQUENCY EMISSION, MHz 268.0000 -6010 FREQUENCY TUNED, MHz 134.0000 Report number TA000171 Page 8 of 48 Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(50+10xLOG(P)) =(Watts ) -(50+10xLOG(P)) =(Watts ) Low Power dB < -40< -73 dBc LEVEL,MARGIN, 2 10 < -73 174.0000< -40< -73 -60 -53 FREQUENCYLEVEL, EMISSION, MHzdBm 154.0000< -40 134.0000 FREQUENCY Report number TA000171 Page 9 of 48 TUNED, MHz Vertex Standard Co., Ltd. NAME OF TEST:Field Strength of Spurious Radiation SPECIFICATION: 47 CFR 2.1053 (a) GUIDE: ANSI/TIA/EIA-603, Paragraph 1.2.12 Definition: Radiated spurious emissions are emissions from the equipment when transmitting load on a frequency or frequencies which are outside an occupied band sufficient to ensure transmission of information of required quality for the class of communications desired. Method of measurement Connect the equipment as illustrated. Adjust the spectrum analyzer for the following settings: 1)Resolution Bandwidth <= 3kHz 2)Video Bandwidth >= 10kHz 3)Sweep Speed <= 2000Hz/second 4)Detector Mode = Positive Peak Place the transmitter to be tested on the turntable in the standard test site. The transmitter is transmitting into a non-radiating load which is placed on the turntable. The RF cable to this load should be of minimum length. STANDARD TEST SITE For each spurious measurment the test antenna should be adjusted to the correct length for the frequency involved. This length maybe determined from a calibration ruler supplied with the equipment. Measurements shall be made from the lowest radio frequency generated in the…

Text truncated - open the document above for the full version.
