K6630653Y3DVHF FM Marine Transceiver

ECLIPSE GPS GX1410GPS ECLIPSE GX1410  Meets ITU-R M.493-16 class D DSC (Digital Selective Calling)  Input and Output of GPS information to NMEA 0183 compatible devices  Integrated 66 Channel Internal GPS receiver (GX1410GPS only)  Built in Separate Receiver for CH70 (Receiving DSC Calls)  Automatic DSC polling of up to 6 ships GPS positions*  Auto DSC channel selection & DSC test call  DSC distress, individual, group, all ships, position request and position report  Large Viewable Display, Easy to Mount, Submersible IPX8 (5 feet or 1.5 m for 30 minutes) Noise canceling microphone with channel change, 16/S and H/L key buttons  GPS position and time shown on a full dot matrix display*  Preset Key used to recall up to 10 favorite channels  Programmable scan, priority scan, and Multi Watch (Dual Watch or Triple Watch)  Noise cancelling microphone with channel change selection, 16/S and H/L keys *External GPS device required for GX1410. Owner’s Manual TABLE OF CONTENTS QUICK REFERENCE ...........................................2 1 GENERAL INFORMATION ............................ 3 2 PACKING LIST .............................................. 3 3 OPTIONAL ACCESSORIES .......................... 3 4 ONLINE WARRANTY REGISTRATION ........ 4 5 Safety Precautions (Be Sure to Read) ........ 4 6 GETTING ST ARTED ...................................... 6 6.1 ABOUT VHF RADIO .................................... 6 6.2 SELECTING AN ANTENNA ......................... 6 6.3 Coaxial Cable ............................................... 6 6.4 DISTRESS AND HAILING (CHANNEL 16) .. 7 6.5 CALLING ANOTHER VESSEL ( CHANNEL 16 OR 9 ) ................................... 8 6.6 Accuracy of COG* ........................................ 8 7 CONTROLS AND INDICATORS .................... 9 7.1 FRONT PANEL ............................................ 9 7.2 MICROPHONE .......................................... 11 7.3 REAR PANEL ............................................. 12 8 INSTALLATION ............................................ 13 8.1 SAFETY / WARNING INFORMATION ....... 13 8.2 LOCATION ................................................. 13 8.3 MOUNTING THE RADIO ........................... 14 8.3.1 Supplied Mounting Bracket ....................... 14 8.3.2 Optional MMB-84 Flush Mount Bracket .... 14 8.4 ELECTRICAL CONNECTIONS ................. 15 8.5 CONNECTION OF EXTERNAL DEVICES TO THE RADIO ......................... 16 8.5.1 Connecting the NMEA 0183/ NMEA 0183-HS to the Radio .................... 16 8.5.2 Accessory Cables ..................................... 17 8.5.3 Connection to External GPS or Chart Plotter .............................................. 17 8.5.4 GPS Input - optional SCU-31 External GPS Antenna ............................................ 18 8.5.5 Connection to External Speaker ............... 18 8.5.6 Connecting the SCU-38 External GPS Antenna to the Radio (GX1410GPS only) ................................... 18 8.6 INITIAL SETUP REQUIRED WHEN TURNING ON THE POWER FOR THE FIRST TIME ............................................... 19 8.6.1 Maritime Mobile Service Identity (MMSI) .. 19 8.7 CHECKING GPS CONNECTIONS (GPS STATUS DISPLAY) ........................... 20 8.8 GPS CONFIGURATION ............................. 22 8.8.1 Changing the GPS Time ........................... 22 8.8.2 Changing the Time Area ........................... 22 8.8.3 Changing the Time Format ....................... 23 9 BASIC OPERATION .................................... 24 9.1 TURNING ON AND OFF THE TRANSCEIVER .......................................... 24 9.2 RECEPTION .............................................. 24 9.3 TRANSMISSION ........................................ 24 9.3.1 Transmit Power ......................................... 24 9.4 TRANSMIT TIME-OUT TIMER ( TOT ) ........ 25 9.5 BASIC OPERATION OF THE SETUP MENU ............................................ 25 9.6 SIMPLEX/DUPLEX CHANNEL USE .......... 26 9.7 CHANNEL GROUP .................................... 26 9.8 NOAA WEATHER CHANNELS (in USA and Canada only) .......................... 27 9.8.1 NOAA Weather Alert ................................. 27 9.8.2 NOAA Weather Alert Testing ..................... 27 9.9 MULTI WATCH (TO PRIORITY CHANNEL) ........................ 28 9.9.1 Setting up the Multi Watch Operation ....... 28 9.9.2 Starting the Dual Watch ............................ 28 9.10 SCANNING .............................................. 29 9.10.1 Selecting the Scan Type ........................... 29 9.10.2 Programming Scan Memory ..................... 30 9.10.3 Memory Scanning (M-SCAN) ................... 30 9.10.4 Priority Scanning ( P-SCAN ) ...................... 31 9.11 PRESET CHANNELS: INST ANT ACCESS .................................. 31 9.11.1 Programming ............................................ 31 9.11.2 Operation .................................................. 32 9.11.3 Deletion ..................................................... 32 10 DIGITAL SELECTIVE CALLING (DSC) .... 33 10.1 GENERAL ................................................ 33 10.2 DISTRESS ALERT ................................... 33 10.2.1 Transmitting a DSC Distress Alert ............. 33 10.2.2 Receiving a Distress Alert ......................... 37 10.3 ALL SHIPS CALL ..................................... 38 10.3.1 Transmitting an All Ships Call ................... 38 10.3.2 Receiving an All Ships Call ....................... 39 10.3.3 Setting up the All Ships Call Ringer .......... 39 10.4 INDIVIDUAL CALL ................................... 40 10.4.1 Setting up the Individual / Position Call Directory ............................... 40 10.4.2 Setting up Individual Call Reply ................ 41 10.4.3 Setting up the Individual Call Acknowledgment ....................................... 42 10.4.4 T ransmitting an Individual Call .................. 42 10.4.5 Receiving an Individual Call ...................... 44 10.4.6 Setting up the Individual Call Rin…

Text truncated - open the document above for the full version.

YAESU MUSEN CO., LTD. Covered Equipment Certification Attestation Letter 7/30/2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: K6630653Y3D (YAESU MUSEN CO., LTD.) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. (YAESU MUSEN CO., LTD.) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Masatoshi Muraishi Title: - Company Name: YAESU MUSEN CO., LTD. Date: 7/30/2024

2024-08-01 FCC ID: K6630653Y3D Product Name: VHF FM Marine Transceiver Gentlemen: By means of this document, YAESU MUSEN CO., LTD. declares the following Marine Radio model numbers: GX1410GPS, GX1410 are in compliance with the following DSC standards: Part 2 & 80 ITU-R M.493-13 IEC 60945 IEC 62238 Sincerely, Contact: Masatoshi Muraishi Applicant: YAESU MUSEN CO., LTD.

2024-07-30 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd / Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China / Xu Yang,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with YAESU MUSEN CO., LTD. / Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan. Agency agreement expiration date: 2025-07-30 By: Masatoshi Muraishi Signature Printed Title: - On behalf of : YAESU MUSEN CO., LTD. Telephone: +81-3-6410-8121

2024-07-30 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: K6630653Y3D Product Name: VHF FM Marine Transceiver Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  BOM  Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. By: Masatoshi Muraishi Signature Printed Title: - On behalf of : YAESU MUSEN CO., LTD. Telephone: +81-3-6410-8121

Differences declaration 2024-08-01 FCC ID: K6630653Y3D Product Name: VHF FM Marine Transceiver Model Numbers: GX1410GPS, GX1410 To whom concern: Our company YAESU MUSEN CO., LTD. Here by declares: Multi-model differences are as follows: Main model: Listed model: Main Model No.: GX1410GPS Schematic diagram 电路原理图 PCB layout PCB走线 Appearance 外观结构 Model name 型号命名 Other 其它 Series Model No.: GX1410   ∆ ∆  Note: 1. If it is a same, mark it as  如相同, 则标识为 2. If there is a difference, mark it as ∆; If there are differences other than model name differences, please describe them in detail 如有差异，则标注为∆; 除了型号命名差异外，如有其它差异则需要在下面详细描述 Model No.: Differences describe Main model no.: GX1410GPS Series model no.: GX1410 The difference between GX1410GPS and GX1410 lies in the presence or absence of GPS function, as well as differences in appearance color. The schematic and PCB layout are completely identical. By: Masatoshi Muraishi Signature Printed Title: - On behalf of : YAESU MUSEN CO., LTD.

Report No.: CHTW24070094 Page: 32 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7. EXTERNAL AND INTERNAL PHOTOS 7.1. External Photos GX1410GPS Report No.: CHTW24070094 Page: 33 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070094 Page: 34 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) GX1410 Report No.: CHTW24070094 Page: 35 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09)

GX1410GPS

Report No.: CHTW24070094 Page: 36 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7.2. Internal Photos GX1410GPS Report No.: CHTW24070094 Page: 37 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070094 Page: 38 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070094 Page: 39 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) GX1410 Report No.: CHTW24070094 Page: 40 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070094 Page: 41 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070094 Page: 42 of 42 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 8. APPENDIX REPORT

Page: 1 of 14 TEST REPORT For FCC Part15B Report No. .......................................: CHTW24070098 Report verification: Project No. ..................................: SHT2407005804W FCC ID ............................................. : K6630653Y3D Applicant’s name ........................... : YAESU MUSEN CO., LTD. Address ............................................. : Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan Product Name ................................ : VHF FM Marine Transceiver Trade Mark ....................................... : Standard Horizon Model No. ......................................... : GX1410GPS Listed Model(s) ................................. : GX1410 Standard ......................................... : FCC CFR Title 47 Part 15 Subpart B Date of receipt of test sample...........: Jul.09, 2024 Date of testing..............................: Jul.10, 2024 - Jul.22, 2024 Date of issue.................................: Jul.23, 2024 Result .................. ........................: Pass Compiled by (position+printed name+signature) ... : File administrators Caspar Chen Supervised by (position+printed name+signature) ... : Project Engineer Caspar Chen Approved by (position+printed name+signature) ... : RF Manager Xu yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No.: CHTW24070098 Page: 2 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) Contents 1. TEST STANDARDS AND REPORT VERSION ........................................... 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION .................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Testing Laboratory Information 5 4. TEST CONFIGURATION ................................................................. 6 4.1. Descriptions of test mode 6 4.2. Support unit used in test configuration 6 4.3. Environmental conditions 6 4.4. Statement of the measurement uncertainty 6 4.5. Equipments Used during the Test 7 5. TEST CONDITIONS AND RESULTS ..................................................... 8 5.1. Conducted Emissions 8 5.2. Radiated Emissions 9 6. TEST SETUP PHOTOS OF THE EUT .................................................. 13 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................. 14 Report No.: CHTW24070098 Page: 3 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC CFR Title 47 Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version information Revision No. Date of issue Description N/A 2024-07-23 Original Report No.: CHTW24070098 Page: 4 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer 5.1 Conducted Emissions 15.107(a) N/A - 5.2 Radiated Emissions 15.109(a) PASS Yifan Wang Note: #1: The test result does not include measurement uncertainty value Report No.: CHTW24070098 Page: 5 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 3. SUMMARY 3.1. Client Information Applicant: YAESU MUSEN CO., LTD. Address: Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan Manufacturer: YAESU MUSEN CO.,LTD. Address: 43 Utsuroda, Morijuku, Sukagawa-shi,Fukushima 962-0001 Japan 3.2. Product Description Main unit information: Product Name: VHF FM Marine Transceiver Trade Mark: Standard Horizon Model No.: GX1410GPS Listed Model(s): GX1410 Power supply: DC 13.8V Hardware version: N/A Software version: N/A 3.3. Testing Laboratory Information Laboratory Name Shenzhen Huatongwei International Inspection Co., Ltd. Laboratory Location Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Connect information: Tel: 86-755-26715499 E-mail: [email protected] http://www.szhtw.com.cn Qualifications Type Accreditation Number FCC Registration Number 762235 FCC Designation Number CN1181 Report No.: CHTW24070098 Page: 6 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 4. TEST CONFIGURATION 4.1. Descriptions of test mode Test mode Description Test mode O1 Power on EUT and keep it turned on 4.2. Support unit used in test configuration The EUT has been associated with peripherals and configuration operated in a manner tended to maximize its emission characteristics in a typical application. The following peripheral devices and…

Text truncated - open the document above for the full version.

Report No.: CHTW24070098 Page: 13 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 6. TEST SETUP PHOTOS OF THE EUT Radiated Emissions (30MHz-1GHz) Radiated Emissions (Above 1GHz)
