K6630673Y3DVHF FM Marine Transceiver

zInternational ITU-R M.493-16 Class D DSC (Digital Selective Calling) zIntegrated dual channel AIS (Automatic Identification System) receiver zAIS/AIS SART target display: MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG zNMEA 2000 and NMEA0183 Compatible zIntegrated 66 Channel Internal GPS receiver zContact Class A or B AIS Ship with DSC zProgrammable CP A or TCPA collision avoidance alarms zSubmersible IPX8 (1.5 meter for 30 minutes) z80dB Commercial grade receiver zDSC position request and report functions zGM (Group Monitor) using DSC Group Position Calling zNavigation (LAT/LON, SOG and COG) information shown on display zMOB (Man Over-Board) Operation zV ersatile user-programmable scanning, priority scan and Dual/Triple Watch zIntegrated 32 Code Voice Scrambler and 4 Code Voice Scrambler z30 W att PA/Loud Hailer with preprogrammed fog signals and listen back zNoise canceling for both transmit and receive audio zSecond Station Remote Microphone * zIntercom Feature between Radio and Second Station Remote Microphone* *(Optional SSM-70H (RAM4) or SSM-72H (RAM4X) required) MATRIX NMEA2000 GPS GX2410GPS Owner’s Manual TABLE OF CONTENTS QUICK REFERENCE ........................................... 2 1 GENERAL INFORMATION ............................ 3 2 P ACKING LIST ............................................... 4 3 OPTIONAL ACCESSORIES .......................... 4 4 ONLINE W ARRANTY REGISTRATION ......... 4 5 Safety Precautions (Be Sure to Read) ........ 5 6 GETTING ST ARTED ...................................... 7 6.1 ABOUT VHF RADIO ................................................................... 7 6.2 SELECTING AN ANTENNA ....................................................... 7 6.3 COAXIAL CABLE ........................................................................ 7 6.4 DISTRESS AND HAILING (CHANNEL 16) ............................... 8 6.5 CALLING ANOTHER VESSEL (CHANNEL 16 OR 9) ............. 9 6.6 WHA T IS THE RANGE FOR AIS RECEIVERS? .................... 10 6.7 Accuracy of COG ....................................................................... 10 7 CONTROLS AND INDICATORS .................. 11 7.1 FRONT PANEL .......................................................................... 11 7.2 MICROPHONE .......................................................................... 13 7.3 REAR PANEL ............................................................................ 14 8 INSTALLATION ............................................ 16 8.1 SAFETY / WARNING INFORMATION .................................... 16 8.2 LOCATION ................................................................................. 16 8.3 MOUNTING THE RADIO ......................................................... 16 8.3.1 Supplied Mounting Bracket ...................................... 16 8.3.2 Optional MMB-84 Flush Mount Bracket ................... 17 8.4 ELECTRICAL CONNECTIONS ............................................... 18 8.5 CONNECTION OF EXTERNAL DEVICES TO THE RADIO . 19 8.5.1 Connecting the NMEA 0183/NMEA 0183-HS to the Radio . 19 8.5.2 Accessory Cables .................................................... 19 8.5.3 Internal GPS (DSC Output) to Chart Plotter ............ 20 8.5.4 Connection to External GPS or Chart Plotter .......... 20 8.5.5 Connection to External PA/HAIL Speaker ............... 21 8.5.6 Connecting optional SCU-38 External GPS Antenna . 21 8.5.7 Connecting optional SCU-31 External GPS Antenna . 21 8.5.8 Optional SSM-70H (RAM4) Microphone ................. 22 8.5.9 Optional SCU-30 Wireless Access Point Installation . 24 8.6 INITIAL SETUP REQUIRED WHEN TURNING ON THE POWER FOR THE FIRST TIME .............................. 24 8.6.1 Maritime Mobile Service Identity (MMSI) ................. 24 8.7 CONFIRMING GPS SIGNAL (GPS STATUS DISPLAY) ....... 26 8.8 GPS CONFIGURATION ........................................................... 27 8.8.1 Setting the GPS Time .............................................. 27 8.8.2 Setting the Time Area .............................................. 27 8.8.3 Setting the Time Format .......................................... 28 8.8.4 Setting COG to True or Magnetic ............................ 28 9 BASIC OPERATION ..................................... 29 9.1 TURNING THE TRANSCEIVER ON AND OFF ..................... 29 9.2 RECEPTION .............................................................................. 29 9.3 TRANSMISSION ....................................................................... 29 9.3.1 Transmit Power ........................................................ 30 9.4 BASIC OPERATION OF THE SETUP MENU ........................ 30 9.5 TRANSMIT TIME-OUT TIMER (TOT) ..................................... 31 9.6 SIMPLEX/DUPLEX CHANNEL USE ....................................... 31 9.7 CHANNEL GROUP ................................................................... 31 9.8 NOAA WEATHER CHANNELS ............................................... 32 9.8.1 NOAA Weather Alert ................................................ 32 9.8.2 NOAA Weather Alert Testing .................................... 33 9.9 MULTI WATCH (TO PRIORITY CHANNEL) ........................... 33 9.9.1 Setup the Multi Watch Operation ............................. 33 9.9.2 Starting Dual Watch ................................................. 33 9.10 SCANNING ............................................................................. 34 9.10.1 Selecting Scan Type ........................................... 34 9.10.2 Programming Scan Memory ............................... 34 9.10.3 Memory Scanning (M-SCAN) .............................. 35 9.10.4 Priority Scanning (P-SCAN) ................................ 35 9.11 PRESET CHANNELS: INSTANT ACCESS ......................... 36 9.11.1 Programming ....................................................... 36 9.11.2 Operation ............................................................ 36 9.11.3 Deletion ...................................…

Text truncated - open the document above for the full version.

69 11.7.4 Saving the Reported Position as a Waypoint The transceiver can save a position report call in the radio’s memory as a waypoint. 1. After the position report call has been received, press the [SAVE] soft key. 2. If you want to change the name of the waypoint, rotate the DIAL/ENT knob to select “NAME”, then press the [SELECT] soft key. 3. Enter the name of the waypoint you want to reference in the directory. For details, refer to “11.4.1 Setting up the Individual / Position Call Directory”. 4. Press the [ENTER] soft key to save the waypoint into memory. 5. Press the [OK] soft key to return to the position report display. Navigating to a Saved Waypoint Refer to section “12.1.1 Starting and Stopping Navigation” for details. 11.7.5 Setting up a Position Report Ringer The transceiver position report ringer may be turned OFF. 1. Press & hold [ ]  “DSC SETUP”  “DSC BEEP” 2. Rotate the DIAL/ENT knob to select “POS REPORT”, then press the [SELECT] soft key. 3. Rotate the DIAL/ENT knob to select “OFF”. 4. Press the [ENTER] soft key to store the selected setting. 5. Press the [ CLEAR] key to return to radio operation. To enable the ringer tone, repeat the above procedure, rotate the DIAL/ENT knob to select “ON” in the step 3 above. 70 11.8 AUTO POSITION POLLING The transceiver has the capability to automatically track six vessels programmed into the individual directory, or to automatically send your position information to the programmed stations. 11.8.1 Setting up the Polling Operation 1. Press & hold [ ]  “DSC SETUP”  “AUTO POSITION POLLING” 2. Rotate the DIAL/ENT knob to select the desired operation (AUTO POS REQUEST and AUTO POS REPORT), and press the [ENTER] soft key. 3. Press the [CLEAR] key to return to radio operation. 11.8.2 Setting up the Polling Time Interval 1. Press & hold [ ]  “DSC SETUP”  “AUTO POS INTERVAL” 2. Rotate the DIAL/ENT knob to select the desired interval time (30 second, 1, 2, 3, and 5 minutes) and press the [ENTER] soft key. 3. Press the [CLEAR] key to return to radio operation. 11.8.3 Selecting Vessels to be Automatically Polled NOTE The radio uses the individual directory to select vessels to be automatically polled. Refer to section “11.4.1 Setting up the Individual / Position Call Directory” and enter the MMSI of vessels you may want to poll before proceeding. 1. [ ]  “DSC CALL”  “AUTO POS POLLING” 2. Rotate the DIAL/ENT knob to select “SELECTED ID”, then press the [SELECT] soft key. 3. The radio will show a highlighted blank row when you select the vessel for the first time. Press the [SELECT] soft key. 71 4. The radio will show the vessels programmed in the individual directory. Rotate the DIAL/ENT knob to select the desired vessel, then press the [ENTER] soft key. 5. For more entries, rotate the DIAL/ENT knob to select a blank row, press the [SELECT] soft key, then perform step 4. 6. When finished, press the [CLEAR] key to exit to the radio mode. 11.8.4 Enabling/Disabling Auto POS Polling 1. [ ]  “DSC CALL”  “AUTO POS POLLING” 2. Rotate the DIAL/ENT knob to select “ACTIVATION”, then press the [SELECT] soft key. 3. Rotate the DIAL/ENT knob to select “START” to enable transmissions or “STOP” to disable, then press the [ENTER] soft key. 4. Press the [CLEAR] key to return to radio operation. 5. Auto POS Polling starts and the “” icon will appear on the display. 11.9 DSC TEST This function is used to contact another DSC equipped vessel to ensure the DSC functions of the radio are operating. NOTE To use the DCS Test feature, a radio that is to receive the test call also needs to have the DSC Test feature. To perform the DSC test you will need to enter the MMSI of another vessel into the individual directory or manually enter the MMSI using the procedure below. 11.9.1 Programming MMSI into Individual Directory Refer to section “11.4.1 Setting up the Individual / Position Call Directory”. 72 11.9.2 Transmitting a DSC Test to Another Vessel DSC Test call using the Individual/Position Directory 1. [ ]  “DSC CALL”  “DSC TEST CALL” 2. Rotate the DIAL/ENT knob to select “HISTORY” or “MEMORY”, then press the [SELECT] soft key. 3. Rotate the DIAL/ENT knob to select the ship name, then press the [SELECT] soft key. 4. Press the [YES] soft key to transmit the DSC test call to the other vessel. 5. Press the [QUIT] soft key to return to radio operation. DSC Test Call by Manually Entering an MMSI 1. [ ]  “DSC CALL”  “DSC TEST CALL”  “MANUAL” 2. Rotate the DIAL/ENT knob to select “NEW ID”, then press the [SELECT] soft key. 3. Rotate the DIAL/ENT knob to select the first digit in the MMSI, then press the [SELECT] soft key. 4. Repeat step 3 until all the numbers of the MMSI are shown on the display. 5. P ress the [FINISH] soft key to show the test call page. 6. Press the [YES] soft key to transmit the DSC test call to the other vessel. 7. Press the [QUIT] soft key to return to radio operation. 73 NOTE When the radio receives a test call reply from the vessel that was called, the radio will ring and show “RX TEST CALL” on the display, this confirms the called radio has received the test call. 11.9.3 Receiving a DSC Test Call When another vessel transmits a DSC Test call to the GX2410 following will happen: 1. When a DSC Test call is received, the radio will auto- matically respond to the calling vessel. 2. T o exit from the DSC Test call display, press the [QUIT] soft key. 11.10 DSC LOG OPERATION The GX2410 logs transmitted calls, received DSC distress calls, and other calls (individual, group, all ships, etc.). The DSC log feature is similar to an answer machine where calls are recorded for review and an “” icon will appear on the radio's display. The GX2410 can store up to 100 transmitted calls, up to the latest 50 distress calls, and up to the latest 100 other calls (individual, group, all ships, position report, position request acknowledge and test call acknowledge). NOTE When the “DSC LOG” menu is selected, the transceiver may display high- priority logged c…

Text truncated - open the document above for the full version.

Yaesu USA 6125 Phyllis Dr. Cypress, CA 90630 (Phone)714.827.7600 (Fax)714.827.8100 UNITED STATES DESIGNATED AGENT LETTER Date: 12 July 2024 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Yaesu Musen Co., Ltd. Company Name: Yaesu USA, Inc. FRN: 0013655220 FRN: 0001523877 Grantee Code: K66 Contact Name: Masatoshi Muraishi Contact Name Mikio Maruya Address: Omori Bellport D building 3F, 6-26-3 Minami-oi, Shinagawa-ku, Tokyo Address: 6125 Phyllis Drive Cypress, City/Province/Zip: 140-0013 City/Province/Zip: CA 90630 Telephone: +81-3-6410-8121 Telephone: (714) 827-7600 Fax: +81-3-5753-5123 Fax: Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: K6630673Y3D ATTN: Director of Certification: We, Yaesu Musen Co., Ltd. and Mikio Maruya understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, Yaesu Musen Co., Ltd. and Mikio Maruya acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Masatoshi Muraishi Name (Printed): Mikio Maruya Title: Engineering Division Title: Executive Vice President, Engineering Signature: Signature:

YAESU MUSEN CO., LTD. Covered Equipment Certification Attestation Letter 7/30/2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: K6630673Y3D (YAESU MUSEN CO., LTD.) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. (YAESU MUSEN CO., LTD.) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Masatoshi Muraishi Title: - Company Name: YAESU MUSEN CO., LTD. Date: 7/30/2024

2024-08-01 FCC ID: K6630673Y3D Product Name: VHF FM Marine Transceiver Gentlemen: By means of this document, YAESU MUSEN CO., LTD. declares the following Marine Radio model numbers: GX2410GPS are in compliance with the following DSC standards: Part 2 & 80 ITU-R M.493-13 IEC 60945 IEC 62238 Sincerely, Contact: Masatoshi Muraishi Applicant: YAESU MUSEN CO., LTD.

2024-07-30 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd / Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China / Xu Yang,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with YAESU MUSEN CO., LTD. / Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan. Agency agreement expiration date: 2025-07-30 By: Masatoshi Muraishi Signature Printed Title: - On behalf of : YAESU MUSEN CO., LTD. Telephone: +81-3-6410-8121

2024-07-30 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: K6630673Y3D Product Name: VHF FM Marine Transceiver Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  BOM  Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. By: Masatoshi Muraishi Signature Printed Title: - On behalf of : YAESU MUSEN CO., LTD. Telephone: +81-3-6410-8121

Report No.: CHTW24070080 Page: 32 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7. EXTERNAL AND INTERNAL PHOTOS 7.1. External Photos Report No.: CHTW24070080 Page: 33 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09)

GX2410GPS

Report No.: CHTW24070080 Page: 34 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7.2. Internal Photos Report No.: CHTW24070080 Page: 35 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070080 Page: 36 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070080 Page: 37 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070080 Page: 38 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTW24070080 Page: 39 of 39 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 8. APPENDIX REPORT

Page: 1 of 14 TEST REPORT For FCC Part15B Report No. .......................................: CHTW24070084 Report verification: Project No. ..................................: SHT2407005802W FCC ID ............................................. : K6630673Y3D Applicant’s name ........................... : YAESU MUSEN CO., LTD. Address ............................................. : Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan Product Name ................................ : VHF FM Marine Transceiver Trade Mark ....................................... : Standard Horizon Model No. ......................................... : GX2410GPS Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart B Date of receipt of test sample...........: Jul.09, 2024 Date of testing..............................: Jul.10, 2024 - Jul.22, 2024 Date of issue.................................: Jul.23, 2024 Result .................. ........................: Pass Compiled by (position+printed name+signature) ... : File administrators Caspar Chen Supervised by (position+printed name+signature) ... : Project Engineer Caspar Chen Approved by (position+printed name+signature) ... : RF Manager Xu yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No.: CHTW24070084 Page: 2 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) Contents 1. TEST STANDARDS AND REPORT VERSION ........................................... 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION .................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Testing Laboratory Information 5 4. TEST CONFIGURATION ................................................................. 6 4.1. Descriptions of test mode 6 4.2. Support unit used in test configuration 6 4.3. Environmental conditions 6 4.4. Statement of the measurement uncertainty 6 4.5. Equipments Used during the Test 7 5. TEST CONDITIONS AND RESULTS ..................................................... 8 5.1. Conducted Emissions 8 5.2. Radiated Emissions 9 6. TEST SETUP PHOTOS OF THE EUT .................................................. 13 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................. 14 Report No.: CHTW24070084 Page: 3 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC CFR Title 47 Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version information Revision No. Date of issue Description N/A 2024-07-23 Original Report No.: CHTW24070084 Page: 4 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer 5.1 Conducted Emissions 15.107(a) N/A - 5.2 Radiated Emissions 15.109(a) PASS Yifan Wang Note: #1: The test result does not include measurement uncertainty value Report No.: CHTW24070084 Page: 5 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 3. SUMMARY 3.1. Client Information Applicant: YAESU MUSEN CO., LTD. Address: Omori Bellport D building 3F, 6-26-3 Minamioi, Shinagawa-ku, Tokyo 140-0013 Japan Manufacturer: YAESU MUSEN CO.,LTD. Address: 43 Utsuroda, Morijuku, Sukagawa-shi,Fukushima 962-0001 Japan 3.2. Product Description Main unit information: Product Name: VHF FM Marine Transceiver Trade Mark: Standard Horizon Model No.: GX2410GPS Listed Model(s): - Power supply: DC 13.8V Hardware version: N/A Software version: N/A 3.3. Testing Laboratory Information Laboratory Name Shenzhen Huatongwei International Inspection Co., Ltd. Laboratory Location Building 7, Baiwang Idea Factory, No.1051, Songbai Road, Yangguang Community, Xili Subdistrict, Nanshan District, Shenzhen, Guangdong, China Connect information: Tel: 86-755-26715499 E-mail: [email protected] http://www.szhtw.com.cn Qualifications Type Accreditation Number FCC Registration Number 762235 FCC Designation Number CN1181 Report No.: CHTW24070084 Page: 6 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 4. TEST CONFIGURATION 4.1. Descriptions of test mode Test mode Description Test mode O1 Power on EUT and keep it turned on 4.2. Support unit used in test configuration The EUT has been associated with peripherals and configuration operated in a manner tended to maximize its emission characteristics in a typical application. The following peripheral devices and interface…

Text truncated - open the document above for the full version.

Report No.: CHTW24070084 Page: 13 of 14 Date of issue: 2024-07-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06 (2023-09) 6. TEST SETUP PHOTOS OF THE EUT Radiated Emissions (30MHz-1GHz) Radiated Emissions (Above 1GHz)
