K6610604840UHF TRANSMITTER

VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. VERTEX STANDARD HK LTD. Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong A P2 P1 P3 P4 APCO P25/FM TRANSCEIVER VX-7200 OPERATING MANUAL Unsafe Radiation Distance Congratulations! You now have at your fingertips a valuable communications tool: a VERTEX STAN- DARD two-way radio! Rugged, reliable and easy to use, your VERTEX STANDARD radio will keep you in constant touch with your colleagues for years to come, with negligible maintenance downtime. Please take a few minutes to read this manual carefully. The information presented here will allow you to derive maximum performance from your radio, in case ques- tions arise later on. We’re glad you joined the VERTEX STANDARD team. Call on us anytime, because communications is our business. Let us help you get your message across. NOTICE ! There are no owner-serviceable parts inside the transceiver. All service jobs must be referred to an authorized VERTEX STANDARD Service Represen- tative. Consult your Authorized VERTEX STANDARD Dealer for installa- tion of optional accessories. SAFETY/WARNING INFORMATION WARNING - DO NOT operate the VX-7200 radio when any person(s) (by- standers) outside the vehicle are within the distances shown in the chart at the bottom of this section. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd. The radio must be used in vehicle-mount configurations with a maximum op- erating duty factor not exceeding 50%, in typical Push-to-Talk configurations. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure condi- tions of its passengers and bystanders by maintaining the minimum separa- tion distance shown below. Failure to observe these restrictions will result in exceeding the FCC RF ex- posure limits. Antenna Installation: For rear deck trunk installation, the antenna must be located at least the fol- lowing distance away from rear-seat passengers in order to comply with the FCC RF exposure requirements. For roof top installations, the antenna must be placed in the center of the roof. VX-7200 ( UHF TYPE D ) 2.82 Feet ( 0.86 m ) VX-7200 ( UHF TYPE A ) 3.93 Feet ( 1.2 m ) VX-7200 ( VHF ) 1.97 Feet ( 0.6 m ) VX-7200 SERIES OPERATING MANUAL INTRODUCTION The VX-7200 Series are full-featured APCO P25/FM transceiver designed for flex- ible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide variety of applications with a wide range of operating capability provided by their leading-edge design. The 501-channel memories can each be programmed with a 12-character channel name. Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VER- TEX STANDARD VPL-1 (or FIF-10) Programming Cable and CE76 Software. The pages which follow will detail the many advanced features provided on the VX- 7200 Series transceiver. After reading this manual, you may wish to consult with your Network Administrator regarding precise details of the configuration of this equipment for use in your application For North American Users Regarding 406 MHz Guard Band The U.S. Coast Guard and National Oceanographic and Atmospheric Admin- istration have requested the cooperation of the U.S. Federal Communications Commission in preserving the integrity of the protected frequency range 406.0 to 406.1 MHz, which is reserved for use by distress beacons. Do not attempt to program this apparatus, under any circumstances, for operation in the fre- quency range 406.0 - 406.1 MHz if the apparatus is to be used in or near North America. A P2 P1 P3 P4 1 VX-7200 SERIES OPERATING MANUAL CONTROLS & CONNECTORS Front Panel Important! - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below describe a typically- configured radio.
VOL Knob Turn this control clockwise to increase the volume.  Microphone Jack Connect the microphone plug to this jack.  Emergency Microphone The emergency microphone is located behind this small slit. When the emer- gency feature is activated, this microphone is enabled.  [ P1 ] - [ P4 ] Buttons (Programmable Function Buttons) These buttons can be set up for special applications, such as High/Low power selection, Monitor, Talk-Around, etc., as determined by your network require- ments and programmed by your VERTEX STANDARD dealer.  [ A ] Button (Programmable Function Button) This button can be set up for special applications, such as High/Low power se- lection, Monitor, Talk-Around, etc., as determined by your network requirements and programmed by your VERTEX STANDARD dealer. A P2 P1 P3 P4
  2 VX-7200 SERIES OPERATING MANUAL  ( POWER ) Button Press and hold in this button for 2 seconds to toggle the transceiver’s power “on” and “off.”  BUSY/TX Indicator Indicates transceiver’s Transmit/Receive Status Steady Red: Transmitting in progress Steady Green: Signaling Off Blinking Green: Busy Channel/Squelch Off  [
] / [  ] Buttons (Programmable Function Buttons) Pressing either button changes the current channel (and displayed channel num- ber or name). Holding in either button for more than 1.5 second causes the radio to begin stepping (repeatedly) upward or downward through the channels. LCD (Liquid Crystal Display) The display includes a 3-character numeric section showing Channel Group num- ber…

Text truncated - open the document above for the full version.

VX-7100 SERIES OPERATING MANUAL VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. VERTEX STANDARD HK LTD. Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong P2P1 TX/BUSY A 12 3 4 Unsafe Radiation Distance Congratulations! You now have at your fingertips a valuable communications tool: a VERTEX STAN- DARD two-way radio! Rugged, reliable and easy to use, your VERTEX STANDARD radio will keep you in constant touch with your colleagues for years to come, with negligible maintenance downtime. Please take a few minutes to read this manual carefully. The information presented here will allow you to derive maximum performance from your radio, in case ques- tions arise later on. We’re glad you joined the VERTEX STANDARD team. Call on us anytime, because communications is our business. Let us help you get your message across. NOTICE ! There are no owner-serviceable parts inside the transceiver. All service jobs must be referred to an authorized VERTEX STANDARD Service Represen- tative. Consult your Authorized VERTEX STANDARD Dealer for installa- tion of optional accessories. SAFETY/WARNING INFORMATION WARNING - DO NOT operate the VX-7100 radio when any person(s) (by- standers) outside the vehicle are within the distances shown in the chart at the bottom of this section. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd. The radio must be used in vehicle-mount configurations with a maximum op- erating duty factor not exceeding 50%, in typical Push-to-Talk configurations. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure condi- tions of its passengers and bystanders by maintaining the minimum separa- tion distance shown below. Failure to observe these restrictions will result in exceeding the FCC RF ex- posure limits. Antenna Installation: For rear deck trunk installation, the antenna must be located at least the fol- lowing distance away from rear-seat passengers in order to comply with the FCC RF exposure requirements. For roof top installations, the antenna must be placed in the center of the roof. VX-7100 ( UHF TYPE D ) 2.82 Feet ( 0.86 m ) VX-7100 ( UHF TYPE A ) 3.93 Feet ( 1.2 m ) VX-7100 ( VHF ) 1.97 Feet ( 0.6 m ) VX-7100 SERIES OPERATING MANUAL INTRODUCTION The VX-7100 Series are full-featured FM transceiver designed for flexible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide vari- ety of applications with a wide range of operating capability provided by their lead- ing-edge design. Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VERTEX STANDARD VPL-1 Programming Cable and CE59 Software. The pages which follow will detail the many advanced features provided on the VX-7100 Series transceiver. After reading this manual, you may wish to consult with your Network Administrator regarding precise details of the configuration of this equipment for use in your application P2P1 TX/BUSY A 12 3 4 1 VX-7100 SERIES OPERATING MANUAL P2P1 TX/BUSY A 12 3 4 CONTROLS & CONNECTORS Front Panel Important! - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below discribe a typically-con- figured radio.
VOL Knob Turn this control clockwise to increase the volume.  Microphone Jack Connect the microphone plug to this jack.  Emergency Microphone The emergency microphone is located behind this small slit. When the emer- gency feature is activated, this microphone is enabled.  [ MON ], [ A ], [
] Buttons (Programmable Function Buttons) These buttons can be set up for special applications, such as High/Low power selection, Monitor, Talk-Around, etc., as determined by your network require- ments and programmed by your VERTEX STANDARD dealer.  ( POWER ) Button Press and hold in this button for 2 seconds to toggle the transceiver’s power “on” and “off.”
 2 VX-7100 SERIES OPERATING MANUAL  TX/BUSY Indicator Indicates the transceiver’s Transmit/Receive Status. Steady Red: Transmitting in progress Steady Green: Signaling Off Blinking Green: Busy Channel/Squelch Off  Channel Number Indicator Indicates the operating channel.  Transceiver Status Indicator The “P1” and “P2” indicators show current transceiver status, which can be customized via programming by your VERTEX STANDARD dealer to meet your communications/network requirements. The possible “P1” and “P2” dis- plays are explained below. CONTROLS & CONNECTORS MONI SCAN Channel +4 CH LOW TA ( Talk Around ) Encryption Disable ( Requires optional Unit ) Emergency HOME Horn Alert Public Adress Key Lock EXT ACC REC/PLAY INDICATOR P1P2 This indicator blinks when CTCSS- or DCS- controlled squelch is disabled. The indicator is Illuminated constantly while the audio is pass- ing normally. Illuminates the indicator when the operating channel is selected on the SCAN channel. Illuminates the indicator when the radio recalls the alternate channel list. Illuminates the indicator when the radio’s trans- mitter is set to the “Low Power” mode. Illuminates the indicator when the “Talk Around” function is activated. Illuminates the indicator when the “Voice Scrambler” function is disabled temporarily. Illuminates the indicator when the “Emergency” feature is activated. Illuminates the indicator when you recall the Home group/channel. Illuminates the indicator whe…

Text truncated - open the document above for the full version.

January 11, 2006 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-7100-G8-45/VX-7200-G8-45 (FCC ID: K6610604840) Gentlemen: Part 15.19 Compliance Statement is placed on the bottom of case. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

January 11, 2006 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-7100-G8-45/VX-7200-G8-45 (FCC ID: K6610604840) Gentlemen: A. Part 15.21 Compliance Statement Drawing: B. Part 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on inside back cover) Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device. 20mm 97mm

January 11, 2006 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: VX-7100-G8-45/VX-7200-G8-45 (FCC ID: K6610604840) Gentlemen: The equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. Programming of this product’s transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personal. The operator cannot be program transmit frequencies using the equipment’s external operation controls. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

November 24, 2005 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: VX-7100-G6-45/VX-7200-G6-45 (FCC ID: K6610604640) Pursuant to Sections 0.457 (d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: ・ Block Diagram ・ Schematics These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Front view (FRONT-C-UNIT (for VX-7100)) Front view (FRONT-D-UNIT (for VX-7200)) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Rear view Left view FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Right view Top view FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Bottom view Microphone FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. DC Power Cable

VX-7100-G8-45 / VX-7200-G8-45VX-7100-G8-45 / VX-7200-G8-45 LABEL DRAWINGLABEL DRAWING Vertex Standard Co., Ltd.Vertex Standard Co., Ltd. ID / Part 15.19 and CAUTION drawings ID drawing Part 15.19 and CAUTION drawings Label location VX-7100-G8-45 VERTEX STANDARD CO., LTD. MADE IN JAPAN IC: 511B-10604840 FCC ID: K6610604840 4909959000000 SER NO. 00000000 ! ! Device restricted to occupational use to satisfy FCC RF exposure compliance. See owner's manual for specific operating requirement CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. VX-7200-G8-45 VERTEX STANDARD CO., LTD. MADE IN JAPAN IC: 511B-10604840 FCC ID: K6610604840 4909959000000 SER NO. 00000000

FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Removed top cover Inside of EUT with shield case and MODEM-UNIT FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Inside of EUT without shield case and MODEM-UNIT Side-A of RF-UNIT FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Side-B of RF-UNIT Inside of front panel with PWB (FRONT-C-UNIT (for VX-7100)) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Inside of front panel (for FRONT-C-UNIT (for VX-7100)) Side-A of FRONT-C-UNIT (for VX-7100) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Side-B of FRONT-C-UNIT (for VX-7100) Inside of front panel with PWB (FRONT-D-UNIT (for VX-7200)) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Inside of front panel (for FRONT-D-UNIT (for VX-7200)) Side-A of FRONT-D-UNIT (for VX-7200) with LCD FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Side-A of FRONT-D-UNIT (for VX-7200) without LCD Side-B of FRONT-D-UNIT (for VX-7200) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Front of LCD (for VX-7200) Back of LCD (for VX-7200) FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Side-A of MODEM-UNIT Side-B of MODEM-UNIT FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Inside of chassis Inside of top case FCC ID: K6610604840 IC ID: 511B-10604840 Vertex Standard Co., Ltd. Inside of top cover Inside of microphone

FCC ID: K6610604840 IC ID: 511B-10604840 FCC ID: K6610604840 IC ID: 511B-10604840 FCC ID: K6610604840 IC ID: 511B-10604840

Page 1/4 VX-7100-G8-45/VX-7200-G8-4 Address Device name DescriptionTYP VALUE [MAIN-UNIT] Q 1001 Transistor DTC114TE Q 1002 Transistor DTC144EE Q 1003 IC2SC3356 R24 Q 1004 ICNJM7808DL1A Q 1005 Transistor DTC144EE Q 1006 FETRTQ030P02 Q 1007 Transistor DTA144EE Q 1008 Transistor DTC144EE Q 1009 Transistor DTC144EE Q 1010 FETRTQ030P02 Q 1011 Transistor DTC114TE Q 1012 Transistor DTC144EE Q 1013 Transistor UMG2N Q 1014 ICCD4053BPWR Q 1015 FETRTQ030P02 Q 1016 ICCD4053BPWR Q 1017 Transistor UN911F Q 1018 Transistor DTC144EE Q 1019 Transistor DTC114TE Q 1021 ICLA8630M-B-R Q 1022 Transistor 2SC3356 R25 Q 1023 Transistor DTC144EE Q 1024 Transistor DTC144EE Q 1025 Transistor 2SC4617 R Q 1026 Transistor 2SC4617 R Q 1027 Transistor 2SC4617 R Q 1028 Power Module RA55H3847M Q 1029 ICM62364FP 600D Q 1030 Transistor DTC144EE Q 1031 Transistor DTA124EE Q 1032 Transistor DTC144EE Q 1033 Transistor DTC144EE Q 1034 ICBD6111FV-E2 Q 1035 ICSPM5001 Q 1036 ICNJM2125F Q 1037 ICAK2345 Q 1038 Transistor 2SC5226-4 Q 1039 ICTDA1519CTH Q 1040 Transistor DTA124EE Q 1041 Transistor 2SC4617 R Q 1042 Transistor NJM2904V Q 1044 Transistor 2SA1774 R Q 1045 Transistor DTC114TE Q 1046 Transistor 2SC3356 R24 Q 1047 Transistor DTC144EE Q 1049 Transistor 2SC5226-4 Q 1051 Transistor DTC144EE Q 1053 Transistor DTC144EE Q 1054 Transistor 2SK508 K52 Q 1055 Transistor DTC144EE Q 1057 Transistor 2SC5226-4 Q 1058 Transistor 2SC4226 R24 Q 1059 Transistor 2SC5226-4 Q 1060 ICTAR5S35 Q 1061 Transistor XN1501 Q 1062 Transistor 2SB1201S Q 1063 ICCD4066BPWR Q 1064 ICLC73881M Q 1065 ICS-80835CNMC-B8U Q 1066 Quadruple OP-AM PNJM12902V Q 1067 Transistor 2SC4617 R Q 1068 ICCD4066BPWR FCC ID: K6610604840 IC ID: 511B-10604840 Semi-Conductor Parts List Vertex Standard Co., Ltd. Page 2/4 VX-7100-G8-45/VX-7200-G8-4 Address Device name DescriptionTYP VALUE FCC ID: K6610604840 IC ID: 511B-10604840 Semi-Conductor Parts List Q 1069 ICTAR5S50 Q 1070 Transistor DTC144EE Q 1071 FET3LN01S Q 1072 Transistor 2SC4617 R Q 1073 Transistor DTC144EE Q 1074 Quadruple OP-AM PNJM12902V Q 1075 Transistor DTC114TE Q 1076 Quadruple OP-AM PNJM12902V Q 1077 FET3LN01S Q 1078 FET2SK880GR Q 1079 ICTA31136FN Q 1080 ICBR93L66RFVM Q 1081 Transistor DTC144EE Q 1082 FET3LN01S Q 1083 CPULC87F5BP6A Q 1084 Transistor DTC144EE Q 1085 ICSA7025DK Q 1086 FET3LN01S Q 1087 Transistor DTC144EE Q 1088 Quadruple OP-AM PNJM12902V Q 1089 Quadruple OP-AM PNJM12902V Q 1091 Transistor 2SC4617 R Q 1092 Transistor DTC144EE Q 1094 Transistor 2SC3357 RF Q 1095 Quadruple OP-AM PNJM12902V Q 1096 Transistor DTC144EE Q 1097 Transistor DTC144EE Q 1101 ICTC4W66FU Q 1102 Transistor DTA144EE Q 1103 Transistor 2SA1602A-1F Q 1104 Transistor 2SC4617 R Q 1107 Transistor DTA124EE Q 1108 ICLM2902PWR Q 1109 ICTC4W66FU D 1001 DiodeXB15A709A0HR D 1002 DiodeP6KA18 D 1003 Varactor Diode HVC306B D 1004 Varactor Diode HVC306B D 1005 DiodeXB15A709A0HR D 1006 DiodeXB15A709A0HR D 1007 Diode1SS400 D 1008 Varactor Diode HVC306B D 1009 Varactor Diode HVC306B D 1010 DiodeBAS316 D 1011 Diode1SS400 D 1012 DiodeBAS316 D 1013 DiodeHSM88AS D 1014 DiodeHSM88AS D 1015 DiodeHVC327C D 1016 Diode1SS400 D 1017 Diode1SS400 D 1018 DiodeHVC383B D 1019 Zener Diode UDZS 5.6B D 1020 DiodeHSC277TRF D 1021 DiodeRCCA-201Q43UA D 1022 Dual Diode DAN222 D 1023 Diode1SS400 D 1024 Dual Diode DA221 D 1025 Diode1SS400 D 1026 Dual Diode DA221 D 1027 DiodeBAS316 D 1029 Dual Diode DA221 D 1030 DiodeHVC327C Vertex Standard Co., Ltd. Page 3/4 VX-7100-G8-45/VX-7200-G8-4 Address Device name DescriptionTYP VALUE FCC ID: K6610604840 IC ID: 511B-10604840 Semi-Conductor Parts List D 1033 Diode1SS400 D 1035 DiodeHVC327C D 1036 DiodeHVC327C D 1037 DiodeHVC327C D 1039 DiodeHVC327C D 1043 DiodeHVC327C D 1044 Dual Diode DA221 D 1045 Dual Diode DAN222 D 1046 DiodeHVC383B D 1047 Zener Diode UDZS 16B D 1048 Dual Diode DAN222 D 1049 Diode1SS400 D 1050 Zener Diode UDZS 16B D 1051 Diode1SS400 D 1052 Dual Diode DAN222 D 1053 Zener Diode UDZS 16B D 1054 Dual Diode DAN222 D 1055 Zener Diode UDZS 16B D 1057 Dual Diode DA221 D 1058 Dual Diode DA221 D 1059 Dual Diode DA221 D 1060 Dual Diode DA221 D 1061 Dual Diode DA221 D 1062 Zener Diode UDZS 16B D 1063 Zener Diode UDZS 16B D 1064 Zener Diode UDZS 16B D 1065 Zener Diode UDZS 16B D 1066 Zener Diode UDZS 16B D 1067 Dual Diode DA221 D 1068 Diode1SS400 D 1070 DiodeHSC277 D 1071 DiodeHSC277 D 1072 DiodeHSC277 D 1073 DiodeHSC277 D 1074 Dual Diode DA221 D 1075 Diode1SS400 D 1076 Zener Diode UDZS 16B [MODEM-UNIT] Q 7004 Transistor 2SC5107-O Q 7005 ICIC TC4W53FU Q 7006 ICTAR5S50 Q 7009 Quadruple OP-AM PLMV324IPWR Q 7012 ICAK4554V Q 7015 ICTPS76301DBVR Q 7018 ICTMS320VC5416PGE120 Q 7020 ICTC7S32FU Q 7022 ICMBM29LV400TC-90 Q 7024 ICTC7W00FU Q 7030 ICTPS76333 D 7001 Diode1SS355 D 7002 DiodeRB751S-40 D 7003 DiodeRB751S-40 D 7004 DiodeRB751S-40 D 7005 DiodeRB751S-40 D 7006 DiodeRB751S-40 D 7007 DiodeRB751S-40 D 7008 DiodeRB751S-40 [FRONT-C-UNIT (501CH)] Q 5001 Transistor DTC144EEVX- 7200 Q 5002 Transistor XP1501VX- 7200 Q 5003 Transistor CPH6102VX- 7200 Q 5004 Transistor DTC144EEVX- 7200 Vertex Standard Co., Ltd. Page 4/4 VX-7100-G8-45/VX-7200-G8-4 Address Device name DescriptionTYP VALUE FCC ID: K6610604840 IC ID: 511B-10604840 Semi-Conductor Parts List Q 5005 Transistor XP1501VX- 7200 Q 5006 Transistor 2SA1602AVX- 7200 Q 5007 ICM5278L09MVX- 7200 Q 5008 ICNJU6624AFG1-03VX- 7200 Q 5009 ICM5278L05MVX- 7200 Q 5010 ICTC4S66FVX- 7200 D 5001 LEDBRPG1211CVX- 7200 D 5002 Diode1SS400VX- 7200 D 5003 LEDTLOU1020VX- 7200 D 5004 LEDTLOU1020VX- 7200 D 5005 LEDTLOU1020VX- 7200 D 5006 LEDTLOU1020VX- 7200 D 5007 LEDTLOU1020VX- 7200 D 5008 LEDTLOU1020VX- 7200 D 5009 Dual Diode DA204U VX- 7200 D 5010 LEDTLOU1020VX- 7200 D 5011 LEDTLOU1020VX- 7200 D 5012 LEDTLOU1020VX- 7200 D 5013 Diode1SS400VX- 7200 D 5014 Dual Diode DA221VX- 7200 D 5015 Diode1SS400VX- 7200 D 5016 Dual Diode DA204U VX- 7200 D 5017 Dual Diode DA221VX- 7200 D 5018 Diode1SS400VX- 7200 D 5019 LEDTLOU1020VX- 7200 D 5020 Zener Diode UDZS 4.3BVX- 7200 [FRONT-D-UNIT (4CH)] Q 4001 Transistor DTC144EEVX- 71…

Text truncated - open the document above for the full version.

FCC ID: K6610604840 IC ID: 511B-10604840 Alignment 1/6 Vertex Standard Co., Ltd. VX-7100-G8-45 / VX-7200-G8-45 Alignment Introduction The VX-7100 / VX-7200 is carefully aligned at the factory for the specified performance across the frequency range specified for each version. Realignment should therefore not be necessary except in the event of a component failure, or altering version type. All component replacement and service should be performed only by an authorized Vertex Standard representative, or the warranty policy may be void. The following procedures cover the sometimes critical and tedious adjustments that are not normally required once the transceiver has left the factory. However, if damage occurs and some parts subsequently are placed, realignment may be required. If a sudden problem occurs during normal operation, it is likely due to component failure; realignment should not be done until after the faulty component has been replaced. We recommend that servicing be performed only by authorized Vertex Standard service technicians who are experienced with the circuitry and fully equipped for repair and alignment. Therefore, if a fault is suspected, contact the dealer from whom the transceiver was purchased for instructions regarding repair. Authorized Vertex Standard service technicians realign all circuits and make complete performance checks to ensure compliance with factory specifications after replacing any faulty components. Those who do undertake any of the following alignments are cautioned to proceed at their own risk. Problems caused by unauthorized attempts at realignment are not covered by the warranty policy. Also, Vertex Standard reserves the right to change circuits and alignment procedures in the interest of improved performance, without notifying owners. Under no circumstances should any alignment be attempted unless the normal function and operation of the transceiver are clearly understood, the cause of the malfunction has been clearly pinpointed and any faulty components replaced, and realignment determined to be absolutely necessary. The following test equipment (and thorough familiarity with its correct use) is necessary for complete realignment. Correction of problems caused by misalignment resulting from use of improper test equipment is not covered under the warranty policy. While most steps do not require all of the equipment listed, the interactions of some adjustments may require that more complex adjustments be performed afterwards. Do not attempt to perform only a single step unless it is clearly isolated electrically from all other steps. Have all test equipment ready before beginning, and follow all of the steps in a section in the order presented. Required Test Equipment ˆ RF Signal Generator with calibrated output level at 200MHz ˆ Deviation Meter (linear detector) ˆ In-line Wattmeter with 5% accuracy at 200MHz ˆ 50 Ω RF Dummy Load with power rating 100W at 200MHz ˆ 8 Ω /10W AF Dummy Load ( Attention: Audio output is BTL output) ˆ Regulated DC Power Supply (standard 13.6V DC, 15A) ˆ Frequency Counter with 0.2ppm accuracy at 200MHz ˆ AC Voltmeter ˆ DC Voltmeter ˆ VHF Sampling Coupler ˆ IBM PC / compatible Computer with Microsoft DOS v3.0 or later operating system ˆ Vertex Standard VPL-1 Connection Cable & Alignment program FCC ID: K6610604840 IC ID: 511B-10604840 Alignment 2/6 Vertex Standard Co., Ltd. Alignment Preparation & Precautions A 50- RF Dummy Load and in-line wattmeter must be connected to the main antenna jack in all procedures that call for transmission, except where specified otherwise. Correct alignment is not possible with an antenna. After completing one step, read the following step to determine whether the same test equipment will be required. If not, remove the test equipment (except dummy load and wattmeter, in connected) before proceeding. Correct alignment requires that the ambient temperature be the same as that of the transceiver and test equipment, and that this temperature be held constant between 20 and 30°C (68 - 86 °F). When the transceiver is brought into the shop from hot or cold air, it should be allowed time to come to room temperature before alignment. Whenever possible, alignments should be made with oscillator shields and circuit boards firmly affixed in place. Also, the test equipment must be thoroughly warmed up before beginning. Note: Signal levels in dB referred to in the alignment procedure are based on 0dBμ EMF = 1μV. Setup the test equipment as shown for transceiver alignment, apply 13.6V DC power to the transceiver. Refer to the drawings below for Alignment Points. PC POWER SUPPLY 13.6V DC RF SIGNAL GENERATOR 50 Ω DUMMY LOAD IN-LINE WATTMETER DEVIATION METER FREQUENCY COUNTER RF SAMPLING COUPLER TRANSCEIVER ANT MIC/SP COM port VPL-1 connection cable The transceiver must be programmed for use in the intended system before alignment is attempted. The RF parameters are loaded from the file during the alignment process. In order to facilitate alignment over the complete switching range of the equipment it is recommended that the channel data in the transceiver is preset as the chart below. Channels Frequency BAND-LOW 380.000MHz BAND-MID 425.000MHz BAND-HIGH 470.000MHz The alignment mode is accessed by “Alignment mode” command from the computer whilst switching on. And the alignment tool operates it automatically. During the alignment mode, normal operation is suspended. Use the alignment tool program running on PC. FCC ID: K6610604840 IC ID: 511B-10604840 Alignment 3/6 Vertex Standard Co., Ltd. The alignment tool outline Installation the tool This alignment tool consists, MS-DOS based, only one execute file " AC035adj.exe ". You can make a directory as you wish, and copy this file. That is all of the installation process. Boot the tool In command line mode, move to the directory that you copied AC035adj.exe and , key in " AC035adj [enter] " and boot the alignment tool. Enter to the alignment mode To enter…

Text truncated - open the document above for the full version.

Page 1 of 30 REPORT ON Radio testing of the VERTEX STANDARD VX-7100-G8-45/VX-7200-G8-45 In accordance with ANSI/TIA/EIA-603, RSS-119 January 2006Report number TA000261 Vertex Standard Co., Ltd. GENERAL INFORMATION TRANSMITTERS Switchable x Variable N/A RＥＣＥＩＶERS This re port was prepared by Vertex Standard Co., Ltd. NUMBER OF CHANNELS: FCC ID: TRADE NAME: UHF Transceive r 5M000001 13.6 MANUFACTURER:Vertex Standard Co., Ltd. K6610604840 VERTEX STANDARD TYPE OF EMISSION: FREQUENCY RANGE: RSS-119 VOLTAGE RQUIREMENTS: SERIAL NUMBER: SPECIFICATION ARE REFERE…

Text truncated - open the document above for the full version.
