C4FM FDMA 144/430 MHz DUAL BAND DIGITAL TRANSCEIVER OPERATING MANUAL YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA 6125 Phyllis Drive, Cypress, CA 90630, U.S.A. YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. YAESU HK LTD. Unit 1306-1308, 13F., Millennium City 2, 378 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong FTM-400DR 1 Before Using This Equipment Before Using This EquipmentContents Programmable Memory Scan (PMS) ................... 37 Writing into a Programmable Memory ............. 37 Performing Programmable Memory Scan ....... 39 Useful Functions .................................................... 41 Dual Reception (DW) Functions ............................... 41 Dial Dual Reception VFO mode → Home channel ......................... 41 Memory Dual Reception Memory channel → Home Channel ............... 42 Using the DTMF Function......................................... 42 Sending the Registered DTMF Code ....................... 43 Sending a DTMF Code Manually ............................. 44 Communicating with a Specific Remote Station . 45 Using the Tone Squelch Function ............................. 45 Selecting a Tone Frequency ................................ 46 Searching for the Frequency of the Tone Squelch Used by the Remote Station ................................ 46 Selecting a DCS Code ......................................... 47 Searching for the Frequency of the DCS Used by the Remote Station .............................................. 47 Notification of Call from a Remote Station by the Bell............................................................................ 48 Calling Only a Specific Station New Pager Function .................................................................... 48 Flow of Operation to Use the Pager Function ...... 48 Setting the Code of Your Station .......................... 49 Turning on the New Pager Function .................... 49 Calling a Specific Station ..................................... 50 Being Called by the Remote Station (Standby Operation) ............................................................ 51 Functions Used as Needed.................................... 52 Setup Menu .............................................................. 52 Settings for the Setup Menu ................................ 52 Setup Menu Operations List ................................ 52 Apply settings to contents displayed on screen. .. 59 Setting the Background Color of the Screen ....... 60 Setting the Frequency Width for Band Scope ...... 60 Adjusting the LCD Backlight Brightness Level ..... 61 Adjusting LCD Contrast ....................................... 61 Switching between Time and Voltage display ...... 62 Adjusting volume respectively to A/B Bands. ....... 62 Setting the Display Method for Memory Channels .............................................................. 63 Setting the Squelch Type for transmission ........... 63 Setting the display format for the Clock Function 64 Setting the Time Zone .......................................... 65 Setting the Automatic Repeater Shift ................... 65 Setting the Clock Shift of the Microcomputer ....... 66 Setting the Program Keys on the Microphone ..... 66 Setting the Bandwidth to Scope ........................... 67 Setting the unit of measurement to be displayed . 67 Automatically Turning Off the Power APO Function....................................................... 68 Restricting the Continuous Transmission Time TOT Function ....................................................... 68 Setting PIN Code for a BLUETOOTH headset .... 69 Selecting Datum for GPS function. ...................... 69 Before Using This Equipment ................................. 3 Safety Precautions (Be Sure to Read) ....................... 3 Before Transmitting Radio Waves .............................. 8 Accessory and Option ................................................ 9 Attaching Accessory Items ....................................... 10 Connecting the Panel Screen to the Main Unit .... 10 Connect the accessory microphone (MH-48). ..... 10 Setting up the Panel Screen with the accessory bracket. .................................................................11 Names for various parts, Functional Parts and their Functions. ................................................................. 12 Description for Panel Screen ............................... 12 Description about the Screen............................... 13 Description of Microphone (MH-48) ..................... 16 Using the microSD Memory Card ............................. 17 Usable microSD memory cards. .......................... 17 Precautions for when using a microSD memory card. ..................................................................... 18 Installing/removing microSD memory card .......... 18 Formatting the microSD Memory Card ................ 19 Basic Operation ...................................................... 20 Communication......................................................... 20 Changing the Beep Sound. .................................. 20 Using the Timer Function ..................................... 21 The ALTITUDE function for measuring altitude. ... 22 Locking Keys and Switches ................................. 22 Changing Transmission Output............................ 24 Adjusting Microphone Sensitivity (MIC GAIN) ..... 24 Other Settings........................................................... 25 Adjusting Time ..................................................... 25 Muting Sounds ..................................................... 26 Adjusting Squelch Level....................................... 26 Manually switching frequency steps .................... 27 Resetting applied settings .................................... 27 Repeater Operation ....................................…

Text truncated - open the document above for the full version.

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan 12 September 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: FTM-400DR (FCC ID: K6620345X40) Gentlemen: The scanner receiver equipment meets the requirements of the FCC Rules, 15.121(a). Compliance is achieved through the following methods: The scanner receiver in this equipment is incapable of tuning, or readily being altered, by the User to operate within the frequency bands allocated to the Domestic Public Cellular Telecommunications Service in Part 22. Blocking of the cellular frequencies is implemented in the firmware of the unit’s main control central processing unit (CPU). Coverage of 824 – 849 MHz and 869 – 894 MHz is completely blocked, since it is done in the microprocessor, and cannot be re-enabled by any user-accessible procedure, including diode, resistor, or jumper changes, nor by connection of any external device such as a personal computer, nor by installation of any “special” enabling semiconductor device. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan 12 September 2012 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: FTM-400DR (FCC ID: K6620345X40) Pursuant to Sections 0.457 (d) (1) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: Confidential ・ Block Diagram ・ Schematics ・ Parts List ・ Alignment ・ Internal Photograph Short-Term Confidential ・ Operating Manual ・ External Photos These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (1) (ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan 11 October 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046, USA Re: FTM-400DR (FCC ID: K6620345X40) Gentlemen: A. Part 15.19 & 15.21 Compliance Statement Drawing: 97mm 1. Changes or modifications to this device not expressly approved YAESU MUSEN could void the user’s authorization to operate this device. 2. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions; (1) This device may not cause harmful interference, and (2) this device must accept any interference including interference that may cause undesired operation. 3. The scanning receiver in this equipment is incapable of tuning, or readily being altered, by the user to operate within the frequency bands allocated to the Domestic public Cellular Telecommunications Service in the Part 22. 40mm B. Part 15.19 & 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on inside cover 3) Sincerely , YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 1 / 13 YAESU MUSEN CO., LTD. FTM-400DR External Photograph Contents 1. OVERALL IMAGE ....................................................................................................................2 2. PANEL-UNIT ............................................................................................................................3 3. MAIN-UNIT ..............................................................................................................................6 4. ACCESSORIES .........................................................................................................................9 5. OPTION...................................................................................................................................12 FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 2 / 13 YAESU MUSEN CO., LTD. 1. OVERALL IMAGE Fig.1-1 Overall image (Standard) Fig.1-2 MH-85 MICROPHONE WITH CAMERA (Option) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 3 / 13 YAESU MUSEN CO., LTD. 2. PANEL-UNIT Fig.2-1 PANEL-UNIT (Top View) Fig.2-2 PANEL-UNIT (Bottom View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 4 / 13 YAESU MUSEN CO., LTD. Fig.2-3 PANEL-UNIT (Front View) Fig.2-4 PANEL-UNIT (Back View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 5 / 13 YAESU MUSEN CO., LTD. Fig.2-5 PANEL-UNIT (Left View) Fig.2-6 PANEL-UNIT (Right View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 6 / 13 YAESU MUSEN CO., LTD. 3. MAIN-UNIT Fig.3-1 MAIN-UNIT (Top View) Fig.3-2 MAIN-UNIT (Bottom View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 7 / 13 YAESU MUSEN CO., LTD. Fig.3-3 MAIN-UNIT (Front View) Fig.3-4 MAIN-UNIT (Back View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 8 / 13 YAESU MUSEN CO., LTD. Fig.3-5 MAIN-UNIT (Left View) Fig.3-6 MAIN-UNIT (Right View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 9 / 13 YAESU MUSEN CO., LTD. 4. ACCESSORIES Fig.4-1 MH-48 DTMF MICROPHONE Fig.4-2 CONTROL CABLE FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 10 / 13 YAESU MUSEN CO., LTD. Fig.4-3 MOUNTING BRACKET FOR PANEL-UNIT (Angel 1) Fig.4-4 MOUNTING BRACKET FOR PANEL-UNIT (Angel 2) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 11 / 13 YAESU MUSEN CO., LTD. Fig.4-5 MOUNTING BRACKET @ ATTCHED PANEL-UNIT Fig.4-6 DC POWER CORD (With Fuse) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 12 / 13 YAESU MUSEN CO., LTD. 5. OPTION Fig.5-1 MH-85 MICROPHONE WITH CAMERA (Front View) Fig.5-2 MH-85 (Rear View) FCC ID: K6620345X40 FTM-400DR External Photograph IC: 511B-20345X40 13 / 13 YAESU MUSEN CO., LTD. Fig.5-3 MH-85 (Top View)

FTM-400DR LABEL DRAWING YAESU MUSEN CO., LTD. ID Label drawing Label location Model:FTM-400DR MADE IN JAPAN YAESU MUSEN CO., LTD. IC:511B-20345X40 FCC ID:K6620345X40 2K000001

FCC PART 15 SCANNING RECEIVER Applicant YAESU MUSEN CO., LTD. Address TENNOZU PARKSIDE BUILDING 2-5-8 HIGASHI-SHINAGAWA, SHINAGAWA-KU, TOKYO 140-0002 FCC ID: K6620345X40 Model Number FTM-400DR Product Description SCANNING RECEIVER Date Sample Received 10/26/2012 Date Tested 10/31/2012 Tested By Joe Scoglio Approved By Mario R. de Aranzeta Report Number 2806AUT12TestReport.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, Fl 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Certificate # 0955-01 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620345X40 REPORT #: Y\YAESU\2806AUT12\2806AUT12TestReport.doc Page 2 of 13 TABLE OF CONTENTS GENERAL REMARKS ............................................................................................................. 3 GENERAL INFORMATION ...................................................................................................... 4 TEST EQUIPMENT LIST ......................................................................................................... 5 TEST PROCEDURE ................................................................................................................ 6 RADIATED SPURIOUS EMISSIONS ........................................................................................ 7 POWER LINE CONDUCTED INTERFERENCE ....................................................................... 12 38 dB REJECTION RADIO ................................................................................................... 13 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620345X40 REPORT #: Y\YAESU\2806AUT12\2806AUT12TestReport.doc Page 3 of 13 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 10/31/2012 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620345X40 REPORT #: Y\YAESU\2806AUT12\2806AUT12TestReport.doc Page 4 of 13 GENERAL INFORMATION The test results relate only to the items tested. DUT Description SCANNING RECEIVER FCC ID K6620345X40 Model Number FTM-400DR DUT Power Source 110–120Vac/50– 60Hz DC Power mobile Battery Operated Exclusively Test Item Prototype Pre-Production Production Modifications to DUT None Test Standards FCC Part 15, Subpart B, ANSI C63.4-2003 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620345X40 REPORT #: Y\YAESU\2806AUT12\2806AUT12TestReport.doc Page 5 of 13 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A 12/31/11 12/31/13 Analyzer Open-Frame Tower Preamplifier HP 8449B 3008A01075 07/22/09 09/15/13 Analyzer Open-Frame Tower Quasi- Peak Adapter HP 85650A 2043A00305 10/26/09 09/15/13 Analyzer Open-Frame Tower RF Preselector HP 85685A 3107A01282 07/22/09 09/15/13 Analyzer Open-Frame Tower Spectrum Analyzer HP 8566B/ 85662A 2627A03154/ 2648A14276 07/22/09 09/15/13 Antenna: Biconnical Eaton 94455-1 1057 05/31/11 05/31/13 Antenna: Biconnical Eaton 94455-1 1096 05/04/11 05/04/13 Antenna: Biconnical Electro-Metrics BIA-25 1171 06/13/12 06/13/14 Antenna: Log- Periodic Eaton 96005 1243 05/31/11 05/31/13 Antenna: Log- Periodic Electro-Metrics LPA-25 1122 05/04/11 05/04/13 Antenna: Log- Periodic Electro-Metrics LPA-30 409 06/17/11 06/17/11 LISN Electro-Metrics ANS-25/2 2604 10/28/11 10/28/13 LISN Electro-Metrics EM-7820 2682 02/01/11 02/01/13 Signal Generator HP 8640B 2308A21464 02/23/12 02/23/14 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620345X40 REPORT #: Y\YAESU\2806AUT12\2806AUT12TestReport.doc Page 6 of 13 TEST PROCEDURE General: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. Radiation Interference: The test procedure used was ANSI Standard C63.4-2003 using a spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The video bandwidth was always greater than or equal to the RBW. Formula Of Conversion Factors: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBμV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) Meter Reading + ACF +CL = FS 33 20 dBμV + 10.36 dB/m +0.40 dB =30.76 dBμV/m @ 3m ANSI C63.4-2003 Section 10.1.7 Measurement Procedures: The unit under test was placed on a table 80 cm high and with dimensions of 1mby 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and verticals planes. If power line conducted testing was requi…
