K6620445X20AMATEUR RADIO WITH SCANNING RECEIVER

C4FM FDMA 144/430 MHz DUAL BAND DIGITAL TRANSCEIVER OPERATING MANUAL YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA 6125 Phyllis Drive, Cypress, CA 90630, U.S.A. YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. YAESU HK LTD. Unit 1306-1308, 13F., Millennium City 2, 378 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong FT1DR 2 Before Reading This Manual Before Reading This Manual Contents Recalling a Memory Channel ............................... 41 Recalling the Home Channel ............................... 42 Returning to the Previous Frequency .............. 42 Deleting the Memory Channel ............................. 42 Restoring the Deleted Memory Channel ......... 43 Using Memory Banks ............................................... 43 Registering a Memory Channel in a Memory Bank ..................................................................... 44 Recalling a Memory Bank .................................... 44 Canceling Memory Channel Registration in a Memory Bank ...................................................... 45 Convenient Special Banks ....................................... 45 Registering Your Favorite Special Memory Channels in a Memory Bank ................................ 45 Recalling a Special Bank to Listen to the JR Railway Radio ...................................................... 46 Recalling a Special Bank to Listen to the International VHF (Marine) Radio ........................ 46 Scanning Function ................................................. 48 Using the Scanning Function.................................... 48 VFO Scan ............................................................ 48 Canceling Scanning ........................................ 49 Skipping a Frequency You Do Not Want Scan (Skip Search Memory) .................................... 49 Specifying the Frequency You Do Not Want to Scan ................................................................ 50 Deleting a Frequency Saved in the Skip Search Memory ........................................................... 50 Selecting a Reception Method When Scanning Stops ............................................................... 51 Memory Scanning ................................................ 51 Specifying a Skip/Selected Memory Channel ........................................................................ 53 Scanning Only the Selected Memory Channel ........................................................... 54 Scanning a Memory Bank .................................... 54 Memory Bank Link Scan ................................. 55 Programmable Memory Scan (PMS) ................... 56 Writing into a Programmable Memory ............. 56 Performing Programmable Memory Scan ....... 56 Using the Search Function ....................................... 57 Spectrum Scope Searching for a Signal Using a Signal Strength Graph ....................... 57 Using the GPS Function ........................................ 58 What is GPS? ........................................................... 58 Activating the GPS Function..................................... 58 Method of Positioning by GPS.................................. 59 Explanation of GPS Screen and Operation .............. 61 BACK TRACK Function ............................................ 62 Causing the FT1DR to Memorize the Current Point ..................................................................... 62 Using the BACK TRACK Function ....................... 63 Description of the BACK TRACK Function Screen ............................................................................. 63 Before Reading This Manual ................................... 2 Introduction ................................................................. 4 Features of FT1DR ................................................ 4 How to Read This Manual ...................................... 5 Checking Bundled Items ........................................ 5 Safety Precautions (Be Sure to Read) ....................... 6 Names and Functions of Controls ............................ 12 Basic Operation ...................................................... 15 Preparation ............................................................... 15 Installing the Antenna........................................... 15 Attaching the Supplied Belt Clip/Protective Cap ............................................................................. 15 Attaching the Protective Cap ........................... 15 Installing the Belt Clip ...................................... 15 Attaching a Hand Strap ........................................ 16 How to Use the Battery Case (FBA-39) (Option) ............................................................................. 16 Installing/Removing the Battery Pack .................. 17 Installing the Battery Pack ............................... 17 Removing the Battery Pack ............................. 17 Charging the Battery Pack ................................... 18 Connecting an External Power Supply for Use in Vehicle ................................................................. 20 Connecting to an External Power Supply Using a Power Cable ........................................................ 21 Communication......................................................... 23 Turning on the Power ........................................... 23 Adjusting the Volume Level.................................. 24 Selecting an Operating Band ............................... 25 Selecting a Frequency Band ................................ 27 Tuning in to a Frequency ..................................... 28 Performing Communication ................................. 29 Listening to the Radio ............................................... 30 Listening to an AM or FM Broadcast .................... 30 To deactivate the radio function ....................…

Text truncated - open the document above for the full version.

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 22, 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046, USA Re: FT1DR (FCC ID: K6620445X20) Gentlemen: A. Part 15.19 & 15.21 Compliance Statement Drawing: B. Part 15.19 & 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on inside cover 3) Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager 40mm 97mm 1. Changes or modifications to this device not expressly approved YAESU MUSEN could void the user’s authorization to operate this device. 2. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions; (1) This device may not cause harmful interference, and (2) this device must accept any interference including interference that may cause undesired operation. 3. The scanning receiver in this equipment is incapable of tuning, or readily being altered, by the user to operate within the frequency bands allocated to the Domestic public Cellular Telecommunications Service in the Part 22.

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 22, 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: FT1DR (FCC ID: K6620445X20) Gentlemen: The scanner receiver equipment meets the requirements of the FCC Rules, 15.121(a). Compliance is achieved through the following methods: The scanner receiver in this equipment is incapable of tuning, or readily being altered, by the User to operate within the frequency bands allocated to the Domestic Public Cellular Telecommunications Service in Part 22. Blocking of the cellular frequencies is implemented in the firmware of the unit’s main control central processing unit (CPU). Coverage of 824 – 849 MHz and 869 – 894 MHz is completely blocked, since it is done in the microprocessor, and cannot be re-enabled by any user-accessible procedure, including diode, resistor, or jumper changes, nor by connection of any external device such as a personal computer, nor by installation of any “special” enabling semiconductor device. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 22, 2012 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: FT1DR (FCC ID: K6620445X20) Pursuant to Sections 0.457 (d) (1) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: Confidential ・ Block Diagram ・ Schematics ・ Parts List ・ Alignment ・ Internal Photos Short-Term Confidential ・ Operating Manual ・ External Photos These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (1) (ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Front View With Antenna Rear View With Antenna / Without Belt Clip FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Front View Without Antenna Rear View Without Antenna / With Belt Clip FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Left Side View Right Side View FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Right Side View Remove the Cover To p Vi e w FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Bottom View Rear View Without Battery Pack FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Battery Pack (Inside) Battery Pack with Belt Clip FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. Antenna Desktop Charger FT1DR External Photos FCC ID: K6620445X20 / IC: 511B-20445X20 YAESU MUSEN CO., LTD. AC Adapter Microphone

FT1DRFT1DR LABEL DRAWINGLABEL DRAWING YAESU MUSEN CO., LTD.YAESU MUSEN CO., LTD. ID Label drawing Model:FT1DR Label location CAUTION Label drawing 2:1 2:1 FCC ID: K6620445X20 IC: 511B-20445X20 YAESU MUSEN CO., LTD. MADE IN JAPAN SER NO 00000000 WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIOTELPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES AND FEDERAL LOW.

FCC PART 15 SCANNING RECEIVER Applicant YAESU MUSEN CO., LTD. Address TENNOZU PARKSIDE BUILDING 2-5-8 HIGASHI-SHINAGAWA, SHINAGAWA-KU, TOKYO 140-0002 FCC ID: K6620445X20 Model Number FT1DR Product Description AMATEUR RADIO WITH SCANNING RECEIVER Date Sample Received 7/5/2012 Date Tested 7/20/2012 Tested By Joe Scoglio Approved By Mario R. de Aranzeta Report Number 1677AUT12TestReport.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, Fl 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Certificate # 0955-01 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620445X20 REPORT #: Y\YAESU\1677AUT12\1677AUT12TestReport.doc Page 2 of 15 TABLE OF CONTENTS GENERAL REMARKS ............................................................................................................... 3 GENERAL INFORMATION ........................................................................................................ 4 TEST EQUIPMENT LIST ........................................................................................................... 5 TEST PROCEDURE .................................................................................................................. 6 RADIATED SPURIOUS EMISSIONS .......................................................................................... 7 POWER LINE CONDUCTED INTERFERENCE......................................................................... 10 38 Db REJECTION RADIO ..................................................................................................... 15 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620445X20 REPORT #: Y\YAESU\1677AUT12\1677AUT12TestReport.doc Page 3 of 15 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 7/20/2012 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620445X20 REPORT #: Y\YAESU\1677AUT12\1677AUT12TestReport.doc Page 4 of 15 GENERAL INFORMATION The test results relate only to the items tested. DUT Description AMATEUR RADIO WITH SCANNING RECEIVER FCC ID K6620445X20 Model Number FT1DR DUT Power Source 110–120Vac/50– 60Hz DC Power 7’4V BATTERY Battery Operated Exclusively Test Item Prototype Pre-Production Production Modifications to DUT None Test Standards FCC Part 15, Subpart B, ANSI C63.4-2003 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620445X20 REPORT #: Y\YAESU\1677AUT12\1677AUT12TestReport.doc Page 5 of 15 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A 12/31/11 12/31/13 3-Meter OATS TEI N/A N/A 12/31/11 12/31/13 3-Meter Semi- Anechoic Chamber Panashield N/A N/A 12/31/11 12/31/13 Analyzer Silver Tower Quasi-Peak Adapter HP 85650A 3303A01844 11/23/10 11/23/12 Analyzer Silver Tower RF Preselector HP 85685A 2926A00983 11/10/10 11/10/12 Analyzer Silver Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 11/10/10 11/10/12 Antenna: Biconnical Eaton 94455-1 1057 05/31/11 05/31/13 Antenna: Biconnical Eaton 94455-1 1096 05/04/11 05/04/13 Antenna: Biconnical Electro- Metrics BIA-25 1171 06/13/12 06/13/14 Antenna: Log-Periodic Eaton 96005 1243 05/31/11 05/31/13 Antenna: Log-Periodic Electro- Metrics LPA-25 1122 05/04/11 05/04/13 LISN Electro- Metrics ANS-25/2 2604 10/28/11 10/28/13 LISN Electro- Metrics EM-7820 2682 02/01/11 02/01/13 Signal Generator HP 8640B 2308A21464 02/23/12 02/23/14 APPLICANT: YAESU MUSEN CO., LTD. FCC ID: K6620445X20 REPORT #: Y\YAESU\1677AUT12\1677AUT12TestReport.doc Page 6 of 15 TEST PROCEDURE General: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. Radiation Interference: The test procedure used was ANSI Standard C63.4-2003 using a spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The video bandwidth was always greater than or equal to the RBW. Formula Of Conversion Factors: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBμV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) Meter Reading + ACF +CL = FS 33 20 dBμV + 10.36 dB/m +0.40 dB =30.36 dBμV/m @ 3m ANSI C63.4-2003 Section 10.1.7 Measurement Procedures: The unit under test was placed on a table 80 cm high and with dimensions of 1mby 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and verticals planes. If power line conducted testing was required for this device, th…

Text truncated - open the document above for the full version.
