K6630193X20Marine Transceiver

FCC ID: K6630193X20 IC ID: 511B-30193X20 Operating Manual 1/39 Vertex Standard Co., Ltd. Congratulations on your purchase of the HX600S! Whether this is your first portable marine VHF transceiver, or if you have other STANDARD HORIZON equipment, the STANDARD HORIZON organization is committed to ensuring your enjoyment of this high performance transceiver, which should provide you with many years of satisfying communications even in the harshest of environments. STANDARD HORIZON technical support personnel stands behind every product sold, and we invite you to contact us should you require technical advice or assistance. We appreciate your purchase of the HX600S, and encourage you to read this manual thoroughly, so as to learn and fully understand the capabilities of the HX600S. WARNING This radio is capable of transmitting on VHF Marine. The FCC allows the use of VHF Marine band on water areas only. However the FCC does not allow the use of the VHF Marine band when on land. If persons use the VHF Marine Band on land and interfere with others communicating, the FCC will be notified and search for the interference. Responsible parties found to be transmitting on the VHF Marine Band on land could be fined up to $10,000 for the first offense. The FCC does however prohibit the use in aircraft. FCC ID: K6630193X20 IC ID: 511B-30193X20 Operating Manual 2/39 Vertex Standard Co., Ltd. SAFETY TRANING INFORMATION This Radio has been tested and complies with the Federal Communications Commission (FCC) RF exposure limits for Occupational Use/Controlled exposure environment. In addition, it complies with the following Standards and Guidelines: - FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation. - FCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. - ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3kHz to 300 GHz. - ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave. WARNING: This radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as Occupational Use Only, meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards. This radio is not intended for use by the General Population in an uncontrolled environment. CAUTION: To ensure that your expose to RF electromagnetic energy is within the FCC allowable limits for occupational use, always adhere to the following guidelines: - This radio is NOT approved for use by the general population in an uncontrolled environment. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control its RF exposure conditions. - When transmitting, hold the radio in a vertical position with its microphone 1 to 2 inches (2.5 to 5 cm) away from your mouth and keep the antenna at least 1 inch (2.5cm) away from your head and body. - The radio must be used with a maximum operating duty cycle not exceeding 50 %, in typical Push-to-Talk (PTT) configurations. DO NOT transmit for more than 50 % of total radio use time (50 % duty cycle). Transmitting more than 50 % of the time can cause FCC RF exposure compliance requirements to be exceeded. The radio is transmitting when the red LED on the top of the radio is illuminated. You can cause the radio to transmit by pressing the PTT button. - DO NOT transmit when the radio is used in Body Worn configuration with the following FCC ID: K6630193X20 IC ID: 511B-30193X20 Operating Manual 3/39 Vertex Standard Co., Ltd. accessory: belt-clip. It must be used ONLY for (1) there is a 4 cm distance from the body during transmitting, (2) monitoring purposes, using the speaker only and (3) for carrying purposes. - Always use VERTEX STANDARD authorized accessories. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to assure that this radio operates with the FCC RF exposure limits of this radio. Electromagnetic Interference/Compatibility During transmissions, this radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. Do not operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, health care facilities, aircraft, and blasting sites. NOTE This radiotelephone complies with the requirements of RTCM Paper 56-95/SC101 Standards for digital selective calling (DSC) for Marine transceivers. FCC AND CANADA RADIO LICENSE INFORMATION Standard Horizon radios comply with the Federal Communication Commission (FCC) and Industry-Canada requirements that regulate the Maritime Radio Service. MARITIME STATION LICENSE An FCC ship station license is no longer required for any vessel traveling in U.S. waters which uses a VHF marine radio, RADAR or EPIRB, and which is not required to carry radio equipment. However, any vessel required to carry a marine radio on an international voyage, carrying a HF single side band radiotelephone or marine satellite terminal. FCC license forms, including applications for ship (506) and land station licenses can be downloaded via the Internet at www.fcc.gov/forms. To obtain a form from the FCC, call (888) 225-5322. MARINE RADIO CALL SIGN Currently the FCC does not require recreational boaters to have a Ship Radio Station License. The USCG recommends the boats registration number and the state to be used. FCC ID: K6630193X20 IC ID: 511B-30193X20 Operating Manual 4/39 Vertex Standard Co., Ltd. CANADIAN SHIP STATION LICENSING You may need a license when traveling in Canada. If you do need a licen…

Text truncated - open the document above for the full version.

October 19, 2005 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: HX600S/HX500S (FCC ID: K6630193X20) Pursuant to Sections 0.457 (d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: ・ Block Diagram ・ Schematics These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

October 19, 2005 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX600S/HX500S (FCC ID: K6630193X20) Gentlemen: A. Part 15.21 Compliance Statement Drawing: B. Part 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on inside back cover) Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device. 20mm 97mm

October 19, 2005 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX600S/HX500S (FCC ID: K6630193X20) Gentlemen: The equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. Programming of this product’s transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personal. The operator cannot be program transmit frequencies using the equipment’s external operation controls. Sincerely, Vertex Standard Co., Ltd. Mr. Moto Kurihara Group Leader of Engineering Division

FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Front view with Antenna Rear view with Antenna FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Front view without Antenna Rear view without Antenna FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Left view Right view FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Top view Bottom view FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Battery Pack Battery Pack FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Top of Battery Charger (CD-30) Bottom of Battery Charger FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Top of AC Adapter (PA-38B) Bottom of AC Adapter FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Antenna Speaker/Microphone (CMP460) FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Speaker/Microphone (MH-57A4B) VOX Headset (VC-24) FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Earpiece Microphone (VC-27)

HX600SHX600S LABEL DRAWINGLABEL DRAWING Vertex Standard Co., Ltd.Vertex Standard Co., Ltd. ID / Part 15.19 and CAUTION drawings ID drawing Part 15.19 and CAUTION drawings Label location HX600S K6630193X20 511B-30193X20 4909959000000 ! ! Device restricted to occupational use to satisfy FCC RF exposure compliance. See owner's manual for specific operating requirement CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Removed Front Panel Side-A of MAIN-UNIT with LCD FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Side-A of MAIN-UNIT without LCD Side-B of MAIN-UNIT FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. LCD LCD FCC ID: K6630193X20 IC ID: 511B-30193X20 Vertex Standard Co., Ltd. Inside of front panel Inside of chassis

FCC ID: K6630193X20 IC ID: 511B-30193X20 Circuit Description 1/3 Vertex Standard Co., Ltd. HX600S Circuit Description Receiver Signal Flow The HX600S includes two receiver front ends, each optimized for a particular frequency range and mode combination. Duplexer Signals between 0.5 and 1.8 MHz received at the antenna terminal pass through a first low-pass filter composed of L1039, L1040, C1300 and C1301. Received VHF bands signals, after passing through a low-pass filter to the T/R switch circuit composed of diode switch D1048, D1049. VHF Bands Reception Received VHF bands signals pass through the Duplexer circuit, low-pass filter/high-pass filter circuit, T/R switch circuit, and protector diode D1050 before additional filtering by a high-pass filter prior to application to RF amplifier Q1065. The amplified RF signal is passed through the band-pass filter to first mixer Q1042. Meanwhile, VHF output from the VCO is applied through diode Band switch D1025 and T/R switch D1026 to mixer Q1042 as the first local signal. The TUNE-voltage from the D/A converter Q1014 is amplified by DC amplifier Q1037 and Q1039, and applied to varactors D1033, D1035, D1038, D1039, D1028, D1029, D1036, D1037, D1040, and D1041 in the variable frequency band-pass filters. By changing the electrostatic capacitance of the varactors, optimum filter characteristics are provided for each specific operating frequency. 0.5 - 1.8 MHz Reception Received MW signals pass through the Duplexer circuit, low-pass filter circuit, protector diode D1057 before additional filtering by a band-pass filter prior to application to RF amplifier Q1079. The amplified RF signal is pass through the band-pass filter to first mixer Q1074. Meanwhile, MW output from the VCO is applied through diode Band switch D1024 to mixer Q1074 as the first local signal. The TUNE-voltage from the D/A converter Q1034 is amplified by DC amplifier Q1037, Q1039 and applied to varactor D1055 in the variable frequency band-pass filters. By changing the electrostatic capacitance of the varactor, optimum filter characteristics are provided for each specific operating frequency. First Intermediate Frequency (Narrow FM / AM) The 47.25 MHz first intermediate frequency from first mixers for AM and FM-narrow signals is passed through NAR/WIDE switch D1056 and 47.25 MHz monolithic crystal filter (MCF) XF1001 to narrow IF amplifier Q1072 for input to pin 16 of Narrow IF IC Q1063 after amplitude limiting by D1045. Meanwhile, a portion of the output of 11.7 MHz crystal X1001 is multiplied fourfold by Q1070 and Q1077 to provide the 46.8 MHz second local signal, applied to the Narrow IF IC. Within the IC, this signal is mixed with the 47.25 MHz first intermediate frequency signal to produce the 450 kHz second intermediate frequency. This second IF is filtered by ceramic filter CF1001 and amplified by the limiting amplifier within the Narrow IF IC before quadrate detection by ceramic discriminator CD1001. Demodulated audio is output from pin 9 of the Narrow IF IC through narrow mute analog switch Q1047 before de-emphasis at Q1053. The demodulated audio signal from the Q1063 passes through a band-pass filter and squelch gate Q1029. The resulting audio is amplified by AF amplifier Q1009 and output through MIC/EAR jack J1001 to internal speaker or an external earphone. First Intermediate Frequency (Wide FM) The 45.8 MHz first intermediate frequency from first mixers for Wide FM signals is passed through NAR/WIDE switch D1056 and IF amplifier Q1080 and second mixer FCC ID: K6630193X20 IC ID: 511B-30193X20 Circuit Description 2/3 Vertex Standard Co., Ltd. Q1073. The 10.7 MHz intermediate frequency product of the mixer is delivered to the 10.7 MHz ceramic filter CF1002 passed through NAR/WIDE switch D1046 for input to pin 16 of IF IC Q1063 after amplitude. Meanwhile, a portion of the output of 11.7 MHz crystal X1001 is multiplied threefold by Q1082 to provide the 35.1 MHz second local signal, applied to the second mixer Q1073. Within the second mixer, this signal is mixed with the 45.8 MHz first intermediate frequency signal to produce the 10.7 MHz second intermediate frequency. Meanwhile, a portion of the output of 11.7 MHz crystal X1001 is amplitude by Q1070 and Q1077 to provide the 11.7 MHz third local signal, applied to the IF IC. Within the IC, this signal is mixed with the 10.7 MHz second intermediate frequency signal to produce the 450 kHz third intermediate frequency. Demodulated audio is output from pin 9 of the Narrow IF IC through narrow mute analog switch Q1047 before de-emphasis at Q1053. The demodulated audio signal from the Q1063 passes through a band-pass filter and squelch gate Q1029. The resulting audio is amplified by AF amplifier Q1009 and output through MIC/EAR jack J1001 to internal speaker or an external earphone. Squelch Control Signal components in the neighborhood of 15 kHz contained in the discriminator output pass through an active band-pass filter composed of R1226, R1230, R1239, C1176, C1182 and the operational amplifier between pins 7 and 8 within IF IC Q1063. They are then rectified by D1032 and D1034 to obtain a DC voltage corresponding to the level of noise. This voltage is input to pin 16 of CPU Q1026, which compares the input voltage with a previously set threshold. When the input voltage drops below the threshold, normally due to the presence of a carrier, turning on squelch gate Q1029 and allowing any demodulated audio to pass. At the same time, Q1002 and/or Q1004 and/or Q1006 goes on, causing the BUSY/TX lamp D1009 to light. Transmitter Signal Flow Transmit/Receive Switching Closing PTT switch S1002 pulls the base of Q1008 low, causing the collector to go high. This signal is input to pin 22 (PTT) of CPU Q1026, allowing the CPU to recognize that the PTT switch has been pushed. When the CPU detects closure of the PTT switch, pin 31 (TX/RX) goes high. This control signal is switches Q1083. At the same time, PLL division data is input to PLL IC Q102…

Text truncated - open the document above for the full version.

Page 1/3 HX600S Address Device name DescriptionTYP VALUE [MAIN-UNIT] Q 1001 Transistor 2SC4617 Q 1002 Transistor FMMTL618TA Q 1003 ICTLP281 Q 1004 Transistor FMMTL618TA Q 1005 Transistor CPH6202 Q 1006 Transistor FMMTL618TA Q 1007 Transistor 2SC4617 Q 1008 Transistor DTA144EE Q 1009 ICTDA2822D Q 1010 ICNJM12902V Q 1011 Transistor UMD5N Q 1012 Transistor FMMTL718TA Q 1014 ICM62364FP Q 1015 Transistor 2SJ347 Q 1016 Transistor 2SA1774 Q 1017 Transistor 2SC4617 Q 1020 ICBR24L64F Q 1022 Transistor HN1J02FU Q 1023 Transistor DTC143ZE Q 1024 Transistor DTC143ZE Q 1025 Transistor DTC144EE Q 1026 ICLC87F7BC8A-F56G2 Q 1027 ICMB15A01PFV1 Q 1028 Transistor 2SJ364 Q 1029 ICNJM12902V Q 1031 Transistor DTC143ZE Q 1032 Transistor DTC144EE Q 1033 ICBU4094BCFV Q 1034 Transistor 2SC5555ZD Q 1036 Transistor 2SC4617 Q 1037 Transistor 2SA1774 Q 1039 Transistor UMW1N Q 1040 Transistor 2SC5555ZD Q 1041 Transistor DTC144EE Q 1042 Transistor 3SK318 Q 1043 Transistor UMA4N Q 1044 Transistor UMD5N Q 1045 ICNJM12904R Q 1046 Transistor 2SC4617 Q 1047 Transistor 2SJ364 Q 1048 Transistor 2SC5226-5 Q 1049 Transistor 2SC4617 Q 1051 Transistor UMD5N Q 1052 ICS-80835CNMC-B8U Q 1053 Transistor DTC144EE Q 1054 ICNJM2125F Q 1055 Transistor 2SC4617 Q 1056 Transistor 2SK3475 Q 1057 ICNJM2211M Q 1058 ICS-812C35AUA-C2P Q 1059 Transistor UMW1N Q 1060 Transistor CPH6102 Q 1061 Transistor UMA4N Q 1062 Transistor DTC144EE Q 1063 ICTA31136FN Q 1064 Transistor 2SC4617 Q 1065 Transistor 2SC5555ZD Q 1066 Transistor 2SK3476 Q 1067 Transistor UMB3N Q 1068 Transistor UMA4N Q 1069 Transistor DTC144EE Q 1070 Transistor 2SC4617 FCC ID: K6630193X20 IC ID: 511B-30193X20 Semi-Conductor Parts List Vertex Standard Co., Ltd. Page 2/3 HX600S Address Device name DescriptionTYP VALUE FCC ID: K6630193X20 IC ID: 511B-30193X20 Semi-Conductor Parts List Q 1071 Transistor UMB3N Q 1072 Transistor 2SC4915 Q 1073 Transistor 2SC4915 Q 1074 Transistor 2SC4617 Q 1075 Transistor 2SC4617 Q 1076 Transistor UMB3N Q 1077 Transistor 2SC4915 Q 1078 Transistor DTC144EE Q 1079 Transistor 2SC4915 Q 1080 Transistor 2SC4915 Q 1081 Transistor DTC144EE Q 1082 Transistor 2SC4915 Q 1083 Transistor UMD5N D 1001 LED19-215UYOC/S530A2 D 1002 LED19-215UYOC/S530A2 D 1003 LEDBRPG1211C-TR D 1004 LED19-215UYOC/S530A2 D 1005 Zener Diode UDZS TE-17 5.1B D 1006 Diode1SS400 D 1007 LED19-215UYOC/S530A2 D 1008 LED19-215UYOC/S530A2 D 1009 LEDSDDF01000A1 D 1010 LED19-215UYOC/S530A2 D 1011 LEDCL-191WA-D-T D 1012 LED19-215UYOC/S530A2 D 1013 DiodeDA221 D 1014 Diode1SS400 D 1015 Varactor Diode 1SV325 D 1016 DiodeHSC277 D 1017 DiodeHVC359 D 1018 DiodeHSC277 D 1019 Diode1SS400 D 1020 DiodeHSC277 D 1021 DiodeDAN222 D 1022 DiodeDAN222 D 1023 Varactor Diode 1SV325 D 1024 Diode1SS400 D 1025 Diode1SS400 D 1026 DiodeDAN222 D 1027 DiodeRB751S-40 D 1028 Varactor Diode 1SV325 D 1029 Varactor Diode 1SV325 D 1030 DiodeDA221 D 1031 DiodeDA221 D 1032 DiodeDA221 D 1033 Varactor Diode HVC369B D 1034 DiodeDA221 D 1035 Varactor Diode HVC369B D 1036 Varactor Diode 1SV325 D 1037 Varactor Diode 1SV325 D 1038 Varactor Diode HVC369B D 1039 Varactor Diode HVC369B D 1040 Varactor Diode 1SV325 D 1041 Varactor Diode 1SV325 D 1042 Diode1SS400 D 1043 DiodeRB521S-30 D 1044 DiodeDA221 D 1045 DiodeDA221 D 1046 DiodeDAN222 D 1047 Diode1SS400 D 1048 DiodeRLS135 D 1049 Diode1SV307 D 1050 Diode1SS302 Vertex Standard Co., Ltd. Page 3/3 HX600S Address Device name DescriptionTYP VALUE FCC ID: K6630193X20 IC ID: 511B-30193X20 Semi-Conductor Parts List D 1051 DiodeDA221 D 1053 Diode1SS400 D 1054 DiodeDA221 D 1055 Varactor Diode KV1520 D 1056 DiodeDAP222 D 1057 Diode1SS302 D 1058 DiodeDA221 D 1059 Diode1SS400 D 1060 Diode1SS400 D 1061 Diode1SS400 D 1062 Diode1SS400 Vertex Standard Co., Ltd.

Page 1 of 34 REPORT ON Radio testing of the STANDARD HORIZON HX600S In accordance with ANSI/TIA/EIA-603, RSS-182 October 2005Report number TA00023 5 Vertex Standard Co., Ltd. GENERAL INFORMATION TRANSMITTERS x Switchable Variable N/ A RＥＣＥＩＶERS This re port was prepared by Vertex Standard Co., Ltd. 50 1.5[A] Collector Voltage:7.2[V] 2000 10 DC 65 ANSI/TIA/EIA-603 156.050 to163.425 50 1st 2nd Date 20 / October /200 5 Test performed by M.Kurihara INPUT IMPEDANCE (MIC): MAXIMUM POWER RATING: INPUT IMPEDANCE (RF): INTERMEDIATE FREQUENCIES: FREQUENCY RANGE: OUTPUT IMPEDANCE (RF): Collector Current: Report number TA000235 Page 2 of 3 EUT DESCRIPTION: 7.2 5L000001 [V] HX600S K6630193X2 0 STANDARD HORIZON MODEL NAME: [W]AUDIO OUTPUT POWER: OUTPUT IMPEDANCE (SP):[Ω]8 0.4 [Ω] [MHz] [kHz] -47.25 -450 [MHz] [W] [Ω] [Ω] [MHz] [W] 16K0G3E, 16K0G2B( for Distres s POWER OUTPUT RATING: 156 1 157.4to to5 TYPE OF EMISSION: FREQUENCY RANGE: RSS-182 VOLTAGE RQUIREMENTS: SERIAL NUMBER: SPECIFICATION ARE REFERENCE D NUMBER OF CHANNELS: FCC ID: TRADE NAME: FM Transceive r MANUFACTURER:Vertex Standard Co., Ltd. IC ID:511B-30193X2 0 Vertex Standard Co., Ltd. Report number TA000235Page 3 of 34 HX600S Channel Settin gs HILOW 1CH16156.800156.80025k5W1W 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Power Transmit Frequency [MHz] CH No. Receive Frequency [MHz] CH Spacing Shown on LCD Vertex Standard Co., Ltd. NAME OF TEST:R.F. Power Output (Conducted) SPECIFICATION:47 CFR 2.1046 (a) GUIDE:ANSI/TIA/EIA-603, Paragraph 2.2.1 TEST EQUIPMENT: As per attached page The EUT was connected to a resistive coaxial attenuator of normal load impedance, and the modulated output powerwas measured by means of an R.F. power meter. Measurement accuracy is ± 4% Report number TA000235 Page 4 of 34 MEASUREMENT PROCEDURE 156.80016 1.020 1. 2. MEASUREMENT RESULTS 156.800 CHANNEL R.F. POWER, WATTS 16 HIGHLOW NOMINAL, MHz 5.040 28.4 dBm (ERP) Vertex Standard Co., Ltd. (1) COAXUAL ATTENUATORWEINSCHELL 49-10-43KL458 (2) RF COUPLERADVANTEST TR415339730008 (3) POWER SENSORAgilent 8482B2349A02533 (4) POWER METERAgilent 8901B POWER MODE3026A02806 (5) FREQUENCY COUNTERAgilent 8901B FREQUENCY MODE3026A02806 (2) Serial Numbe rInstruments Test Sample Report number TA000235 Page 5 of 3 4 TRANSMITTER POWER CONDUCTED MEASUREMENTS Power Supply TEST 1: R.F. POWER OUTPUT TEST 2: FREQUENCY STABILIT Y (4)(3)(1) Description (5) Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) SPECIFICATION:47 CFR 2.1051 GUIDE: ANSI/TIA/EIA-603, Paragraph 2.2.13 TEST EQUIPMENT:As per attached page The emissions were measured for the worst case as follows: (a): within a band of frequencies defined by the carrier frequency plus and minus one channel. (b): from the lowest frequency generated in the EUT and to at least the 10th harmonic of the carrier frequency, or 40GHz, whichever is lower. The magnitude of spurious emissions that are attenuated more than 20dB below the permissible value need not be specified. MEASUREMENT RESULTS: FREQUENCY OF CARRIER, MH z=,, SPECTRUM SEARCHED, GHz=0 to 10 x F c MAXIMUM RESPONSE, Hz= ALL OTHER EMISSIONS=>= 20dB BELOW LIMIT 156.80 2500 Report number TA000235 Page 6 of 3 4 0 MEASUREMENT PROCEDURE 3. 1. 2. Vertex Standard Co., Ltd. Test Sample (2) COAXUAL ATTENUATORAgilent 8498A1801A02723 (1) AUDIO GENERATORAgilent 8903B2742A03633 (1) DescriptionSerial Numbe r (3) SPECTRUM ANALYZER (2) COAXUAL ATTENUATOR Instruments KL458 Power Supply ADVANTEST TR417385580005 WEINSCHELL 49-10-43 (2)(3) TRANSMITTER SPURIOUS EMISSION TEST 1: OCCUPIED BANDWIDTH (IN-BAND SPURIOUS) TEST 2: OUT-OF-BAND SPURIOUS Report number TA000235 Page 7 of 3 4 Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(43+10xLOG(P))=(Watts) -(43+10xLOG(P))=(Watts) High Power -27.8-64.814.8 MARGIN, dBmdBcdBTUNED, MHz 156.8000 1 FREQUENC Y EMISSION, MHz 313.6000 FREQUENC Y -505 Report number TA000235 Page 8 of 3 4 -43 LEVEL,LEVEL, Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(43+10xLOG(P))=(Watts) -(43+10xLOG(P))=(Watts) Low Power dBc LEVEL,MARGIN, 1 dB 5 Report number TA000235 Page 9 of 3 4 FREQUENCYFREQUENCYLEVEL, TUNED, MHzEMISSION, MH zdBm -50 -43 Vertex Standard Co., Ltd. NAME OF TEST:Field Strength of Spurious Radiation SPECIFICATION:47 CFR 2.1053 (a) GUIDE:ANSI/TIA/EIA-603, Paragraph 1.2.12 Definition: Radiated spurious emissions are emissions from the equipment when transmitting load on a frequency or frequencies which are outside an occupied band sufficient to ensure transmission of information of required quality for the class of communications desired. Method of measuremen t Connect the equipment as illustrated. Adjust the spectrum analyzer for the following settings: 1)Resolution Bandwidth <= 3kHz 2)Video Bandwidth >= 10kHz 3)Sweep Speed <= 2000Hz/second 4)Detector Mode = Positive Peak Place the transmitter to be tested on the turntable in the standard test site. The transmitter is transmitting into a non-radiating load which is placed on the turntable. The RF cable to this load should be of minimum length. STANDARD TEST SITE For each spurious measurment the test antenna should be adjusted to the correct length for the frequency involved. This length maybe determined from a calibration ruler supplied with the equipment. Measurements shall be made from the lowest radio frequency generated in the equipment to the tenth harmonic of the carrier, except for the region close to the carrier qeual to ± the test bandwidth (see section 1.3.4.4). For each s purious frequency, raise and lower the test antenna from 1 m to 4 m to obtain a maximum readin g on the spectrum analyzer with the test antenna at horizontal polarity. MEASUREMENT PROCEDURE 1.2.12.1 Test antenna B) A) 1.2.12. 2 Report number TA000235 Page 10 of 3 C) TRANSMITTER UNDER TEST STANDARD TRANSMITTER LOAD SPECTRUM ANALYZER D) E) Vertex Standard Co., Ltd. NAME OF TEST:Field Strength of Spurious Radiation Repeat step E) for each spurious f…

Text truncated - open the document above for the full version.
