K6630323X30HANDHELD MARINE TRANSCEIVER

FCC ID:K6630323X30 IC ID:511B-30323X30 Operating Manual Vertex Standard Co.,Ltd. 1 HX750S Operating Manual Congratulations on your purchase of the HX750S! Whether this is your first portable marine VHF transceiver, or if you have other STANDARD HORIZON equipment, the STANDARD HORIZON organization is committed to ensuring your enjoyment of this high performance transceiver, which should provide you with many years of satisfying communications even in the harshest of environments. STANDARD HORIZON technical support personnel stands behind every product sold, and we invite you to contact us should you require technical advice or assistance. We appreciate your purchase of the HX750S, and encourage you to read this manual thoroughly, so as to learn and fully understand the capabilities of the HX750S. WARNING This radio is capable of transmitting on VHF Marine. The FCC allows the use of VHF Marine band on water areas only. However the FCC does not allow the use of the VHF Marine band when on land. If persons use the VHF Marine Band on land and interfere with others communicating, the FCC will be notified and search for the interference. Responsible parties found to be transmitting on the VHF Marine Band on land could be fined up to $10,000 for the first offense. The FCC does however prohibit the use in aircraft. RF EXPOSURE SAFETY STATEMENT SAFETY INFORMATION Your wireless handheld portable transceiver contains a low power transmitter. When the Push-to-Talk (PTT) button is pushed, the transceiver sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission adopted RF exposure guidelines with safety levels for hand-held wireless devices. This device is authorized to operate at a duty factor not to exceed 50% (this corresponds to 50% transmission time and 50% reception time). WARNING: To maintain compliance with the FCC’s RF exposure guidelines, this transmitter and its antenna must maintain a separation distance of at least 1 inch (2.5 centimeters) from your face. Speak in a normal voice, with the antenna pointed up and away from the face at the required separation distance. If you use a headset accessory for this radio, with the radio worn on your body, use only the Vertex Standard belt clip for this transceiver, and ensure that the antenna is at least 1 inch (2.5 centimeters) from your body when transmitting. Use only the supplied antenna. Unauthorized antennas, modifications, or attachments could damage the transmitter, and may violate FCC regulations. NOTE This radio telephone complies with the requirements of RTCM Paper 56-95/SC101 Standards for digital selective calling (DSC) for Marine transceivers. FCC ID:K6630323X30 IC ID:511B-30323X30 Operating Manual Vertex Standard Co.,Ltd. 2 FCC AND CANADA RADIO LICENSE INFORMATION Standard Horizon radios comply with the Federal Communication Commission (FCC) and Industry-Canada requirements that regulate the Maritime Radio Service. MARITIME STATION LICENSE An FCC ship station license is no longer required for any vessel traveling in U.S. waters which uses a VHF marine radio, RADAR or EPIRB, and which is not required to carry radio equipment. However, any vessel required to carry a marine radio on an international voyage, carrying a HF single side band radiotelephone or marine satellite terminal. FCC license forms, including applications for ship (506) and land station licenses can be downloaded via the Internet at www.fcc.gov/forms. To obtain a form from the FCC, call (888) 225-5322. MARINE RADIO CALL SIGN Currently the FCC does not require recreational boaters to have a Ship Radio Station License. The USCG recommends the boats registration number and the state to be used. CANADIAN SHIP STATION LICENSING You may need a license when traveling in Canada. If you do need a license contact their nearest field office or regional office or write: Industry Canada Radio Regulatory Branch Attn: DOSP 300 Slater Street Ottawa, Ontario Canada, KIA 0C8 FCC/INDUSTRY CANADA INFORMATON The following data pertaining to the transceiver is necessary to fill out the license application. FCC Type Accepted: Part 80 Output Power with FNB-V99LI: 1 W (Low), 2.5 W (Mid) ,5 W (High) , and 6 W (Nor) Emission: 16K0G3E, 16K0G2B Frequency Range: 156.025 to 163.275MHz FCC Type Number: Industry Canada Type Approval: FCC ID:K6630323X30 IC ID:511B-30323X30 Operating Manual Vertex Standard Co.,Ltd. 3 FCC NOTICE Unauthorized changes or modifications to this equipment may void compliance with FCC Rules. Any change or modification must be approved in writing by STANDARD HORIZON, a Marine Division of VERTEX STANDARD. NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ˆ Increase the separation between the equipment and receiver. ˆ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ˆ Consult the dealer or an experienced marine electronics technician for help. 1. GENERAL INFORMATION 1.1 INTRODUCTION The HX750S is a SUBMERSIBLE miniature 6-Watt portable two way marine transceiver. The transceiver has all allocated USA, International, or Canadian channels. It has emergency channel 16 which can be immediately selected from any channel by pressing the [16/9] key. NOAA Weather chan…

Text truncated - open the document above for the full version.

November 17, 2005 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: HX750S (FCC ID: K6630323X30) Pursuant to Sections 0.457 (d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: ・ Block Diagram ・ Schematics These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, Vertex Standard Co., Ltd Yukimasa Tomita Director of Engineering Division

November 17, 2007 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX750S (FCC ID: K6630323X30) Gentlemen: Part 15.19 Compliance Statement is placed on the rear of case. Sincerely, Vertex Standard Co., Ltd. Yukimasa Tomita Director of Engineering Division

November 17, 2007 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX750S (FCC ID: K6630323X30) Gentlemen: A. Part 15.21 Compliance Statement Drawing: B. Part 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on the back cover page) Sincerely, Vertex Standard Co., Ltd. Yukimasa Tomita Director of Engineering Division Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device. 20mm 97mm

FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Front view with Antenna Rear view with Antenna FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Front view without Antenna Rear view without Antenna FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Right view Left view FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Top view Bottom view FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Battery Pack(FNB-99Li) Battery Pack(FNB-99Li) FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Top of Battery Charger (CD-39) Side of Battery Charger(CD-39) FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Top of AC Adapter (NC-88B) Bottom of AC Adapter FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Antenna Speaker/Microphone (CMP460) FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Speaker/Microphone (MH-57A4B) VOX Headset (VC-24) FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Earpiece Microphone (VC-27)

HX750SHX750S LABEL DRAWINGLABEL DRAWING Vertex Standard Co., Ltd.Vertex Standard Co., Ltd. ID / Part 15.19 and CAUTION drawings ID drawing Part 15.19 and CAUTION drawings Label location HX750S K6630323X30 511B-30323X30 4909959000000 ! ! Device restricted to occupational use to satisfy FCC RF exposure compliance. See owner's manual for specific operating requirement CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Removed Rear Panel Side-A of MAIN-UNIT with LCD FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Side-A of MAIN-UNIT without LCD Side-B of MAIN-UNIT Without chassis FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Side-B of MAIN-UNIT With chassis LCD(Front) FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. LCD(Back) Inside of front panel FCC ID:K6630323X30 IC ID: 511B-30323X30 Vertex Standard Co., Ltd. Inside of Rear panel Inside of chassis

FCC ID: K6630323X30 IC ID: 511B-30323X30 Circuit Description 1/3 Vertex Standard Co., Ltd. HX750S Circuit Description Receiver Signal Flow VHF Bands Reception Received VHF bands signals pass through the low-pass filter/high-pass filter circuit, T/R switch circuit composed of diode switch D1040 (RLS135), D1041 (RSL135), and protector diode D1042 (1SS400) before additional filtering by a high-pass filter prior to application to RF amplifier Q1043 (2SC5006). The amplified RF signal is passed through the band-pass filter to first mixer Q1035 (3SK318). Meanwhile, VHF output from the VCO is applied through diode Band switch D1024 (DAN235E) to mixer Q1035 as the first local signal. First Intermediate Frequency The 47.25 MHz first intermediate frequency from first mixers is passed through 47.25 MHz monolithic crystal filter (MCF) XF1001 to IF amplifier Q1042 (2SC4915-0) for input to pin 16 of Narrow IF IC Q1040 (NJM2591V) after amplitude limiting by D1037 (DA221). Meanwhile, a portion of the output of 11.7 MHz crystal X1001 is multiplied fourfold by Q1037 (2SC4915) to provide the 46.8 MHz second local signal, applied to the IF IC. Within the IC, this signal is mixed with the 47.25 MHz first intermediate frequency signal to produce the 450 kHz second intermediate frequency. This second IF is filtered by ceramic filter CF1001 (LTWC450F) and amplified by the limiting amplifier within the IF IC before quadrate detection by ceramic discriminator CD1001 (JTBC450C7). Demodulated audio is output from pin 9 of the IF IC Q1040 The demodulated audio signal from the Q1040 is Passed Through a band-pass filter and de-emphasis filter to the volume control IC Q1018 (BU502FS) The audio signal passed through the volume control IC to the audio power amplifier Q1001 (TDA2822D), providing up to 0.7 W to 16 Ohm loudspeaker. Squelch Control Signal components in the neighborhood of 15 kHz contained in the discriminator output pass through an active band-pass filter composed of R1211, R1213, R1214, C1172, C1182 and the operational amplifier between pins 7 and 8 within IF IC Q1040. They are then rectified by D1031 and D1033 (both DA221) to obtain a DC voltage corresponding to the level of noise. This voltage is input to pin 16 of CPU Q1017 (LC87F5BP8A-F56G2), which compares the input voltage with a previously set threshold. If the DC squelch control voltage is “High” microprocessor Q1017(LC87F5BP8A-F56G2)control Pin 22 of volume control IC Q1018(BU2502FS) goes “LOW”, this disabling the AF audio. Also, the microprocessor steps scanning, if active, and allows audio to pass through the volume control IC Q1018 (BU2502FS) FCC ID: K6630323X30 IC ID: 511B-30323X30 Circuit Description 2/3 Vertex Standard Co., Ltd. Transmitter Signal Flow Transmit/Receive Switching Closing PTT switch S1001 pulls the base of Q1003 (2SA1744R) low, causing the collector to go high. This signal is input to pin 22 (PTT) of CPU Q1017, allowing the CPU to recognize that the PTT switch has been pushed. When the CPU detects closure of the PTT switch, pin 31 (TX/RX) goes high. This control signal is switches Q1044 (UMD5N). At the same time, PLL division data is input to PLL IC Q1019 (LV2105V) from the CPU, to disable the receiver power saver. Also, switching Q1041 (UMD5N) to disable the receiver circuits. Then causing the red side of BUSY/TX lamp D1016 to light. Modulation Voice signal input from either built-in microphone MC1001 (CZ034DP363) or external jack J1001 is pre-emphasized by C1014 and R1021, and processed by microphone amplifier Q1007 (NJM12902AV), IDC (instantaneous deviation control) circuit to prevent over-modulation, and active low-pass filter. Transmission Modulating audio passes through deviation setting D/A converter Q1018 to MOD of the VCO. This signal is applied to varactor D1021 (HSC277) in the tank circuit of VCO Q1020 (2SC5231), which oscillates at the desired transmitting frequency. The modulated VCO signal is buffered by amplifier Q1021 (2SC5555) and delivered through T/R diode switch D1024. The modulated low-level transmit signal from the VCO is applied to amplifier Q1030 (2SC5226-5). The modulated transmit signal from the VCO is amplified by Q1033 (RD01MUS1) and RF power amplifier Q1039 (RD09MUP2) up to 6 W. The RF output passes through TX diode switch D1040. RF output is passed by T/R switch and low-pass filter to suppress harmonics and spurious products before output to the antenna at the antenna terminal. PLL Frequency Synthesizer PLL IC Q1019 consists of a data shift register, reference frequency divider, phase comparator, charge pump, intermittent operation circuit, and band selector switch. Serial PLL data from the CPU is converted into parallel data by the shift register in the PLL IC and is latched into the comparative frequency divider and reference frequency divider to set a frequency dividing ratio for each. An 11.7 MHz reference signal produced by X1001 is input to REF pin 1 of the PLL IC. The internal reference frequency divider divides the 11.7 MHz reference by 2,340 (or 1,872) to obtain a reference frequency of 5 kHz (or 6.25 kHz), which is applied to the phase comparator. Meanwhile, a sample of the output of VCO Q1021 is input to the PLL IC, where it is frequency-divided by the internal comparative frequency divider to produce a comparative frequency also applied to the phase comparator. The phase comparator compares the phase between the reference frequency and comparative frequency to output a pulse corresponding to the phase difference between them. This pulse is input to the charge pump, and the output from the charge pump passes through a loop filter composed of L1005, R1138, C1106, R1140, C1109, R1143, and FCC ID: K6630323X30 IC ID: 511B-30323X30 Circuit Description 3/3 Vertex Standard Co., Ltd. C1112, which convert the pulse into a corresponding smoothed varactor control voltage (VCV). The VCV is applied to varactor D1019 and D1020 (HVC350B) in the VCO tank circuit to eliminate phase difference between the …

Text truncated - open the document above for the full version.

FCC ID: K6630323X30 IC ID: 511B-30323X30 Alignment 1/4 Vertex Standard Co., Ltd. HX750S Alignment All component replacement and service should be performed only by an authorized STANDARD HORIZON representative, or the warranty policy may be voided. The following procedures cover the sometimes critical and tedious adjustments that are not normally required once the transceiver has left the factory. However, if damage occurs and some parts are replaced, realignment may be required. If a sudden problem occurs during normal operation, it is likely due to component failure; realignment should not be done until after the faulty component has been replaced. We recommend that servicing be performed only by authorized STANDARD HORIZON service technicians who are experienced with the circuitry and fully equipped for repair and alignment. Therefore, if a fault is suspected, contact the dealer from whom the transceiver was purchased for instructions regarding repair. Authorized STANDARD HORIZON service technicians realign all circuits and make complete performance checks to ensure compliance with factory specifications after replacing any faulty components. Those who do undertake any of the following alignments are cautioned to proceed at their own risk. Problems caused by unauthorized attempts at realignment are not covered by the warranty policy. Also, STANDARD HORIZON must reserve the right to change circuits and alignment procedures in the interest of improved performance, without notifying owners. Under no circumstances should any alignment be attempted unless the normal function and operation of the transceiver are clearly understood, the cause of the malfunction has been clearly pinpointed and any faulty components replaced, and the need for realignment determined to be absolutely necessary. The following test equipment (and thorough familiarity with its correct use) is necessary for complete realignment. Correction of problems caused by misalignment resulting from use of improper test equipment is not covered under the warranty policy. While most steps do not require all of the equipment listed, the interactions of some adjustments may require that more complex adjustments be performed afterwards. Do not attempt to perform only a single step unless it is clearly isolated electrically from all other steps. Have all test equipment ready before beginning, and follow all of the steps in a section in the order presented. Required Test Equipment ο Radio Tester with calibrated output level at 200 MHz ο In-line Wattmeter with 5% accuracy at 200 MHz ο 50 Ω, 10 W RF Dummy Load ο Regulated DC Power Supply adjustable from 3 to 15 VDC, 2A ο Frequency Counter: ±0.2 ppm accuracy at 200 MHz ο AF Signal Generator ο AC Voltmeter ο DC Voltmeter: high impedance ο VHF Sampling Coupler Alignment Preparation & Precautions A 50 Ω RF load and in-line wattmeter must be connected to the main antenna jack in all procedures that call for transmission, except where specified otherwise. Correct alignment is not possible with an antenna. After completing one step, read the next step to see if the same test equipment is required. If not, remove the test equipment (except dummy load and wattmeter, if connected) before proceeding. Correct alignment requires that the ambient temperature be the same as that of the transceiver and test equipment, and that this temperature be held constant between 20 ~ 30 °C (68 ~ 86 °F). When the transceiver is brought into the shop from hot or cold air, it should be allowed some time to come to room temperature before alignment. Whenever possible, alignments should be made with oscillator shields and circuit boards firmly affixed FCC ID: K6630323X30 IC ID: 511B-30323X30 Alignment 2/4 Vertex Standard Co., Ltd. in place. Also, the test equipment must be thoroughly warmed up before beginning. Set up the test equipment as shown below for transceiver alignment, apply 7.4 VDC power to the transceiver. Notes: signal levels in dB referred to in alignment are based on 0 dBμ = 0.5 μV (closed circuit). PLL Section PLL Reference Frequency ˆ Connect the wattmeter, dummy load, and frequency counter to the antenna jack. ˆ Set the transceiver to CH16 (156.800 MHz) then turn the transceiver off. ˆ Press and hold in the PTT , [SQL], [▲] and [▼] key while turn the transceiver on to enter the alignment mode. ˆ Press the [▼] or [▲] key to select the display to [rEF xx]. ˆ Press the [MEM] key to enable adjustment of the PLL Reference Frequency. ˆ Press the PTT key to transmit the transceiver, if necessary, press the [ ▼ ] or [ ▲ ] key to adjust the frequency so the counter frequency is 156.800 MHz (±100 Hz). ˆ Press the [MEM] key to save the new setting. ˆ Press and hold the [PWR] key for 2 seconds to turn the transceiver off. Receiver Section Squelch Hysteresis Adjustment ˆ Connect the Radio Tester to the antenna jack. ˆ Set the transceiver to CH16 (156.800 MHz) then turn the transceiver off. ˆ Press and hold in the PTT , [SQL] , [▲] and [▼] key while turn the transceiver on to enter the alignment mode. ˆ Press the [ ▼ ] or [ ▲ ] key to select the display to [ HS xx]. ˆ Press the [MEM] key to enable adjustment of this Alignment Mode. ˆ Press the [ ▼ ] or [ ▲ ] key to adjust the hysteresis level. ˆ Press the [MEM] key to save the new setting. Squelch Threshold Adjustment ˆ Adjust the Radio Tester output level -12 dBμ (with a standard FM modulation: ±3.0 kHz deviation @ 1 kHz) at 156.800 MHz. ˆ Press the [ ▼ ] or [ ▲ ] key to select the display to [ TH xx]. ˆ Press the [MEM] key to read the Squelch Threshold data. ˆ Press the [MEM] key to save the new setting. Squelch Tight Adjustment ˆ Adjust the Radio Tester output level -4 dBμ (with a standard FM modulation: ±3.0 kHz deviation @ 1 kHz) at 156.800 MHz. ˆ Press the [ ▼ ] or [ ▲ ] key to select the display to [TI xxx]. ˆ Press the [MEM] key to read the Squelch Tight data. ˆ Press the [MEM] key again to save the new setting. ˆ Press the hold the [PWR] key for 2 second…

Text truncated - open the document above for the full version.

1 FCC ID: K6630323X30/IC ID: 511B-30323X30 HX750SSemi-Conductor Parts List Address Parts Code Device NameDescriptionTYP VAL MAIN-UNIT D 1001 G2070998 Zener DiodeEDZ TE-61 5.1B D 1002 G2070998 Zener DiodeEDZ TE-61 5.1B D 1003 G2071096 LED19-213/S2C-AN1P2B/3T D 1004 G2071096 LED19-213/S2C-AN1P2B/3T D 1005 G2070634 Diode1SS400 TE61 D 1006 G2071096 LED19-213/S2C-AN1P2B/3T D 1009 G2071096 LED19-213/S2C-AN1P2B/3T D 1010 G2071096 LED19-213/S2C-AN1P2B/3T D 1012 G2071096 LED19-213/S2C-AN1P2B/3T D 1013 G2071096 LED19-213/S2C-AN1P2B/3T D 1014 G2070634 Diode1SS400 TE61 D 1015 G2071096 LED19-213/S2C-AN1P2B/3T D 1016 G2070860 LEDCL-165HR/YG-D-T D 1017 G2071174 LEDWH104S(TAPE) D 1018 G2070634 Diode1SS400 TE61 D 1019 G2070596 DiodeHVC350B-TRF-E D 1020 G2070596 DiodeHVC350B-TRF-E D 1021 G2070584 DiodeHSC277TRF-E D 1022 G2070848 Diode1SV325(TPH3.F) D 1023 G2070634 Diode1SS400 TE61 D 1024 G2070612 DiodeDAN235E TL D 1025 G2070178 DiodeDA221 TL D 1028 G2070634 Diode1SS400 TE61 D 1029 G2070178 DiodeDA221 TL D 1031 G2070178 DiodeDA221 TL D 1032 G2070634 Diode1SS400 TE61 D 1033 G2070178 DiodeDA221 TL D 1034 G2070634 Diode1SS400 TE61 D 1037 G2070178 DiodeDA221 TL D 1039 G2070752 DiodeRB715F T106 D 1040 G2070128 DiodeRLS135 TE-11 D 1041 G2070128 DiodeRLS135 TE-11 D 1042 G2070634 Diode1SS400 TE61 D 1043 Q9000867 Surge Absorber EZAEG3A50AV DS1001 G6090186 LCDAM032N Q 1001 G1091542 ICTDA2822D013TR Q 1002 G3117748R Transistor2SA1774 TL R Q 1004 G3070334 TransistorFMMTL618TA Q 1005 G3346178R Transistor2SC4617 TL R Q 1006 G3070343 TransistorUMD5N TR Q 1007 G1093592 ICNJM12902V-TE1 Q 1009 G3070335 TransistorFMMTL718TA Q 1010 G3070284 TransistorRT2C00M-T111-1E Q 1011 G3070247 TransistorRT1N441U-T11-1 Q 1012 G3117748R Transistor2SA1774 TL R Q 1013 G3070343 TransistorUMD5N TR Q 1014 G1093876 ICBR24L64F-WE2 Q 1015 G3346178R Transistor2SC4617 TL R Q 1016 G3117748R Transistor2SA1774 TL R Q 1017 G1094209 ICLC87F7BC8A-F56G2-E Q 1018 G1094524 ICBU2502FS(TAPE) Q 1019 G1093191 ICLV2105V-TLM Q 1020 G3352318H Transistor2SC5231C8-TL Vertex Standard Co.,Ltd. 2 FCC ID: K6630323X30/IC ID: 511B-30323X30 HX750SSemi-Conductor Parts List Address Parts Code Device NameDescriptionTYP VAL Q 1021 G3355557 Transistor2SC5555ZD-TR Q 1022 G1094009 ICLM2902PWR Q 1023 G3117748R Transistor2SA1774 TL R Q 1024 G3346178R Transistor2SC4617 TL R Q 1025 G3346178R Transistor2SC4617 TL R Q 1026 G3070247 TransistorRT1N441U-T11-1 Q 1027 G3346178R Transistor2SC4617 TL R Q 1028 G3070247 TransistorRT1N441U-T11-1 Q 1029 G3346178R Transistor2SC4617 TL R Q 1030 G3352268E Transistor2SC5226-5-TL Q 1031 G1093672 ICS-812C35AUA-C2P-T2G Q 1032 G1093606 ICS-80835CNMC-B8U-T2-G Q 1033 G3070321 MOSFETRD01MUS1-T113 Q 1034 G1094009 ICLM2902PWR Q 1035 G4803188 MOSFET3SK318 TL Q 1036 G3117748R Transistor2SA1774 TL R Q 1037 G3349158O Transistor2SC4915-O(TE85L.F) Q 1038 G1094097 ICTAR5S50U(TE85L.F) Q 1039 G3070367 MOSFETRD09MUP2(TAPE) Q 1040 G1094024 ICNJM2591V-TE1 Q 1041 G3070343 TransistorUMD5N TR Q 1042 G3349158O Transistor2SC4915-O(TE85L.F) Q 1043 G3350068 Transistor2SC5006-T1 Q 1044 G3070343 TransistorUMD5N TR Q 1046 G1094010 ICLM2904PWR Vertex Standard Co.,Ltd.

Page 1 of 31 REPORT ON Radio testing of the STANDARD HORIZON HX750S In accordance with ANSI/TIA/EIA-603, RSS-182 November 2007Report number TA00056 4 Vertex Standard Co., Ltd. GENERAL INFORMATION TRANSMITTERS x Switchable Variable N/ A RＥＣＥＩＶERS This re port was prepared by Vertex Standard Co., Ltd. 50 1.7[A] Collector Voltage:7.4[V] 2000 10 DC 65 ANSI/TIA/EIA-603 156to163.275 50 1st 2nd Date 22 / November /200 7 Test performed by Shige.Takahashi INPUT IMPEDANCE (MIC): MAXIMUM POWER RATING: INPUT IMPEDANCE (RF): INTERMEDIATE FREQUENCIES: FREQUENCY RANGE: OUTPUT IMPEDANCE (RF): Collector Current: Report number TA000564 Page 2 of 3 1 EUT DESCRIPTION: 7.4 7K000001 [V] HX750S K6630323X3 0 STANDARD HORIZON MODEL NAME: [W]AUDIO OUTPUT POWER: OUTPUT IMPEDANCE (SP):[Ω]16 0.7 [Ω] [MHz] [kHz] 47.25 450 [MHz] [W] [Ω] [Ω] [MHz] [W] 16K0G3E POWER OUTPUT RATING: 156 1 157.425to to6 TYPE OF EMISSION: FREQUENCY RANGE: RSS-182 VOLTAGE RQUIREMENTS: SERIAL NUMBER: SPECIFICATION ARE REFERENCE D NUMBER OF CHANNELS: FCC ID: TRADE NAME: FM Transceive r MANUFACTURER:Vertex Standard Co., Ltd. IC ID:511B-30323X3 0 Vertex Standard Co., Ltd. Report number TA000564Page 3 of 31 HX750S Channel Settin gs HILOW 1CH16156.800156.80025k6W1W 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Power Transmit Frequency [MHz] CH No. Receive Frequency [MHz] CH Spacing Shown on LCD Vertex Standard Co., Ltd. NAME OF TEST:R.F. Power Output (Conducted) SPECIFICATION:47 CFR 2.1046 (a) GUIDE:ANSI/TIA/EIA-603, Paragraph 2.2.1 TEST EQUIPMENT: As per attached page The EUT was connected to a resistive coaxial attenuator of normal load impedance, and the modulated output powerwas measured by means of an R.F. power meter. Measurement accuracy is ± 4% Report number TA000564 Page 4 of 31 MEASUREMENT PROCEDURE 156.80016 1.060 1. 2. MEASUREMENT RESULTS 156.800 CHANNEL R.F. POWER, WATTS 16 HIGHLOW NOMINAL, MHz 5.720 23.0 dBm (ERP) Vertex Standard Co., Ltd. Report number TA000564 Page 5 of 31 (1) COAXUAL ATTENUATORWEINSCHELL 49-10-43*** (2) RF COUPLERADVANTEST TR4153*** (3) POWER SENSORAgilent 8482B*** (4) POWER METERAgilent 8901B POWER MODE*** (5) FREQUENCY COUNTERAgilent 8901B FREQUENCY MODE*** (2) Serial Numbe rInstruments Test Sample TRANSMITTER POWER CONDUCTED MEASUREMENTS Power Supply TEST 1: R.F. POWER OUTPUT TEST 2: FREQUENCY STABILIT Y (4)(3)(1) Description (5) Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) SPECIFICATION:47 CFR 2.1051 GUIDE: ANSI/TIA/EIA-603, Paragraph 2.2.13 TEST EQUIPMENT:As per attached page The emissions were measured for the worst case as follows: (a): within a band of frequencies defined by the carrier frequency plus and minus one channel. (b): from the lowest frequency generated in the EUT and to at least the 10th harmonic of the carrier frequency, or 40GHz, whichever is lower. The magnitude of spurious emissions that are attenuated more than 20dB below the permissible value need not be specified. MEASUREMENT RESULTS: FREQUENCY OF CARRIER, MH z=,, SPECTRUM SEARCHED, GHz=0 to 10 x F c MAXIMUM RESPONSE, Hz= ALL OTHER EMISSIONS=>= 20dB BELOW LIMIT Report number TA000564 Page 6 of 31 156.80 2. 2600 3. 1. MEASUREMENT PROCEDURE 0 Vertex Standard Co., Ltd. Report number TA000564 Page 7 of 31 Test Sample (2) COAXUAL ATTENUATORAgilent 8498A*** (1) AUDIO GENERATORAgilent 8903B*** (1) DescriptionSerial Numbe r (3) SPECTRUM ANALYZER (2) COAXUAL ATTENUATOR Instruments *** Power Supply ADVANTEST TR4173*** WEINSCHELL 49-10-43 (2)(3) TRANSMITTER SPURIOUS EMISSION TEST 1: OCCUPIED BANDWIDTH (IN-BAND SPURIOUS) TEST 2: OUT-OF-BAND SPURIOUS Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(43+10xLOG(P))=(Watts) -(43+10xLOG(P))=(Watts) High Power Report number TA000564 Page 8 of 31 MARGIN, dBmdBcdBTUNED, MHz 1 FREQUENC Y EMISSION, MHz FREQUENCY -516 -43 LEVEL,LEVEL, Vertex Standard Co., Ltd. NAME OF TEST:Unwanted Emissions (Conducted) LIMIT'S), dBc:-(43+10xLOG(P))=(Watts) -(43+10xLOG(P))=(Watts) Low Power Report number TA000564 Page 9 of 31 dBc LEVEL,MARGIN, 1 dB 6 FREQUENC YFREQUENCYLEVEL, TUNED, MHzEMISSION, MH zdBm -51 -43 Vertex Standard Co., Ltd. NAME OF TEST:Field Strength of Spurious Radiation SPECIFICATION:47 CFR 2.1053 (a) GUIDE:ANSI/TIA/EIA-603, Paragraph 1.2.12 Definition: Radiated spurious emissions are emissions from the equipment when transmitting load on a frequency or frequencies which are outside an occupied band sufficient to ensure transmission of information of required quality for the class of communications desired. Method of measuremen t Connect the equipment as illustrated. Adjust the spectrum analyzer for the following settings: 1)Resolution Bandwidth <= 3kHz 2)Video Bandwidth >= 10kHz 3)Sweep Speed <= 2000Hz/second 4)Detector Mode = Positive Peak Place the transmitter to be tested on the turntable in the standard test site. The tr…

Text truncated - open the document above for the full version.
