K6630563X20HANDHELD MARINE TRANSCEIVER

Page 1HX100/HX150 HX100/HX150 Floating VHF FM Marine Transceiver Owner’s Manual HX100/HX150Page 2 TABLE OF CONTENTS Quick Reference Guide ....................................................................................................................................3 1. GENERAL INFORMATION ........................................................................................................................ 4 1.1 INTRODUCTION............................................................................................................................ 4 1.2 SAFETY INFORMATION .............................................................................................................. 5 2. ACCESSORIES ..........................................................................................................................................6 2.1 PACKING LIST .............................................................................................................................. 6 3. ABOUT THIS RADIO ................................................................................................................................ 8 3.1 ABOUT THE VHF MARINE BA ND ............................................................................................ 8 3.2 ABOUT WA TER RESISTANCE ................................................................................................... 8 3.3 DISTRESS AND HAILING ( CHANNEL 16 ) ................................................................................ 8 3.4 CALLING ANOTHER VESSEL ( CHANNEL 16 OR 9 ) ............................................................... 9 3.5 OPERATING ON CHANNEL 13 ................................................................................................ 10 3.6 OPERATING ON CHANNEL 67 ................................................................................................ 10 3.7 SIMPLEX / DUPLEX CHANNEL USE ........................................................................................ 10 3.8 AUTOMATED RADIO CHECK S ERVICE .................................................................................. 11 4. GETTING STARTED ................................................................................................................................ 12 4.1 RADIO CARE ............................................................................................................................... 12 4.2 BATTERIES AND CHARGERS .................................................................................................. 12 4.2.1 BATTERY SAFETY ......................................................................................................... 13 4.2.2 BATTERY INSTALLATION / REMOVAL .......................................................................... 14 4.2.3 BATTERY CHARGING .................................................................................................... 15 4.3 BELT CLIP INSTALLATION / REMOVAL ................................................................................... 16 CONTROLS AND INDICATORS ....................................................................................................................17 5.1 CONTROLS AND SWITCHES ................................................................................................... 17 5.2 LCD INDICATORS ...................................................................................................................... 20 6. BASIC OPERATION ................................................................................................................................ 22 6.1 PROHIBITED COMMUNICATIONS ............................................................................................ 22 6.2 INITIAL SETUP ........................................................................................................................... 22 6.3 RECEPTION ................................................................................................................................ 22 6.4 TRANSMISSION .......................................................................................................................... 23 6.4.1 TRANSMIT TIME-OUT TIMER ( TOT ) .............................................................................. 23 6.5 USA, CANADIAN, AND INTERNATIONAL CHANNELS .......................................................... 24 6.6 KEYPAD LOCK ........................................................................................................................... 24 6.7 NOAA WEATHER CHANNELS .................................................................................................. 24 6.7.1 NOAA WEATHER ALERT ................................................................................................ 25 6.7.2 NOAA WEATHER ALERT TESTING ................................................................................ 25 6.8 PRESET CHANNELS ( 0 ~ 9 ) : INSTANT ACCESS ................................................................... 26 6.8.1 PROGRAMMING ............................................................................................................. 26 6.8.2 OPERATION ..................................................................................................................... 26 6.8.3 DELETING A PRESET CHANNEL ................................................................................ 26 6.9 SCANNING .................................................................................................................................. 27 6.9.1 PROGRAMMING SCAN MEMORY ............................................................................... 27 6.9.2 SELECTING SCAN TYPE .............................................................................................. 27 6.9.3 OPERATION ..................................................................................................................... 28 6.9.3.1 Priority Scan .........................…

Text truncated - open the document above for the full version.

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 27, 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX150 (FCC ID: K6630563X20) Gentlemen: Part 15.19 Compliance Statement is placed on the rear of case. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 27, 2012 Federal Communications Commission Authorization and Evaluation Division, 7435 Oakland Mills Road Columbia, MD 21046 USA Re: HX150 (FCC ID: K6630563X20) Gentlemen: A. Part 15.21 Compliance Statement Drawing: B. Part 15.21 Compliance Statement Drawing Location: IN OPERATION MANUAL (location on the Cover 3) Sincerely, YAESU MUSEN CO., LTD. Shoji Mukawa Engineering Division Manager Part 15.21: Changes or modifications to this device not expressly approved by YAESU MUSEN could void the user’s authorization to operate this device. 20mm 120mm

Tel: 81-(0)3-6711-4121・Fax: 81-(0)3-6711-4278 YAESUMUSENCO.,LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan June 27, 2012 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: HX150 (FCC ID: K6630563X20) Pursuant to Sections 0.457 (d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requires confidential treatment of some of the information accompanying this Application, as listed below: ・ Block Diagram ・ Schematics These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for this Application. Sincerely, YAESU MUSEN CO., LTD. Shouji Mukawa Engineering Division Manager

FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 1 Front view with Antenna Rear view with Antenna and Belt Clip FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 2 Front view Rear view with Battery and Belt Clip FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 3 Right view Left view FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 4 Top view Bottom view FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 5 Battery Pack (FNB-124LI) Battery Pack (FNB-124LI) FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 6 Battery Cover Battery Cover (Inside)) FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 7 AC Adapter (PA-48) Charger (CD-57) FCC ID:K6630563X20 HX150 External Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. 8 Bottom of Charger (CD-57) Belt Clip (Clip-24)

HX150HX150 LABEL DRAWINGLABEL DRAWING YAESU MUSEN Co., Ltd.YAESU MUSEN Co., Ltd. ID / Part 15.19 and CAUTION drawings ID drawing Part 15.19 and CAUTION drawings Label location Model: HX150 4909959000000 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. YAESU MUSEN CO., LTD. MADE IN CHINA FCC ID:K6630563X20 IC: 511B-30563X20 00000000

FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. Side-A of MAIN-UNIT with LCD Side-A of MAIN-UNIT without LCD FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. Side-B of MAIN-UNIT with chassis Side-B of MAIN-UNIT without chassis FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. View of chassis View of chassis FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. LCD (Front) LCD (Back) FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. Inside of front case Inside of rear case FCC ID:K6630563X20 HX150 Internal Photos IC: 511B-30563X20 YAESU MUSEN Co., Ltd. Inside of Charger (CD-57)

FCC ID: K6630563X20 IC: 511B-30563X20 Circuit Description 1/1 YAESU MUSEN Co., Ltd. HX150 Circuit Description 1. Receive Signal Path Incoming RF from the antenna is delivered to the RF Unit and passes through a low-pass filter consisting of coils L1001, L1002, L1003 and L1004,capacitors C1012, C1016, C1019,C1024 and C1036. Signals within the frequency range of the transceiver enter a band-pass filter consisting of coils L1007, L1009, L1010 and L1012, capacitors C1043, C1047, C1049, L1051 and C1053, then amplified by Q1010. The amplified RF is delivered to single chip transciver IC Q1015. 2. Audio Amplifier The demodulated audio signal from the Q1015 passes through the audio power amplifier Q1019, providing up to 500 mW of audio power to the 16ohm loudspeaker. 3. Squelch Control Squelch control is automatically performed by Q1015. The internal Electric audio volume is controlled by a RSSI level. Q1013 controls audio power amplifier Q1019 in response to the control signal from Q1015. 4. Transmit Signal Path The speech input from the microphone MC1001 passes through the pre-emphasis circuit to Q1011, which contains the IDC. The audio signal is applied to Q1015, which has passed through the low-pass filter. The filtered audio signal is frequency modulation inside the Q1015. The modulated signal from the Q1015 is then passes through the buffer amplifier Q1012, driver amplifier Q1009, then amplified transmit signal is applied to the final amplifier Q1008 up to 5.0 watts output power. The transmit signal then passes through the antenna switch D1004 and is low-pass filtered to suppress harmonic spurious radiation before delivery to the antenna. 4-1 Automatic Transmit Power Control Current from the final amplifier is sampled by C1018 and C1021, and R1003 and R1009, and is rectified by D1003. The resulting DC is feed back through Q1011 to the amplifier Q1008 and Q1009 for control of the power output. When the microprocessor selects ”High” or “Low” power levels, pin 4 of Q1013 voltage is generated according to the power levels. 5. Q1015 Single chip tansceiver IC RDA1846 The RDA1846 is a highly integrated single-chip transceiver for Walkie Talkie applications. It totally realizes the translation from RF carrier to voice in the RX path and from voice to RF carrier in the TX path, requiring only one micro controller. 6. Miscellaneous Circuits Push-To-Talk Transmit Activation When the PTT switch on the main PCB is closed, pin 60 of Q1013 goes low. This signal disables the receiver by disabling the 3.3 V supply bus at Q1005 to the RF amplifier Q1010. At the same time, Q1006 activate the transmit 3.3 V supply line to enable the transmitter.

FCC ID: K6630563X20 IC: 511B-30563X20 Alignment YAESU MUSEN Co., Ltd. 1 HX150 Alignment The HX150 has been carefully aligned at the factory for the specified performance across the marine band. Realignment should therefore not be necessary except in the event of a component failure. All component replacement and service should be performed only by an authorized Standard Horizon representative, or the warranty policy may be voided. The following procedures cover the sometimes critical and tedious adjustments that are not normally required once the transceiver has left the factory. However, if damage occurs and some parts are replaced, realignment may be required. If a sudden problem occurs during normal operation, it is likely due to component failure; realignment should not be done until after the faulty component has been replaced. We recommend that servicing be performed only by authorized Standard Horizon service technicians who are experienced with the circuitry and fully equipped for repair and alignment. Therefore, if a fault is suspected, contact the dealer from whom the transceiver was purchased for instructions regarding repair. Authorized Standard Horizon service technicians realign all circuits and make complete performance checks to ensure compliance with factory specifications after replacing any faulty components. Those who do undertake any of the following alignments are cautioned to proceed at their own risk. Problems caused by unauthorized attempts at realignment are not covered by the warranty policy. Also, Standard Horizon, a division of Yaesu Musen must reserve the right to change circuits and alignment procedures in the interest of improved performance, without notifying owners. Under no circumstances should any alignment be attempted unless the normal function and operation of the transceiver are clearly understood, the cause of the malfunction has been clearly pinpointed and any faulty components replaced, and the need for realignment determined to be absolutely necessary. The following test equipment (and thorough familiarity with its correct use) is necessary for complete realignment. Correction of problems caused by misalignment resulting from use of improper test equipment is not covered under the warranty policy. While most steps do not require all of the equipment listed, the interactions of some adjustments may require that more complex adjustments be performed afterwards. Do not attempt to perform only a single step unless it is clearly isolated electrically from all other steps. Have all test equipment ready before beginning, and follow all of the steps in a section in the order presented. FCC ID: K6630563X20 IC: 511B-30563X20 Alignment YAESU MUSEN Co., Ltd. 2 Required Test Equipment ˆ RF Signal Generator with calibrated output level at 200 MHz ˆ Deviation Meter (linear detector) ˆ AF Millivoltmeter ˆ SINAD Meter ˆ Inline Wattmeter with 5% accuracy at 200 MHz ˆ Regulated DC Power Supply: 0V to 10 VDC, 5A ˆ 50-ohm Non-reactive Dummy Load: 10 W at 200 MHz ˆ Frequency Counter: > 0.1 ppm accuracy at 200 MHz ˆ AF Signal Generator ˆ DC Voltmeter: high impedance ˆ VHF Sampling Coupler ˆ AF Dummy Load: 16 Ohms, 1 W ˆ Oscilloscope ˆ Spectrum Analyzer ˆ HX150 Marine Transceiver Alignment Preparation & Precautions A dummy load and inline wattmeter must be connected to the main antenna jack in all procedures that call for transmission. Correct alignment is not possible with an antenna. After completing one step, read the following step to determine whether the same test equipment will be required. If not, remove the test equipment (except dummy load and wattmeter, if connected) before proceeding. Correct alignment requires that the ambient temperature be the same as that of the transceiver and test equipment, and that this temperature be held constant between 68 °F and 86 °F (20 °C and 30 °C). When the transceiver is brought into the shop from hot or cold air it should be allowed some time for thermal equalization with the environment before alignment. If possible, alignments should be made with oscillator shields and circuit boards firmly affixed in place. Also, the test equipment must be thoroughly warmed up before beginning. Note: Signal levels in dB referred to in this procedure are based on 0 dBμ = 0.5 μV (closed circuit). FCC ID: K6630563X20 IC: 511B-30563X20 Alignment YAESU MUSEN Co., Ltd. 3 Before Alignment ˆ Set up the test equipment as shown below, and set the DC Power Supply voltage to 7.4 V. ˆ Set the channel to CH 16 and SQL "0" Starting the alignment mode ˆ Press and hold in the [16/9], [▲] and [PRESET] key while turning the transceiver on to enter the Alignment Mode. Adjustment of PLL frequency ˆ Connect the frequency counter to the antenna jack. ˆ Press the [SCAN/DW] key till “RE” is displayed. ˆ Press [ ▲ ] or [ ▼ ] keys while pressing the [PTT] key to set the frequency to 156.80000MHz ± 100Hz. ˆ Press [VOL/SQL] key to fix the alignment data. Adjustment of TX High Power ˆ Connect the wattmeter and 50-ohm dummy load to the antenna jack. ˆ Press the [SCAN/DW] key till “HI” is displayed. ˆ Press [ ▲ ] or [ ▼ ] keys while pressing the [PTT] key to set the power to 4.9 ± 0.1W. ˆ Press [VOL/SQL] key to fix the alignment data. Adjustment of TX Low Power ˆ Connect the wattmeter and 50-ohm dummy load to the antenna jack. ˆ Press the [SCAN/DW] key till “Lo” is displayed. ˆ Press [ ▲ ] or [ ▼ ] keys while pressing the [PTT] key to set the power to 0.8 ± 0.1W. ˆ Press [VOL/SQL] key to fix the alignment data. Adjustment of the Maximum Deviation ˆ Connect the linear detector to the antenna jack and connect the AF signal generator to the Alignment Jig. ˆ Set the AF signal output level to 200mVrms at 1kHz ˆ Press the [SCAN/DW] key till “Md” is displayed. ˆ Press [ ▲ ] or [ ▼ ] keys while pressing the [PTT] key to set the deviation to 4.4 ± 0.1kHz. ˆ Press [VOL/SQL] key to fix the alignment data. FCC ID: K6630563X20 IC: 511B-30563X20 Alignment YAESU MUSEN Co., Ltd. 4 …

Text truncated - open the document above for the full version.

1 FCC ID: K6630563X20 / IC: 511B-30563X20 HX150Semi-Conductor Parts List Address Parts Code Device NameDescriptionTYP VAL MAIN-UNIT D 1003 G2070752 DiodeRB715F T106 D 1004 G2070128 DiodeRLS135 TE-11 D 1005 G2070984 DiodeRSX101VA-30TR D 1006 G2070128 DiodeRLS135 TE-11 D 1007 G2070634 Diode1SS400 TE61 D 1008 G2070634 Diode1SS400 TE61 D 1009 G2070078 DiodeIMN10 T108 D 1010 G2071116 LEDSML-512DWT86 D 1011 G2071116 LEDSML-512DWT86 D 1015 G2070906 Zener DiodeUDZS TE-17 3.9B DS1001 G6090218 LCDAM055N Q 1001 G1094549 ICTAR5S33U(TE85L.F) Q 1002 G1093670 ICS-812C30AMC-C2K-T2G Q 1003 G3211327R Transistor2SB1132 T100 R Q 1004 G1094305 ICNJW4100V(TE1) Q 1005 G3070343 TransistorUMD5N TR Q 1006 G3070343 TransistorUMD5N TR Q 1007 G3070075 TransistorDTC144EE TL Q 1008 G3070465 MOSFETNE5550979A Q 1009 G3070467 MOSFETNE5550234 Q 1010 G4802948 FET3SK294(TE85L) Q 1011 G1093969 ICLMV321IDCKR Q 1012 G3352268E Transistor2SC5226-5-TL Q 1013 G1094941 ICR5F2L3AACNFP Q 1015 G1094942 ICRDA1846 Q 1016 G3070102 TransistorDTC143ZE TL Q 1017 G3346178R Transistor2SC4617 TL R Q 1018 G3211327R Transistor2SB1132 T100 R Q 1019 G1094906 ICBH7824FVM-TR Q 1020 G3070075 TransistorDTC144EE TL CHARGE-UNIT D 2001 G2070684 Diode1SR154-400 TE25 D 2002 G2070634 Diode1SS400 TE61 Q 2001 G1094432 ICBA09CC0FP(TAPE) Q 2002 G3070448 MOSFETRRR030P03 Q 2003 G3070075 TransistorDTC144EE TL YAESU MUSEN CO., LTD.

Applicant: Yaesu Musen Co., Ltd. FCC ID: K6630563X20 IC: 511B-30563X20 Model(s): HX150 DUT Type: Portable VHF PTT Marine Radio Transceiver 156.025 - 157.425 MHz 2012 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 37 Date(s) of Evaluation July 25, 2012 Test Report Serial No. 071312K66-T1186-S80V Test Report Revision No. Rev. 1.0 (1st Release) Test Report Issue Date July 27, 2012 Description of Test(s) Specific Absorption Rate RF Exposure Category Gen. Pop. / Uncontrolled Test Lab Certificate No. 2470.01 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION FCC & IC Name CELLTECH LABS INC. Test Lab Information Address 21-364 Lougheed Road, Kelowna, B.C. V1X 7R8 Canada Test Lab Accreditation(s) ISO 17025 A2LA Test Lab Certificate No. 2470.01 Name YAESU MUSEN CO., LTD. Applicant Information Address Tennozu Parkside Bldg., 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo, Japan 140-0002 Application Type(s) FCC TCB Certification IC CB Certification Standard(s) Applied FCC 47 CFR §2.1093 IC Health Canada Safety Code 6 FCC OET 65, Supplement C IC RSS-102 Issue 4 Procedure(s) Applied IEEE 1528-2003 IEC 62209-2:2010 FCC Licensed Non-Broadcast Transmitter Held to Face (TNF) Device Classification(s) IC Maritime Radio Transmitter and Receiver (RSS-182) Device RF Exposure Category FCC/IC General Population / Uncontrolled Environment FCC ID: K6630563X20 Device Identifier(s) IC: 511B-30563X20 Device Model(s) HX150 Test Sample Hardware Revision No. CB6026000 Test Sample Firmware Revision No. V006 Test Sample Serial No. 2I000002 (Identical Prototype) Date of Sample Receipt July 25, 2012 Date(s) of Evaluations July 25, 2012 Device-Under-Test Description (DUT) Portable FM VHF Push-To-Talk (PTT) Marine Radio Transceiver VHF Transmit Frequency Range(s) 156.025 - 157.425 MHz (VHF Marine Band) Manuf. Rated Output Power 5.0 Watts + 0.2 dB High Power setting Measured RF Output Power 5.22 Watts 37.2 dBm Conducted 156.7 MHz (Ch. 14) Battery Type(s) Tested Li-Ion 7.4 V 1030 mAh Model: FNB-124LI Antenna Type(s) Tested Flexible Whip (detachable) Body-worn Accessories Belt-Clip (For carrying purpose only - radio does not contain external audio connector) Max. SAR Level(s) Evaluated Face-held 0.265 W/kg 1g 50% PTT duty factor FCC/IC Spatial Peak SAR Limit Head/Face 1.6 W/kg 1g 50% PTT duty factor General Population / Uncontrolled Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada Safety Code 6 for the General Population / Uncontrolled Exposure environment. The device was tested in accordance with the measurement procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 4, IEEE Standard 1528-2003 and IEC International Standard 62209-2:2010. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results and statements contained in this report pertain only to the device(s) evaluated. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. Test Report Approved By Sean Johnston Lab Manager Celltech Labs Inc. Applicant: Yaesu Musen Co., Ltd. FCC ID: K6630563X20 IC: 511B-30563X20 Model(s): HX150 DUT Type: Portable VHF PTT Marine Radio Transceiver 156.025 - 157.425 MHz 2012 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 37 Date(s) of Evaluation July 25, 2012 Test Report Serial No. 071312K66-T1186-S80V Test Report Revision No. Rev. 1.0 (1st Release) Test Report Issue Date July 27, 2012 Description of Test(s) Specific Absorption Rate RF Exposure Category Gen. Pop. / Uncontrolled Test Lab Certificate No. 2470.01 TABLE OF CONTENTS 1.0 INTRODUCTION____________________________________________________________________4 2.0 SAR MEASUREMENT SYSTEM _______________________________________________________4 3.0 FCC POWER THRESHOLDS FOR PTT DEVICES (F < 0.5 GHZ) _____________________________5 4.0 RF OUTPUT POWER MEASUREMENT _________________________________________________5 5.0 NO. OF TEST CHANNELS (N C ) ________________________________________________________5 6.0 SAR PROBE CALIBRATION & MEASUREMENT FREQUENCIES ____________________________5 7.0 MANUFACTURER’S DISCLOSED ACCESSORY LISTING __________________________________6 8.0 FLUID DIELECTRIC PARAMETERS ____________________________________________________7 9.0 SAR MEASUREMENT SUMMARY _____________________________________________________9 10.0 DETAILS OF SAR EVALUATION _____________________________________________________9 11.0 SAR LEVEL CORRECTION FOR FLUID DEVIATION (IC RSS-102 / IEC 62209-2) _____________10 12.0 SAR EVALUATION PROCEDURES __________________________________________________11 13.0 SYSTEM PERFORMANCE CHECK ___________________________________________________12 14.0 SIMULATED EQUIVALENT TISSUES _________________________________________________13 15.0 SAR LIMITS _____________________________________________________________________13 16.0 ROBOT SYSTEM SPECIFICATIONS__________________________________________________14 17.0 PROBE SPECIFICATION (ET3DV6) __________________________________________________15 18.0 SIDE PLANAR PHANTOM __________________________________________________________15 19.0 BARSKI PLANAR PHANTOM _______________________________________________________15 20.0 DEVICE HOLDER _________________________________________________________________15 21.0 TEST …

Text truncated - open the document above for the full version.

FCC PART 80 AND IC RSS-182 TEST REPORT APPLICANT YAESU MUSEN CO., LTD. TENNOZU PARKSIDE BUILDING 2-5-8 HIGASHI-SHINAGAWA, SHINAGAWA-KU, TOKYO 140-0002 FCC ID K6630563X20 IC CERTIFICATION 511B-30563X20 MODEL NUMBER HX150 PRODUCT DESCRIPTION HANDHELD MARINE TRANSCEIVER DATE SAMPLE RECEIVED 7/11/2012 DATE TESTED 7/16/2012 TESTED BY Nam Nguyen APPROVED BY Mario de Aranzeta TIMCO REPORT NO. 1731AUT12TestReport.doc TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. TABLE OF CONTENTS 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 Applicant: YAESU MUSEN CO., LTD. FCC ID: K6630563X20 IC CERT #: 511B-30563X20 Report: Y\YAESU\1731AUT12\1731AUT12TestReport.doc Page 2 of 19 TABLE OF CONTENTS GENERAL REMARKS ......................................................................................................... 3 GENERAL INFORMATION .................................................................................................. 4 TEST PROCEDURES ......................................................................................................... 5 TECHNICAL DATA ............................................................................................................. 6 RF POWER OUTPUT .......................................................................................................... 7 MODULATION CHARACTERISTICS .................................................................................... 8 AUDIO FREQUENCY RESPONSE ....................................................................................... 9 AUDIO LOW PASS FILTER ............................................................................................... 10 AUDIO INPUT VERSUS MODULATION ............................................................................. 11 OCCUPIED BANDWIDTH ................................................................................................. 12 SPURIOUS EMISSIONS AT ANTENNA TERMINALS (CONDUCTED) ................................... 14 FIELD STRENGTH OF SPURIOUS EMISSIONS ................................................................. 16 FREQUENCY STABILITY .................................................................................................. 18 EMC EQUIPMENT LIST ................................................................................................... 19 Applicant: YAESU MUSEN CO., LTD. FCC ID: K6630563X20 IC CERT #: 511B-30563X20 Report: Y\YAESU\1731AUT12\1731AUT12TestReport.doc Page 3 of 19 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, u…
