K66VX-4000LLow VHF Transceiver

VX-4000 OPERATING MANUAL MANUAL DE OPERACIÓN VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 17210 Edwards Rd., Cerritos, CA 90703, U.S.A. International Division 8350 N.W. 52nd Terrace, Suite 201, Miami, FL 33166, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K. YAESU GERMANY GmbH Am Kronberger Hang 2, D-65824 Schwalbach, Germany VERTEX STANDARD HK LTD. Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong POWER Congratulations! You now have at your fingertips a valuable communications tool - a two-way radio! Rugged, reliable and easy to use, your radio will keep you in constant touch with your colleagues for years to come, with negligible maintenance down time. Please take a few minutes to read this manual carefully. The information presented here will allow you to derive maximum performance from your radio. After reading it, keep the manual handy for quick reference, in case questions arise later on. We’re glad you joined the team. Call on us any time, because our business is communications. Let us help you get your message across. NOTICE There are no user-serviceable points inside this transceiver. All service jobs must be referred to your Authorized Service Center or Network Administrator. Safety / Warning Information WARNING - DO NOT operate the VX-4000L radio when someone (bystanders) outside the vehicle is within 47 inches (1.2 meter) of the antenna. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd. The radio must be used in vehicle-mount configurations with a maximum operating duty factor not exceeding 50%, in typical Push-to-Talk configurations. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure conditions of its passengers and bystanders by maintaining the minimum separation distance of 47 inches (1.2 m). Failure to observe these restrictions will result in exceeding the FCC RF exposure limits. Antenna Installation: For rear deck trunk installation, the antenna must be located at least 47 inches (1.2 m) away from rear seat passengers in order to comply with the FCC RF exposure requirements. For roof top installation, the antenna must be placed in the center of the roof. Page 1 VX-4000 Operating Manual VX-4000 Operating Manual The VX-4000 Series are full-featured FM transceivers designed for flexible mobile and base station business communications in the VHF Low-Band (60/25 Watts: program- mable), VHF High-Band (50/25 Watts: programmable) and UHF (40/25 Watts: program- mable) Land Mobile Bands. Each model is designed for reliable business communica- tions in a wide variety of applications, with a wide range of operating capability provided by its leading-edge design. The 250-channels memories can each be programmed with a 8-character channel name. A 39-tone programmable CTCSS encoder/decoder is built in as standard. Important channel frequency data is stored in EEPROM and flash memory on the CPU, and is easily programmable by dealers using a personal computer and the VERTEX STAN- DARD CT-71 Programming Cable and CE35 Software. Special built-in features include: rThe 250-channels memories can each be programmed with a 8-character channel name. rCTCSS (Continuous Tone Coded Squelch System); rDCS (Digitally Coded Squelch); rExtensive Selective Calling selections; and rTwo sets of scanning channels, one set preset by the dealer and another which is operator-selectable. The pages which follow will detail the many advanced features provided on the VX-4000 transceiver. After reading this manual, you may wish to consult with your Network Ad- ministrator regarding precise details of the configuration of this equipment for use in your application. POWER Page 2 VX-4000 Operating Manual Controls & Connectors Front Panel Å PWR Button Press the button to turn the transceiver ON and OFF. Ç TX Indicator This lamp glows red when the radio is transmitting. É BUSY Indicator This lamp glows green when the channel is busy. Ñ Liquid Crystal Display The display include an 8-character alpha-numeric section showing channel and group names, status and identity information, and error messages. Additional indicators on the display show priority channel assignments and scan include / exclude selection. Ö p/q Button Pressing these buttons changes the current group (and displayed group number or name). Holding this button for more than 1/2 second causes the function to repeat. Ü HOME Indicator This lamp glows orange when incorrect position at the setting of CE35. á Programmable Function Button This button can be set up for special applications, such as high/low power selection, monitor, dimmer, talk-around, and call alert function, as determined by your network requirements and programmed by your VERTEX STANDARD dealer. The default function is set as Dimmer Button. A POWER ÉÇÑÖ á àâä Ü Å Page 3 VX-4000 Operating Manual à VOLUME Knob This knob sets the volume of the receiver. â CHANNEL Selector Knob This knob select the operating channel. ä Programmable Function Button This button can be set up for special applications, such as high/low power selection, monitor, dimmer, talk-around, and call alert function, as determined by your network requirements and programmed by your VERTEX STANDARD dealer. Side Panel Microphone Jack (It is on both sides.) Connect the microphone plug to this jack. Microphone Jack Page 4 VX-4000 Operating Manual REAR (Heatsink) ¿ 13.8-V DC Cable Pigtail w/Connector The supplied DC power cable must be connected to this 2-pin connector. Use only the supplied fused cable, extended if necessary, for power connection. ¡ External Speaker Jack An external loudspeaker may be connected to this 2-contact, 3.5-mm mini-phone jack. Caution…
