K8CPROXRadar Level Gauge

User ́s Guide i Edition 2.Ref. No: 306010E Saab TankRadar Æ Pro User ́s Guide Second edition Copyright © September 1998 Saab Marine Electronics AB Saab TankRadar Æ Pro ii Edition 3.Ref. No: 306010E Copyright © March 1999 Saab Marine Electronics AB The contents, descriptions and specifications within this manual is subject to change without notice. Saab Marine Electronics AB accepts no responsibility for any errors that may appear in this manual. Trademarks HART is a registered trademark of HART Communication Foundation Modbus is a registered trademark of Modicon. Pentium is a registered trademark of Intel Corporation. Windows95 and Windows NT are trademarks of Microsoft Corporation. Spare Parts Any substitution of non-recognized spare parts may jeopardize safety. Repair, e.g. substitution of components etc, may also jeopardize safety and is under no circumstances allowed. Saab Tank Control will not take any responsibility for faults, accidents, etc caused by non-recognized spare parts or any repair which is not made by Saab Tank Control. Specific FCC Requirements (USA only) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Saab TankRadar Pro generates and uses radio frequency energy. If it is not installed and used properly, that is, in strict accordance with the manufacturer ́s instructions, it may violate FCC regulations on radio frequency emission. Saab TankRadar Pro has been Part 15 certified under test conditions which assume a closed metallic tank. Installation on non-metallic tanks, tanks with open manholes, external-float- ing-roof tanks without stillpipes etc. are not covered by this certificate, and require a Part 90 site-license. If you have an installation like this, contact your Saab Tank Control representative for help with the necessary license applica- tion. Saab TankRadar Æ Pro iii Edition 2.Ref. No: 306010E Contents About this manual ........................................................ vii 1 Introduction ............................................................ 1-1 The TankRadar Pro System .......................................................... 1-1 Measurement Principle .................................................................. 1-3 2 Mechanical Installation ......................................... 2-1 Socket Requirements .................................................................... 2-1 Free Space Requirements ............................................................. 2-2 Dimensions ..................................................................................... 2-3 Tools ................................................................................................ 2-3 Mounting the Rod Antenna ........................................................... 2-4 Tank flange diameter = 50 mm (2”) .............................................. 2-4 Tank flange diameter = 65 mm (3”) .............................................. 2-5 Mounting the Cone Antenna - PTFE sealing ............................... 2-6 Mounting the Cone Antenna - Quartz Sealing ............................ 2-8 Mounting the Cone Antenna - Process Seal ............................. 2-10 Preparations ............................................................................... 2-10 Torque ........................................................................................ 2-13 Mounting the Parabolic Antenna ................................................ 2-14 3 Electrical Installation ............................................ 3-1 Identication of Installed Options .................................................. 3-1 Junction Box .................................................................................. 3-2 External Connections .................................................................... 3-3 Non-Intrinsically SafeJunction Box -EEx e ................................... 3-3 Intrinsically Safe Junction Box - EEx i .......................................... 3-4 Alternative Non-intrinsically Safe Junction Box ............................ 3-5 Saab TankRadar Æ Pro iv Edition 2.Ref. No: 306010E Connecting to a TRL2 Bus Interface ............................................ 3-6 Connecting HART devices ............................................................ 3-7 Active output (internal loop supply) .............................................. 3-7 Passive output (external loop supply) ........................................... 3-7 Intrinsically safe conditions ........................................................... 3-8 Non-Intrinsically safe conditions ................................................... 3-8 Connecting the Display Panel ...................................................... 3-9 Cables ........................................................................................... 3-10 Safety ............................................................................................ 3-10 Power Supply ............................................................................... 3-10 Grounding .................................................................................... 3-10 CENELEC .................................................................................. 3-10 FM .............................................................................................. 3-10 System Overview ......................................................................... 3-11 Display Panel .............................................................................. 3-11 Analog Outputs ............................................................................ 3-11 Digital Communication................................................................. 3-11 Power Supply ....................................................…

Text truncated - open the document above for the full version.

Request for confidentiality Saab Tank Control respectfully requests that in accordance with §§ 0.457 (d), 0.459 confidentiality be provided for all detailed technical information, for the schematics, and for the block diagrams contained within this application. In support of this request, we show the following. Enclosed within our application is technical information, which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage in the marketplace. The equipment covered in this application is a Radar Level Gauge designed for measurement in closed metallic tanks under Part 15 as well as under open conditions under Part 90, in the later case with a site-license. Saab is one of the world’s largest producers of level gauges and has sold and installed more than 30,000 gauges worldwide. Saab requires that all installations of the above- captioned device be performed by Saab’s personnel, who are the sole source of maintenance for the gauges. Additionally, Saab maintains records on the sale and installation of all such gauges worldwide. To assist in assuring that we receive the full value of our license and protect our competitive posture, we respectfully request grant of confidentiality for all information mentioned above. We feel that a grant of confidentiality is only proper as our gauges only enters the stream of commerce under strict control of our employees. The gauge will consequently not be subject to the examination of our competitors. For the above stated reasons, Saab Tank Control hereby requests that our application be processed to grant in accord with the Commission’s Rules and the stated intention of the Bureau in creation of those same Rules. Linköping 1999-02-22 Mikael Kleman, Development manager
