KF5ORTOVOX3Avalanche Transceiver

22GB ORTOVOX 3+ TechnOlOgy and FuncTiOns Being rescued immediately by your companions with the 3+, avalanche probes and shovels is practically the only chance of survival after being buried by an avalanche. Read the in- structions of use for the 3+ avalanche transceiver carefully, practice how to handle it and train how to rescue your companions effectively! You can find valuable information about help- ing your companions, preventing ac- cidents and about the current safety products from ORTOVOX at www.ortovox.com The ORTOVOX 3+ avalanche trans- ceiver does not protect you against avalanches. Never go backcountry skiing and freeriding alone – always do these types of sport in a small group. You can reach us by email at [email protected] ORTOVOX wishes you wonderful, safe tours! Here are the benefits of the ORTOVOX avalanche transceiver 3+ english Automatic switch over to the best transmission antenna (“Smart Antenna”) 3-antenna technology Signal analysis (scan the avalan- che debris and locate every signal quickly and accurately) Marking function (3 signals) Only 1 ALKALINE battery AA 1.5V Partner check Automatic transmission switch over Update 23GB cOnTenTs OpeRaTiNg elemeNTs 24 TeCHNiCal DaTa 25 eU DeClaRaTiON OF CONFORmiTY 26 QUiCK gUiDe 27 sWiTCHiNg ON/ OFF 27 selF TesT 27 paRTNeR CHeCK 28 seaRCH 30 sigNal seaRCH 30 COaRse seaRCH 31 FiNe seaRCH 32 maRKiNg 33 piNpOiNT seaRCH aND pROBiNg 33 aDVaNCeD iNsTRUCTiONs FOR Use 34 aUTOmaTiC TRaNsmissiON sWiTCH OVeR 34 mUlTiple BURials 34 iNTeRFeReNCe 36 seRViCe 37 iNDeX 39 gUaRaNTee 41 seRViCe aDDResses 102 24GB OpeRaTing elemenTs 2 3 4 5 6 7 8 9 1 10 sliding sWiTch (seaRch mOde) TRansmissiOn sWiTch OVeR (TRansmissiOn mOde) diRecTiOn aRROW disTance indicaTOR BaTTeRy capaciTy numBeR OF signals maRKing BuTTOn lOudspeaKeR On/OFF sWiTch, BaTTeRy cOmpaRTmenT lOcKing slide subject to changes (08/ 2010) The back of the carrier bag contains an extra compartment for storing the 3+ and carrying straps. 25GB Technical daTa Name: ORTOVOX 3+ FUNCTiON: digital CasiNg: ergonomic, waterproof, impact resistant siZe: 119 x 71 x 25mm FReQUeNCY: 457 kHz The 3+ receives transmission signals from every avalanche transceiver con- forming to standards without restrictions. DigiTal R eCepTiON RaNge: 40m seaRCH sTRip WiDTH: up to 40m TempeRaTURe RaNge: -20° C to +45° C if the transceiver gets wet, do not use direct heat, i.e. such as a hair dryer to dry it out. Heat applied in a direct manner may permanently damage the device beyond repair. pOWeR sUpplY: 1 alkaline aa 1.5 V lR 06 battery OpeRaTiNg Time: Transmitting: approx. 250 hours Receiving: approx. 15 hours WeigHT: approx. 189g incl. battery (Comfort carrier bag approx. 98g) aDDiTiONal FUNCTiONs partner-Check Update The ORTOVOX 3+ exceeds the high requirements of the european standard eN 300 718. 26GB eu declaRaTiOn OF cOnFORmiTy eU DeClaRaTiON OF CONFORmiTY manufacturer: X-log elektronik gmbH person responsible: Johann Nowotny, Bahnhofstr. 95, D-82166 gräfelfing declares that the product: type: ORTOVOX, model: 3+ intended purpose: avalanche victim search device when used properly meets the essential requirements according to article 3 of the R&TTe regulations 1999/5/eC and that the following standards have been applied: 1. Health (article 3.1.a of the R&TTe regulations), eTs 300 718 edition: 05/01 2. safety (article 3.1.a of the R&TTe regulations), eTs 300 718 edition: 05/01 3. electromagnetic compatibility (article 3.1.b of the R&TTe regulations) eTsi eN 300 718-1, edition: 05/01 4. efficient use of the radio frequency spectrum (article 3.2.b of the R&TTe regulations) eTsi eN 300 718-2, edition: 05/01 5. e lectromagnetic compatibility and radio band matters (article 3.3.e of the R&TTe regulations) eTsi eN 300 718-3, edition: munich, July 26, 2010 p.p. andrea Reintges CHANGES OR MODIFICATIONS TO THIS DEVICE NOT APPROVED BY ORTOVOX CAN VOID THE US- ERS AUTHORITY TO OPERATE THE EQUIPMENT. INFORMATION FOR THE USER Registration Number: FCC iD No. KF5 ORTOVOX 3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) the device may not cause harmful interference and (2) the device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for an intentional radiator pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference to radio or television reception, which can be deter- mined by turning the equipment off and on, the user is encouraged to try to correct the interfer- ence by one or more of the following measures: - Reorient or relocate the receiving antenna. - increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. 27GB QuicK guide sWiTching On/ OFF sWiTching On Undo the lOCKiNg sliDe (10) and turn the sWiTCH-ON leVeR (1) counter-clockwise. The sWiTCH-ON leVeR is now secured from being switched off unintentional. Right now the appliance number is indicated, the self-test starts and the remaining battery capacity is shown in %. sWiTching OFF Undo the lOCKiNg sliDe (10) and turn the sWiTCH-ON leVeR (1) clock- wise. selF-TesT and TRansmissiOn mOde The self-test is visible on the display. The remaining battery capacity (6) is shown: 99 (%). after a successful self-test the ORTOVOX 3+ starts transmitting and the transmission elements flash on the dis…

Text truncated - open the document above for the full version.

Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Certification and Signatures We certify that these Test Results are true results obtained from the tests of the equipment stated, and relates only to the equipment tested. We further certify that the measurements shown in this Test Results package were made in accordance with the procedures indicated and vouch for the qualifications of all Retlif Testing Laboratories personnel taking them. Scott Wentworth Branch Manager NVLAP Approved Signatory Todd Hannemann Laboratory Supervisor iNARTE Certified ATL-0255-T Non-Warranty Provision The testing services have been performed, findings obtained and reports prepared in accordance with generally accepted laboratory principles and practices. This warranty is in lieu of all others, either expressed or implied. Non-Endorsement This test report contains only findings and results arrived at after employing the specific test procedures and standards listed herein. It is not intended to constitute a recommendation, endorsement or certification of the product or material tested. This test report may not be used by the client to claim product endorsement by NVLAP, NIST or any agency of the U.S. Government. Page 2 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Revision History Revisions to this document are listed below; the latest revised document supersedes all previous issues of this document. Revision Date Pages Affected - July 26, 2010 Original Release A August 9, 2010 5, 6 Page 3 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Program Summary Job Number: R-5344N Customer: Ortovox USA, Inc. Address: 455 Irish Hill Road Hopkinton, NH 03229 Test Sample: Avalanche Transceiver/Beacon Model Number: 3+ Serial Number: N/A Type: Avalanche Transceiver Power Requirements: 1.5 VDC Internal Battery Frequency Operation: 457 kHz Application: Locates avalanche victims Manufacturer/Applicant: Ortovox Sportartikel Manufacturer Address: Rotwandweg 5 D-82024 Taufkirchen Germany Test Specification: FCC Rules and Regulations Part 15, Subpart C, Paragraph 15.209 Test Procedure: ANSI C3.4:2003 Purpose: The purpose of this test program was to demonstrate compliance of the Avalanche Transceiver/Beacon to the requirements of FCC Part 15.209. Test Methods: The following table depicts the test methods that were performed on the EUT and the corresponding test results: Testing Date(s) Test Method Test Results July 14-15, 2010 15.209, Radiated Emissions (450 kHz to 1 GHz) Complied Test Sample Operation: The Avalanche Transceiver/Beacon is used to locate avalanche victims and is powered by 1.5 VDC via internal battery. It is manually activated by the user and in transmit mode, will continuously transmit at 457 kHz. During testing, the EUT was continuously transmitting at 457 kHz with a new battery installed. As the test sample operates at close to 100% duty cycle no duty cycle factor was applied. Page 4 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Sample/Test Program: • 15.203 Antenna Requirements -The device uses a permanently attached internal antenna. The antenna is totally enclosed inside the case. • 15.205 Restricted Bands - No emissions were observed from the EUT in any restricted bands. • 15.207 Conducted Emissions-Not applicable (battery operated device) • 15.209 Radiated Emissions-Fundamental Frequency 457 kHz, Harmonic/Spurious Emissions 450 kHz to 1000MHz • No harmonic or spurious emissions above the third harmonic were observed within 10dB of the specified limit at test distances of 1 or 3 meters. • Radiated Emissions from the EUT were measured in all three axis. The attached Radiated Emissions test data shows the maximized fundamental emission of each orientation. Determination of Field Strength Limits: The field strength limits shown below were calculated as instructed in Section 15.209. Fundamental Frequency: 457 kHz Where F is the frequency in kHz, the formula for calculating the maximum permitted fundamental field strength at 300 meters is: 2400/(F) = Field Strength Limit (uV/M @ 300 meters) 2400/(457) = 5.25uV/M Field Strength Limit of 5.25uV/M = 14.4 dBuV/M The maximum permitted unwanted emission level cannot exceed the level of the fundamental emission. Distance Factor: Testing was performed at a 3 meter distance and the field strength reading extrapolated to 300 meters for comparison to the 300 meter limit. The field strength reading was extrapolated using the extrapolation (distance) factor of 40dB/decade as specified in 15.31 (f) (2) for frequencies below 30MHz. Distance Factor from 300 meters to 3 meters (2 decades) = -80dB Page 5 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Methods: 15.209 Radiated Emissions The test sample was placed on an 80cm high wooden test stand which was located 3 meters from the test antenna on an FCC listed open area test site. Emissions from the EUT were maximized by rotating the test sample and adjusting the test sample orientation and antenna polarization. Test Results: The maximized peak field strength at 457 kHz was 1.49uV/M (3.49 dBμV/M)` and met the average limit specified in 15.209 therefore also meeting the peak emission requirement specified in 15.35. No harmonic/spurious emissions were observed at 3 or 1 meter test distances. The maximized corrected peak field strength was calculated as follows: R C = M R + C F - D F Where: R C = Corrected Reading in dBμV/M M R = Uncorrected Meter Reading in dBμV C F = Correction Factor in dB (Antenna Factor + Cable Loss) D F = Distance Factor in dB M R = 74.39 dBμV C F = 9.10 dB D F = 80 dB R C = 74.39dBuV + 9.1dB – 80dB = 3.49 dBμV/M Page 6 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Radiated Emissions Test Setup Photographs Page 7 of 13 Test Report No. R-5344N, Rev. A FCC ID: KF5OR…

Text truncated - open the document above for the full version.

Test Report No. R-5344N FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Photographs Radiated Emissions Test Setup Test Report No. R-5344N FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Photographs Radiated Emissions Test Setup, Horizontal Antenna Polarization Test Setup, Vertical Antenna Polarization Test Report No. R-5344N FCC ID: KF5ORTOVOX3 Retlif Testing Laboratories R Test Photographs Radiated Emissions Test Setup, Planar Test Setup, Co-Planar
