KH7BT006UAA-XBluetooth Protocol Analyzer

3385 Scott Blvd, Santa Clara, CA 95054-3115 Tel: +1/408.727.6600 Fax: +1/408.727.6622 For Software Version 2.30 Manual Version 1.0 28 November, 2003 CATC Merlin II ™ Bluetooth ™ Protocol Analyzer User’s Manual ii Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Document Disclaimer The information contained in this document has been carefully checked and is believed to be reliable. However, no responsibility can be assumed for inaccuracies that may not have been detected. CATC reserves the right to revise the information presented in this document without notice or penalty. Trademarks and Servicemarks CATC, Merlin II, BTTracer, BTTrainer, Merlin, Merlin’s Wand, Merlin Mobile, and BusEngine are trademarks of Computer Access Technology Corporation. Microsoft, Windows NT, Windows 2000, Windows 98SE, Windows ME, and Windows XP are registered trademarks of Microsoft Inc. All other trademarks are property of their respective companies. Copyright Copyright © 2003, Computer Access Technology Corporation (CATC); All Rights Reserved. Portions of this product are supplied courtesy of Richard Herveille. Copyright (c) 2002, 2003 Richard Herveille, [email protected]. All rights reserved. This document may be printed and reproduced without additional permission, but all copies should contain this copyright notice. FCC Conference Statement This equipment has been tested and found to comply with the limits for a Class A digital device and an intentional radiator, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at their own expense. The end user of this product should be aware that any changes or modifications made to this equipment without the approval of CATC could result in the product not meeting the Class A limits, in which case the FCC could void the user's authority to operate the equipment. iii Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Important Notice: To comply with FCC RF exposure requirements (sections 1.1307 and 1.310 of the Rules) only the antenna supplied by CATC must be used for this device. The antenna must be located at least 20 cm away from all persons. FCC Testing applies to FCC ID: KH7BT006UAA-X. EU Conference Statement This equipment complies with the R&TT Directive 1999/5/EC. It has been tested and found to comply with EN55022:1994/A1:1995/A2:1997 Class A, EN61000-4-2:1995, EN61000-4-3:1995, EN61000-4-4:1995, EN61000-4-5:1995, EN61000-4-6:1995, EN61000-4-11:1994, EN61010-1:1993, and ESTI EN 300 328-1 V1.2.2 (2000-07). Manual Version 1.0Part number: 730-0055-00 iv Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 1 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 TABLE OF CONTENTS Chapter 1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Bluetooth™ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Automation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Physical Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Display Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Recording Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Bluetooth BusEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 External Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Chapter 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 System Components/Packing List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Analyzer LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Rear Panel Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Setting Up the Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Installing the Analyzer Software on the PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Your First Bluetooth Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Inquiry Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 External Interface Breakout Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Connecting the Breakout Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Configuring the Analyzer for the Breakout Board . . . . . . . . . . . . . . . . . 14 Chapter 3 Updates…

Text truncated - open the document above for the full version.

83 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 You see the Errors window: Use any combination of the listed packet/signaling/protocol errors as a Trigger. CRC Error A CRC error in the packet data payload of the previous data packet. HEC Error An HEC (header error check) error in the packet header for the previous Bluetooth data packet. FEC Error An uncorrectable FEC (Forward Error Correction) error in the packet header for the previous Bluetooth data packet. Threshold Exceeded Indicates that the number of single-bit FEC errors detected since the current recording started has exceeded the specified value. Invalid Packet Type An invalid value was detected in the 'packet type' field of the packet header for the previous Bluetooth data packet. Header Length Error Indicates that a received Bluetooth data packet was terminated before all bits of the packet header were received. 84 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Payload Length Error Indicates that the payload of a received Bluetooth data packet was either longer than expected, or that a Bluetooth data packet terminated before the expected end of the payload data. Sync Loss When set, indicates that a loss of piconet synchronization occurred during the frequency slot prior to this slot. External Input Signals Selecting "External Input Signals" causes the analyzer to trigger on an external signal received from the breakoutboard. Breakout Board (Edge Triggered) The following names are derived from pins on the CATC-provided breakout board. •TRIG IN - Selectable Edge triggered inputs. Will trigger on any edge it detects. 85 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 6.7 Recording Options - Actions The Actions screen allows you to specify the type of action that Merlin II should perform when it encounters the events specified in the Events window. Action Buttons - Their Functions The Action buttons in the right side of the window provide the means of setting triggers, filters, and restarts. To set an action, you simply drag your mouse from an Event to an Action. As described further on, this movement will link the two via an arrow. Trigger The Trigger button enables event triggering. Filter In/Out The Filter In/Out button allows events to be filtered in or out of the recording. Filtering provides a useful method of excluding data from the trace so you can conserve recording memory. 86 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Restart The Restart button causes the two counters Count1 and Count2 to be reset to zero. It also causes the search for event sequences to restart. Event sequences are sequences of events that trigger the end of the recording. Restart buttons provide you with a way of saying "If you see a sequence of A, B, C, and D, then trigger. However, if you see X anywhere during the sequence, restart your search." Count1, Count2 Count1 and Count2 are counters for specifying how many events must occur before an event can cause a trigger. Counters allow conditions to be made such as "Trigger after the 21st Poll packet" (see screenshot below). The Actions window showing a condition based on a Poll packet and a counter. This condition reads "Trigger after the 21st Poll packet." Connecting Events to Counters To connect an event to a counter, click an Event button, then click one of the two counter buttons. The Counter will reposition itself immediately below the event. A line will the connect the counter to the Trigger button. This latter connection between the Counter button and the Trigger button occurs because counters always work in association with triggers. Counters act as assistants to triggers. Setting Multiple Conditions with Counters You can create multiple event conditions by linking a counter to multiple events or by linking two counters to two or more events. 87 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Linking Multiple Events to One Counter - When two or more Events are strung together and then connected to a counter, the event button that is touching the counter gets counted. The example below reads "Trigger after you see a sequence of a packet with the specified payload followed by a 21 null packets." Linking Two Events to Two or More Counters - If an Event is linked to Count1 and a second event is linked to Count2, it creates an "or" statement. This statement reads "Trigger when Count1 OR Count2 has reached their specified values." This example reads "Trigger when Count1 has counted 5 Poll packets or Count2 has counted 10 errors." 88 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 Blue Dot Menus Count1, Count2 and a few other buttons in the Actions window have blue dots in their top left-hand corners that indicate the presence of context-sensitive menus. These menus let you set the button’s values and/or operations. Click the left mouse button on a dot to open the menu. Counters Blue Dot Menu The Count1 and Count2 blue dot menus allow the value of their counters to be changed. The value you specify here tells Merlin II how many instances of an event must take place before a trigger occurs. The counter can be set between 1 and 65,535. To set a Counter, Step 1Click on the blue dot in the upper left corner of the Count button. You see the Change Counter Value menu: Step 2Click Change Counter Value You see the Input Counter Value menu Step 3Enter an input value to tell the Analyzer how many times this event must occur before triggering the end of a recording Step 4Click OK. Filter Out/In Blue Dot Menu The Filter Out/In button toggles between "Filter Out" and "Filter In". •Filter In records ONLY those packets related to the specified event. •Filter Out records all packets EXCEPT those related to the specified event. 89 Merlin II Protocol Analyzer User’s ManualCATCSW Version 2.30 To filter an event in or out of a recording, Step 1Click the blue dot on Filter Out. (Note: the button may say Filter In depending on the last a…

Text truncated - open the document above for the full version.

PROPOSED FCC ID LABEL AND LOCATION COMPUTER ACCESS TECHNOLOGY CORPORATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: KH7BT006UAA-X FCC ID LABEL

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR BLUETOOTH PROTOCOL ANALYZER MODEL NUMBER: BT006UAA-X FCC ID: KH7BT006UAA-X REPORT NUMBER: 03U2361-1 ISSUE DATE: DECEMBER 1, 2003 Prepared for COMPUTER ACCESS TECHNOLOGY CORPORATION 2403 WALSH AVENUE SANTA CLARA, CA 95051 U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 2 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION.........................................................................................................................4 3. TEST METHODOLOGY..................................................................................................................5 4. FACILITIES AND ACCREDITATION..........................................................................................5 5. CALIBRATION AND UNCERTAINTY.........................................................................................6 5.1. MEASURING INSTRUMENT CALIBRATION............................................................................6 5.2. MEASUREMENT UNCERTAINTY..............................................................................................6 5.3. TEST AND MEASUREMENT EQUIPMENT...............................................................................7 6. SETUP OF EQUIPMENT UNDER TEST.......................................................................................8 7. APPLICABLE LIMITS AND TEST RESULTS...........................................................................10 7.1. RADIATED EMISSIONS............................................................................................................10 7.1.1. TRANSMITTER RADIATED SPURIOUS EMISSIONS................................................10 7.1.2. TRANSMITTER RADIATED EMISSIONS ABOVE 1 GHZ..........................................13 7.1.3. WORST-CASE RADIATED EMISSIONS BELOW 1 GHZ............................................22 7.2. POWERLINE CONDUCTED EMISSIONS................................................................................23 8. SETUP PHOTOS..............................................................................................................................26 REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 3 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: COMPUTER ACCESS TECHNOLOGY CORPORATION 2403 WALSH AVENUE SANTA CLARA, CA 95051 U.S.A. EUT DESCRIPTION: BLUETOOTH PROTOCOL ANALYZER MODEL: BT006UAA-X DATE TESTED: 11/17/03 – 11/19/03 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: THU CHAN FRANK IBRAHIM EMC SUPERVISOR EMC SUPERVISOR COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 4 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION The EUT is a Bluetooth Protocol Analyzer The transmitter has a maximum peak conducted output power as follows: The radio utilizes an external dipole antenna with a maximum gain of 2.0 dBi. Frequency RangeModeOutput PowerOutput Power (MHz)(dBm)(mW) 2400 - 2483.5Inquiry Mode2.061.61 REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 5 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4/1992, FCC CFR 47 Part 2 and FCC CFR 47 Part 15. 4. FACILITIES AND ACCREDITATION The open area test sites and condu…

Text truncated - open the document above for the full version.

REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 26 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 8. SETUP PHOTOS RADIATED RF MEASUREMENT SETUP RADIATED FRONT PHOTO REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 27 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. RADIATED BACK PHOTO REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 28 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. DIGITAL DEVICE RADIATED EMISSIONS SETUP DIGITAL DEVICE FRONT PHOTO REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 29 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. DIGITAL DEVICE BACK PHOTO REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 30 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP LINE CONDUCTED FRONT PHOTO REPORT NO: 03U2361-1 DATE: 12/1/2003 EUT: BLUETOOTH PROTOCOL ANALYZER FCC ID: KH7BT006UAA-X Page 31 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. END OF REPORT LINE CONDUCTED BACK PHOTO
