Northwest EMC TCB Compliance Opinion Rev. 12/08/09 DIGC0117 Information about the Applicant Grantee (Company Name) Digital Control, Inc. FCC Contact Person Bruce E. Kolpack Address 19625 62nd Avenue South, Suite B103 City, State, Zip Kent, WA 98032 Job Number DIGC0117 Model F5Dp 19/12, F5Dp 12/1.3, F5DLp 19/12 FCC ID KKG50416 Agent NA Approval Type Original Equipment Class DCD Part 15, low power Tx below 1.705 MHz Rule Part 15.209 Overview This application is for an original filing of a low frequency transmitter under three models, F5Dp 19/12, F5Dp 12/1.3 and F5DLp 19/12. The FCC ID for the three models is KKG50416. The F5Dp 19/12 and F5Dp 12/1.3 are electrically and mechanically identical. The F5DLp 19/12 differs in the length of antenna. The test report shows both the 12 kHz and 19.2 kHz settings to have been tested and the data reported shows the results of the 19”, Model F5DLp 19/12, which has the highest output power. Confidentiality requested for allowed files. Request is properly addressed and referenced. Agent authorization has been verified. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 4/12/2011

I ~ C I ® DIGITAL CONTROL INCORPORATE D 19625 62NO AVENUE SOUTH, SUITE 8-103 • KENT, WASHINGTON 98032 USA PHONE 425-251-0701 ·FAX 425-251·0702. www.digitt·akcom April 7, 2011 To whom it may concern, We are seeking original certification approval of the DigiTrak<!> F F5<!> fluid pressure monitoring transmitters (models: F5Dp 19/12, F5Dp 12/1.3, and F5DLp 19/12) under Part 15.209 of FCC rules. The FCC to number for this product is KKG50416. The product is an underground low frequency magnetic field transmitter and is part of a system that is used for guiding and fluid pressure monitoring purposes in a horizontal directional drilling operation. The DigiTrak® F5Dp 19/12 and F5Dp 12/1.3 transmitters are electrically and mechanically identical to each other. The power requirement, power output, and modulation are the same as well as the method, equipment, and materials used in the manufacture. The devices differ only in labeling and frequency of operation (F5Dp 19/12 operates at either 19 kHz or 12 kHz, the F5Dp 12/1.3 operates at either 12 kHz or 12 kHz and 1.3 kHz simultaneously). The F5DLp 19/12 differs from the F5Dp models in the length of antenna, thus the output power and power consumption (battery life) are also different. The F5DLp 19/12 is 19" (48.26 cm) long and with a specified transmitting range of 85 It (25.9 m) where the F5Dp 19/12 and F5Dp 12/1.3 are 15" (38.1 cm) long with a specified transmitting range of 65 It (19.8 m). The F5Dp 19/12 and F5DLp 19/12 models are identical in frequency and modulation as well as the method, equipment, and materials used in the manufacture. The test report DIGC0117 represents all models. Sincerely, ;j~ /:::::. \ ,- Bruce E. Kolpack Digital Control Inc. 1962562"' Ave. South, Suite B103 Kent WA, 98032

I ~ C I ® DIGITAL CONTROL . I NCORPORATEO 19625 62ND AVENUE SOUTH, SUITE 8-103 • KENT. WASHINGTON 98032 USA PHONE 425-251·0701 ·FAX 425·251·0702· www.digitrBk.com March 18,2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We hereby respectfully request that, under the provisions of 47 CFR § 0.459, the documents listed below and attached with this application for certification be provided with confidential status and not made routinely available for public inspection: (1) Schematics. pdf (2) Operational Description.pdf (3) Frequency Block Diagram.pdf Any exhibitlinfonnation for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain company trade secrets. Significant engineering resources were expended designing the pa11s of the product shown in the schematics, frequency block diagram, and operational description. It is our belief that it would be difficult to reverse-engineer the product from publicly available information (including the product itself). Substantial competitive harm to us could therefore result should these documents be made available to the public. We face both domestic and foreign competition in our market (locating equipment for horizontal directional drilling), including product piracy (attempts at direct knock-offs). Disclosure of the documents listed above would provide our competitors and potential product pirates with an unfair competitive advantage, by allowing them to copy our technical solutions without the development expense. We protect this infOimation through the following primary procedures: (I) all employees and contractors are required to sign nondisclosure agreements, as are any visitors, vendors or other third parties who may be exposed to any confidential information, and (2) the information is only provided to employees and third parties on a "need to know" basis. The information is not publicly available, and is not included in our operating manuals or on our website. We are not aware of the infonnation listed above having been disclosed to any third party not bound by a nondisclosure agreement. The materials listed above should not be available for public disclosure at any time. Our products can remain in service for extended periods of time (more than ten or fifteen years), and the rate of significant technological change in our industry is sufficiently slow that even the copying by our competitors of technical information from many years in the past could result in the creation of a product that might be competitively harinful to us. Sincerely, ~'C k(l'_ BlUce E. Kolpack Product Development Manager

F5Dp 12/1.3 External Photos Side 1 Side 2 Label Front end Rear end F5Dp 19/12 External Photos Side 1 Side 2 Label Front end Rear end F5DLp 19/12 External Photos Side 1 Side 2 Label Front end Rear end

F5Dp 12/1.3 External Photos Side 1 Side 2 Label Front end Rear end F5Dp 19/12 External Photos Side 1 Side 2 Label Front end Rear end F5DLp 19/12 External Photos Side 1 Side 2 Label Front end Rear end

F5Dp Internal Photos (represents both the F5Dp 12/1.3 and F5Dp 19/12) Board with Roll/Pitch Sensor Module and Battery Housing Circuit board top Circuit board top, antenna removed Circuit board bottom F5DLp Internal Photos Board with Sensor Roll/Pitch and Pressure Sensing Module Circuit board top, antenna removed Circuit board bottom

.38±.04 1.29 5.50 .25 2X .12 2X .45 .38±.04 1.44 14 2 3 3 54 6 5 WINDING MUST HAVE EVEN SPACING C 3/4" lg. 3-1/4" lg. NOTES: 1. INDUCTANCE - 31μH 2μH WITH WINDING APROX. 21-23 WRAPS. NUMBER OF WRAPS ARE FOR REFERENCE ONLY. 2. WIND WIRE, ITEM 2, AS SHOWN. 3. CUT TO LENGTH AND INSTALL TUBING, ITEM 3, AS SHOWN. 4 WRAP 2-3 TURNS OF TAPE, ITEM 4, AROUND COILS AND LEADS. 5 WRAP 2-3 TURNS OF TAPE, ITEM 4, AROUND COILS AND EXTENSION WIRES COVERED WITH TUBING, ITEM 3, AS SHOWN. NO CONTACT BETWEEN COILS AND EXTENSION WIRES ALLOWED. 6 STRIP AND TIN ENDS WITH RoHS COMPLIANT SOLDER AS SHOWN. 7. COAT ASSEMBLY WITH VARNISH, ITEM 5. C C C C12/14/10DIM. .38.04 WAS .37. MODIFIED NOTES 1 AND 4DFMM B10/21/10UPDATED GRAPHICSDFMM A8/10/10INITIAL RELEASEDFJP REVDATEDESCRIPTIONBYCK REVISIONS ITEM NO PART NUMBER DESCRIPTIONQTY 1309-0001-00FERRITE ROD, Ø.25x5.5 LG, NAT'L MAGNETICS RX-250-5500-M201 2312-0007-00WIRE, ESSEX, 18 AWG, SINGLE BUILD FILM INSULATED or =AR 3330-0031-00TUBING, 1/16 ID x 1/8 OD, McMASTER 5114K11 or = 4" 4330-0032-00TAPE, 1/4 WIDE, YELLOW, DIGIKEY 57-YELLOW-1/4X72YD-ND or = AR 5330-0033-00VARNISH, DOLPH'S SYNTHINE AC-43 or =AR D C B A B C D 6 7 8 8 7 6 5 4 3 2 1 Third Angle Projection NTS 175-0255-00 Assy, Antenna, Ø.25x5.5 lg. 11/25/09 D.Feldman D. FELDMAN C 19625 62nd Ave. S. Suite B-103 Kent, Wa. 98032 1-800-288-3610 or (425)-251-0701 DCI Fax (425)-251-0702 Stargate Fax (253)-395-2828 www.Digital-Control.com D IGITAL C ONTROL I NCORPORATED JP .030 .01 1 DECIMAL X.XX = DECIMAL X.XXX = X° = 1 1 OF SH REV DRAWING NUMBER TITLE DATE SCALE SIGNED CHECKED BY ENGINEER DRAWN BY THIS DRAWING IS CONFIDENTIAL AND IS SUPPLIED WITH THE UNDERSTANDING THAT IT IS NOT SHOWN TO OTHER PERSONS OR COMPANIES WITHOUT THE WRITTEN CONSENT OF DIGITAL CONTROL, INC. TOLERANCES INCHES (EXCEPT AS NOTED)

Digital Control, Inc. RoHS transmitter Models: F5Dp 19/12 F5Dp 12/1.3 F5DLp 19/12 Report No. DIGC0117 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2010 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Last Date of Test: December 14, 2010 Digital Control, Inc. Model: RoHS transmitter Emissions Test Description Specification Test Method Pass/Fail Field Strength of Fundamental FCC 15.209:2010 ANSI C63.10:2009 Pass Field Strength of Spurious Emissions FCC 15.209:2010 ANSI C63.10:2009 Pass Modifications made to the product See the Modifications section of this report Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834D-1). Approved By: Tim O’Shea, Operations Manager NVLAP Lab Code: 200630-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 06/29/09 Barometric Pressure The recorded barometric pressure has been normalized to sea level. Revision Number Description Date Page Number 00 None Accreditations and Authorizations FCC Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP Northwest EMC, Inc. is accredited under the National Voluntary Laboratory Accreditation Program (NVLAP) for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. NVLAP is administered by the National Institute of Standards and Technology (NIST), an agency of the U.S. Commerce Department. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 2004/108/EC, and ANSI C63.4. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. Industry Canada Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS-Gen, Issue 2 and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. (Site Filing Numbers - Hillsboro: 2834D-1, 2834D-2, Sultan: 2834C-1, Irvine: 2834B-1, 2834B-2, Brooklyn Park: 2834E-1) CAB Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. Australia/New Zealand The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP). Accreditations and Authorizations VCCI Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conducted and radiated measurement facilities have been registered in accordance with Regulations for Voluntary Control Measures, Article 8. (Registration Numbers. - Hillsboro: C-1071, R-1025, G-84, C-2687, T- 1658, and R-2318, Irvine: R-1943, G-85, C-2766, and T-1659, Sultan: R-871, G-83, C-1784, and T-1511, Brooklyn Park: R-3125, G-86, G-141, C-3464, and T-1634). BSMI Northwest EMC has been designated by NIST and validated by C-Taipei (BSMI) as a CAB to conduct tests as described in the APEC Mutual Recognition Agreement (US0017). GOST Northwest EMC, Inc. has been assessed and accredited by the Russian Certification bodies Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC, to perform EMC and Hygienic testing for Information Technology Products. As a result of their laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification KCC Northwest EMC, Inc is a CAB designated by MRA partners and recognized by Korea. (Assigned Lab Numbers: Hillsboro: US0017, Irvine: US0158, Sultan: US0157, Brooklyn Park: US0175) VIETNAM Vietnam MIC has approved Northwest EMC as an accredited test lab. Per Decision No. 194/QD-QLC…
