KL7-600R-V1EchoPoint Reader

Savi Technology Inc

Click to zoom

Application Details

Equipment Class: DSR - Part 15 Remote Control/Security Device Transceiver
Date of Grant: Dec 29, 2001
Application Purpose: Original Equipment
Date of Application: Dec 29, 2001
Equipment Note: EchoPoint Reader
Frequency Range: 433.92000000 - 433.92000000
Company: Savi Technology Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

@puQv Srhqr TS% Dhyyhv Bvqr Wrv vv@puQv Srhqr TS% Dhyyhv Bvqr First edition (September 2001) Part number 805-03620-001 Rev. B Copyright © 2001 Savi Technology, Inc. All rights reserved. Printed in the United States of America. Information in this manual is subject to change without notice and does not represent a commitment from the vendor. The software and/or databases described in this document are furnished under a license agreement or nondisclosure agreement. The software and/or databases may be used or copied only in accordance with the terms of the agreement. It is against the law to copy the software on any medium except as specifically allowed in the license or nondisclosure agreement. Savi, Batch Collection, and TyTag are registered trademarks and Adaptive Routing, EchoPoint, EchoPoint Signpost, Enhanced Batch Collection, Hand Held Interrogator (HHI), Savi Asset Manager, Savi Fixed Interrogator, Savi GateReader, Savi Mobile Manager, Savi MobileReader, Savi Retriever, Savi SDK, Savi SmartChain, Savi System, Savi Tools, SaviReader, SaviTag, and SealTag are trademarks of Savi Technology, Inc. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. This manual was produced by the Savi Technology Publications Group. Please address any comments or requests for updates to: Savi Technology, Inc. Publications Manager 615 Tasman Drive Sunnyvale, CA 94089-1707 Phone: 1-408-743-8000 Facsimile1-408-543-8650 Web Site: http://www.savi.com Author: Marlowe Conde Contributors: Ralph Orton, Gustavo Padilla, Eugene Schlindwein Layout Design and Production: Marlowe Conde @puQv Srhqr TS% Dhyyhv Bvqrvvv VT Srtyh 6hy VT Srtyh 6hy @puQv Srhqr TS% Arqrhy 8vphv 8vv A88 Ivpr The Federal Communications Commission has established technical standards regarding radio frequency energy emitted by computer devices. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference with radio/TV reception. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications to this equipment that are not expressly approved by Savi Technology could void the warranty and the authority to operate this equipment. Savi Technology is not responsible for radio/TV interference caused by using unauthorized cable or by making unauthorized changes to this equipment. Qqp Thsr The EchoPoint Reader SR-600-101 is ETL listed (UL 1950). v@puQv Srhqr TS% Dhyyhv Bvqr VT Srtyh 6hy Irx 6qhr T6% Arqrhy 8vphv 8vv A88 Ivpr The Federal Communications Commission has established technical standards regarding radio frequency energy emitted by computer devices. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference with radio/TV reception. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications to this equipment that are not expressly approved by Savi Technology could void the warranty and the authority to operate this equipment. Savi Technology is not responsible for radio/TV interference caused by using unauthorized cable or by making unauthorized changes to this equipment. @puQv Srhqr TS% Dhyyhv Bvqr Drhvhy Srtyh 6hy Drhvhy Srtyh 6hy @puQv Srhqr TS% 9rpyhhv s 8sv Hereby, Savi Technology, Inc. 615 Tasman Drive Sunnyvale, California 94086-1707 declares that the EchoPoint Reader SR-600-101 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Qqp Thsr CB Scheme (IEC 60950). Irx 6qhr T6% 9rpyhhv s 8sv Xhvt This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. 0889 8rv v uv Bvqr The following table explains guide conventions and typography usage. Bvqr8rv ExampleMeaning and Use Note:Notes call attention to facts or advice that deserve special attention. Caution notices call attention to the possibility of damaging the product, the system, or your work (for example, potential loss of data). Warning notices call attention to the possibility of injury to people. Examples provide a scenario to further explain the preceding direction or procedure. Urvhy GpxrqBold type is used for prompts, field names, and other text as displayed on the screen. 6)cDITU6GGBold type is also used for text you enter exactly as shown. $96U6Monospaced type is used for system messages, examples of data files, program code, and other text where column alignment is important. name.bmp or tag_idItalic type is used for emphasis of a word or phrase that is new or especially important. 8y + aUsed for a keyboard control codes or manual keystrokes. This example t…

Text truncated - open the document above for the full version.

Cover Letter(s)

In response to our comments raised on December 13, 2001 for the Savi Technology FCC ID: KL7-612R- V1, please see our replies below: After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequency of all oscillators in the device (CFR2.1033(a)(5)). A revised block diagram with a table indicating the frequency of oscillators contained in each block has been uploaded. 2) Photographs may not be held confidential based only upon on the basis of trade secrets. Please remove the request for photographs from the letter of confidentiality or provide a better justification. The request for confidentiality has been revised to remove photographs from its scope. The updated request has been uploaded. 3) The theory of operation provided information with respect to meeting the requirements of 15.231(a) & 15.231(e). In specific please address the following concerns: a) The information is somewhat ambiguous (i.e. what is the timing between elements, of the collection mode, etc.) Please provide a timing diagram showing worse case timing elements and possible variants that occur between reader and tag as mentioned in the Theory of Operation. The Reader is based on Savi’s existing Reader (KL7-410R-V1. (The only difference between the 600 series reader and the existing 410 series is that the 410 series had an additional digital interface board(providing a LONWorks interface). All other characteristics (RF circuit board, antennas, power supply, digital control board and enclosure) are the same. I have uploaded the Theory of Operations submitted to the FCC for the KL7-410R-V1 that was submitted to the FCC. b) The Theory of Operation categorizes all of the collection mode signals under 15.231(a), and only the data under 15.231(e). However the test report separates only the "wake up" signal. Please provide a better explanation of which signals are categorized under 15.231(a) and which ones under 15.231(e). Also explain why each type of signal is categorized as which. All transmissions in the collection cycle are control signals since they control the tags (Wake-up, hello, sleep and find), causing the tags to either power-up, transmit their code or go back to sleep mode. Data signals may be used to send data to certain tags, as detailed in the Theory of Operations. The “Hello”, “Sleep” and “Find” control signals and the data signals are identical in the sense that they use the same output power and do not exceed a duty cycle of 30mS in a 100mS period. This duty cycle allows for a duty cycle correction factor of 10dB to be applied to the peak output level to calculate the average output level. The Wake-Up signal, because it is a continuous signal for 5 seconds (and, therefore, has no duty cycle correction factor), uses a lower peak output power. By measuring the data/control signals against the radiated emissions limits of 15.231(e) it is demonstrated that the control signals meet the field strength limits of 15.231(a) and the data signals the limits of 15.231(e). The Wake-Up signal, with its lower peak output power, was measured and compared to the 15.231(a) limit c) The duty cycle in the report was listed as 33% for all types of signals, while the theory of operation states 30% and 12%. Please explain. At the time of testing, the worst-case anticipated duty cycle for the acknowledge signal was 33%. Once the firmware was reviewed it was realized that a maximum of 30% would be required for this signal. The hello, sleep and find signals all have a duty cycle of 10% and the data signals have a duty cycle of 12%. d) Please explain what is meant by the Data transmission mode where "the duty cycle of data pulses is limited by firmware control to maximum 12 ms every 100 ms. Data transmissions, as explained in the Theory of Operations, are used to send data to the Tags. These transmissions are very rare. When data signals are sent, they last no more than 1 second. Within that one-second period they have a duty cycle of 12% (when measured over any 100mS interval). 4) Please explain the purpose of 2 identical transmitters in the unit. The theory of operation does not bring up this issue. Are they ever expected to transmit at the same time? If so, how does this affect the measurements made? Each transmitter powers an orthogonal antennal to provide 360-degree coverage. Only one transmitter is operated at any time. The 5-second wake-up signal is actually two transmissions – 2.5 seconds from one transmitter immediately followed by a 2.5 second transmission from the other. For all other types of transmissions, the signal is transmitted from one transmitter and then repeated, 100mS later, from the second transmitter to give an omni-directional coverage. 5) FYI, Page 8 of 16 states that the EUT was received on October 4, 2001 and tested on September 6, 2001. The EUT was received on September 4, 2001, this is a typographical error. 6) It appears that the data/control signals measured were higher than the wakeup signal. Was this expected since the reports states that the wakeup signals was to meet 15.231(a), while the data/control was to meet 15.231(e)? As detailed under 2(b) the peak value of the Wake-UP signal is lower than the control/data signals because there is no average correction factor that can be applied, while the average correction factor for the control/data signals is 10dB. 7) FYI, the information requested in item 3) & 4) will need to be provided before a final the review of the test report can be completed. Noted If you have further questions, please do not hesitate to contact me via [email protected] . Regards Mark Briggs

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 13, 2001 RE: Savi Technology FCC ID: KL7-612R-V1 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequency of all oscillators in the device (CFR2.1033(a)(5)). 2) Photographs may not be held confidential based only upon on the basis of trade secrets. Please remove the request for photographs from the letter of confidentiality or provide a better justification. As an alternative, you may use a black marker to "black out" the top of any readable components and provide new internal photographs. Please provide feedback with respect to this issue. 3) The theory of operation provided information with respect to meeting the requirements of 15.231(a) & 15.231(e). In specific please address the following concerns: a) The information is somewhat ambiguous (i.e. what is the timing between elements, of the collection mode, etc.) Please provide a timing diagram showing worse case timing elements and possible variants that occur between reader and tag as mentioned in the Theory of Operation. b) The Theory of Operation categorizes all of the collection mode signals under 15.231(a), and only the data under 15.231(e). However the test report separates only the "wake up" signal. Please provide a better explanation of which signals are categorized under 15.231(a) and which ones under 15.231(e). Also explain why each type of signal is categorized as which. c) The duty cycle in the report was listed as 33% for all types of signals, while the theory of operation states 30% and 12%. Please explain. d) Please explain what is meant by the Data transmission mode where "the duty cycle of data pulses is limited by firmware control to maximum 12 ms every 100 ms. 4) Please explain the purpose of 2 identical transmitters in the unit. The theory of operation does not bring up this issue. Are they ever expected to transmit at the same time? If so, how does this affect the measurements made? 5) FYI, Page 8 of 16 states that the EUT was received on October 4, 2001 and tested on September 6, 2001. 6) It appears that the data/control signals measured were higher than the wakeup signal. Was this expected since the reports states that the wakeup signals was to meet 15.231(a), while the data/control was to meet 15.231(e)? 7) FYI, the information requested in item 3) & 4) will need to be provided before a final the review of the test report can be completed. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. l Page 2December 13, 2001 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

Dear Tim, You had asked for some clarification on certain issues to do with the operation of the device, specifically: Please explain if the collection mode process is considered a manual or automatic in nature ( I could not derive enough information from the manual to determine this)? Also, please explain how the device complies with 15.231 (a)(3). The Theory of operations does not seem to adequately address this. The collection mode can be either manual (via operator) or automatic (via triggering by motion sensors connected into the system). In both cases the collections are random events, triggered by the movement of vehicles/persons via motion sensors or by the user of the system initiating a collection manually. There are no collections at pre-determined intervals so the system meets 15231(a)(3) requirements. Please contact me via doc@elliottlabs if you have any further questions on the above. Best wishes for 2002 ! Regards Mark To: [email protected] Subject: Re: Savi SR-600-101 Cc: dave guidotti <[email protected]>, [email protected] Page 1 of 1In 12/30/2001Printed for "Timothy R. Johnson" <[email protected]>

External Photos

External Photographs

ID Label/Location Info

2 3 19 43 26 30 15 39 30 27 13 4 14 30 7 12 30 8 10 22 21 25 1 38 16 31 26 17 31 32 32 32 31 31 X6 X2 X2 4X 5X 31 32 5X X2 X4 12X 8X 6X X2 { { } } 2X 31 32{ 5X X2 9 3 4 2 5 X2 5 X2 TO ITEM 19 TO ITEM # 7 6 7 9 18 28 5 11 13 3 X2 40 41 2X 5 14 26 32 X2 15 34 12 16 10 10 18 17 23 24 X2 30 X2 33 6 6 35 6 A A 8 6 20 BB VIEW A - A VIEW B - B 19 D C B A A B C D 12345678 8 7 6 5 4 3 21 REVISIONS ZONE DESCRIPTION DATEAPPROVED E F E F REV. SIZE D CODE APL01 DRAWING NO. 860-03610-001 REV. A SHEET 2 OF 4 FILE NAME: 860-03610-001.SLDDRW SCALE 1:2 COMPUTER GENERATED DRAWING DATA BASE MUST BE UPDATED UPDATED: 09/24/01 SEE SHEET ONE

Internal Photos

Internal Photographs Assembly views – top and bottom sections Bottom section – assembly view Top and bottom sides of interrogator board PWB 738-02425-001 Rev B Top and Bottom Views Power Supply Board – Top and Bottom Views RF Board – Top View with and without shields RF Board – Bottom View Antenna Board – Top and Bottom

Test Report

File: R45036 Page 1 of 16 Electromagnetic Emissions Test Report and Application for Grant of Equipment Authorization pursuant to FCC Part 15, Subpart C Specifications for an Intentional Radiator and FCC Part 15, Subpart B Specifications for a Receiver on the Savi Technology, Inc. Model: EchoPoint Reader 600, model SR-600-101 FCC ID: KL7 - 612R- V1 GRANTEE: Savi Technology, Inc. 615 Tasman Drive Sunnyvale, CA 94089-1707 TEST SITE: Elliott Laboratories, Inc. 684 W. Maude Avenue Sunnyvale, CA 94086 REPORT DATE: October 16, 2001 FINAL TEST DATE: September 6, 2001 AUTHORIZED SIGNATORY: ______________________________ Mark Briggs Director of Engineering This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories, Inc. Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036 Page 2 of 16 pages TABLE OF CONTENTS COVER PAGE..................................................................................................................................................................................1 TABLE OF CONTENTS...............................................................................................................................................................2 SCOPE.............................................................................................................................................................................................4 OBJECTIVE...................................................................................................................................................................................4 STATEMENT OF COMPLIANCE..............................................................................................................................................5 EMISSION TEST RESULTS.......................................................................................................................................................5 LIMITS OF CONDUCTED INTERFERENCE VOLTAGE....................................................................................................5 LIMITS OF RADIATED FIELD STRENGTH - RECEIVER.................................................................................................6 BANDWIDTH...........................................................................................................................................................................6 DUTY CYCLE CALCULATION..............................................................................................................................................6 PERIOD OF OPERATION........................................................................................................................................................6 LIMITS OF RADIATED FIELD STRENGTH –INTENTIONAL RADIATOR.................................................................7 MEASUREMENT UNCERTAINTIES....................................................................................................................................7 EQUIPMENT UNDER TEST (EUT) DETAILS..........................................................................................................................8 GENERAL...................................................................................................................................................................................8 ENCLOSURE..............................................................................................................................................................................8 SUPPORT EQUIPMENT..........................................................................................................................................................8 EXTERNAL I/O CABLING......................................................................................................................................................8 TEST SOFTWARE...................................................................................................................................................................8 TEST SITE......................................................................................................................................................................................9 GENERAL INFORMATION....................................................................................................................................................9 CONDUCTED EMISSIONS CONSIDERATIONS................................................................................................................9 RADIATED EMISSIONS CONSIDERATIONS....................................................................................................................9 MEASUREMENT INSTRUMENTATION................................................................................................................................10 RECEIVER SYSTEM...............................................................................................................................................................10 INSTRUMENT CONTROL COMPUTER............................................................................................................................10 LINE IMPEDANCE STABILIZATION NETWORK (LISN).............................................................................................10 FILTERS/ATTENUATORS...................................................................................................................................................11 ANTENNAS............................................................................................................................................................................11 ANTENNA MAST AND EQUIPMENT TURNTABLE....................................................................................................11 INSTRUMENT CALIBRATION..................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036 Exhibit Page 3 of 9 Pages EXHIBIT 3: Test Configuration Photographs Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036 Radiated Emissions Test Configuration Photographs Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036 Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036 Conducted Emissions Test Configuration Photographs Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: October 16, 2001 File: R45036

Contact Information

Applicant

Rosemary Johnston(Vice President, Operations)

[email protected]571-227-7918Fax: 571-227-7960

Technical Contact

Elliott Laboratories, Inc.Mark Briggs

[email protected]408-245-7800

684 W. Maude Ave. · Sunnyvale, California · United States

Non-Technical Contact

Elliott Laboratories, Inc.Mark Briggs

[email protected]408-245-7800

Test Firm

Elliott Laboratories LLCDavid Bare

[email protected]408-245-7800Fax: 408-245-3499

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	433.92 MHz - 433.92 MHz	-

Confidentiality

Long Term

Grant Notes

Collection Mode of operation meets with the requirements of 15.231(a)(1) & (a)(2). Data Transmission Mode of operation meets with the requirements of 15.231(e) and is permitted with a duration of no more than one second and the silent period between transmissions shall be at least 30 times the duration of the transmission, but in no case less than 10 seconds.
