FCC ID: KLS-87-200 Response to E-Mail received 11 th December 2000 for Application to FCC for McMurdo R3 Radio Our response to the FCC E-Mail of 11 th Dec 2000 is set out below in the same order :- 1) Maritime Rules Branch to be contacted to help determine the proper category for this unit. 2) The Aeronautical VHF Radio is specifically not listed in Section 80.1101, however the applicable IMO, IEC etc etc standards and regulations are listed in the European Marine Equipment Directive ANNEX A.1/5.16 , which is scanned in below:- 2) contd To assist with the box numbered A.1/5.16 above the following information is provided:- IMO performance standards (under development by COMSAR) is the IMO Resolution MSC 80(70). TS 101 089 is the European ETSI standard. Our compliance statement follows: CFR 47 PART 80.1101(b) ParaREQUIREMENTSTATUS 1IMO RESOLUTION A.694(17)Not GMDSS, Aeronautical band only. Compliant sections 2 through 9 2CCIT RECOMMENDATION E.161 Not applicable. No keypad. Channels accessible by toggle switch. 3CCIT RECOMMENDATION Q.11Not applicable. No keypad. Channels accessible by toggle switch. 4IEC-PUBLICATION 92-101Not applicable. Not connected to ship supply. 5IEC-PUBLICATION 533Not applicable. Not permanently on, emergency communications only. 6IEC-PUBLICATION 945Compliant with relevant parts. 7ISO STANDARD 3791Not applicable. No keypad. Channels accessible by toggle switch. FCC 47 PART 80.1101(c) ParaREQUIREMENTSTATUS 1IMO RESOLUTION A.525(13)Not applicable. No printing capabilities. 2IMO RESOLUTION A.609(15)Not applicable. Aeronautical band only. 3IMO RESOLUTION A.610(15)Not applicable. 4IMO RESOLUTION A.613(15)Not applicable. 4(ii)CCIR Recommendations 493-4Not applicable. 4(iii)CCIR Recommendations 625-1Not applicable. 4(iv)IMO RESOLUTION A.700(17)Not applicable. 5IMO RESOLUTION A.611(15)Not applicable 6IMO RESOLUTION A.604(15)Not applicable. 7IMO RESOLUTION A.605(15)Not applicable. Aeronautical band only. 8IMO RESOLUTION A.698(17)Not applicable. Not INMARSAT equipped. Aeronautical band only. 9IMO RESOLUTION A.663(16)Not applicable. Not INMARSAT equipped. Aeronautical band only. 10IMO RESOLUTION A.664(16)Not applicable. Not INMARSAT equipped. Aeronautical band only. 3)Response to follow FCC R&R Section 2.1033(c) (1) Manufacturer Name and Address:- Norbit A/S, Postboks 141, N-7501 Stj Ø rdal, NORWAY. Tel: 0047 74 820430 Fax: 0047 74820431 Applicant for Certification:- McMurdo Ltd, Rodney Road, Fratton Ind Estate, Portsmouth, Hampshire, England. PO4 8SG. Tel: 0044 2392 775014 Fax: 0044 2392 827707 (2) FCC Identifier: KLS-87-200 (3) User Manual - already submitted. (4) Type of Emission: Emission code:- A3E (5) Frequency Range:- Transmit: 121.5 MHz or 123.1 MHz Receive: 121.5 MHz or 123.1 MHz (6) Range of Operating Power:- 0.1Watt EIRP (7) None - Not applicable (8) The dc voltage applied:- 3 volts (9) Not Applicable – Factory pre-set. (10) Schematic Drawings:- already submitted. (11) Photograph of labels:- already submitted. (12) Photographs:- already submitted. (13) Not Applicable - Analogue Modulation Technique (14) See 2.1046 to 2.1057 below. (15) Not Applicable (16) Not Applicable (17) Not Applicable 47 CFR SECTION 2.1046 TO 2.1057 Where measurements have been made in house, the following test equipment was used. 1.Spectrum analyserHewlett Packard ESA-L1500A 2.Frequency counterPhilips PM6680 3.Temperature chamberMontford BMC24 4.Attenuator N-type 50Ω in-line attenuator 10dB 5.ThermometerComark 2001 6.Rubidium Frequency StandardFEI Communications FE-5680A * 7.Digital Storage OscilloscopeLeCroy 9304AM 8.Sweep/ function generatorThandar TG502 * Used for frequency stability measurements only. All measurements made by Richard Read, Senior Design Engineer. 2.1046: RF power output The output power to the antenna was measured as 21.3dBm, (135mW), using a spectrum analyser. (This figure does not include cable loss, which is estimated as 0.5dB.) Test report no. 97/7096/4 page 8 gives the carrier power as 140mW. 2.1047: Modulation characteristics The microphone was disconnected and the audio pre-amp was fed with the output of an audio sweep generator. (It was not possible to view the response directly, as the DSO has no X-input!). Readings were taken at spot frequencies. Frequency kHz Output V pk-pk Relative gain dB 11.50 21.04-3.2 30.68-6.9 40.34-12.9 50.13-21.2 -25 -20 -15 -10 -5 0 12345 Frequency (KHz) Amplitude relative to 1KHz, dB 2.1049: Occupied bandwidth The FCC definition of occupied bandwidth is’ the frequency bandwidth such that below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5 per cent of the total mean power radiated’. This corresponds to the 23dB bandwidth, (10log0.005). Modulation was applied with a swept signal ramping from 1KHz to 5KHz. The figure above shows that the occupied bandwidth for the 121.5MHz transmission is 8.5kHz. 2.1051: Spurious emissions at antenna terminals The R3 VHF radio is not designed to operate without an antenna; the antenna is an integral part of the unit. However, measurements of the spectrum at the transmitter output are shown below. The limit of 1.5GHz is the limitation of the available test equipment. 2.1053: Field strength of spurious radiation Refer to performance test report no. 97/7096/4 page 18. 2.1055: Frequency stability Measurements were carried out in 10C steps between -20C and +50C as required under part 80 of the rules. All measurements made with the frequency counter referenced to a Rubidium frequency standard. Temperature, degrees C Frequency, MHz Error from nominal. ppm Error Hz -20121.49983451.362139918165.5 -10121.49982151.469135802178.5 0121.49980581.598353909194.2 10121.49985141.223045268148.6 20121.49970642.416460905293.6 30121.49945654.473251029543.5 40121.49925816.106172839741.9 50121.49911717.266666667882.9 55121.49910477.36872428895.3 2.1057: Frequency spectrum to be investigated The maximum frequency of operation is 123.1MHz; therefore the maximum frequency investigat…
