KNY-6231812519Wireless Data Transceiver

FreeWave  Spread Spectrum Wireless Data Transceiver User Manual FreeWave Technologies, Inc. 1880 South Flatiron Court Boulder, CO 80301 USA (303) 444-3862 (303) 786-9948 Fax www.freewave.com FreeWave  Spread Spectrum Wireless Data Transceiver User Manual FreeWave Technologies, Inc. 1880 South Flatiron Court Boulder, CO 80301 USA (303) 444-3862 (303) 786-9948 Fax www.freewave.com FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l i This manual is for use by purchasers and other authorized users of the FreeWave™ Wireless Data Transceiver only. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, or for any purpose without the express written permission of FreeWave Technologies, Inc. Warranty Your FreeWave Wireless Data Transceiver is warranted against defects in materials and manufacturing for a period of two years from the date of purchase. In the event of a product failure due to materials or workmanship, FreeWave Technologies will, at its discretion, repair or replace the product. FreeWave Technologies, its suppliers, and its licensors shall in no event be liable for any damages arising from the use of or inability to use this product. This includes business interruption, loss of business information, or other loss which may arise from the use of this product. Information in this document is subject to change without notice. © 1995-2002 FreeWave Technologies, Inc. All rights reserved. Microsoft and Windows are registered trademarks of the Microsoft Corporation. pcANYWHERE is a registered trademark of Symantec Corporation. Other product names mentioned in this manual may be copyrights, trademarks, or registered trademarks of their respective companies and are hereby acknowledged. The FreeWave Wireless Data Transceiver is made in the United States of America. Printed in the United States of America. FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l ii FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l iii FCC Notification This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation. This device must be operated as supplied by FreeWave Technologies, Inc. Any changes or modifications made to the device without the express written approval of FreeWave Technologies may void the user's authority to operate the device. CAUTION: The model numbers DGR09 and DGR-115 have maximum transmitted output power of 955mW and 1 Watt, respectively. It is required that the transmit antenna be kept at least 23 cm away from nearby persons to satisfy FCC RF exposure requirements. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ♦ Reorient or relocate the receiving antenna. ♦ Increase the separation between the equipment and receiver. ♦ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ♦ Consult the dealer or an experienced radio/TV technician for help. Note: Whenever any FreeWave Technologies module is placed inside an enclosure a label must be placed on the outside of that enclosure which includes the module's FCC ID. FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l iv FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l v This product is licensed by The United States. Diversion contrary to U.S. law is prohibited. Shipment or re-export of this product outside of The United States may require authorization by the U.S. Bureau of Export Administration. Please contact FreeWave Technologies for assistance and further information. FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l vi FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l vii Model# DGRO9RFS is suitable for use in Class 1, Division 2, Groups A, B, C, and D or non- hazardous locations only. Input voltages for Model# DGRO9RFS are determined by the label on the bottom of the board. If the board has Label A shown below the input voltage is 6 to 14 volts DC. If the board has Label B shown below the input voltage is 6 to 14 volts DC at a maximum baud rate of 57.6 KBaud or 6 to 18 volts DC at a maximum baud rate of 19.2 KBaud, operation mode of multipoint slave or multipoint slave/repeater only. Class 1 Div 2 Label A Class 1 Div 2 Label B FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l viii FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V4.2l ix Table of Contents QUICK START.....................................................................................................1 QUICK START ON A MULTIPOINT SYSTEM....................................................2 TUNING TRANSCEIVER PERFORMANCE.......................................................3 OPERATION MODE SELECTIONS....................................................................6 (0) POINT-TO-POINT MASTER.................…

Text truncated - open the document above for the full version.

Page 1 of 2 file://C:\Request of Confidentiality 22.jpg9/4/02 FreeWave Technologies, Inc. 1880 S. Flatiron Court, Suite F Boulder, CO 80301 July 9, 2002 TCB BABT Product Service 4855 Patrick Henry Drive, Building 6 Santa Clara, CA 95054 Re: FreeWave Technologies, Inc. (Grantee Code: KNY) Request for New Equipment Identifier Model Number DGR09RMS Dear Sir or Madam: Pursuant to Sections 2.1043(d) and 2.933 of the Commission’s Rules, FreeWave Technologies, Inc. (“FreeWave”), hereby requests that one of our radio transceivers (model number DGR09RAS, FCC Identifier KNY21161341911919, granted August 2, 2001), which currently is limited to fixed-mounted installation on permanent outdoor structures, be reevaluated and approved as a mobile radio transceiver, using model number DGR09RMS and FCC Identifier KNY-6231812519. FreeWave’s model number DGR09RAS currently is approved for professional installation in a NEMA-type enclosure with antennas mounted on fixed outdoor structures. The instant request for a new FCC equipment identifier seeks to use an electrically identical device (FreeWave model number DGR09RMS) for mobile applications, also requiring professional installation. FreeWave’s model number DGR09RMS is electrically identical to FreeWave’s previously certified model number DGR09RAS, and there are no differences in the circuitry, design, or construction of these two transceiver models. For this reason, in accordance with Sections 2.1043(d) and 2.933, FreeWave’s new DGR09RMS radio transceiver does not require separate certification. In support of the instant request for the new FCC Identifier, attached hereto is the following documentation: • Original test data for the DGR09RAS device; and • An exhibit providing the maximum permissible exposure calculations, demonstrating that the DGR09RMS unit meets the General Population/Uncontrolled Exposure limits specified in Section 1.1310 of the Commission’s Rules if antenna(s) are installed to provide a separation distance of at least 23 cm from all persons. FreeWave proposes that the following language appear on the equipment authorization for the new identifier: “The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 23 cm from all persons and must not be co- located or operating in conjunction with any other antenna or transmitter. This device must be installed in NEMA enclosures. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. Professional installation of this product is required.” FreeWave certifies that the information contained in this letter and the attachments hereto accurately describes the device for which a new equipment Identifier is requested. In accordance with Section 2.1043(b)(2), FreeWave confirms that the DGR09RMS radio transceiver will not be marketed with the changes requested herein prior to the grant of this request. Please direct any questions concerning this request to the undersigned or to counsel for FreeWave, Henry Goldberg, Esq., at (202) 429-4900. Respectfully submitted, Aleksey Pozhidaev Engineer, FreeWave Technologies, Inc. Phone: (303) 444-3862 Fax: (303) 786-9948 1 24 September, 2002 FreeWave Technologies, Inc. 1880 S. Flatiron Court, Suite F Boulder, CO 80301 TUV America Inc. 10040 Mesa Rim Road San Diego, CA 92121 FCC ID # KNY-6231812519, model # DGR09RMS Re: FCC Rules and Regulations Part 15.203 requirements confirmation With this letter FreeWave Technologies as a manufacturer of the DGR09RMS radio transceivers would like to confirm that the DGR09RMS radio transceivers will be sold by the FreeWave Technologies sales department to be used by industrial/commercial customers and will not be available for the general public, will not be sold retail or by mail order. The DGR09RMS transceiver is aimed at applications where customers needed an embedded product providing high speed RS232/RS422/RS485 asynchronous data communications. Potential applications include remote monitoring and data gathering, Internet access, and differential GPS. Sincerely, Aleksey Pozhidaev R&D Manager Phone (303) 444-3862 Fax (303) 786-9948 April 24, 2001 Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: KNY21161341911919 Dear Mr. Dichoso: This letter is to respond to the Correspondence Reference Number 18731 regarding our spread spectrum radio transceiver DGRO9RAS (FCC ID: KNY21161341911919, EA99651). The DGR09RAS transceiver is a derivative of the DGR09 device, which was submitted to the FCC and approved as a module in November 2000 (FCC ID # KNY-1931852313419). FreeWave Technologies manufactures wireless data transceivers for applications such as gathering SCADA information from remote oil/gas pumping stations at a central site. Because of the specifics of the application, each wireless modem in such a system will be installed professionally. The customer’s telemetry equipment, along with the radio, are typically installed in a NEMA weather tight enclosure. For this reason, a modular approval is appropriate for the radio. RESPONSE TO QUESTION 4. However, the use of a non standard RF connector along with the inability to disconnect antennas makes such use of a module impracticable. In consultation with Richard Fabina, we were told to seek a modular approval with a professional installation limitation. This will allow us to use standard connectors and antenna connections. Indeed, this has been approved by the FCC for other manufacturers ( For example, “Microhard Systems” Inc., FCC ID # NS900P3 has such an approval). Following advice from Mr. Richard Fabina, we have modified the DGR09 radio transceiver module with the straight SMA connector and to submitted this modified transceiver to the FCC for a new approval as a different device (DGR09RAS) with no changes in any documentation or submittal folder. The letters, which we received fro…

Text truncated - open the document above for the full version.

FreeWave Technologies, Inc. 1880 S. Flatiron Court, Suite F Boulder, CO 80301 November 27, 2002 TCB BABT Product Service 4855 Patrick Henry Drive, Building 6 Santa Clara, CA 95054 Re: FreeWave Technologies, Inc. (Grantee Code: KNY) Request for New Equipment Identifier Model Number DGR09RMS Dear Mr. Ward: This letter is to address the concern regarding the compliance of our DGR09RMS spread spectrum limited modular transmitter (FCC ID # KNY-6231812519) with the requirements of the Public Notice DA 00-1407, dated June 30, 2000. Question. An LMA will be issued in those instances where the grantee can demonstrate that it will retain control over the final installation of the device such that compliance of the end product is assured. In such a case, an operating condition on the grant of equipment authorization for the module would state that the module is only approved for use when installed in devices produced by a specific manufacturer, typically the Grantee. Response. FreeWave confirms that it will exercise control over the final installation of this module, such that compliance of the end product is assured. To do so, FreeWave has instructed its sales department personnel to make sure that devices, in which the DGR09RMS data transceivers are installed in, will not be not be available for sale to general public. These instructions will be given in writing to sales personnel, who will be required to respond to the instructions with a written acknowledgement. In addition, FreeWave will provide its customers with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. FreeWave confirms that the DGR09RMS limited modular transmitter will only be installed in the devises produced by FreeWave Technologies, Inc. Respectfully undersigned, Aleksey Pozhidaev R&D Manager, FreeWave Technologies, Inc. Phone: (303) 444-3862 Fax: (303) 786-9948

Antennas list included in this file GainManufacturerManufacturer Model #Page 10 dBLarsenYA00062 6 dBLarsenYA6-9003 5 dBAntennex Maxrad EB8965C BMEFC8985HD 4 3 dBMaxradMAX-90535 0 dBJEMAJA900SS6 0 dBMobile MarkPSTG0-915FW7 0 dBMobile MarkPSTN3-915S8 0 dBMobile MarkPSTG0-915SE9 0 dBMobile MarkPSTN3-915N10

Name:DSCN0015.JPG Dimensions:1600 x 1200 pixels

Name:DSCN0002.JPG Dimensions:1024 x 768 pixels

Page 1 of 1 file://C:\Inet\attach\EmCond01.JPG4/11/02 Page 1 of 1 file://C:\Inet\attach\EmCond02.JPG4/11/02 Page 1 of 1 file://C:\Inet\attach\EmRad02.jpg4/11/02 Page 1 of 1 file://C:\Inet\attach\EmRad01.jpg4/11/02
