KNYPRW1001ERmini-PCI radio Module

FreeWave Technologies Inc.
mini-PCI radio Module - FCC ID KNYPRW1001ER - FreeWave Technologies Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Aug 19, 2013
Application Purpose
Original Equipment
Date of Application
Aug 13, 2013
Equipment Note
mini-PCI radio Module
Frequency Range
907.00000000 - 922.00000000
Company
FreeWave Technologies Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Part Number: LFC0002AA Revision: A Last Updated: 07/22/2013 FreeWave W0900-01 RF Module Guide FreeWave Technologies, Inc. 5395 Pearl Parkway, Suite 100 Boulder, CO 80301 USA 303.381.9200 www.FreeWave.com Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 21cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. OEM Integration Conditions This device is intended only for OEM integrators under the following conditions 1. The antenna must be installed such that 21 cm is maintained between the antenna and users, and 2. The transmitter module may not be co-located with any other transmitter or antenna IMPORTANT!: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 21 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: KNYPRW1001ER”. 3 Introduction This document describes the applicability of user operation of FreeWave’s W0900-01 RF module to keep compliance with regulatory requirements. Host System This module is intended to be used only with FreeWave’s system products. FreeWave’s system must supply regulated voltage to the module. Antenna Usage This module can only be used with the type of antennas approved to be used with FreeWave’s system. The use of a higher gain or a different type of antenna than the antennas approved with FreeWave’s FCC submission requires new FCC approval. The antennas used with this module may only be collocated and placed as identified on the FCC grant. Module Label The host system containing this module must either:  Make the module label visible so the FCC ID is visible in the installation  Label the end system product with the FCC ID and IC ID of the module

External Photos

RV-0000000 Project No.: 1306185 Page 2 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 8 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 9 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 10 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 11 of 1 3 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 12 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 13 of 13 Neutron Engineering Inc. 1306185 1306185

ID Label/Location Info

Label Location 3 x 1.8 CM

Internal Photos

RV-0000000 Project No.: 1306185 Page 3 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 4 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 5 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 6 of 13 Neutron Engineering Inc. 1306185 1306185 RV-0000000 Project No.: 1306185 Page 7 of 13 Neutron Engineering Inc. 1306185

RF Exposure Info

Report No.: NEI-FCCP-1-1306185 Page 72 of 82 Neutron Engineering Inc. 8.1.6 TEST RESULTS EUT: mini-PCI radio Module Model Name : W0900-01 Temperature: 26°C Relative Humidity: 60% Test Voltage: AC 120V/60Hz Test Mode : TX 907MHz/912MHz/917MHz/922MHz Configuration (11B 20MHz) Frequency (MHz) Power Density (dBm) LIMIT (dBm) Test Result 912MHz -4.28 8 Compliant 917MHz -4.82 8 Compliant Configuration (11G 5MHz) Frequency (MHz) Power Density (dBm) LIMIT (dBm) Test Result 907MHz 6.80 8 Compliant 912MHz 7.03 8 Compliant 917MHz 7.97 8 Compliant 922MHz 7.77 8 Compliant Configuration (11G 10MHz) Frequency (MHz) Power Density (dBm) LIMIT (dBm) Test Result 907MHz 2.69 8 Compliant 912MHz 5.54 8 Compliant 917MHz 4.96 8 Compliant 922MHz 6.02 8 Compliant Configuration (11G 20MHz) Frequency (MHz) Power Density (dBm) LIMIT (dBm) Test Result 912MHz 2.43 8 Compliant 917MHz 3.74 8 Compliant

Test Report

Report No.: NEI-FCCP-1-1306185 Page 1 of 82 Neutron Engineering Inc. FCC Radio Test Report FCC ID: KNYPRW1001ER This report concerns (check one) : Original Grant Class I Change Issued Date : Jul. 04, 2013 Project No. : 1306185 Equipment : mini-PCI radio Module Model Name : W0900-01 Applicant : FreeWave Technologies Inc. Address : 5395 Pearl Parkway, Suite 100, Boulder, Colorado, United States 80301 Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: May 11, 2010 Date of Test: May 11, 2010 ~ Jun. 07, 2010 Testing Engineer : (Rush Kao) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Report No.: NEI-FCCP-1-1306185 Page 2 of 82 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-1306185 Page 3 of 82 Neutron Engineering Inc. Table of Contents Page REPORT ISSUED HISTORY 5 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFEWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.4 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION 14 4.1.2 MEASUREMENT INSTRUMENTS LIST 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST 20 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS-BETWEEN 30MHZ - 1000MHZ 22 4.2.8 TEST RESULTS-ABOVE 1000MHZ 24 5 . BANDWITH TEST 48 5.1 APPLIED PROCEDURES / LIMIT 48 5.1.1 MEASUREMENT INSTRUMENTS LIST 48 5.1.2 TEST PROCEDURE 48 5.1.3 DEVIATION FROM STANDARD 48 5.1.4 TEST SETUP 48 Report No.: NEI-FCCP-1-1306185 Page 4 of 82 Neutron Engineering Inc. Table of Contents Page 5.1.5 EUT OPERATION CONDITIONS 48 5.1.6 TEST RESULTS 49 6 . PEAK OUTPUT POWER TEST 56 6.1 APPLIED PROCEDURES / LIMIT 56 6.1.1 MEASUREMENT INSTRUMENTS LIST 56 6.1.2 TEST PROCEDURE 56 6.1.3 DEVIATION FROM STANDARD 56 6.1.4 TEST SETUP 56 6.1.5 EUT OPERATION CONDITIONS 56 6.1.6 TEST RESULTS 57 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 58 7.1 APPLIED PROCEDURES / LIMIT 58 7.1.1 MEASUREMENT INSTRUMENTS LIST 58 7.1.2 TEST PROCEDURE 58 7.1.3 DEVIATION FROM STANDARD 58 7.1.4 TEST SETUP 58 7.1.5 EUT OPERATION CONDITIONS 58 7.1.6 TEST RESULTS 59 8 . POWER SPECTRAL DENSITY TEST 71 8.1 APPLIED PROCEDURES / LIMIT 71 8.1.1 MEASUREMENT INSTRUMENTS LIST 71 8.1.2 TEST PROCEDURE 71 8.1.3 DEVIATION FROM STANDARD 71 8.1.4 TEST SETUP 71 8.1.5 EUT OPERATION CONDITIONS 71 8.1.6 TEST RESULTS 72 9 . RF EXPOSURE TEST 79 9.1 RF EXPOSURE REQUIREMENTS / LIMIT: 79 9.1.1 MPE CALCULATION METHOD 79 10 . EUT TEST PHOTO 80 Report No.: NEI-FCCP-1-1306185 Page 5 of 82 Neutron Engineering Inc. REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-R1005001 Original Issue. Jun. 09, 2010 NEI-FCCP-1-R1005001A A. Changed applicant name and address. B. Changed brand name、model name and FCCID No. Jun. 23, 2010 NEI-FCCP-1-1306185 A. Changed applicant name and address. B. Changed brand name、model name and FCCID No. Jul. 04, 2013 Revised Version No. Description Issued Date - Initial Issue. Jul. 04, 2013 Report No.: NEI-FCCP-1-1306185 Page 6 of 82 Neutron Engineering Inc. 1. CERTIFICATION E q u i p m e n t : mini-PCI radio Module Brand Name : FreeWave Model Name : W0900-01 A p p l i c a n t : FreeWave Technologies Inc. Date of Test : May 11, 2010 ~ Jun. 07, 2010 Standards : FCC Part15, Subpart C / ANCI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1306185) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: NEI-FCCP-1-1306185 Page 7 of 82 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Reference Description Results Transmitter Mode (…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: NEI-FCCP-1-1306185 Page 80 of 82 Neutron Engineering Inc. 10. EUT TEST PHOTO Conducted Measurement Photos 1306185 1306185 Report No.: NEI-FCCP-1-1306185 Page 81 of 82 Neutron Engineering Inc. Radiated Measurement Photos 1306185 1306185 Report No.: NEI-FCCP-1-1306185 Page 82 of 82 Neutron Engineering Inc. Radiated Measurement Photos 1306185

Contact Information

Applicant

Richard Reisbick(VP Engineering)
[email protected]303-981-5017Fax: 303-786-8393

Technical Contact

Neutron Engineering Inc.Kate Lin
886-2-2657-3299

Taiwan

Non-Technical Contact

Neutron Engineering Inc.Kate Lin
[email protected]886-2-2657-3299

Test Firm

BTL Inc.Andy Chiu
[email protected]886-2-2657-3299Fax: 886-2-2657-3331

Technical Specifications

#Rule PartsFrequency RangePower Output
115C907 MHz - 922 MHz930.00 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antenna used for this transmitter must be installed to provide a separation distance of at least 21 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
