KPU41788Keyless Entry System

Housing removed

PRODUCT SERVICE TEST RESULT SUMMARY FCC PART 15 Subpart C Section 15.231 MANUFACTURER'S NAME Visteon Asia Pacific, Inc. NAME OF EQUIPMENT Keyless Entry System MODEL NUMBER 41788 MANUFACTURER'S ADDRESS Hiroshima Sangyo Bunka Center 9F 16-35, Hijiyama-honmachi, Minami-ku, Hiroshima 732-0816 Japan TEST REPORT NUMBER WC400072 TEST DATE 13 January 2004 According to testing performed at TÜV Product Service Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 15 Subpart C Section 15. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV Product Service Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 15 Subpart C Section 15.231. Date: 27 January 2004 Location: Taylors Falls MN R. M. Johnson T. K. Swanson USA Tested By Reviewed By Not Transferable File No. WC400072, Page 1 of 10 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMC EMISSION - T E S T R E P O R T Test Report File No. : WC400072 Date of issue: 27 January 2004 Model No. : 41788 Product Type : Keyless Entry System Applicant : Visteon Asia Pacific, Inc. Address : Hiroshima Sangyo Bunka Center 9F : 16-35 Hijiyama-honmachi, Minami-ku, Hiroshima 732-0816 Japan Manufacturer : Visteon Electronics Shanghai Plant Address : 300 Minolta Road : Songjiang country Shanghai, China 201600 Test Result : „ Positive † Negative Test Project Number : Reference(s) WC400072 Total pages including Appendices 24 TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. WC400072, Page 2 of 10 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE D I R E C T O R Y - EMISSIONS Page(s) A) Documentation Test report 1 - 10 Directory 2 Test Regulations 3 Environmental Conditions 4 EUT Information (Operating Modes, cables) 7 Deviation from standard / Summary 9 Test-setups (Photos) 10 Test-setup (drawing) Appendix A B) Test data results Conducted emissions 10/150 kHz - 30 MHz 5, 8 Radiated emissions electric field 30 MHz - 3200 MHz 6, 8 Emission Bandwidth 8 Duty Cycle Signal Deactivation ------ --- 8 C) Appendix A Test Data Sheets and Test Setup Drawing(s) A2 – A4 D) Appendix B Constructional Data Form and/or Product Information Form B2 – B8 E) Appendix C Measurement Protocol C1 - C2 File No. WC400072, Page 3 of 10 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- † - EN 50081-1 / 1991 † - EN 55011 / 1991 † - Group 1 † - Group 2 † - Class A † - Class B † - EN 55013 / 1990 † - EN 55014 / 1987 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55014 / A2:1990 † - EN 55014 / 1993 † - Household appliances and similar † - Portable tools † - Semiconductor devices † - EN 55015 / 1987 † - EN 55015 / A1:1990 † - EN 55015 / 1993 † - EN 55022 / 1987 † - Class A † - Class B † - EN 55022 / 1994 † - Class A † - Class B † - BS † - VCCI † - Class A † - Class B „ - FCC Part 15 Subpart C Section 15.231 † - AS 3548 (1992) † - Class A † - Class B † - CISPR 11 (1990) † - Group 1 † - Group 2 † - Class A † - Class B † - CISPR 22 (1993) † - Class A † - Class B File No. WC400072, Page 4 of 10 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE Environmental conditions in the lab: Actual Temperature : 17C Relative Humidity : 30 % Atmospheric pressure : 98.0 kPa Power supply system : Battery Sign Explanations: † - not applicable „ - applicable File No. WC400072, Page 5 of 10 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE Emissions Test Conditions: CONDUCTED EMISSIONS ( Interference Voltage ) The C ONDUCTED E MISSIONS (I NTERFERENCE V OLTAGE ) measurements were performed at the following test location: „ - Test not applicable † - Wild River Lab Large Test Site (Open Area Test Site) † - Wild River Lab Small Test Site (Open Area Test Site) † - Oakwood Lab (Open Area Test Site) † - Wild River Lab Screen Room † - New Brighton Lab Shielded Room Emissions Test Conditions: RADIATED EMISSIONS ( Magnetic Field ) The R ADIATED E MISSIONS (M AGNETIC F IELD ) measurements were perf…

Text truncated - open the document above for the full version.

File No. WC400072, Page A2 of A4 TÜV PRODUCT SERVICE INC 19333 Wild Mountain Road Taylors Falls MN 55084-1758 Tel: 651 638 0297 Fax: 651 638 0298 Rev.No 1.0 PRODUCT SERVICE TEST SETUP FOR EMISSIONS TESTING WILD RIVER LAB Small Test Site (STS) EUT 180 270 90 0 60 Hz 50 Hz Turntable is 1.2 meters in diameter Enlarged View of Shelter (4 meters square) STS Building Shelter 3 meter antenna 10 meter antenna 30 meter antenna Turntable Control Cable Ground Screen (34 meters long x 12 meters wide) 8 meters
