KUTMKA315315MHz remote control

Skylink Remote Control Model : MKA-315 PRELIMINARY COPY 1. INTRODUCTION In this package, you will find a Skylink Remote transmitter with 3V lithium battery. The Remote transmitter allows you to operate the Skylink’s receiver. There are four buttons on the transmitter MKA-315, each button can be programmed to control Skylink receiver. 2. PROGRAM THE TRANSMITTER TO RECEIVER In order for the remote control to communicate with the receiver, the transmitter must be programmed to the receiver. Follow the brief instructions below to program transmitter to the receiver you want to control. Refer to the receiver user’s instructions to set up the unit. 1. Press the Learn button on the receiver unit. 2. Once the learn button is pressed, the receiver LED will flash quickly. Release the Learn button. 3. Press any one of the 4 buttons on the transmitter that you want to program to the receiver 4. Once the transmitter is programmed, the receiver LED will flash slowly. 5. You may now operate the receiver with this new transmitter. 3. OPERATION Press the button for 1 second and release, this will activate the “learned” Skylink receiver(s). 4. BATTERY The remote control operates on one 3-volt lithium battery that is installed at the factory. Dispose of used battery properly according to the instructions. 5. WARRANTY If, within one year from date of purchase, this product should become defective (except battery), due to faulty workmanship or materials, it will be repaired or replaced, without charge. Proof of purchase is required. 6. FCC statement The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. 7. IC This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. 8. CUSTOMER SERVICE If you would like to order Skylink’s products or have difficulty getting them to work, please : 1. visit our FAQ section at www.skylinkhome.com, or 2. email us at [email protected], or 3. call our toll free at 1-800-304-1187 from Monday to Friday, 9am to 5pm EST. Fax (800) 286-1320. SKYLINK TECHNOLOGIES INC., 17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3 Email: [email protected] Website: http://www.skylinkhome.com © 2014 Skylink Group

TM :CPL: CAPITAL PROSPECT LTD. Rm. 03, 13lF., Block. B, Veristrong lnd. Centre, 34-36 Au PuiWan Street, Fo Tan, N.T., Hong Kong. Tel: (852) 2602 1318 Fax: (852) 2602 4684 Email: [email protected] Authoritv to Act as Asent Date: _Au97,2014 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 Mclean, Y A 22101 To Whom It May Concern: CMA Industrial Development Foundation Limited is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR I .2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: (6 months) I, By: Title: (Signat _Project Manager On behalf of: _Capital Prospect Ltd. Joe Ns (Print name) Telephone: (Company Name) 26021318 022311 -6

TM :CPL: CAPITAL PROSPECT LTf). Rm. 03, 13/F., Block. B, Veristrong lnd. Centre, 34-36 Au PuiWan Street, Fo Tan, N.T., Hong Kong. Tel: (852) 26021318 Fax: (852) 2602 4684 Email: [email protected] Request for Confident Date: Aug 7,2014 Subiect: Confidentiality Request for: KUTMKA3 15/4454A-MKA3 l5 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP- I 00, Section I 0, the applicant requests that a part of the subject FCC application be held confidential. fl Short Term fl Permanent* *Note: (lnsert Explanation as Necessary) Capital Prospect Ltd has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confi dentiality: The applibant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term cpnfidential be withheld from public view for a period of (!8Q)3_ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that lC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, Type of Confidentiality Requested I Short term I Permanent f] Short term n Short term I-l Permanent*2 E Short Term I Permanent fl Short Term f] Permanent I Short Term I Permanent ! Short term I Permanent ! Short term Project Manager_ ignature/Titlea) Exhibit Block Diagrams External Photos Intemal Photos Operation Description/Theory of Operation Parts List & Placement/BoM Tune-Up Procedure Schematics Test Setup Photos User's Manual -Joe Ng- (Print name) require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: "The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting." details. 022311 -6

External Photo

PROPRIETARY INFORMATION CPL CAPITAL PROSPECT LTD. MODEL : MKA-315 LABELING DIAGRAM DATE : 7 AUG, 2014 PAGE : 1 OF 1 SIZE : 2 0 X 12mm Model : MKA-315 IC:4454A-MKA315 FCC ID : KUTMKA315

Internal Photo

TEST REPORT Report No. : AS0047343(0) Date : 19 Aug 2014 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 24 Mr. WONG Lap-pong, Andrew Manager Electrical Division FCC ID: KUTMKA315 IC: 4454A-MKA315 Application No. : LS028462(0) Applicant : Capital Prospect Ltd 1303B, Veristrong Industrial center, 36 Aupuiwan street Fotan, Hong Kong Sample Description : One(1) item of submitted sample stated to be 315MHz Transmitter of Model No. MKA-315 Radio Frequency : 315MHz Transmitter Rating : 1 x 3V button cell No. of submitted sample : Two (2) piece (s) Date Received : 24 Jul 2014. Test Period : 31 Jul 2014 to 08 Aug 2014. Test Requested : FCC 47CFR Part 15 Certification. Industry Canada Interference Causing Equipment Standard RSS-210. Test Method : 47 CFR Part 15 (10-1-12 Edition) ANSI C63.4 – 2009 RSS-210 Issue 8 RSS-GEN Issue 3 Test Result : See attached sheet(s) from page 2 to 24. Conclusion : The submitted sample was found to comply with requirement of FCC 47CFR Part 15 Subpart C and Industry Canada RSS-210 Issue 8. TEST REPORT Report No. : AS0047343(0) Date : 19 Aug 2014 Page 2 of 24 FCC ID: KUTMKA315 IC: 4454A-MKA315 Table of Contents 1 General Information ................................................................................................................................... 3 1.1 General Description ............................................................................................................................ 3 1.2 Location of the test site ....................................................................................................................... 4 1.3 List of measuring equipment............................................................................................................... 5 1.4 Measurement Uncertainty ................................................................................................................... 5 2 Description of the radiated emission test ................................................................................................... 6 2.1 Test Procedure .................................................................................................................................... 6 2.2 Test Result .......................................................................................................................................... 7 2.3 Radiated Emission Measurement Data ............................................................................................... 8 3 Description of the Line-conducted Test ..................................................................................................... 9 3.1 Test Procedure .................................................................................................................................. 10 3.2 Test Result ........................................................................................................................................ 10 3.3 Graph and Table of Conducted Emission Measurement Data .......................................................... 10 4 Photograph ...............................................................................................................................................11 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................. 11 4.2 Photographs of the External and Internal Configurations of the EUT.............................................. 11 5 Supplementary document......................................................................................................................... 12 5.1 Bandwidth ......................................................................................................................................... 12 5.2 Duty cycle ......................................................................................................................................... 12 5.3 Transmission time ............................................................................................................................. 13 6 Appendices...............................................................................................................................................14 TEST REPORT Report No. : AS0047343(0) Date : 19 Aug 2014 Page 3 of 24 FCC ID: KUTMKA315 IC: 4454A-MKA315 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for remote control. It operates at 315MHz and the oscillation of radio control is generated by a 9.84375 MHz crystal and RF IC. The EUT is powered by 1 x 3V button cell. There are four buttons on th EUT. When the buttons are pressed, the EUT will send data to receiver.. The antenna terminal is permanently attached in EUT and the radio output power is unable to adjust. The brief circuit description is listed as follows: - U1 and its associated circuit act as code generator - U4, Y2 and its associated circuit act as RF circuit - C3, L2 and its associated circuit act as RF filter - U2, U3 and its associated circuit act as power detect TEST REPORT Report No. : AS0047343(0) Date : 19 Aug 2014 Page 4 of 24 FCC ID: KUTMKA315 IC: 4454A-MKA315 1.2 Location of the test site Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at: Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also taken pursuant to the procedures of ANSI C63.4 – 2009. A shielded room is located at : Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. FCC Registration Number: 552221 IC Assigned Code: 4093A-2 TEST REPORT Report No. : AS0047343(0) Date : 19 Aug 2014 Page 5 of 24 FCC ID: KUTMKA315 IC: 4454A-MKA315 1.3 List of measuring equipment Equip…

Text truncated - open the document above for the full version.

Test Setup Photo Front View (30MHz – 1GHz) Rear View (30MHz – 1GHz) Front View (9kHz – 30MHz) Rear View (9kHz – 30MHzHz) Front View (1GHz – 3.15GHz) Rear View (1GHz – 3.15GHz)
