Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Level measurement in hygienic applications Application • Continuous, non-contact level measurement of liquids and solids in hygienic applications • Process connections: for hygiene applications (e.g.: Tri-Clamp or M24 adapter concept) • Maximum measuring range: 15 m (49 ft) • Process temperature:–40 to +150 °C (–40 to +302 °F) • Pressure: –1 to +20 bar (–14.5 to +290 psi) • Accuracy: ±1 mm (±0.04 in) Your benefits • PTFE or PEEK antenna for hygienic requirements • Reliable measurement thanks to strong signal focusing, even with multiple internal fixtures • Easy, guided commissioning with intuitive user interface • Heartbeat Technology for predictive and preventive maintenance •Bluetooth®wireless technology for commissioning, operation and maintenance • CIP and SIP capabilities - up to protection class IP69 ProductsSolutionsServices Technical Information Micropilot FMR43 IO-Link Free-space radar TI01729F/00/EN/04.24-00 71656888 2024-04-19 Micropilot FMR43 IO-Link 2Endress+Hauser Table of contents About this document ........................3 Symbols....................................3 List of abbreviations...........................3 Graphic conventions...........................4 Function and system design...................4 Measuring principle............................4 Measuring system ............................5 Communication and data processing ................5 Reliability ..................................5 Device-specific IT security .......................5 Input .....................................5 Measured variable.............................5 Measuring range..............................5 Operating frequency..........................11 Transmission power...........................11 Output..................................11 Output signal...............................11 Switching capacity............................11 Signal on alarm for devices with current output.........11 Load .....................................11 Damping..................................12 Protocol-specific data .........................12 Power supply .............................12 Terminal assignment..........................12 Available device plugs .........................13 Supply voltage ..............................13 Power consumption ..........................13 Potential equalization .........................13 Overvoltage protection.........................13 Performance characteristics..................13 Reference conditions ..........................13 Resolution .................................14 Maximum measurement error....................14 Influence of ambient temperature.................15 Reaction time...............................15 Response time..............................15 Warm-up time (according to IEC 62828-4)...........15 Installation ..............................16 Mounting instructions .........................16 Mounting location............................16 Orientation................................16 Mounting the device..........................17 Beam angle................................19 Environment .............................21 Ambient temperature range .....................21 Storage temperature..........................22 Operating height.............................22 Climate class ...............................22 Degree of protection ..........................22 Pollution degree.............................22 Vibration resistance ..........................22 Shock resistance .............................22 Electromagnetic compatibility (EMC)...............22 Process ..................................23 Pressure range..............................23 Dielectric constant............................24 Mechanical construction....................25 Design, dimensions...........................25 Dimensions................................26 Weight ...................................30 Materials .................................30 Surface roughness............................35 Display and user interface...................35 Languages .................................35 LED indicator...............................36 Onsite display ..............................36 Remote operation ............................37 System integration ...........................38 Supported operating tools ......................38 Certificates and approvals ...................38 Hygienic design requirements....................38 Compliance with requirements derived from cGMP ......38 TSE (BSE) compliance (ADI free - Animal Derived Ingredients)..........................38 EN 302372 radio standard......................38 FCC......................................39 Industry Canada.............................39 ASME BPE.................................39 Ordering information.......................39 Identification...............................40 Calibration.................................40 Factory verification certificate....................41 Service...................................41 Application packages .......................41 Heartbeat Technology.........................41 Accessories ..............................42 Device-specific accessories ......................42 DeviceCare SFE100...........................43 FieldCare SFE500............................43 Device Viewer...............................43 Field Xpert SMT70............................43 Field Xpert SMT77............................43 SmartBlue app..............................43 Documentation............................43 Standard documentation........................43 Supplementary device-dependent documentation.......43 Registered trademarks......................44 Micropilot FMR43 IO-Link Endress+Hauser3 About this document SymbolsSafety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal i…
Text truncated - open the document above for the full version.
Long/Short-term Confidentiality Request To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: LCGFMR43L To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the Grante hereby requests long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics ☐ Parts List ☒ Block Diagram ☐ Tune-Up Info ☒ Operational Description In addition, the Grantee requests the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☐ for an initial period of days ☐ until: ☒ not applicable ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Grantee understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Authorized Agent / RECD Assistant
Nonroutine Long-term Confidentiality Request To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: LCGFMR43L To Whom it may concerns, Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rule and KDB726920, the Grantee hereby requests nonroutine long-term confidential treatment of information accompanying this application as outlined below: ☒ Internal Photos of a non-consumer device where the circuit board is enclosed in epoxy or in a material that would destroy the circuit board if removed, or the device is sealed and disassembly would destroy the product. ☐ Internal Photos of a non-consumer device where the device is not accessible to the general public (for example a device mounted on the top of a large tower or in a fenced enclosure that is only serviceable by the licensee or designated technicians). ☐ Installation Manual is very technical and is not provided to the consumer because the consumer cannot service the device. ☐ Integration Manual is not made available to the public as this module is solely integrated by our company in our own final products and will not be sold to any other integrators. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Grantee and provide unjustified benefits to its competitors. If you have any questions, please feel free to contact me. Yours sincerely, Authorized Agent / RECD Assistant
External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 1 of 8 EUT 5b, 3-D-view 1 External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 2 of 8 EUT 5b, 3-D-view 2 External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 3 of 8 EUT 5b, marking External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 4 of 8 EUT 5b, connector view External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 5 of 8 EUT 6b 3-D-view 1 External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 6 of 8 EUT 6b, 3-D-view 2 External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 7 of 8 EUT 6b, marking External photographs Examiner:Thomas KÜHNRevision:00 Date of issue: 15.07.2024Order Number: 23-110973page 8 of 8 EUT 6b, connector view
Lable Location Information Version with Display Board 71599584 - Front Foil Display - Extended Order Code contains “K” Version with Display Board 71548029 - Front Foil LED Display – Extended Order Code contains “D” Lable Position
Königswinkel 10 32825 Blomberg, Germany Phone: +49 (0) 52 35 / 95 00-0 Fax: +49 (0) 52 35 / 95 00-10 [email protected] www.phoenix-testlab.de FCC RF Exposure Evaluation Report Number: F230973E3 Equipment under Test (EUT): Level probing radar FMR43 Applicant: Endress+Hauser SE+Co. KG Manufacturer: Endress+Hauser SE+Co. KG Examiner: Thomas KÜHN Report Number: F230973E3 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 2 of 13 References CFR 47 Rule part 1 Practice and Procedure CFR 47Rule part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations KDB 447498 D01 General RF Exposure Guidance v06 T h i s t e s t r e p o r t i s o n l y v a l i d i n i t s o r i g i n a l f o r m. Any reproduction of its contents in extracts without written permission of the accredited test laboratory PHOENIX TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. PHOENIX TESTLAB GmbH is not responsible for any generalisations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the PHOENIX TESTLAB Logo and the TEST REPORT NUMBER. Assessed and written by: Signature Reviewed and approved by: Signature Examiner: Thomas KÜHN Report Number: F230973E3 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 3 of 13 Contents: Page 1. Identification ................................................................................................................................. 4 1.1. Applicant ................................................................................................................................................... 4 1.2. Manufacturer ............................................................................................................................................ 4 1.3. Test Laboratory ........................................................................................................................................ 4 1.4. EUT (Equipment under Test) ................................................................................................................... 5 1.5. Technical Data of Equipment ................................................................................................................... 5 1.6. Additional Information .............................................................................................................................. 6 2. Methods ........................................................................................................................................ 7 2.1. RF exposure test exemptions for single sources ..................................................................................... 7 1.1.1 General Exemption CFR 47 §1.1307(b)(3)(i)(A) ............................................................................. 7 1.1.2 SAR Based Exemption CFR 47 §1.1307(b)(3)(i)(B) ........................................................................ 7 1.1.3 MPE Based Exemption CFR 47 §1.1307(b)(3)(i)(C) ....................................................................... 7 1.1.4 Stand alone MPE evaluation limits .................................................................................................. 8 2.2. RF exposure test exemptions for simultaneous transmission sources .................................................... 9 1.1.5 1 mW Test Exemption for simultaneous transmission sources ....................................................... 9 1.1.6 Simultaneous transmission SAR based and MPE based test exemptions ..................................... 9 1.1.7 Test exemption based on the SAR to Peak Location Separation Ratio ........................................ 10 3. Results of evaluation ................................................................................................................... 11 3.1. Used evaluation methods ....................................................................................................................... 11 3.2. Evaluation Distance ............................................................................................................................... 11 3.3. Output power .......................................................................................................................................... 11 4. MPE evaluation ........................................................................................................................... 12 4.1. Stand-alone MPE results ....................................................................................................................... 12 4.2. Simultaneous MPE results ..................................................................................................................... 13 5. Conclusion .................................................................................................................................. 13 6. Report History ............................................................................................................................. 13 Examiner: Thomas KÜHN Report Number: F230973E3 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 4 of 13 1 Identification 1.1 Applicant Name: Endress+Hauser SE+Co. KG Address: Hauptstr. 1 79689 Maulburg Country: Germany Name for contact purposes: Mr. Ralf REIMELT Phone: +49 76 22 28 – 18 90 Fax: +49 76 22 28 – 15 890 eMail Address: [email protected] 1.2 Manufacturer Name: Endress+Hauser SE+Co. KG Address: Hauptstr. 1 79689 Maulburg Country: Germany Name for contact purposes: Mr. Ralf REIMELT Phone: +49 76 22 28 – 18 90 Fax: +49 76 22 28 – 15 890 eMail Address: [email protected] 1.3 Test Laboratory The tests were carried out by: PHOENIX TESTLAB GmbH Königswinkel 10 32825 Blomberg Germany Accredited by Deutsche Akkreditierungsstelle GmbH in compliance with DIN EN ISO/IEC 17025 under Reg. N…
Text truncated - open the document above for the full version.
Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 1 of 32 A.1 Results of EUT 5b A.1.1 Operating bandwidth and maximum value of peak power 230973_54.png: Operating bandwidth FMR43L 5b: A.1.2 Maximum value of peak power 230973_5.png: Maximum value of peak power FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 2 of 32 A.1.3 Transmitter timing 230973_53--00004.png: Transmitter timing with minimum pulse rate FMR43L 5b: 230973_53--00005.png: Transmitter timing with maximum pulse rate FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 3 of 32 230973_53--00006.png: Transmitter sweep time FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 4 of 32 A.1.4 Unwanted emissions Spurious emissions from 9 kHz to 30 MHz (measured in 3 m distance) FMR43L 5b: Spurious emissions from 30 MHz to 1 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 5 of 32 Spurious Spurious emissions from 1 GHz to 4 GHz FMR43L 5b: Emissions around 2.4 GHz caused by the BLE-part of the EUT. Spurious emissions from 4 GHz to 12 GHz FMR43L 5b: 0 20 40 60 80 100 1G2G3G4G Lev el in dBμV/m Frequenc y in Hz P review Result 2-A VGP review Result 1-P K+ §15.209 & RSS-GEN 1-40 GHz P k 3m co nt.§15.209 & RSS-GEN 1-40 GHz A V 3m co nt. §15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. 0 10 20 30 40 50 60 70 80 456789101112 Lev el in dBμV/m Frequency in GHz P review Result 2-A VGP review Result 1-P K+ §15.209 & RSS-GEN 1-40 GHz P k 3m co nt.§15.209 & RSS-GEN 1-40 GHz A V 3m co nt. §15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 6 of 32 Spurious emissions from 12 GHz to 18 GHz FMR43L 5b: Spurious emissions from 18 GHz to 26.5 GHz FMR43L 5b: 0 10 20 30 40 50 60 70 80 12131415161718 Lev el in dBμV/m Frequency in GHz P review Result 1-P K+§15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. §15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. 0 10 20 30 40 50 60 70 80 18192021222324252626.5 Lev el in dBμV/m Frequency in GHz P review Result 1-P K+§15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. §15.209 & RSS-GEN 1-40 GHz P k 3m co nt. §15.209 & RSS-GEN 1-40 GHz A V 3m co nt. Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 7 of 32 Spurious emissions from 26.5 GHz to 40 GHz FMR43L 5b: 230973_7.png: Spurious emissions from 40 GHz to 55 GHz FMR43L 5b: 10 20 30 40 50 60 70 80 90 26.528303234363840 Level in dBμV/m Frequency in GHz P review Result 1-P K+ Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 8 of 32 230973_9.png: Spurious emissions from 55 GHz to 75 GHz FMR43L 5b: 230973_12.png: Spurious emissions from 75 GHz to 90 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 9 of 32 230973_14.png: Spurious emissions from 90 GHz to 110 GHz FMR43L 5b: 230973_24.png: Spurious emissions from 110 GHz to 130 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 10 of 32 230973_15.png: Spurious emissions from 130 GHz to 150 GHz FMR43L 5b: 230973_34.png: Spurious emissions from 150 GHz to 174.8 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 11 of 32 230973_39.png: Spurious emissions from 182 GHz to 200 GHz FMR43L 5b: 230973_17.png: Spurious emissions from 200 GHz to 220 GHz FMR43L 5b): Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 12 of 32 230973_21.png: Spurious emissions from 220 GHz to 260 GHz FMR43L 5b: 230973_18.png: Spurious emissions from 260 GHz to 300 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 13 of 32 230973_22.png: Spurious emissions from 300 GHz to 330 GHz FMR43L 5b: Remark: Due to the difference between the frequency range predefined in the analyser (up to 325 GHz) and the frequency range used (up to 330 GHz) for band J, an exclamation mark is displayed. All adjusted correction data and factors covering the used frequency range. 230973_50.png: Spurious emissions from 330 GHz to 364 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 14 of 32 230973_49.png: Spurious emissions from 364 GHz to 398 GHz FMR43L 5b: 230973_48.png: Spurious emissions from 398 GHz to 432 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 15 of 32 230973_47.png: Spurious emissions from 432 GHz to 466 GHz FMR43L 5b: 230973_46.png: Spurious emissions from 466 GHz to 500 GHz FMR43L 5b: Annex A Measurement results Test engineer: Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number:23-110973page 16 of 32 230973_52.png: Spurious emissions from 500 GHz to 550 GHz FMR43L 5b: Remark: Due to the difference between the frequency range predefined in the analyser and the frequency range used for free configurable band user, an exc…
Text truncated - open the document above for the full version.
Königswinkel 10 32825 Blomberg, Germany Phone: +49 (0) 52 35 / 95 00-0 Fax: +49 (0) 52 35 / 95 00-10 [email protected] www.phoenix-testlab.de Test Report Report Number: F230973E1 Equipment under Test (EUT): Level probing radar FMR43 Applicant: Endress+Hauser SE+Co. KG Manufacturer: Endress+Hauser SE+Co. KG Examiner: Thomas KÜHN Report Number: F230973E1 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 2 of 34 References [1] ANSI C63.10-2020, American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices [2] FCC CFR 47 Part 15, Radio Frequency Devices [3] KDB publication 890966 D01 v01r01, Measurement procedure for Level Probing Radars v01 (September 2014) Test Result The requirements of the tests performed as shown in the overview (clause 4) were fulfilled by the equipment under test. The complete test results are presented in the following. “Passed” indicates that the equipment under test conforms with the relevant limits of the testing standard without taking any measurement uncertainty into account as stated in clause 1.4 of ANSI C63.10 (2020). However, the measurement uncertainty is calculated and shown in this test report. Tested and written by: Signature Reviewed and approved by: Signature T h i s t e s t r e p o r t i s o n l y v a l i d i n i t s o r i g i n a l f o r m. Any reproduction of its contents in extracts without written permission of the accredited test laboratory PHOENIX TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. PHOENIX TESTLAB GmbH is not responsible for any generalisations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the PHOENIX TESTLAB Logo and the TEST REPORT NUMBER. Examiner: Thomas KÜHN Report Number: F230973E1 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 3 of 34 Contents: Page 1.1 Applicant ................................................................................................................................................... 4 1.2 Manufacturer ............................................................................................................................................ 4 1.3 Test Laboratory ........................................................................................................................................ 4 1.4 EUT (Equipment under Test) ................................................................................................................... 5 1.5 Technical Data of Equipment ................................................................................................................... 5 1.6 Dates ........................................................................................................................................................ 6 5.1 Test setups ............................................................................................................................................... 8 5.2 Fundamental emissions bandwidth ........................................................................................................ 17 5.3 Fundamental emission ........................................................................................................................... 19 5.4 Unwanted emissions (radiated) .............................................................................................................. 21 5.5 Frequency stability ................................................................................................................................. 27 5.6 AC power-line conducted emissions ...................................................................................................... 29 Examiner: Thomas KÜHN Report Number: F230973E1 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 4 of 34 Identification 1.1 Applicant Name: Endress+Hauser SE+Co. KG Address: Hauptstr. 1 79689 Maulburg Country: Germany Name for contact purposes: Mr. Ralf REIMELT Phone: +49 76 22 28 – 18 90 Fax: [email protected] eMail Address: +49 76 22 28 – 15 890 Applicant represented during the test by the following person: Mr. Ralf REIMELT (partly) 1.2 Manufacturer Name: Endress+Hauser SE+Co. KG Address: Hauptstr. 1 79689 Maulburg Country: Germany Name for contact purposes: Mr. Ralf REIMELT Phone: +49 76 22 28 – 18 90 Fax: [email protected] eMail Address: +49 76 22 28 – 15 890 Manufacturer represented during the test by the following person: Mr. Ralf REIMELT (partly) 1.3 Test Laboratory The tests were carried out by: PHOENIX TESTLAB GmbH Königswinkel 10 32825 Blomberg Germany Accredited by Deutsche Akkreditierungsstelle GmbH (DAkkS) in compliance with DIN EN ISO/IEC 17025 under Reg. No. D-PL-17186-01-00, FCC Test Firm Designation Number DE0004, FCC Test Firm Registration Number 469623, CAB Identifier DE0003 and ISED# 3469A. Examiner: Thomas KÜHN Report Number: F230973E1 Date of Issue: 31.07.2024 Order Number: 23-110973 Page 5 of 34 1.4 EUT (Equipment under Test) EUT number Model name Serial number Sensor board Display board Mainboard Power board Terminal board Hardware version Software version 5b FMR43 FMR43_IOL-_035 71607254 71599584 71439136 71502179 71508546 01.00.00 01.00.00 6b FMR43_IOL_019 EUT number Display type Housing material Antenna Antenna gain 5b Front Foil display Stainless steel PTFE M24 29.17 dBi 6b PTFE ½” 26.93 dBi 11 *: Declared by the applicant. Note: PHOENIX TESTLAB GmbH does not take samples. The samples used for tests are provided exclusively by the applicant. 1.5 Technical Data of Equipment Rated rf-output power: * 20 dBm/MHz Antenna type: * Refer table above Operating frequency band: * 174,800 MHz to 182,000 MHz Nominal channel bandwidth(s): * 7,200 MHz Type of modulation: * FMCW Antenna connector: * None FCC ID: LCGFMR43L Temperature range: * -50 °C to +80 °C Supply voltage range: * U n…
Text truncated - open the document above for the full version.
1/2 FMR43L - PTFE M24 - antenna pattern Measurement setup Measured antenna patterns of EUT Max. gain: 29.17 dBi Max. backlobe gain*: -1.9 dBi Max. gain: 29.35 dBi Max. backlobe gain*: -2.3 dBi (*) Backlobe gain means antenna gain in the half-sphere opposing the intended installation direction of the radar device. 2/2 FMR43L - PTFE ½” - antenna pattern Measurement setup Measured antenna patterns of EUT Max. gain: 26.93 dBi Max. backlobe gain*: -8.1 dBi Max. gain: 27.05 dBi Max. backlobe gain*: -4.1 dBi (*) Backlobe gain means antenna gain in the half-sphere opposing the intended installation direction of the radar device.
Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 1 of 20 Test setup semi anechoic chamber with EUT 5b (9 kHz to 1 GHz), position 1 Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 2 of 20 Test setup semi anechoic chamber with EUT 5b (9 kHz to 1 GHz), position 2 Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 3 of 20 Test setup semi anechoic chamber with EUT 5b (9 kHz to 30 MHz) Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 4 of 20 Test setup semi anechoic chamber with EUT 5b (30 MHz to 1 GHz) Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 5 of 20 Test setup fully anechoic chamber with EUT 5b (<40 GHz) Annex B Test setup photos Examiner:Thomas KÜHNReport Number: F230973E1 Date of issue: 31.07.2024Order Number: 23-110973page 6 of 20 Test setup fully anechoic chamber with EUT 5b (1 GHz to 12 GHz) Annex B Test set…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 174.80 GHz - 182.00 GHz | 302.00 mW |
