LE2APPCAM21WIFI Network Camera

1 APPCAM21 2 CAMERA OVERVIEW 3 KIT CONTENT 4 Quick Start Guide 1. Run APK file to install the APP to your mobile device, then ”Click “OMGuard Lite” on mobile desktop to run the APP, as showed below 2. Select “Click here to add camera” for camera setup 5 3. There are 3 ways for IP cam connection setup. But for 1 st time installation of your IP cam, we need to setup the connection between IP cam and your router by entering SSID and PW of your router to the IP CAM for Wi-Fi connection. Therefore, please select “AP Wizard add” option to proceed with the setup 4. Click “Next” 6 5. Click “Next” 6. First of all, we need to establish direct link between your mobile device to the IP CAM, please click “Wi-Fi” to link with Camera via Wi-Fi direct connection 7 7. IP CAM’s SSS ID will be shown as “IIPCAM_XXXXX” , Please select this SSID for direct connection, then and enter PW “88888888” to establish the link (“88888888” is the default password) 8. Upon Connection enter ID/PW to continue; the default ID is “admin”, no need to enter any PW (Blank). Then, click “Next” for moving to router search 8 9. Select the router you are going to use and enter the router password. 10. NOW, the IP camera will reboot to save changes, so please wait for about a minute; if the green LED turns steady on, it means the IP cam has connected to the router successfully (Note: pairing will be finished when the indicator stays on in green light). ,Then click “Next” to continue 9 11. Now, you need to change the Wi-Fi connection back to your router, after change the Wi-Fi connection, Click “Next” to continuous 12. Now a new Cam setup window will show up, the default name is “IPC-XXXXXXXXXXXX”. You can change the name in any format like “Home” or “Office” if prefer, then Click “Save” to finish the setup 10 13. The camera will be shown on the list. Click on the Icon to viewing and control other function of the IP Cam. 14. For viewing camera, you can click below “RED” area 11 15. You can click “tool” (as below RED area) for enter, edit, or delete this camera. 16. If you would like to playback the previous recorded video or photos, please click “Gallery” at the bottom menu ※IP Cam reset: Press “reset” for 10 sec. till the green light is off. Then Press “reset” again till the green light is on. Then press “reset” again for 3 sec and u will see the green light is flashing FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. IC Statement: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The distance between user and products should be no less than 20cm La distance entre l'utilisateur et de produits ne devrait pas être inférieure à 20cm

JSW Pacific Corporation 3F-3, No.700, Chung-Zheng Road, Chung Ho City, Taipei Hsien Taiwan DATE :2014-3-21 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hans.Hu of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong (Name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all res ponsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, s till resides with JSW Pacific Corporation and 3F-3, No.700, Chung-Zheng Road, Chung Ho City, Taipei Hsien Taiwan ( applicant name and address). Dated this / Day of 03/21/2014 / Agency agreement expiration date: 03/21/2015 By: M. H. Chen Sig naturePrinted Ti tle: Vice President On behalf of : JSW Pacific Corporation Tel ephone: 886-2-82278582

JSW Pacific Corporation 3F-3, No.700, Chung-Zheng Road, Chung Ho City, Taipei Hsien Taiwan DATE 2013-3-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: LE2APPCAM21 Product Name: WIFI Network Camera Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this / Day of 3/21/2014 / By: M. H. Chen Signature Printed Title: Vice President On behalf of : JSW Pacific Corporation Telephone: 886-2-82278582

Adapter 1 Adapter 2 Adapter 3 Adapter 1 Adapter 2 Adapter 3

label size: 25mm*35mm JSW Pacific Corporation Product Name: WIFI Network Camera Model: APPCAM21 FCC ID: LE2APPCAM21 IC: 4801A-APPCAM21 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Label location

RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation 802.11b mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 40.926 0.01291 1.0 PASS Middle (2437MHz) 42.170 0.01329 1.0 PASS Highest (2462MHz) 42.954 0.01354 1.0 PASS 802.11g mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 13.868 0.00437 1.0 PASS Middle (2437MHz) 13.552 0.00427 1.0 PASS Highest (2462MHz) 13.709 0.00432 1.0 PASS 802.11n(HT20) Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 11.803 0.00372 1.0 PASS Middle (2437MHz) 13.002 0.00410 1.0 PASS Highest (2462MHz) 13.397 0.00423 1.0 PASS 802.11n(HT40) Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 8.770 0.00277 1.0 PASS Middle (2437MHz) 9.183 0.00289 1.0 PASS Highest (2462MHz) 8.851 0.00279 1.0 PASS Remark: antenna gain=2.0 dBi
