LJPNKW-1Dual-Band Tri-Mode Cellular Telephone

Microsoft Corporation

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Apr 18, 2002
Application Purpose: Original Equipment
Date of Application: Apr 18, 2002
Equipment Note: Dual-Band Tri-Mode Cellular Telephone
Frequency Range: 1850.04000000 - 1909.92000000
Company: Microsoft Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

DRAFT [Model] User Guide DRAFT Not for Distribution This user guide is under development. Phone notes NotesWhere to get information My number Wireless service provider Voice mail number Wireless service provider’s customer care Model number [Model] Type label. Located under the battery inside the phone’s back cover. Phone type NKW-1 ESN (Electronic serial number) DRAFT The wireless phone described in this guide is approved for use in TDMA and AMPS networks. LEGAL INFORMATION Part No. ________, Issue No. 1 Copyright ©2002 Nokia Corporation. All rights reserved. Nokia is a registered trademark of Nokia Corporation. Printed in Canada __/2002 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright ©1999-2002. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this user guide was written for Nokia phone [Model]. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. EXPORT CONTROLS This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited. FCC/INDUSTRY CANADA NOTICE Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. DRAFT Contents 1 Safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 Welcome and quick guide . . . . . . . . . . . . . . . . . . . . . . 3 Get the most out of this guide. . . . . . . . . . . . . . . . . . . 3 Understand wireless network services. . . . . . . . . . . . . 5 Register your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 E-newsletters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Understand your phone . . . . . . . . . . . . . . . . . . . . . . . . 6 Get started with the quick guide . . . . . . . . . . . . . . . . 11 Get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 3 Basic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Switch your phone ON or OFF . . . . . . . . . . . . . . . . . .15 Make and answer calls . . . . . . . . . . . . . . . . . . . . . . . .16 Check the Start screen . . . . . . . . . . . . . . . . . . . . . . . .18 Use the selection keys. . . . . . . . . . . . . . . . . . . . . . . . .20 Scroll keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Check in-phone help . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Browse phone menus . . . . . . . . . . . . . . . . . . . . . . . . . 21 Set up your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 4 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Standard text input . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Write with predictive text . . . . . . . . . . . . . . . . . . . . .28 DRAFT 5 Phone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 View the phone book . . . . . . . . . . . . . . . . . . . . . . . . . 31 Save names, numbers and email addresses . . . . . . . 31 Use phone book menus . . . . . . . . . . . . . . . . . . . . . . . 31 Recall names and numbers . . . . . . . . . . . . . . . . . . . . 31 Edit a name or number . . . . . . . . . . . . . . . . . . . . . . . 31 Add a second number to a name . . . . . . . . . . . . . . . 32 Change the number type . . . . . . . . . . . . . . . . . . . . . . 32 Specify the primary number . . . . . . . . . . . . . . . . . . . 32 Erase names and numbers . . . . . . . . . . . . . . . . . . . . . 32 Check memory status . . . . . . . . . . . . . . . . . . . . . . . . . 32 6 Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Check missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Check dialed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Check received calls . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Use call timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 7 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Email messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 8 Personalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 DRAFT 9 Advanced calling features . . . . . . . . . . . . . . . . . . . . .45 Understand active-call options . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Users Manual

RESPONSE 2 (2) Response to FCC correspondence 4121 FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia. All rights reserved. Added items into Accessory section: Carry case (CSM-6) Handsome leather case helps protect your phone and allows for easy keypad access. The clip attaches to your belt for convenience. (shown at right) Carry case (CSL-20) Luxurious, hard leather case with a flap and convenient clip that attaches to your belt. E) Please address how the burst nature of the emission was accounted for in the radiated and conducted emission measurements. Look above A). F) Discussion of how the EUT was operated/controlled during the test to assure the testing of all appropriate modes, maximum power, and any duty factor driven parameters. Supplement C Appendix B part I 2. Look above B). G) Please provide justification of necessary BW per CFR 47 sect. 2.2 ( c). All bandwidths are measured and listed in test report. However, these were not used in emission designators, since FCC has recommended theoretical calculated values to be used in recent TCB workshops. H) Please provide SAR plots with the operating mode of the radio, i.e. AMPs or TDMA. We will do this in all future submissions, but request that this time these modes are identified with following information: - AMPS plots are always the first ones in every operating position and can be identified of crest factor of 1.0 - TDMA plots can be identified of crest factor of 3.0 We apologize for any inconvenience this may have caused. H) Please provide for exhibit the questions associated with answers provided under exhibit 6. We have asked American TCB to do this.

Attestation Statements

Cover Letter(s)

RESPONSE 1 (2) Response to FCC correspondence 4121 FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia. All rights reserved. To: Martin Perrine FCC Equipment Authorization Branch Re: FCC ID: LJPNKW-1 Applicant: Nokia Corporation Correspondence Reference Number: 4121 731 Confirmation Number: TC446362 A) Please address how the burst nature of the emission was accounted for in the radiated and conducted emission measurements. All spectrum analyzer measurements were done using peak detector and duty cycle was used during power meter measurements. B) Discussion of how the EUT was operated/controlled during the test to assure the testing of all appropriate modes, maximum power, and any duty factor driven parameters. Supplement C Appendix B part I 2. Special control software was used allowing control over frequency, mode and power level of EUT. Modulation, duty cycle or any other system specified fixed parameters cannot be altered and they were similar to normal operation. All EMC and RF exposure tests are done using this software. C) Please provide a full parts list. New confidentiality request is included to cover also parts list. D) Please confirm that the CSM-6 is the only body-worn accessory available for this phone. Please update the manual to mention this accessory. CSM-6 is the only provided body-worn accessory, which can be used with headset (i.e. have a call when worn on body). However, CSL-20 is provided as well, but it does not have space/hole for headset connector (located on the bottom of the phone). These accessories will be listed in Accessory section of the user manual. Picture 1. CSL-20 horizontal carrying case Updated text in manual: For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with the Nokia accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. RESPONSE 2 (2) Response to FCC correspondence 4121 FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia. All rights reserved. Added items into Accessory section: Carry case (CSM-6) Handsome leather case helps protect your phone and allows for easy keypad access. The clip attaches to your belt for convenience. (shown at right) Carry case (CSL-20) Luxurious, hard leather case with a flap and convenient clip that attaches to your belt. E) Please address how the burst nature of the emission was accounted for in the radiated and conducted emission measurements. Look above A). F) Discussion of how the EUT was operated/controlled during the test to assure the testing of all appropriate modes, maximum power, and any duty factor driven parameters. Supplement C Appendix B part I 2. Look above B). G) Please provide justification of necessary BW per CFR 47 sect. 2.2 ( c). All bandwidths are measured and listed in test report. However, these were not used in emission designators, since FCC has recommended theoretical calculated values to be used in recent TCB workshops. H) Please provide SAR plots with the operating mode of the radio, i.e. AMPs or TDMA. We will do this in all future submissions, but request that this time these modes are identified with following information: - AMPS plots are always the first ones in every operating position and can be identified of crest factor of 1.0 - TDMA plots can be identified of crest factor of 3.0 We apologize for any inconvenience this may have caused. H) Please provide for exhibit the questions associated with answers provided under exhibit 6. We have asked American TCB to do this.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 8, 2002 RE: FCC ID: LJPNKW-1 I have a few comments on this Application. 1 On page 13 of the report the test lab uses a formula for calculating: ERP = Level + ET – ES + GainAnt. While the calculated values of ERP appear correct, and while this may be an appropriate formula to use to determine ERP, step b and c of the measurement procedure states the measured values of Et and Es are recorded. However, neither values have been given – only the result of the algebraic addition of the two. Please provide the values or at least a sample of Et and Es from the recorded measured values. Also, while the formula may be appropriate, the term “Level” is not defined. Again, while assumptions can be made about this value in the formula, assumptions cannot be made as to what the lab says these values are. Please provide an adequate explanation of the term “Level”. 2 The report Page 21 of 81, “Measurement Of Maximum Deviation”, appears incorrect. The last column is labeled MHz. Please correct this to show the proper designation. Dennis Ward Dt Associates PO Box 1644 Mariposa, CA 95338 mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 4, 2002 RE: FCC ID: LJPNKW-1 I have a few comments on this SAR Application. 1 The reference dielectric and S/M values should be within 5%% of the measured values taken in the System Accuracy Verification. However, at 835MHz for the head verification done on 2/22/02 shows a reference value of 42.3 and a measured value of 39.5 for dielectric (εr). While this is within the +/-10% of the target value in IEEE std 1528, and explanation of the excessive percentage should be made. Please provide an explanation letter for this variance. You may upload this letter to the ATCB website for this application. 2 The Crest Factors used in the report do not have sufficient explanation as to their derivation or source. Please provide an example of the determination of the Crest Factor. Dennis Ward Dt Associates PO Box 1644 Mariposa, CA 95338 mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

NOKIA CORPORATION Nokia Mobile Phones Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 May 10, 2002 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REVISED REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: LJPNKW-1 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices, Tune-Up Procedure and Parts List - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Mikko Halttunen Product Program Manager, PC Site Oulu

External Photos

1 Mar 2002 Exhibit 3: External Photographs FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia Corporation 1 Mar 2002 Exhibit 3: External Photographs FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia Corporation

ID Label/Location Info

MADE IN USA ESN: Code: 0507070 FCC ID: LJPNKW-1 IC: 661E-NKW1 Type: NKW-1 Model: Applicant: Nokia CorporationCopyright2002 Nokia Corporation FCC ID LJPNKW-1: Exhibit 1: Type Label Position 27 Feb 2002 MADE IN USA ESN: Code: 0507070 FCC ID: LJPNKW-1 IC: 661E-NKW1 Type: NKW-1 Model: MADE IN USA ESN: Code: 0507070 FCC ID: LJPNKW-1 IC: 661E-NKW1 Type: NKW-1 Model: 27 Feb 2002 Applicant: Nokia CorporationCopyright2002 Nokia Corporation FCC ID LJPNKW-1: Exhibit 1: Type Label Position NOKIA CORPORATION Nokia Mobile Phones Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 February 27, 2002 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch COMPLIANCE STATEMENT OF LJPNKW-1 The compliance statement can be seen in User Guide of LJPNKW-1 because the size of the handportable LJPNKW-1 and its identification label are so small that the compliance statement cannot be printed visible enough. NOKIA CORPORATION Mikko Halttunen Product Program Manager, PC Site Oulu DRAFT The wireless phone described in this guide is approved for use in TDMA and AMPS networks. LEGAL INFORMATION Part No. ________, Issue No. 1 Copyright ©2002 Nokia Corporation. All rights reserved. Nokia is a registered trademark of Nokia Corporation. Printed in Canada __/2002 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright ©1999-2002. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this user guide was written for Nokia phone [Model]. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. EXPORT CONTROLS This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited. FCC/INDUSTRY CANADA NOTICE Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

Internal Photos

1 Mar 2002 Exhibit 9: Internal Photographs FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia Corporation 1 Mar 2002 Exhibit 9: Internal Photographs FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia Corporation Internal antenna 1 Mar 2002 Exhibit 9: Internal Photographs FCC ID: LJPNKW-1 Applicant: Nokia Corporation Copyright © 2002 Nokia Corporation

RF Exposure Info

NOKIA CORPORATION Nokia Mobile Phones Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 February 27, 2002 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road Columbia, MD. 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID: LJPNKW-1 complies with ANSI/IEEE C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. Compliance was determined by testing appropriate parameters according to standard. NOKIA CORPORATION Mikko Halttunen Product Program Manager, PC Site Oulu PC Site Oulu Exhibit 11: SAR Report DTX04018-EN Applicant: Nokia Corporation FCC ID: LJPNKW-1 Copyright  2002 Nokia Corporation 1 (14) SAR Compliance Test Report Test report no.: Not numbered Date of report: 2002-03-05 Number of pages: 76 Contact person: Kautio Olli Responsible test engineer: Mäkikyrö Pertti Testing laboratory: Nokia Corporation Elektroniikkatie 10 P.O. Box 50 FIN-90571 OULU Finland Tel. +358-7180-08000 Fax. +358-7180-47222 Client: Nokia Corporation Elektroniikkatie 10 P.O. Box 50 FIN-90571 OULU Finland Tel.+358-7180-08000 Fax. +358-7180-47222 Tested devices: LJPNKW-1 CSM-6 Supplement reports: - Testing has been carried out in accordance with: IEEE P1528-200X Draft 6.4 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at PC Site Oulu Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: 2002-03-05 For the contents: Pertti Mäkikyrö Engineering Manager, EMC Miia Nurkkala Test Engineer PC Site Oulu Exhibit 11: SAR Report DTX04018-EN Applicant: Nokia Corporation FCC ID: LJPNKW-1 Copyright  2002 Nokia Corporation 2 (14) CONTENTS 1.SUMMARY FOR SAR TEST REPORT ..........................................................................................................................3 1.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION.................................................................................................................. 3 1.1.1Head Configuration.......................................................................................................................................................... 3 1.1.2Body Worn Configuration............................................................................................................................................... 3 1.1.3Measurement Uncertainty ............................................................................................................................................. 3 2.DESCRIPTION OF TESTED DEVICE .............................................................................................................................4 2.1 PICTURE OF PHONE AND LOCATION OF ANTENNA............................................................................................................................. 4 2.2 D ESCRIPTION OF THE ANTENNA........................................................................................................................................................ 4 2.3 B ATTERY OPTIONS............................................................................................................................................................................. 4 2.4 B ODY WORN ACCESSORIES.............................................................................................................................................................. 5 3.TEST CONDITIONS ........................................................................................................................................................5 3.1 AMBIENT CONDITIONS...................................................................................................................................................................... 5 3.2 RF CHARACTERISTICS OF THE TEST SITE............................................................................................................................................. 5 3.3 T EST SIGNAL, FREQUENCIES, AND OUTPUT POWER.......................................................................................................................... 5 4.DESCRIPTION OF THE TEST EQUIPMENT.................................................................................................................5 4.1 SYSTEM ACCURACY VERIFICATION.................................................................................................................................................... 6 4.2 T ISSUE SIMULANTS............................................................................................................................................................................ 7 4.2.1Head Tissue Simulant ...................................................................................................................................................... 7 4.2.2Muscle Tissue Simulant................................................................................................................................................... 8 4.3 P HANTOMS........................................................................................................................................................................................ 8 4.4 I SOTROPIC E-FIELD PROBE ET3DV6 ...............................................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Hasnain Syed(Director, EMC, SI and RF Compliance)

[email protected]1-425-707-1039Fax: 1-425-706-7329

Technical Contact

Nokia CorporationKare Oksanen

[email protected]011 358 7180 08000

Elektroniikkatie 10 · Oulu · Finland

Non-Technical Contact

Nokia CorporationKare Oksanen

[email protected]011 358 7180 08000

Test Firm

M. Flom Associates, Inc.Morton Flom

[email protected]480-926-3100Fax: 480-926-3598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	723.00 mW	30K0DXW	200 Hz

Confidentiality

Long Term

Grant Notes

Power Output is ERP for Part 22 and EIRP for Part 24. Body worn operations are restricted to belt clips/holsters/accessories tested for this filing. End-Users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values are: Part 22 AMPS Head 1.16W/kg; Body-worn 0.95W/kg; TDMA Head 0.64W/kg; Body-worn 0.61W/kg: Part 24 TDMA 0.69W/kg; Body-worn 0.85W/kg
