[ 1 ] Nokia 3320 User Guide Draft V0.1 Not For Distribution [ 2 ] The wireless phone described in this guide is approved for use in TDMA and AMPS networks. Legal information Part No. 9353391, Issue No. 1 © 2001 Nokia Inc. All rights reserved. Nokia is a registered trademark of Nokia Corporation. Printed in Canada XX/2001 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1999-2001. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this Owner’s Manual was written for Nokia phone NPC-1 and NPW-1. The right to make changes and improvements to any of the products described in this guide without prior notice is reserved. Export Controls This product may also be subject to United States export controls. The United States export laws currently prohibit the export of certain technical data and software into Cuba, Iran, Iraq, Libya, North Korea, Sudan, and Syria, or any national or resident of those countries, or to anyone on the United States Treasury Department’s list of Specially Designated Nationals or the U.S. Commerce Department’s Table of Deny Orders. You agree that you shall not export this product in contravention of United States export laws. FCC/Industry Canada Notice Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. [ 3 ] [ 4 ] Safety first 1 Safety guidelines 1 Road safety comes first 1 Switch off in hospitals 1 Switch off while aboard aircraft 1 Switch off when refueling 1 Switch off near blasting 1 Observe infrared precautions 1 Quick tips 2 Be aware of interference 2 Use your phone sensibly 2 Use only qualified service personnel 2 Use approved accessories and batteries 2 Read instructions before you connect to other de- vices 2 Make sure the phone is on 2 Your phone’s label 3 Welcome 4 Get the most out of this guide 4 Understand the terms 4 Notice text conventions 4 Follow graphic clues 5 Look for updates 5 Understand wireless network services 6 Sign up with a service provider 6 Note differences among service providers 6 Learn about accessibility solution 6 [ 2 ] The Nokia commitment 6 Alternate format user guides 7 LPS-3 Mobile Inductive Loopset 7 Find information about your phone 8 Contact Nokia 9 Have the right information available 9 Have the phone or accessory handy 9 Contact your service provider 10 Set up your phone 11 Attach the battery 11 Charge the battery 11 Remove the battery 12 Important battery information 12 Prolong battery life 12 Connect the headset 13 Use the carrying case 13 Adjust the volume 13 Adjust screen contrast 13 Choose the look of your screen 13 Review the basics 14 Antenna 14 Possible overheating 15 Learn the keys 15 Make and answer calls 16 Check the Start screen 16 Return to the Start screen 17 Check the header line and scroll bar 17 Review phone symbols 18 Use the selection keys 20 Check in-phone help 20 Browse phone menus 20 Scroll through menus 21 Use a shortcut 21 Shortcuts 22 Phone book menu 26 Use the phone book 28 Review ABC and 123 entries 28 Enter letters 28 Enter numbers 29 Enter punctuation and other characters 29 Use special characters in names and phone numbers 30 In ABC mode 30 In 123 mode 30 Check call history 31 Check the call log 31 Check missed calls 32 Check previously dialed calls 32 Check received calls 33 Clear call lists 33 Check call timers 34 Turn on a current call timer 34 Clear call timers 35 [ 4 ] Use advanced calling features 36 Set in-call options 36 Use call waiting 37 Store the call waiting feature code 37 Activate call waiting 37 Manage calls 37 Make a conference call 37 Lookup a number during a conference call 38 Use call forwarding 39 Store the call forwarding feature code 39 Activate call forwarding 39 Redial automatically 41 Use a calling card 41 Save calling card information (step 2) 42 Choose a calling card to use 43 Make a calling card call 43 Send your own number in caller ID 43 Store the Send Own Number feature code 44 Select a phone number 45 Select the phone number 45 Select digital or analog 45 Set touch tones 46 Set touch tone length 46 Store touch tone sequences (strings) 47 Use voice mail 49 Check for messages 49 Set up your voice mailbox 49 Set greetings and passwords 50 Listen to your voice messages 50 Personalize rings & tones 51 What is a profile? 51 Select a different profile 51 Customize a profile 52 Set ring options 53 Set the ring volume 53 Set the ring tone 54 Set a vibrating alert 55 Set keypad tones 55 Set warning and game tones 55 Set the message alert tone 56 Set your phone to answer automatically 56 Set the lights (car kit only) 57 Rename profiles 58 Personalize phone settings 59 Set the display language 59 Set and display the clock 59 Set the clock 59 Display the clock 60 Select the time format 60 Add a welcome note 60 Use 1-touch dialing 61 Set up a 1-touch dial key 61 Change 1-touch dialing numbers 61 Erase 1-touch dialing numbers 62 [ 6 ] Restore factory settings 62 Manage phone security 63 Change your security code 63 Protect your phone with the lock code 64 Turn on the phone lock 64 Store an unlocked phone number 65 Call an unlocked phone number 65 Answer a call while using a lock code 65 Change your lock code 65 Turn off the lock code 66 Lock the keypad 66 Activate keyguard 66 Deactivate keyguard 66 Answer a call while keyguard is active 67 Restrict calls 67 Restrict outgoing calls 67 Restrict incoming calls 68 Manage prepaid s…

Text truncated - open the document above for the full version.

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 March 12, 2001 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch PER:47 CFR 22.919 RE:FCC ID: LJPNPC-1NB The Electronic Serial Number (ESN) for each transceiver is unique. The ESN host component is permanently attached to a main circuit board of the alterable. The ESN is isolated from fraudulent contact and tampering. The host component does not contain other information, it is not removable and its electrical connections are not accessible. The host component does contain other information, and the ESN information is encoded using: (1) Multiplication or division by a polynomial. (2) Cyclic coding. (3) The spreading of ESN bits over various non-sequential memory locations. The ESN is factory set and is not alterable, transferable, removable, or otherwise able to be manipulated. Cellular mobile equipment is designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. NOKIA MOBILE PHONES Seppo Salow Product Program Manager, PC Site Oulu NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 March 12, 2001 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID: LJPNPC-1NB complies with OET Bulletin No. 53 as referenced in Section 22.915 of the Commission’s rules and with EIA/TIA/IS-54-B and TIA/EIA-136 Mobile Station - Land Station Compatibility Standards. Compliance was determined by testing appropriate parameters according to standards. Extensive field testing has been performed in several locations in the USA to verify the compatibility against different systems. NOKIA MOBILE PHONES Seppo Salow Product Program Manager, PC Site Oulu

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 September 14, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of MORTON FLOM, P. Eng., and/or M. FLOM ASSOCIATES, INC. to act as our Agent in all FCC matters. This appointment is effective until otherwise notified by us. This is to advice that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, NOKIA MOBILE PHONES LTD Markku Myrskog Director, Product Creation Center, Oulu

March 12, 2001 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: LJPNPC-1NB and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. For and Behalf of: NOKIA MOBILE PHONES Seppo Salow Product Program Manager, PC Site Oulu

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Andy Leimer / Kwok Chan: Please find attached our reply to your correspondence concerning LJPNPC-1NB (EA100744, correspondence reference number 19291). Kind Regards, Kare Oksanen Engineering Manager, Type Approvals Nokia Mobile Phones, PCC Oulu 1. There is a mistake in the test report. The power output ratings mentioned in the correspondence are referring to radiated power output, but the correct readings are 400 mW (26.0 dBm) ERP for AMPS and 917 mW (29.6 dBm) ERP for TDMA. Corresponding conducted power output ratings in the test reports are 25.78 dBm (AMPS) and 27.18 dBm (TDMA). We are sorry for the inconvenience. 2. The reason for this is that the test equipment the lab is using for radiated power measurement is not capable for measuring averaged TDMA bursts. Therefore we have to provide the peak reading for TDMA mode, which is around 2.5 dB higher compared to averaged reading. Conducted power is measured using duty cycle, which takes into account these characteristics of the modulation method. We verified this by using power meter also for measuring radiated power output at the same time and the difference between AMPS and TDMA mode was almost the same than in conducted measurements. However, these records cannot be used in official report. 3. We are aware of the problems caused by positioning the antenna too close of device holder, and we have done our best in positioning the device in such way that these effects are minimized. We use equipment shown in Figure 1 to provide a standard position for all our phones. Applicant: Nokia Mobile Phones FCC ID: LJPNPC-1NB Correspondence Reference Number: 19291 731 Confirmation Number: EA100744 Figure 1. Positioning equipment This equipment is placed into the device holder to ensure the correct positioning of the phone. After positioning is done, this equipment is removed. Positioning procedure is presented in the following figures. Figure 2. Positioning of the phone Figure 3a. Phone positioned into the holder Applicant: Nokia Mobile Phones FCC ID: LJPNPC-1NB Correspondence Reference Number: 19291 731 Confirmation Number: EA100744 Figure 3b. Phone positioned into the holder Internal antenna location is highlighted using yellow color in Figure 4. The distance between back cover and antenna is around 2mm. Figure 4. Antenna position 4. In the carrying case there is a window on the same side where the strap is for screen and upper-most keypad. If positioned other way around, these are covered by the case. If the carrying case is positioned window facing away from the body, it will be sticking out and does not fit very comfortable. Below on figure 5 the carrying case is positioned in such way than what it would approximately be when carrying in the belt window facing away from the body. Figure 5. Carrying case positioned window facing away from the body Applicant: Nokia Mobile Phones FCC ID: LJPNPC-1NB Correspondence Reference Number: 19291 731 Confirmation Number: EA100744

9 Mar 2001 Exhibit 3: External PhotographsFCC ID: LJPNPC-1NB Applicant: Nokia Mobile Phones Copyright © 2001 Nokia Mobile Phones 9 Mar 2001 Exhibit 3: External PhotographsFCC ID: LJPNPC-1NB Applicant: Nokia Mobile Phones Copyright © 2001 Nokia Mobile Phones

MADE IN USA ESN: Code: 0503270BI FCC ID: LJPNPC-1NB CAN: Type: NPC-1NBModel: 3320 FCC ID: LJPNPC-1NB Copyright2001 Nokia Mobile Phones Exhibit 1: Type Label Position Applicant: Nokia Mobile Phones 13 Mar 2001 MADE IN USA ESN: Code: 0503270BI FCC ID: LJPNPC-1NB CAN: Type: NPC-1NBModel: 3320 MADE IN USA ESN: Code: 0503270BI FCC ID: LJPNPC-1NB CAN: Type: NPC-1NBModel: 3320 FCC ID: LJPNPC-1NB Copyright2001 Nokia Mobile Phones Exhibit 1: Type Label “MADE IN USA” Applicant: Nokia Mobile Phones 13 Mar 2001 MADE IN KOREA ESN: Code: 0503270BI FCC ID: LJPNPC-1NB CAN: Type: NPC-1NBModel: 3320 MADE IN KOREA ESN: Code: 0503270BI FCC ID: LJPNPC-1NB CAN: Type: NPC-1NBModel: 3320 FCC ID: LJPNPC-1NB Copyright2001 Nokia Mobile Phones Exhibit 1: Type Label “MADE IN KOREA” Applicant: Nokia Mobile Phones 13 Mar 2001 NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 March 12, 2001 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch COMPLIANCE STATEMENT OF LJPNPC-1NB The compliance statement can be seen in User Guide of LJPNPC-1NB because the size of the handportable LJPNPC-1NB and its identification label are so small that the compliance statement cannot be printed visible enough. NOKIA MOBILE PHONES Seppo Salow Product Program Manager, PC Site Oulu [ 2 ] The wireless phone described in this guide is approved for use in TDMA and AMPS networks. Legal information Part No. 9353219, Issue No. 1 © 2001 Nokia Inc. All rights reserved. Nokia is a registered trademark of Nokia Corporation. Printed in Canada XX/2001 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1999-2001. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this Owner’s Manual was written for Nokia phone NPC-1 and NPW-1. The right to make changes and improvements to any of the products described in this guide without prior notice is reserved. Export Controls This product may also be subject to United States export controls. The United States export laws currently prohibit the export of certain technical data and software into Cuba, Iran, Iraq, Libya, North Korea, Sudan, and Syria, or any national or resident of those countries, or to anyone on the United States Treasury Department’s list of Specially Designated Nationals or the U.S. Commerce Department’s Table of Deny Orders. You agree that you shall not export this product in contravention of United States export laws. FCC/Industry Canada Notice Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. ws.ug.v1.sw0.0.book Page 2 Friday, February 16, 2001 4:30 PM

9 Mar 2001 Exhibit 9: Internal PhotographsFCC ID: LJPNPC-1NB Applicant: Nokia Mobile Phones Copyright © 2001 Nokia Mobile Phones 9 Mar 2001 Exhibit 9: Internal PhotographsFCC ID: LJPNPC-1NB Applicant: Nokia Mobile Phones Copyright © 2001 Nokia Mobile Phones (without shields)

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 March 12, 2001 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road Columbia, MD. 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID: LJPNPC-1NB complies with ANSI/IEEE C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. Compliance was determined by testing appropriate parameters according to standard. NOKIA MOBILE PHONES Seppo Salow Product Program Manager, PC Site Oulu PC Site Oulu Exhibit 11 DTX02388-EN Applicant: Nokia Mobile Phones FCC ID: LJPNPC-1NB Copyright  2001 Nokia Mobile Phones 1 (13) SAR Compliance Test Report Test report no.: DTX02388-EN Date of report: 20-Apr-2001 Number of pages: 21 Contact person: Olli Kautio Responsible test engineer: Pertti Mäkikyrö Testing laboratory: Nokia Mobile Phones Elektroniikkatie 10 P.O. Box 50 FIN-90571 OULU Finland Tel. +358-10-5051 Fax. +358-10-505 7222 Client: Nokia Mobile Phones Elektroniikkatie 10 P.O. Box 50 FIN-90571 OULU Finland Tel. +358-10-5051 Fax. +358-10-505 7222 Tested devices: LJPNPC-1NB CBM-12 Supplement reports: - Testing has been carried out in accordance with: ANSI/IEEE Std C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz ANSI/IEEE Std C95.3-1992 IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at PC Site Oulu Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: 20-Apr-2001 For the contents: Pertti Mäkikyrö Engineering Manager, EMC Miia Nurkkala Test Engineer PC Site Oulu Exhibit 11 DTX02388-EN Applicant: Nokia Mobile Phones FCC ID: LJPNPC-1NB Copyright  2001 Nokia Mobile Phones 2 (13) CONTENTS 1. SUMMARY FOR SAR TEST REPORT ..........................................................................................................................3 1.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION.................................................................................................................. 3 1.1.1 Head Configuration.......................................................................................................................................................... 3 1.1.2 Body Worn Configuration............................................................................................................................................... 3 1.1.3 Measurement Uncertainty ............................................................................................................................................. 3 2. DESCRIPTION OF TESTED DEVICE .............................................................................................................................4 2.1 PICTURE OF PHONE........................................................................................................................................................................... 4 2.2 D ESCRIPTION OF THE ANTENNA......................................................................................................................................................... 4 2.3 B ATTERY OPTIONS............................................................................................................................................................................. 4 2.4 B ODY WORN ACCESSORIES.............................................................................................................................................................. 4 3. TEST CONDITIONS ........................................................................................................................................................5 3.1 ENVIRONMENT.................................................................................................................................................................................. 5 3.2 T EST SIGNAL, FREQUENCIES, AND OUTPUT POWER.......................................................................................................................... 5 4. DESCRIPTION OF THE TEST EQUIPMENT.................................................................................................................5 4.1 SYSTEM ACCURACY VERIFICATION.................................................................................................................................................... 5 4.2 H EAD TISSUE SIMULANT................................................................................................................................................................... 6 4.3 M USCLE TISSUE SIMULANT............................................................................................................................................................... 6 4.4 P HANTOMS........................................................................................................................................................................................ 7 5. DESCRIPTION OF THE TEST PROCEDURE ................................................................................................................8 5.1 TEST POSITIONS................................................................................................................................................................................. 8 5.1.1 Against Phantom Head ..................................................................................................................................................…

Text truncated - open the document above for the full version.

FCC ID: LJPNPC-1NB MFA p0130008, d0130035 Date: March 29, 2001 Submitted: April 23, 2001 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Nokia Mobile Phones Equipment: 3320 FCC ID: LJPNPC-1NB FCC Rules: 22H, 22.901 (d), Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Morton Flom, P. Eng. enclosure(s) cc: Applicant MF/cvr FCC ID: LJPNPC-1NB MFA p0130008, d0130035 LIST OF EXHIBITS (FCCCERTIFICATION(CELLULAR TRANSMITTERS) - REVISED 9/28/98) APPLICANT: Nokia Mobile Phones FCC ID: LJPNPC-1NB BY APPLICANT: 1. LETTER OF AUTHORIZATION 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) LABEL LOCATION OF LABEL COMPLIANCE STATEMENT LOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 5. DOCUMENTATION: 2.1033(c) (3) USER MANUAL (9) TUNE UP INFO (10) SCHEMATIC DIAGRAM (10) CIRCUIT DESCRIPTION BLOCK DIAGRAM PARTS LIST ACTIVE DEVICES 6. ATTESTATION: ESN: Section 22.919 7. ATTESTATION: OET: Section 22.933 BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: LJPNPC-1NB MFA p0130008, d0130035 TRANSMITTER CERTIFICATION of FCC ID: LJPNPC-1NB MODEL: 3320 Serial Numbers of units tested: 235/13949310 and 235/13949323 to FEDERAL COMMUNICATIONS COMMISSION Rule Part(s) 22H, 22.901 (d), Confidentiality UPDATED REPORT: April 20, 2001 ON THE BEHALF OF THE APPLICANT: Nokia Mobile Phones AT THE REQUEST OF: P.O. Kare Oksanen 3/20/2001 Nokia Mobile Phones Elektroniikkatie 10 Fin-90570 Oulu, Finland Attention of: Olli Kautio, Senior Engineering Manager, Testing & Type Approvals [email protected] and/or Kare Oksanen, R&D Type Approvals [email protected] 011 358 105051; FAX: 011 358 10505 7222 SUPERVISED BY: Morton Flom, P. Eng. FCC ID: LJPNPC-1NB MFA p0130008, d0130035 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: LJPNPC-1NB MFA p0130008, d0130035 TABLE OF CONTENTS RULE DESCRIPTION PAGE . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . General Information 6 . Standard Test Conditions and Engineering Practices 7 2.1046(a) Carrier Output Power (Conducted) 8 2.1046(a) R. F. Power Output (Radiated) 10 2.1047(a) Audio Frequency Response 12 2.1047(a) Audio Low Pass Filter (Voice Input) 14 2.1047(b) Modulation Limiting 17 . Measurement Of Maximum Deviation 20 2.1049(c)(1), 22 Emission Masks (Occupied Bandwidth) 23 22.917 Emission Requirements - . Worst Case Modulation & Wideband Data 41 2.1051, 22.917 Spurious Emissions at Antenna Terminals 52 2.1053(a) Field Strength of Spurious Radiation 57 2.1055(a)(1) Frequency Stability (Temperature Variation) 62 2.1055(b)(1) Frequency Stability (Voltage Variation) 65 FCC ID: LJPNPC-1NB MFA p0130008, d0130035 PAGE NO.1of65. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0130035 d) Client: Nokia Mobile Phones Elektroniikkatie 10 Fin-90570 Oulu, Finland e) Identification: 3320 FCC ID: LJPNPC-1NB Description: Single Band, Dual Mode Cellular Telephone f) EUT Condition: Not required unless specified in individual tests. g) Report Date: March 29, 2001 EUT Received: March 20, 2001 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. ACCESSORIES USED DURING TESTING: SPECIMEN # TYPEMANUFACTURERSERIAL NO s00962 EUT Nokia 235/13949310 s00965 EUT Nokia 234/13949323 s00961 HDC-5 Headset Nokia s00966 ACP-7U Charger Nokia s00915 BMC-2 Battery Nokia s00967 BMC-3 Battery Nokia s00914 BMC-3 Battery Nokia s00917 DCV-10 Desk Top Stand…
