LJPNSW-5NYNon-Broadcast Transmitter Held to Ear

Microsoft Corporation

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: Jan 23, 2001
Application Purpose: Original Equipment
Date of Application: Oct 24, 2000
Equipment Note: Non-Broadcast Transmitter Held to Ear
Frequency Range: 1850.04000000 - 1909.92000000
Company: Microsoft Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Guide Nokia 7160 User Guide The wireless phone described in this guide is approved for use in TDMA and AMPS networks. Copyright information Part No. 9352079, Issue No. 1 © 2000 Nokia Mobile Phones. All rights reserved. Printed in Canada 09/2000 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1999. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this Owner’s Manual was written for Nokia phone NSW-5. The right to make changes and improvements to any of the products described in this guide without prior notice is reserved. These commodities are authorized by the U.S. Government for export only to Canada, Mexico, or the United States. They may not be resold, diverted, transferred, or otherwise disposed of in any other country, either in their original form or after being incorporated through an intermediate process into other end-items, without the written approval of the U.S. Department of State. FCC/Industry Canada Notice Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. [ i ] Contents For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Your phone’s label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1. Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 How to contact Nokia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Contacting your service provider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2. Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Attach your battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Charge your battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Removing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Prolonging battery life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 3. About your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Switch the phone on (or off) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 About your phone’s display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 The Start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Indicators and Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Using the keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Using the selection keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Using the Navi TM roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Using the sliding cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Just in case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 [ ii ] 4. Your phone’s menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Browsing the menus via the roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 List of main menu functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 5. Making/receiving calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Making a call using the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Making a call using the phone book . . . . . . . . . . . . . . . . . . . . . . . 20 Making other types of phone calls. . . . . . . . . . . . . . . . . . . . . . . . . 20 Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Rejecting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Last number redial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Calling your voice mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Adjusting the earpiece volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 6. Letters and numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Entering characters via the Navi TM roller . . . . . . . . . . . . . . . . . . . 23 Entering characters via the keypad . . . . . . . . . . . . . . . . . . . . . . . . 23 7. Phone book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Saving names and numbers . . …

Text truncated - open the document above for the full version.

Attestation Statements

Cover Letter(s)

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 September 14, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of MORTON FLOM, P. Eng., and/or M. FLOM ASSOCIATES, INC. to act as our Agent in all FCC matters. This appointment is effective until otherwise notified by us. This is to advice that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, NOKIA MOBILE PHONES LTD Markku Myrskog Director, Product Creation Center, Oulu

Cover Letter(s)

L:\WordDocs\&Letterhead.doc Sincerely yours, Morton Flom, P. Eng.

External Photos

04 Oct 2000 Exhibit 9FCC ID: LJPNSW-5NY Applicant: Nokia Mobile Phones Copyright © 2000 Nokia Mobile Phones 04 Oct 2000 Exhibit 9FCC ID: LJPNSW-5NY Applicant: Nokia Mobile Phones Copyright © 2000 Nokia Mobile Phones 04 Oct 2000 Exhibit 9FCC ID: LJPNSW-5NY Applicant: Nokia Mobile Phones Copyright © 2000 Nokia Mobile Phones 04 Oct 2000 Exhibit 9FCC ID: LJPNSW-5NY Applicant: Nokia Mobile Phones Copyright © 2000 Nokia Mobile Phones 04 Oct 2000 Exhibit 9FCC ID: LJPNSW-5NY Applicant: Nokia Mobile Phones Copyright © 2000 Nokia Mobile Phones

ID Label/Location Info

Type: NSW-5NY CAN: MADE IN USA FCC ID: LJPNSW -5NY Model: 7160 Code: 0502352 ESN: 25315471011 04 Oct 2000 Applicant: Nokia Mobile Phones FCC ID: LJPNSW-5NY Copyright 2000 Nokia Mobile Phones © Label Position Type: NSW-5NY CAN: MADE IN USA FCC ID: LJPNSW-5NY Model: 7160 Code: 0502352 ESN: 25315471011 Type: NSW-5NY CAN: MADE IN USA FCC ID: LJPNSW -5NY Model: 7160 Code: 0502352 ESN: 2531547 1011 04 Oct 2000 Applicant: Nokia Mobile Phones FCC ID: LJPNSW-5NY Copyright 2000 Nokia Mobile Phones © Label Drawing NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 October 4, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch COMPLIANCE STATEMENT OF LJPNSW-5NY The compliance statement can be seen in User Guide of LJPNSW-5NY because the size of the handportable LJPNSW-5NY and its identification label are so small that the compliance statement cannot be printed visible enough. NOKIA MOBILE PHONES Mikko Julku Product Creation Manager, PCC Oulu The wireless phone described in this guide is approved for use in TDMA and AMPS networks. Copyright information Part No. 9352079, Issue No. 1 © 2000 Nokia Mobile Phones. All rights reserved. Printed in Canada 09/2000 Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates. US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1999. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. The information contained in this Owner’s Manual was written for Nokia phone NSW-5. The right to make changes and improvements to any of the products described in this guide without prior notice is reserved. These commodities are authorized by the U.S. Government for export only to Canada, Mexico, or the United States. They may not be resold, diverted, transferred, or otherwise disposed of in any other country, either in their original form or after being incorporated through an intermediate process into other end-items, without the written approval of the U.S. Department of State. FCC/Industry Canada Notice Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

Internal Photos

RF Exposure Info

Appendix 1 pages 1 - 9 AUTOMATED E-FIELD SCANNING SYSTEM FOR DOSIMETRIC ASSESSMENTS Appendix 2 pages 1 - 8 PROBE ET3DV4 SN: 1105 Appendix 3 pages 1 - 5 DASY- DOSIMETRIC ASSESSMENT SYSTEM CALIBRATION REPORT DATA ACQUISITION ELECTRONICS Appendix 4 page 1 INDUSTRIAL ROBOT AND CONTROL UNIT Appendix 5 pages 1 - 3 BRAIN TISSUE SIMULATING LIQUIDS Brain Tissue Simulating Liquids Preparation of the Liquids Requirements: •Scale •Magneto Stirrer: Heating Plate, Magnetos (recommended). •HP 85070A Dielectric Probe Kit (200MHz to 20GHz) plus mounting device and Network Analyser Canisters or "closed" jars to store the liquid (recommended) Preparation: 1.) Heat the water to about 40" Celsius. 2.) Add salt and bactericide to water while stirring and wait until salt is dissolved. 3.) Add about one third of the sugar. Keep stirring. Wait until sugar is dissolved. Add the second third and when dissolved add the final third. The liquid gains volume and thickens slightly. 4.) Keep stirring at maximum speed possible. 5.) When all the sugar is dissolved, add the HEC. HEC is highly hygroscopic. It forms lumps when added to the liquid. Either "help" the magneto stirrer by stirring from outside or dissolve all of the BEC first in another jar with a little bit of liquid using another stirrer. Add it then to the rest of the solution. Once HEC is added the liquid thickens considerably. 6.) During the whole process watch the temperature to prevent water evaporation. 7.) Once the liquid clears up pour it into canisters. Let it stand for a couple of hours before using it. III Use •When in the item (phantom models), monitor water evaporation. •To minimize water evaporation cover the phantoms when not used. Do not store the liquid in the phantoms, rather store it in closed canisters. •In case water has evaporated, you can add (warm) water to the liquid. Be sure that after stirring it is completely homogeneous. •The liquid can be used for at least 3 months. After longer periods bacteria might grow that are resistant against the bactericide. Recipe 900 MHz: Water40.1% Sugar58.0% Salt (NaCI)0.8% HEC (Hydroxyethylcellulosis)1.0% Preservative Substance 900 MHz: ε r = 42.5 ± 5% and σ = 0.85 ± 10% mho/m Recipe 1800 MHz: Water45.0% Sugar53.9% HEC (Hydroxyethylcellulosis)1.0% Preservative Substance 1800 MHz: ε r = 41.0 ± 5% and σ = 1.65 ± 10% mho/m Appendix 6 pages 1 - 2 GENERIC TWIN PHANTOM Version 3. Appendix 7 pages 1 - 11 PROBE CALIBRATION Prof. Dr. Niels Kuster Tel. +41 1 632 2737, Fax: +41 1 632 105 Institut für Feldtheorie und Höchstfrequenztechnik ETH Zürich CH-8092 Zürich Mr. Ilkka Pankinaho Nokia Mobile Phones NMP/R&D P.O. Box 86 FIN-24101 Salo Finland Zurich, 2 December 1995 Mobile Phone Certification Dear Ilkka, In mid-September, we promised to send preprints of the paper which describes the calibration procedure we developed during the last months. We would appreciate any suggestions and comments, since a thorough calibration is fundamental to enforce the safety limits. In addition, we would like to take this opportunity to inform you about the newest developments towards finalizing the scientific and technical conditions for a type approval. Uncertainties of Measurements: In connection with the calibration, we performed an analysis which assessed the total uncertainty of SAR measurements in shell phan- toms. The results are promising. The total uncertainty can be kept below +20% at 900 MHz. A project to further reduce these uncertainties and to develop a standard calibration procedure has now been submitted to the EU program "Standards, Measurements & Testing." Phantom: Another open issue is the verification that the absorption in homogeneous human phantoms represents well the actual spatial peak absorption in the user. In one study, in close cooperation with the research center of German Telekom, absorp- tion induced in three numerical and three experimental phantoms were compared for the mobile communications frequency at 900 MHz. The various phantoms and our findings are briefly described in the attachment. Requirements of a Certification Procedure: In connection with the recent WTR workshop in Rome, we defined the scientific pre-condition necessary to implement a certification procedure. The manuscript also reflects the requirements which were discussed within CENELEC's TC111 Working group on Mobile Telecommunications Equipment. Please find the manuscript in the attachment as well. DASY: Schmid & Partner Engineering AG (SPEAG) has started the development of DASY3. Besides a general revision and extension of the DASY2 hardware and soft- ware, the main objectives Of DASY3 are improved spatial resolution, improved precision and improved time efficiency. DASY3 will be largely compatible with DASY2, although some of the new functions will not be fully usable without minor hardware updates. SPEAG will keep you informed with respect to these develop- ments. The temperature probes which have been developed for the previously mentioned calibration study will soon be commercially available. The prototype showed a sensitivity of about <0.1 mK/s. It might be interesting to all DASY users that this probe will be fully compatible with DASY2, DASY3 and DASYmini. The active volume of about 1 mm3 is ideal for those laboratories which plan to do calibration or SAR measurements in very small structures. Part of the industry was interested in a video of DASY2 to dernonstrate the test pro- cedure to their customers. Since we already had a video for other occasions, we adapted it to these requests and now have copies available. If you are interested, please return the enclosed form by mail or fax. If you want copies of any of the publications listed on that form, we would be happy to send you these copies as well. If you have any questions regarding our activities in the area of mobile phone certification, please do not hesitate to contact me. For questions regarding the dosimetric assessment system DASY, I suggest you contact SPEAG d…

Text truncated - open the document above for the full version.

RF Exposure Info

NOKIA MOBILE PHONES 13 Appendix 9 pages 2 VERIFY WITH DIPOLE VALIDATION KITS NOKIA MOBILE PHONES 14 NOKIA MOBILE PHONES 15 NOKIA MOBILE PHONES 16 Appendix 10 pages 1 - 27 SAR MEASUREMENT RESULTS NOKIA MOBILE PHONES 17 NOKIA MOBILE PHONES 18 NOKIA MOBILE PHONES 19 NOKIA MOBILE PHONES 20 NOKIA MOBILE PHONES 21 NOKIA MOBILE PHONES 22 NOKIA MOBILE PHONES 23 NOKIA MOBILE PHONES 24 NOKIA MOBILE PHONES 25 NOKIA MOBILE PHONES 26 NOKIA MOBILE PHONES 27 NOKIA MOBILE PHONES 28 NOKIA MOBILE PHONES 29 NOKIA MOBILE PHONES 30 NOKIA MOBILE PHONES 31 NOKIA MOBILE PHONES 32 NOKIA MOBILE PHONES 33 NOKIA MOBILE PHONES 34 NOKIA MOBILE PHONES 35 NOKIA MOBILE PHONES 36 NOKIA MOBILE PHONES 37 NOKIA MOBILE PHONES 38 NOKIA MOBILE PHONES 39 NOKIA MOBILE PHONES 40 NOKIA MOBILE PHONES 41 NOKIA MOBILE PHONES 42 NOKIA MOBILE PHONES 43

RF Exposure Info

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 Oulu FINLAND Tel. +358 10 5051 Fax. +358 10 505 7222 October 4, 2000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road Columbia, MD. 21046 Attention: Equipment Authorization Branch We hereby certify that the transceiver FCC ID: LJPNSW-5NY complies with ANSI/IEEE C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. Compliance was determined by testing appropriate parameters according to standard. NOKIA MOBILE PHONES Mikko Julku Product Creation Manager, PCC Oulu NOKIA MOBILE PHONES 1 October 6th, 2000 P.O. Box 86 Joensuunkatu 7E FIN-24101 SALO Finland FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Branch 7435 Oaklands Mills Road Columbia, MD 21046 SAR TEST REPORT of Nokia 7160 Gentlemen, Please find attached SAR test report of FCC ID: LJPNSW-5NY For and on behalf of Nokia Mobile Phones Ltd. Respectfully, Sami Savela Senior RF Design Engineer Responsible for NMP SAR measurements NOKIA MOBILE PHONES 2 ContentsPage 1.Description of the measurement3 2.Description of calibration by manufacturer4 3.List of standards4 4.Device list5 5.Equipment under test6 5.1Verification and results6 5.2Specification of Liquid6 5.3Specification of position with phone against7 generic twin phantom 5.4The phone position against generic twin 8 phantom 5.5Results of SAR for 1g 9 5.6Evaluation of SAR in body worn configurations10 5.6.1Introduction10 5.6.2Test method10 5.6.3Results12 5.6.4Summary12 Appendix 1 Appendix 2 Appendix 3 Appendix 4 Appendix 5 Appendix 6 Appendix 7 Appendix 8 Appendix 9 Appendix 10 NOKIA MOBILE PHONES 3 1.Description of the measurement These measurements were done by E-field scanning system for dosimetric assessments. It is robot-based system which allows automated E-field scanning in tissue simulating solutions. The measurements are based on the induced specific absorption rate (SAR) definition of relevant ANSI / IEEE standards. The dosimetric assessment system of Nokia Mobile Phones is manufactured by Prof. Niels Kuster at ETH (Schmid & Partner Engineering AG) in Switzerland, Europe. The method used to determine the 1 gram average value of SAR is: Initially a coarse scan is performed over the whole area on a 20 x 20 mm grid. From this coarse scan, the location at which the maximum value is measured is used as the centre for a second, more detailed scan. This second scan is based on a 3 dimensional grid of 4 x 4 x 7 points on a grid of 10 mm for 900 MHz and 5 x 5 x 7 points on a grid of 8 mm for 1800 MHz band. The average SAR values are computed using the 3D spline inter-polation algorithm. The 3D spline is composed on three one-dimensional splines with the “Not a knot” condition in the x, y and z directions (1), (2). The volume is integrated with the trapezoidal algorithm. 1000 points (10x10x10) are interpolated to calculate the average. All neighbouring volumes are evaluated until no neighbouring volume with a higher average is found. (1) W. Gander, Computermathematik, Birkhauser, Basel, 1992 (2) W. H. Press, S. A Teukolsky, W. T. Vettering and B. P. Flannery, Numerical Recipes in C, The Art of Scientific Computing, second edition, Cambridge University Press, 1992 NOKIA MOBILE PHONES 4 2.Description of calibration by manufacturer The calibration of data acquisition electronics and probe was done by the manufacturer. (Appendix 3 and 7) - the data acquisition unit is calibrated and tested using a FLUKE 702 Process Calibrator - measurement uncertainty is less than ± 20% for various tissues simulating solutions and frequencies: - these calibration parameters were measured using a temperature probe developed by manufacturer - description of the probe calibration and examples of the evaluation are enclosed in Appendix 7 3.List of standards ANSI/IEEE Std C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz ANSI/IEEE Std C95.3-1992 IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave NOKIA MOBILE PHONES 5 4.Device list: Automated E-field scanning system for dosimetric assessments System. Calibration due June 2001. Technical data (Appendix 1) Probe ET3DV4, SN: 1105, Recalibrated due June 2001 Technical data (Appendix 2) DASY-dosimetric assessment system, DAE V2, SN: 213, Calibration due June 2001 (Appendix 3) Industrial robot and Control unit, type STÄUBLI CS7 RX 90(CR) NO:595148-01, Technical data (Appendix 4) Generic Twin Phantom Version 3 (Appendix 6). PC COMPAQ 466 laser printer QMS magicolor plus Devices for preparation of the brain tissue simulating liquids -General laboratory equipment for preparation of liquids -Magnetic stirrer with heating plate IKA RET CV, SN:792708 -Scale Mettler Doleto, SN: 2114177678 HP 85070A Dielectric probe system - network analyzer HP 8753B, SN:2716U00762, Calibration due May 2001 - cables - probe stand - dielectric probe kit NO: US33020242 - PC AST PREMMIA 4/66 d - HP-IB 82335B (interface and software) Dipole Validation kit for 900 MHz band, Schmid & Partner Engineering AG, Typ: D900V2, SN: 003, Recalibrated/Verification due June 2002 and Dipole Validation kit for 1800 MHz band, Schmid & Partner Engineering AG, Typ: D1800V2, SN: 207, Recalibrated/Verification due June 2002 - signal generator ROHDE & SCHWARZ, 1038.6002.03 , Calibration due June 2002 - power meter, ROHDE & SCHWARZ, 857.8008.02, Calibration due December 2001 - amplifier ZHL-42 (SMA), 022488-RM:4152 NOKIA MOBILE PHONES 6 5.Equipment under test Unit: NOKIA 7160 FCC-ID: LJPNSW-5NY 5.1Verification and results Validation of the measurement system was made before measurement using the Validation kit. Appendix: 8 and 9. This validation measurement makes sure that the repeatability of SAR measurement value with careful positioning is better than 10 %. On 900 MHz error was < 5 % compared to…

Text truncated - open the document above for the full version.

RF Exposure Info

December 7th, 2000 P.O. Box 86 Joensuunkatu 7E FIN-24101 SALO Finland FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Branch 7435 Oaklands Mills Road Columbia, MD 21046 SAR TEST REPORT of Body Worn Accessory for LJPNSW-5NY Gentlemen, Please find attached SAR test report of FCC ID: LJPNSW-5NY For and on behalf of Nokia Mobile Phones Ltd. Respectfully, Sami Savela Senior RF Design Engineer Responsible for NMP SAR measurements BODY SAR REPORT2 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela Evaluation of SAR in Body Worn Configurations LJPNSW-5NY. Introduction The tests described in this report have been performed in order to demonstrate that the equipment under test complies with the FCC requirements of the SAR specifications. SAR was measured when phone was placed with body worn accessory against the Flat Phantom. Carrying Case accessory CSL-5 (Picture 1) was tested. The measurement test equipment and setup were the same as used and referred in SAR TEST REPORT of LJPNSW-5NY. Picture 1. Carrying Case CSL-5 Test method Measurements were done with the Dasy 2 dosimetric assessment system DAE V2, SN: 213 and with the generic Twin Phantom version 3 from Schmid & Partner Engineering Ag. The phone was positioned in body worn accessory against Flat Phantom. Two different battery options were first evaluated. There was no difference between Thinnest Li-polymer BPS-1 and Thickest BLS-4. Separation distance for CSL-5 is presented in picture 2. The point of maximum SAR was sought. Then the SAR was measured with a 3-dimensional cube measurement. Picture 2. Separation distance with Carrying Case CSL-5 BODY SAR REPORT3 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela The maximum output power level in lowest, middle and highest channel was used (824, 836 and 849 MHz on AMPS mode. 1850, 1880 and 1910 MHz on TDMA PCS mode). Brain equivalent liquid was used. Permittivity and conductivity of muscle tissue simulating liquids at 1880 MHz is shown in table 1 and at 836 MHz in table 2. FCC recommendation is from http://www.fcc.gov/fcc-bin-dielec.sh PermittivityConductivity FCC recommendation54.3321081.436068 Used brain tissue41.01.74 Table 1. Properties of liquids simulating muscle tissue @ 1880 MHz The used brain tissue has higher conductivity and lower permittivity than the liquid FCC recommends to be used. Thus all SAR values are overestimated. PermittivityConductivity FCC recommendation56.1113360.946714 Used brain tissue44.60.80 Table 2. Properties of liquids simulating muscle tissue @ 836 MHz FCC recommended conductivity would lead to higher SAR results than the liquid used. On the other hand, the used permittivity compensates difference caused by the conductivity. When the measured SAR values are multiplied by factor 1.18, which is the difference between the conductivity values, the maximum body SAR result changes from 0,55 to 0,65. This approach leads to overestimate of SAR. Results Graphical presentations of test positions with SAR values are presented in the end of this report. Analog mode AMPS, Body worn, Carry Case CSL-5 meas. nr: Phone positionFrequency MHz / channel Power dBm SAR (1g)[mW/g] 1 Body Worn, against Flat Phantom 824 / 99124.50.38 2 Body Worn, against Flat Phantom 836 / 38324.60.48 3 Body Worn, against Flat Phantom 849 / 79924.60.55 FCC ID: LJPNSW-5NY MEASURED: 2000-12-7/NMP FCC limit1.60[mW/g] (ANSI/IEEE) BODY SAR REPORT4 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela Digital TDMA (Cellular), Body worn, Carry Case CSL-5 meas. nr: Phone positionFrequency MHz / channel Power dBm SAR (1g)[mW/g] 4 Body Worn, against Flat Phantom 824 / 99126.90.23 5 Body Worn, against Flat Phantom 836 / 38327.00.27 6 Body Worn, against Flat Phantom 849 / 79926.80.30 FCC ID: LJPNSW-5NY MEASURED: 2000-12-7/NMP FCC limit1.60[mW/g] (ANSI/IEEE) Digital TDMA (PCS), Body worn, Carry Case CSL-5 meas. nr: Phone positionFrequency MHz / channel Power dBm SAR (1g)[mW/g] 7 Body Worn, against Flat Phantom 1850 / 225.20.26 8 Body Worn, against Flat Phantom 1880 / 100025.30.28 9 Body Worn, against Flat Phantom 1910 / 199825.30.26 FCC ID: LJPNSW-5NY MEASURED: 2000-12-7/NMP FCC limit1.60[mW/g] (ANSI/IEEE) Summary The SAR values found for the portable cellular phone (FCC ID: LJPNSW-5NY) are below the maximum recommended levels of 1.6 mW/g. BODY SAR REPORT5 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT6 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT7 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT8 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT9 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT10 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT11 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT12 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela BODY SAR REPORT13 (13) NOKIA MOBILE PHONES2000-12-7th Sami Savela

RF Exposure Info

NOKIA MOBILE PHONES Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 10 5051 Fax +358 10 505 7222 December 8, 2000 Federal Communications Commission Authorization & Evaluation Division, 7435 Oakland Mills Road…
