LJPRM-58GSM850/1800/1900 Cellular Telephone w/BT

Nokia 6682 User Guide 9237583 ISSUE 1 EN DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product RM-58 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/ Part No. 9237583Copyright © 2005 Nokia. All rights reserved.Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.Nokia, Nokia Connecting People, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.Nokia tune is a sound mark of Nokia Corporation.This product includes software licensed from Symbian Software Ltd (c) 1998-2005. Symbian and Symbian OS are trademarks of Symbian Ltd.Java™ and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. Stac ®, LZS ®, ©1996, Stac, Inc., ©1994-1996 Microsoft Corporation. Includes one or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425. Other patents pending.Hi/fn ®, LZS ®,©1988-98, Hi/fn. Includes one or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425. Other patents pending.Part of the software in this product is © Copyright ANT Ltd. 1998. All rights reserved.US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2005. Tegic Communications, Inc. All rights reserved. This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and non-commercial use in connection with information which has been encoded in compliance with the MPEG-4 Vi sual Standard by a consumer engaged in a personal and non-commercial activity and (ii) for use in connection with MPEG-4 video provided by a lic ensed video provider. No license is granted or shall be implied for any other use. Additional information including that relating to promotional, internal and commercial uses may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.The information contained in this user guide was written for the Nokia 6682 product. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequentia l or indirect damages howsoever caused. The contents of this document are provided ‘a s is’. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior noticeThe availability of particular products ma y vary by region. Please check with the Nokia dealer nearest to you.Export ControlsThis device may contain commodities, tec hnology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.FCC INDUSTRY CANADA NOTICEYour device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. For your safety...........................................1Your phone .................................................5Insert the SIM or USIM card and battery ....................... 5Charge the battery ................................................................ 6Headset..................................................................................... 6The wrist strap........................................................................ 6Keypad lock (keyguard)........................................................ 7Standby mode shortcuts...................................................... 7Tips for efficient use ............................................................. 8Help ........................................................................................... 8Access alternate formats..................................................... 8Register your phone.............................................................. 8Copyright protection ............................................................ 8Keys and parts ........................................................................ 9Switch the phone on ..........................................................10About the display ................................................................10First settings .........................................................................10Configure MMS and Internet settings...........................11Essential indicators .............................................................11Clock........................................................................................12 Clock settings................................................................12World clock....................................................................13 Volume and loudspeaker control ....................................13Insert the memory card .....................................................13Eject the memory card.......................................................14 File manager ........................................................................ 14 View memory consumpt…

Text truncated - open the document above for the full version.

NOKIA CORPORATION Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 December 16, 2004 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: LJPRM-58 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Jyrki Hietaniemi Product Program Manager Mobile Enhancements, Oulu NOKIA CORPORATION Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 December 16, 2004 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 45 days short term confidential treatment of some of the information accompanying this application of FCC ID: LJPRM-58 as outlined below: - Exhibit 3: External photos - Exhibit 7: Test setup photos - Exhibit 8: User's manual - Exhibit 9: Internal photos These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. NOKIA CORPORATION Jyrki Hietaniemi Product Program Manager Mobile Enhancements, Oulu

11 Dec 2005 External Photographs FCC ID: LJPRM-58 Exhibit 3 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved. 11 Dec 2005 External Photographs FCC ID: LJPRM-58 Exhibit 3 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved. 11 Dec 2005 External Photographs FCC ID: LJPRM-58 Exhibit 3 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved.

Label Location Exhibit 1 Applicant: Nokia Corporation FCC ID: LJPRM- IC: 661E-RM 58 58 Copyright2005 Nokia. All Rights Reserved. 12 Jan 2005 Type:RM-58 Model:XXXX 168 MADE IN CHINA CNC ID: XXXXXX FCC ID: LJPRM-58 IC: 661E-RM58 123456/78/123456/0 Code:1234567MYDDFL Label Exhibit 1 Applicant: Nokia Corporation FCC ID: LJPRM- IC: 661E-RM 58 58 Copyright2005 Nokia. All Rights Reserved. 12 Jan 2005 Type:RM-58 Model:XXXX 168 MADE IN CHINA FCC ID: LJPRM-58 IC: 661E-RM58 123456/78/123456/0 Code:1234567MYDDFL AWS Part #:xxxxxxxxxxx Type:RM-58 Model:XXXX 168 MADE IN CHINA CNC ID: XXXXXX FCC ID: LJPRM-58 IC: 661E-RM58 123456/78/123456/0 Code:1234567MYDDFL NOKIA CORPORATION Elektroniikkatie 10 FIN-90570 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 47222 December 16, 2004 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch COMPLIANCE STATEMENT OF LJPRM-58 The compliance statement can be seen in User Guide of LJPRM-58 because the size of the handportable LJPRM-58 and its identification label are so small that the compliance statement cannot be printed visible enough. NOKIA CORPORATION Jyrki Hietaniemi Product Program Manager Mobile Enhancements, Oulu

11 Jan 2005 Internal Photographs FCC ID: LJPRM-58 Exhibit 9 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved. 11 Jan 2005 Internal Photographs FCC ID: LJPRM-58 Exhibit 9 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved. 11 Jan 2005 Internal Photographs FCC ID: LJPRM-58 Exhibit 9 IC: 661E-RM58 Applicant: Nokia Corporation Copyright © 2005 Nokia. All rights reserved.

DOCUMENT NAME: 1 (10) Tre_FCC_0503_02.doc TCC Tampere EMC Test Report For RM-58 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 2 (10) Tre_FCC_0503_02.doc TCC Tampere CONTENTS 1 CUSTOMER INFORMATION....................................................................................................................3 2 EUT AND ACCESSORY INFORMATION.................................................................................................4 2.1 EUT description..................................................................................................................................4 2.2 EUT and accessories.........................................................................................................................4 3 STANDARDS AND MEASUREMENT METHODS....................................................................................5 4 TEST RESULTS........................................................................................................................................6 4.1 AC powerline conducted emissions...................................................................................................6 4.1.1 Limit............................................................................................................................................6 4.1.2 EUT operation mode...................................................................................................................6 4.1.3 Emission measurement data......................................................................................................7 4.2 Radiated emissions............................................................................................................................8 4.2.1 Test method and level, 30 MHz – 8500 MHz.............................................................................8 4.2.2 EUT operation mode...................................................................................................................9 4.2.3 Emission measurement data, 30 MHz – 8500 MHz...................................................................9 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 3 (10) Tre_FCC_0503_02.doc TCC Tampere 1 CUSTOMER INFORMATION Test laboratory: FCC registration number IC file number: TCC Tampere Nokia Oyj Sinitaival 5 FIN-33720 TAMPERE Tel. +358 7180 08000 Fax. +358 7180 46800 94436 (June 14, 2002) IC 3608 (March 5, 2003) Client: Nokia Corporation P.O. Box 300 Yrttipellontie 6 FIN-90230 OULU, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 58300 Contact person: Jorma Hanni Receipt of EUT: 30.12.2004 Date of testing: 5-10.1.2005 Date of report: 18.1.2005 The tests listed in this report have been done to demonstrate compliance with the applicable requirements in FCC rules Part 15 and IC standard ICES-003. Contents approved: The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 4 (10) Tre_FCC_0503_02.doc TCC Tampere 2 EUT AND ACCESSORY INFORMATION 2.1 EUT description The EUT is a mobile phone EUT is a dual triple band (GSM 850/1800/1900 EGPRS) mobile phone. The highest internal frequency of the EUT is 3759.6 MHz 2.2 EUT and accessories The table below lists all EUTs and accessories used in the tests. Later in this test report, only numbers in the last column are used to refer to the devices in each test. Name Type S/N Number EUT Mobile phone RM-58 004400521659605 40150 Accessories Battery BL-5C - 40123 Charger ACP-12 - 40121 USB cable DKU-2 - 40144 Digital camera DS-7 7102516 40076 Printer HP deskjet 1600CC3540A USB8302546 40077 Laptop PC LATITUDE CP M233XT 0009321C-12800-8A5- 2913 40078 Laptop charger PA-2 00085391 40080 Laptop PC LATITUDE D600 0009321C-12800-8A5- 2913 40085 Laptop charger AA22850 00085391 40086 Parallel cable for printer - - 40087 Serial cable for camera - - 40088 Note! Phone HW ID is 0721 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 5 (10) Tre_FCC_0503_02.doc TCC Tampere SUMMARY OF TEST RESULTS Section in CFR 47 Section in ICES-003 Result 15.107,a 5.3 AC powerline conducted emissions PASS 15.109,a 5.5 Radiated emissions PASS 3 STANDARDS AND MEASUREMENT METHODS The tests were performed in guidance of CFR 47 Part 15 Subpart B, ANSI C63.4 (2001), ICES-003 and CISPR 22. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method". The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 6 (10) Tre_FCC_0503_02.doc TCC Tampere 4 TEST RESULTS 4.1 AC powerline conducted emissions EUT 40150 Accessories 40121, 40123, 40144, 40076, 40077, 40078, 40080, 40085, 40086, 40087, 40088 Temp, Humidity, Air Pressure 19ºC49 % RH 986 mbar Date of measurement 5.1.2005 FCC rule part §15.107 ICES-003 section 5.3 Measured by Jari Jantunen Result PASS 4.1.1 Limit CISPR 22 Class B limit Frequency band (MHz) Quasi-peak limit (dBμV) Average limit (dBμV) 0.15 – 0.5 66 – 56 56 – 46 0.5 – 5 56 46 5 – 30 60 …

Text truncated - open the document above for the full version.

DOCUMENT NAME: 1 (10) Tre_FCC_0503_03.doc TCC Tampere EMC Test Report For RM-58 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 2 (10) Tre_FCC_0503_03.doc TCC Tampere CONTENTS 1 CUSTOMER INFORMATION....................................................................................................................3 2 EUT AND ACCESSORY INFORMATION.................................................................................................4 2.1 EUT description..................................................................................................................................4 2.2 EUT and accessories.........................................................................................................................4 3 STANDARDS AND MEASUREMENT METHODS....................................................................................5 4 TEST RESULTS........................................................................................................................................6 4.1 AC powerline conducted emissions...................................................................................................6 4.1.1 Limit............................................................................................................................................6 4.1.2 EUT operation mode...................................................................................................................6 4.1.3 Emission measurement data......................................................................................................7 4.2 Radiated emissions............................................................................................................................8 4.2.1 Test method and level, 30 MHz – 8500 MHz.............................................................................8 4.2.2 EUT operation mode...................................................................................................................9 4.2.3 Emission measurement data, 30 MHz – 8500 MHz...................................................................9 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 3 (10) Tre_FCC_0503_03.doc TCC Tampere 1 CUSTOMER INFORMATION Test laboratory: FCC registration number IC file number: TCC Tampere Nokia Oyj Sinitaival 5 FIN-33720 TAMPERE Tel. +358 7180 08000 Fax. +358 7180 46800 94436 (June 14, 2002) IC 3608 (March 5, 2003) Client: Nokia Corporation P.O. Box 300 Yrttipellontie 6 FIN-90230 OULU, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 58300 Contact person: Jorma Hanni Receipt of EUT: 30.12.2004 Date of testing: 5-10.1.2005 Date of report: 18.1.2005 The tests listed in this report have been done to demonstrate compliance with the applicable requirements in FCC rules Part 15 and IC standard ICES-003. Contents approved: The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 4 (10) Tre_FCC_0503_03.doc TCC Tampere 2 EUT AND ACCESSORY INFORMATION 2.1 EUT description The EUT is a mobile phone EUT is a dual triple band (GSM 850/1800/1900 EGPRS) mobile phone. The highest internal frequency of the EUT is 3759.6 MHz. 2.2 EUT and accessories The table below lists all EUTs and accessories used in the tests. Later in this test report, only numbers in the last column are used to refer to the devices in each test. Name Type S/N Number EUT Mobile phone RM-58 004400521659605 40150 Accessories Battery BL-5C - 40123 Charger ACP-12 - 40121 USB cable DKU-2 - 40144 Digital camera DS-7 7102516 40076 Printer HP deskjet 1600CC3540A USB8302546 40077 Laptop PC LATITUDE CP M233XT 0009321C-12800-8A5- 2913 40078 Laptop charger PA-2 00085391 40080 Laptop PC LATITUDE D600 0009321C-12800-8A5- 2913 40085 Laptop charger AA22850 00085391 40086 Parallel cable for printer - - 40087 Serial cable for camera - - 40088 Note! Phone HW ID is 0721 The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 5 (10) Tre_FCC_0503_03.doc TCC Tampere SUMMARY OF TEST RESULTS Section in CFR 47 Section in ICES-003 Result 15.107,a 5.3 AC powerline conducted emissions PASS 15.109,a 5.5 Radiated emissions PASS 3 STANDARDS AND MEASUREMENT METHODS The tests were performed in guidance of CFR 47 Part 15 Subpart B, ANSI C63.4 (2001), ICES-003 and CISPR 22. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method". The test results are valid for the tested unit(s) only. This report shall not be reproduced except in full, without the written permission of the testing laboratory. TCC Tampere Box 68 FIN-33721 TAMPERE FINLAND Tel. +358 7180 08000 Fax. +358 7180 46880 DOCUMENT NAME: 6 (10) Tre_FCC_0503_03.doc TCC Tampere 4 TEST RESULTS 4.1 AC powerline conducted emissions EUT 40150 Accessories 40121, 40123, 40144, 40076, 40077, 40078, 40080, 40085, 40086, 40087, 40088 Temp, Humidity, Air Pressure 19ºC49 % RH 986 mbar Date of measurement 5.1.2005 FCC rule part §15.107 ICES-003 section 5.3 Measured by Jari Jantunen Result PASS 4.1.1 Limit CISPR 22 Class B limit Frequency band (MHz) Quasi-peak limit (dBμV) Average limit (dBμV) 0.15 – 0.5 66 – 56 56 – 46 0.5 – 5 56 46 5 – 30 60…

Text truncated - open the document above for the full version.

FCC ID: LJPRM-58 IC: 661E-RM58 1 (2) TCC Tampere EUT test setup Picture 1 AC powerline conducted emissions Picture 2 Radiated emissions TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880
