tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 email: [email protected] Compliance Certification Services 561F Monterey Road Morgan Hill, CA 95037 Attention: Mike Kuo Re: Request to withhold portions of certification application from public view FCC Rule Part: 0.459 Applicant: Alvarion Ltd. FCC ID: LKT-ASU-900 Dear Mike, On behalf of my client Alvarion Ltd. I request the following documents be withheld from public view: Schematics Block diagram Theory of operation Alvarion has invested considerable resources in the design and execution of this product and as such, other manufacturers would be afforded an unfair competitive advantage were the referenced documents to be made easily available. If you have questions or need further information, please contact the undersigned. Sincerely, THOMAS N COKENIAS Agent for Alvarion Ltd.

Delivered-To: trephonc-tncokenias:[email protected] From: Mike Kuo <[email protected]> To: "Tom Cokenias (E-mail)" <[email protected]> Subject: FW: Alvarion Ltd., FCC ID:LKT-ASU-900, AN03T2905 Date: Tue, 17 Jun 2003 12:06:38 -0700 -----Original Message----- From: CERTADM Sent: Tuesday, June 17, 2003 12:05 PM To: '[email protected]' Subject: Alvarion Ltd., FCC ID:LKT-ASU-900, AN03T2905 Notice_content ------------- Question #1: The theory of operation did not provide enough technical information. Per the test report, this device is Hybrid system which consists of DTS and Frequency hopping functions. Please provide technical information to address how these two functions are used. ANS 1 Attached is an expanded theory of operation. The description references FCC ID LKT-ASU-900 or FCC ID LKT-IF-900, depending on which product is being described. Question #2: Per the test report and user manual, this 900MHz may be used with 2.4GHz radio ( FCC ID:LKT-IF-24.) and configuration both radios as Cell Extender. Please address the co-location issue during the installation. ANS 2 The updated manuals will include the following wording; Manual changes to CX (AU-I version) Page 2-3 changed to: The higher the placement of the antennas, the better the achievable link quality. (Locate the antennas at least 20 cm (8 in.) away from each other or any other antenna.) Page 2-8 changed to: Installing the 900 MHz Antenna Locate the 900 MHz antenna at least 20 cm (8 in.) away from the 2.4 GHz SU antenna or any other antenna. Refer to the installation instructions included in the antenna kit for proper mounting guidelines. Use only the antennas stated in Table 2-2 of this manual. Page 2-3 of the CX (AU-IF version for FCC ID: LKT-IF-900) The higher the placement of the antennas, the better the achievable link quality. (Locate the antennas at least 20 cm (8 in.) away from each other or any other antenna). Question #3: The transmitter cannot coordinate its hopping sequence with the hopping sequence of other transmitters, or vice versa, for the purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Provide a description on how the device complies with this rule. ANS 3 The requirements for hybrid DTS radios are that the psd is 8dBm or less when hop is stopped, and that dwell time is limited per 15.247, however, the updated technical description describes in some detail how the hopping function is employed. Question #4: The system shall hop to channel frequencies that are selected at the system hopping rate from a pseudorandom ordered list of hopping frequencies. Indicate how the pseudorandom hopping sequence is derived. Provide a list of channel frequencies and a sample of a few sequences. ANS 4 The requirements for hybrid DTS radios are that the psd is 8dBm or less when hop is stopped, and that dwell time is limited per 15.247, however, the updated technical description describes in some detail how the hopping function is employed. Question #5: Each frequency must be used equally on the average by each transmitter. Each new transmission cannot start on the same point in a sequence(except for voice systems.) Some transmissions may need only a few frequency hops to be completed and If the transmission started on the same frequency each time, this frequency would be used more than the others if many short transmissions were sent. Therefore, Describe where the next transmission starts when a sequence is not completed in a previous message. ANS 5 The requirements for hybrid DTS radios are that the psd is 8dBm or less when hop is stopped, and that dwell time is limited per 15.247, however, the updated technical description describes in some detail how the hopping function is employed. Question #6:Section 15.247(a)1 indicates that the system receivers shall have input bandwidths that match the hopping channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization with the transmitted signals. Please explain how the device complies with this rule when a packet is repeated or when multiple packets are sent. What is the receiver input bandwidth? How does the receiver shift frequencies and determine which frequency to shift to in order to synchronize with this transmitter? ANS 6 The requirements for hybrid DTS radios are that the psd is 8dBm or less when hop is stopped, and that dwell time is limited per 15.247, however, the updated technical description describes in some detail how the hopping function is employed. Question #6: How many radios are in CX-2.4-900 Cell extender ? Per the packing in page 36 of user manual, there is only one 2.4GHz radio with 900MHz antenna However, Cell extender is capable of communicating with 900MHz SU. Please explain how this is done ? ANS 6a There is a CX base station configuration with 10 baseT data input and a 902 MHz output. The CX base station also has a 350 MHz IF output (at F connector) to go to the already certified 2.4 GHz FCC ID LKT-IF-24 radio. Question #7: Please provide proposed FCC ID label location. ANS 7 Please refer to attached documents. Question #8: Page 31 of user manual, please indicate which antenna is for p-t-p or p-t-m operation. ANS 8 The 2.4 GHz unit was previously certified for use in a separate FCC action. It was qualified with its integral antenna as a subscriber unit that operates in a point to point communication mode with the associated 2.4 GHz base unit. The other antennas are 900 MHz antennas and as such the rules do not distinguish between point and multipoint, all antenna/cable/EUT configurations must not exceed 36 dBm EIRP. When the power settings of the radio unit are set for maximum output, and the antenna/cable combinations called out in the user manual are employed, EIRP is 36 dBi or less. Question #9: In the user manual, there is no information provided about the output power shall be tuned to during the installation. The output at antenna connector end and the cabl…

Text truncated - open the document above for the full version.

Product Photographs Alvarion FCC ID: LKT-ASU-900 (base station configuration)

FCC ID: LKT-ASU-900 (subscriber unit version) Product Photographs Alvarion Ltd. FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version)

FCC ID Label location Alvarion LTD FCC ID: LKT-ASU-900 CX base station configuration FCC ID label location

FCC ID Label location Alvarion LTD FCC ID: LKT-ASU-900 SU subscriber configuration FCC ID label location

FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version) FCC ID: LKT-ASU-900 (subscriber unit version)

Sheet1 Alvarion MPE CalculationFCC ID: LKT-ASU-900RF Hazard Distance CalculationmW/cm2 from Table1: 0.60 Max RF Powe TX Antenna MPE Cable Model POWER INDEX P, dBm G, dBi Safe Distance, cm 23.3 14.6 28.6 1ftSMA/N cable 900CX 22 dBm 22.4 14.6 25.8 5ft LMR400 900CX 23 dBm 20.6 14.6 21.0 100ft LMR 400 900CX 24 dBm 24.5 14.6 32.8 1ftSMA/N cable SUI 24/24* 23.6 14.6 29.6 10ft LMR 400 SUI 25/24* *attn/pwr Basis of Calculations:E^2/3770 = S, mW/cm2E, V/m = (Pwatts*Ggain*30)^.5/d, metersd = ((Pwatts*G*30)/3770*S))^0.5 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less Page 1

Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 1 EMISSIONS TEST REPORT FOR A LOW POWER TRANSMITTER I. GENERAL INFORMATION Requirement: Federal Communications Commissions Test Requirements: 15.205, 15.207, 15.209, 15.247 Applicant: Alvarion Ltd. Product ID: FCC ID: LKT-ASU-900 II. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) The EUT is a DTS transmitter operating under section 15.247 of FCC Rules. The EUT is a hybrid system, using a frequency hopping function along with digital modulation of the RF carrier. RF Specifications RF Frequency Band 904 – 926 MHz RF Channels Programmable in 1 MHz steps Modulation Type GFSK DTS/FHSS hybrid Transmitter Output Power 24 dBm typical, variable in approx. 1 dB steps Antennas 11 dBi flat panel antenna 14.6 dBi sector antenna 6 dBi and 9 dBi omni antennas Product configurations: CX-2.4-900 base station IF card IF card ethernet antenna 2.4 GHz radio unit* antenna 900 MHz radio board Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 2 enclosure box SUI subscriber unit The base station can be mounted indoors or outdoors. Antenna cable lengths are usually longer for indoor mounted units. The 2.4 GHz external radio is a previously certified Alvarion product, FCC ID: LKT-IF- 24. The IF card delivers a 440 MHz modulated signal and DC power to the radio units. The IF card is identical to the ones used in other Alvarion 2.4 GHz an d 5.7 GHz products. The interface between the Outdoor and Indoor Units is identical to all of BreezeACCESS systems. The subscriber IF circuitry is the same as the base station IF circuitry. Antennas are outdoor fixed mounted. III. TEST LOCATION Frequency hopping timing characteristics were measured at Alvarion’ s laboratory in Carlsbad, CA. All other FCC tests were performed at Compliance Certification Services 571F Monterey Road Morgan Hill, CA 95037 power supply AC main AC/DC IF card 900 MHz radio card antenna ethernet Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 3 T.N. Cokenias 31 May 2003 EMC Consultant/Agent for Alvarion Ltd. Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 4 TEST PROCEDURES The EUT can be configured for use with various antennas and antenna cable lengths. FCC Rules limit power spectral density to 8 dBm in a 3 kHz bandwidth. RF output power is adjusted to meet psd limits while maximizing RF output power. Maximum allowed output power settings are as follow: MaxPower at Antenna connector dBm Power at Cable end, dBm Cable 24.56 23.6 10ft LMR400 24.56 20.8 100ft LMR 400 Radiated Emissions Test Requirement: 15.109, 15.205, 15.209, 15.247 Measurement equipment used: Agilent 4440A Spectrum Analyzer, 9 kHz-26.5 GHz Chase Biconolog antenna EMCO 3115 Horn antenna, 1-18 GHZ ARA Horn antenna, 12 – 26.5 GHz Miteq pre-amplifier, 1 – 26.5 GHz IFI High pass filter, fp = 1800 MHz Test Procedures, 1- 26 GHz: 1. The EUT was placed on a wooden table resting on a turntable on the open air test site. The search antenna was placed 3m from the EUT. The EUT antenna was mounted vertically as per normal installation. 2. The turntable was slowly rotated to locate the direction of maximum emission at each emission falling in the restricted bands of 15.205. 3. Radiated emissions were investigated for a LOW channel, a MID channel, and HIGH channel. Emissions were investigated to the 10 th harmonic. 4. Once maximum direction was determined, the search antenna was raised and lowered in both vertical and horizontal polarizations. The maximum readings so obtained are recorded in the data listed below. Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 5 Radiated Test Set-up, 1-40 GHz d: 1-3m 1-2m d -or- preamplifier Figure 2 Testing was performed at 3 different frequencies Channel Frequency, MHz Low 904 Mid 915 High 926 Radiated emissions were performed at each frequency for 3 different transmitter antennas. Antennas tested: Antenna Type Gain Antenna Manufacturer Model Number omni 9 dBi Mobilemark MFB91579-2400 sector 14.6 dBi Pacific Wireless PAWDC24 Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 6 flat panel 11 dBi MTI MT364023/n Test Results: Worst case results are presented. Refer to separate Excel spread sheet files. Radiated Test Set-up, 30 - 1000 MHz Antenna mast Ground plane 1 - 4 meters 3 meters turntable, laptop computer Figure 3 preamplifier spectrum analyzer Test Procedures, 30 -1000 MHz The EUT was set to RECEIVE/TRANSMIT mode. Radiation emissions from the digital portion of the EUT were measured according to the dictates of ANSI C63.4. Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 7 Test Results Refer to separate attachment. Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 8 AC Line Conducted Emissions Test Requirement: 15.107, 15.207 Measurement Equipment Used: Rohde & Schwarz EMI Receiver ESHS-20 Fischer Custom Communication LISN, FCC-LISN-50/250-25-2 Test Procedure 1. The EUT was placed on a wooden table 40 cm from a vertical ground plane and approximately 80 cm above the horizontal ground plane on the floor. The EUT was set to transmit in normally. 2. Line conducted data was recorded for both NEUTRAL and HOT lines. Test Results PASS. Refer to data sheets in separate attachment. Alvarion Ltd. 902-928 MHz DTS Systems FCC ID: LKT-ASU-900 9 Minimum 6 dB Bandwidth Test Requirement: 15.247(a)2 Measurement Equipment Used: Agilent 4440A Spectrum Analyzer 20 dB attenuator Test Procedures The EUT was configured on a test bench. The EUT was set for continuous operation . Frequency was set to LOW channel. While the transmitter broadcast a steady stream of digital data, the analyzer MAX HOLD function was used to capture the envelope of the transmission occupied bandwidth. The test was repeated at MID channel and at HIGH channel. Test Results: Refer to attached spectrum analyzer charts. Data is presented for both product packaging configurations. Data taken with RES BW of 100 kHz shows minimum 6 dB BW of 1.25 MHz. Minimum requirement: 500 kHz Channel Frequency, MHz Low …

Text truncated - open the document above for the full version.

561F Monterey Road Morgan Hill, CA 95037, U.S.A. Tel: (408) 463-0885 Fax:(408) 463-0888 Data#: 14File#: emi albvarion.EMIDate: 04-02-2003 Time: 09:51:47 Trace: 13 Ref Trace: Condition: FCC CLASS-B 3m CHAMBER 030117 1185 VERTICAL Company : Alvarion Ltd EUT Description : Alvarion 902-928MHz DTS Device Model Number : 900CX AU Test Configurtion: EUT, Antenna, Test Target : FCC classB Mode of Operation: Constant Tx : Note: Page: 1 Read Probe Cable Preamp Limit Over Freq Level Factor Loss Factor Level Line Limit Remark _________ ______ ______ ______ ______ ______ ______ ______ ______ MHz dBuV dB dB dB dBuV/m dBuV/m dB 1 101.780 25.99 10.40 0.93 0.00 37.32 43.50 -6.18 Peak 2 106.630 25.48 10.59 1.00 0.00 37.07 43.50 -6.43 Peak 3 * 919.490 73.84 22.16 3.23 0.00 99.23 46.00 53.23 Peak 4 926.280 12.72 22.20 3.26 0.00 38.18 46.00 -7.82 Peak 561F Monterey Road Morgan Hill, CA 95037, U.S.A. Tel: (408) 463-0885 Fax:(408) 463-0888 Data#: 12File#: emi albvarion.EMIDate: 04-02-2003 Time: 09:41:41 Trace: 10 Ref Trace: Condition: FCC CLASS-B 3m CHAMBER 030117 1185 HORIZONTAL Company : Alvarion Ltd EUT Description : Alvarion 902-928MHz DTS Device Model Number : 900CX AU Test Configurtion: EUT, Antenna, Test Target : FCC classB Mode of Operation: Constant Tx : Note: Page: 1 Read Probe Cable Preamp Limit Over Freq Level Factor Loss Factor Level Line Limit Remark _________ ______ ______ ______ ______ ______ ______ ______ ______ MHz dBuV dB dB dB dBuV/m dBuV/m dB 1 882.630 12.09 21.87 3.20 0.00 37.16 46.00 -8.84 Peak 2 * 919.490 59.52 22.16 3.23 0.00 84.91 46.00 38.91 Peak 3 948.590 11.43 22.32 3.38 0.00 37.13 46.00 -8.87 Peak

06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device w/ 6dBi OMNI EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_Low ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.9041.00.8-1.51.0#N/A#N/AV 1.8089.855.246.427.91.5-36.40.01.049.340.574.054.0-24.7-13.5V, 2nd Har 2.7129.846.432.430.12.3-36.30.01.043.529.674.054.0-30.5-24.4V 3.6169.844.231.331.92.9-36.20.01.043.730.874.054.0-30.3-23.2V 4.5209.844.631.732.93.3-36.10.01.045.732.874.054.0-28.3-21.2V 5.4249.843.131.133.83.7-36.10.01.045.333.474.054.0-28.7-20.6V 6.3289.843.831.834.94.1-36.30.01.047.435.574.054.0-26.6-18.5V 7.2329.844.132.536.14.4-36.30.01.049.337.674.054.0-24.7-16.4V 8.1369.842.330.837.34.7-35.80.01.049.538.074.054.0-24.5-16.0V 9.0409.841.330.038.85.1-35.30.01.050.839.674.054.0-23.2-14.4V 1.8089.850.341.327.91.5-36.40.01.044.335.374.054.0-29.7-18.7H, 2nd har. 2.7129.845.732.730.12.3-36.30.01.042.929.974.054.0-31.1-24.1H 3.6169.843.431.031.92.9-36.20.01.043.030.574.054.0-31.0-23.5H 4.5209.842.731.632.93.3-36.10.01.043.832.774.054.0-30.2-21.3H 5.4249.844.632.633.83.7-36.10.01.046.934.974.054.0-27.1-19.1H 6.3289.842.931.234.94.1-36.30.01.046.534.874.054.0-27.5-19.2H 7.2329.844.732.436.14.4-36.30.01.049.837.674.054.0-24.2-16.4H 8.1369.842.631.137.34.7-35.80.01.049.938.374.054.0-24.1-15.7H 9.0409.842.530.338.85.1-35.30.01.052.039.874.054.0-22.0-14.2H fMeasurement FrequencyAmpPreamp GainAvg LimAverage Field Strength Limit DistDistance to AntennaD CorrDistance Correct to 3 metersPk LimPeak Field Strength Limit ReadAnalyzer ReadingAvgAverage Field Strength @ 3 mAvg MarMargin vs. Average Limit AFAntenna FactorPeakCalculated Peak Field StrengthPk MarMargin vs. Peak Limit CLCable LossHPFHigh Pass Filter Miteq NSP2600-44 Pre-amplifer 1-26GHz EMCO Horn 1-18GHz T60; S/N: 2238 @3m Spectrum Analyzer 8593EM Analyzer Horn > 18GHz (2 ft)(2 ~ 3 ft)(4 ~ 6 ft)(12 ft) Hi Frequency Cables 06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device w/ 6dBi OMNI EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_Hi ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.926V 1.8529.857.951.228.21.6-36.40.01.052.245.574.054.0-21.8-8.5V, 2nd Har 2.7789.846.433.130.22.4-36.30.01.043.730.474.054.0-30.3-23.6V 3.7049.858.946.532.02.9-36.20.01.058.646.274.054.0-15.4-7.8V 4.6309.860.241.033.03.3-36.10.01.061.442.274.054.0-12.6-11.8V 5.5569.847.634.333.93.7-36.20.01.050.136.874.054.0-23.9-17.2V 6.4829.845.332.035.14.1-36.30.01.049.135.874.054.0-24.9-18.2V 7.4089.843.631.936.44.5-36.20.01.049.237.474.054.0-24.8-16.6V 8.3449.842.730.337.74.8-35.70.01.050.538.174.054.0-23.5-15.9V 9.2609.842.330.938.75.1-35.30.01.051.740.374.054.0-22.3-13.7V 1.8529.857.150.628.21.6-36.40.01.051.444.974.054.0-22.6-9.1H, 2nd har. 2.7789.845.432.230.22.4-36.30.01.042.729.574.054.0-31.3-24.5H 3.7049.853.841.832.02.9-36.20.01.053.541.574.054.0-20.5-12.5H 4.6309.855.841.733.03.3-36.10.01.057.042.974.054.0-17.0-11.1H 5.5569.846.533.933.93.7-36.20.01.049.036.474.054.0-25.0-17.6H 6.4829.844.132.035.14.1-36.30.01.048.035.874.054.0-26.0-18.2H 7.4089.842.931.836.44.5-36.20.01.048.437.374.054.0-25.6-16.7H 8.3449.842.230.537.74.8-35.70.01.050.038.374.054.0-24.0-15.7H 9.2609.842.830.138.75.1-35.30.01.052.239.674.054.0-21.8-14.4H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H fMeasurement FrequencyAmpPreamp GainAvg LimAverage Field Strength Limit DistDistance to AntennaD CorrDistance Correct to 3 metersPk LimPeak Field Strength Limit ReadAnalyzer ReadingAvgAverage Field Strength @ 3 mAvg MarMargin vs. Average Limit AFAntenna FactorPeakCalculated Peak Field StrengthPk MarMargin vs. Peak Limit CLCable LossHPFHigh Pass Filter Miteq NSP2600-44 Pre-amplifer 1-26GHz EMCO Horn 1-18GHz T60; S/N: 2238 @3m Spectrum Analyzer 8593EM Analyzer Horn > 18GHz (2 ft)(2 ~ 3 ft)(4 ~ 6 ft)(12 ft) Hi Frequency Cables 06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device w/ 6dBi OMNI EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_ Mid ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.9153.60.8-5.51.0#N/A#N/AV 1.8309.856.648.928.11.6-36.40.01.050.843.174.054.0-23.2-10.9V, 2nd Har 2.7459.847.434.930.22.4-36.30.01.044.632.174.054.0-29.4-21.9V 3.6609.855.140.031.92.9-36.20.01.054.739.674.054.0-19.3-14.4V 4.5759.856.442.633.03.3-36.10.01.057.643.874.054.0-16.4-10.2V 5.4909.844.531.633.83.7-36.20.01.046.934.074.054.0-27.1-20.0V 6.4059.843.831.835.04.1-36.30.01.047.535.674.054.0-26.5-18.4V 7.3209.844.532.136.24.4-36.30.01.049.837.574.054.0-24.2-16.5V 8.2359.842.730.637.54.8-35.70.01.050.238.174.054.0-23.8-15.9V 9.1509.842.230.438.85.1-35.30.01.051.739.974.054.0-22.3-14.1V 1.8309.852.544.528.11.6-36.40.01.046.738.674.054.0-27.3-15.4H, 2nd har. 2.7459.846.032.430.22.4-36.30.01.043.329.774.054.0-30.7-24.3H 3.6609.845.432.931.92.9-36.20.01.045.132.574.054.0-28.9-21.5H 4.5759.846.532.833.03.3-36.10.01.047.734.074.054.0-26.3-20.0H 5.4909.842.931.733…

Text truncated - open the document above for the full version.

561F Monterey Road, San Jose, CA 95037 USA Tel: (408) 463-0885 Fax: (408) 463-0888 Data#: 7File#: 03U1919A.EMIDate: 04-29-2003 Time: 11:02:51 Level (dBuV)Compliance Certification Service 90 40 -10 0.1530 Frequency (MHz) 0.51.2.5.1020 AVERAGE CISPR CLASS-B Trace: 5 Ref Trace: Project # : 03U1919-1 Test Engineer : Thanh Nguyen Company : Alvaron EUT : CX-24-900 Model : CX-24-900 FCC ID LKT-IF-900 Test Config. : EUT/Support Equipment Target of Test: FCC Class B : L1: Peak (Black], Average (Green) : 115Vac, 60Hz 561F Monterey Road, San Jose, CA 95037 USA Tel: (408) 463-0885 Fax: (408) 463-0888 Data#: 14File#: 03U1919A.EMIDate: 04-29-2003 Time: 11:14:25 Level (dBuV)Compliance Certification Service 90 40 -10 0.1530 Frequency (MHz) 0.51.2.5.1020 AVERAGE CISPR CLASS-B Trace: 12 Ref Trace: Project # : 03U1919-1 Test Engineer : Thanh Nguyen Company : Alvaron EUT : CX-24-900 Model : CX-24-900 FCC ID LKT-IF-900 Test Config. : EUT/Support Equipment Target of Test: FCC Class B : L2: Peak (Black], Average (Green) : 115Vac, 60Hz

06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_Low ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.9041.00.8-1.51.0#N/A#N/AV 1.8089.852.541.127.91.5-36.40.01.046.535.174.054.0-27.5-18.9V, 2nd Har 2.7129.844.731.030.12.3-36.30.01.041.928.274.054.0-32.1-25.8V 3.6169.857.440.731.92.9-36.20.01.056.940.274.054.0-17.1-13.8V 4.5209.844.630.532.93.3-36.10.01.045.731.674.054.0-28.3-22.4V 5.4249.843.030.933.83.7-36.10.01.045.333.274.054.0-28.7-20.8V 6.3289.844.732.034.94.1-36.30.01.048.335.674.054.0-25.7-18.4V 7.2329.843.931.836.14.4-36.30.01.049.137.074.054.0-24.9-17.0V 8.1369.842.630.037.34.7-35.80.01.049.837.274.054.0-24.2-16.8V 9.0409.842.030.438.85.1-35.30.01.051.540.074.054.0-22.5-14.0V 1.8089.849.039.527.91.5-36.40.01.043.033.574.054.0-31.0-20.5H, 2nd har. 2.7129.844.541.430.12.3-36.30.01.041.738.674.054.0-32.3-15.4H 3.6169.847.234.231.92.9-36.20.01.046.733.774.054.0-27.3-20.3H 4.5209.843.430.232.93.3-36.10.01.044.531.374.054.0-29.5-22.7H 5.4249.843.830.033.83.7-36.10.01.046.132.374.054.0-27.9-21.7H 6.3289.843.431.434.94.1-36.30.01.047.035.074.054.0-27.0-19.0H 7.2329.844.031.136.14.4-36.30.01.049.236.374.054.0-24.8-17.7H 8.1369.841.529.837.34.7-35.80.01.048.737.074.054.0-25.3-17.0H 9.0409.841.929.938.85.1-35.30.01.051.439.474.054.0-22.6-14.6H fMeasurement FrequencyAmpPreamp GainAvg LimAverage Field Strength Limit DistDistance to AntennaD CorrDistance Correct to 3 metersPk LimPeak Field Strength Limit ReadAnalyzer ReadingAvgAverage Field Strength @ 3 mAvg MarMargin vs. Average Limit AFAntenna FactorPeakCalculated Peak Field StrengthPk MarMargin vs. Peak Limit CLCable LossHPFHigh Pass Filter Miteq NSP2600-44 Pre-amplifer 1-26GHz EMCO Horn 1-18GHz T60; S/N: 2238 @3m Spectrum Analyzer 8593EM Analyzer Horn > 18GHz (2 ft)(2 ~ 3 ft)(4 ~ 6 ft)(12 ft) Hi Frequency Cables 06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_Hi ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.9266.20.8-9.51.0#N/A#N/AV 1.8529.866.749.428.21.6-36.40.01.061.043.774.054.0-13.0-10.3V, 2nd Har 2.7789.846.532.630.22.4-36.30.01.043.929.974.054.0-30.1-24.1V 3.7049.854.839.332.02.9-36.20.01.054.639.174.054.0-19.4-14.9V 4.6309.845.131.933.03.3-36.10.01.046.333.174.054.0-27.7-20.9V 5.5569.844.631.733.93.7-36.20.01.047.134.274.054.0-26.9-19.8V 6.4829.844.232.235.14.1-36.30.01.048.136.074.054.0-25.9-18.0V 7.4089.845.132.236.44.5-36.20.01.050.737.774.054.0-23.3-16.3V 8.3449.843.430.737.74.8-35.70.01.051.238.574.054.0-22.8-15.5V 9.2609.843.331.138.75.1-35.30.01.052.840.674.054.0-21.2-13.4V 1.8529.851.841.428.21.6-36.40.01.046.135.674.054.0-27.9-18.4H, 2nd har. 2.7789.845.632.330.22.4-36.30.01.042.929.674.054.0-31.1-24.4H 3.7049.849.833.632.02.9-36.20.01.049.633.374.054.0-24.4-20.7H 4.6309.844.831.633.03.3-36.10.01.046.032.874.054.0-28.0-21.2H 5.5569.843.631.633.93.7-36.20.01.046.134.174.054.0-27.9-19.9H 6.4829.844.432.135.14.1-36.30.01.048.336.074.054.0-25.7-18.0H 7.4089.844.232.236.44.5-36.20.01.049.837.874.054.0-24.2-16.2H 8.3449.843.430.737.74.8-35.70.01.051.138.474.054.0-22.9-15.6H 9.2609.842.731.038.75.1-35.30.01.052.140.574.054.0-21.9-13.5H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H 1.0H fMeasurement FrequencyAmpPreamp GainAvg LimAverage Field Strength Limit DistDistance to AntennaD CorrDistance Correct to 3 metersPk LimPeak Field Strength Limit ReadAnalyzer ReadingAvgAverage Field Strength @ 3 mAvg MarMargin vs. Average Limit AFAntenna FactorPeakCalculated Peak Field StrengthPk MarMargin vs. Peak Limit CLCable LossHPFHigh Pass Filter Miteq NSP2600-44 Pre-amplifer 1-26GHz EMCO Horn 1-18GHz T60; S/N: 2238 @3m Spectrum Analyzer 8593EM Analyzer Horn > 18GHz (2 ft)(2 ~ 3 ft)(4 ~ 6 ft)(12 ft) Hi Frequency Cables 06/09/03 High Frequency Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: VIEN TRAN Project #: 03I1880-1 Company: Alvarion EUT Descrip.: Alvarion 902-928MHz DTS Device EUT M/N: TBD Test Target: FCC15.247 Mode Oper: Constant Tx_Mid ch Test Equipment: Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1 MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB 0.9153.60.8-5.51.0#N/A#N/AV 1.8309.853.542.128.11.6-36.40.01.047.736.274.054.0-26.3-17.8V, 2nd Har 2.7459.845.532.030.22.4-36.30.01.042.829.274.054.0-31.2-24.8V 3.6609.858.141.631.92.9-36.20.01.057.741.274.054.0-16.3-12.8V 4.5759.845.631.533.03.3-36.10.01.046.732.774.054.0-27.3-21.3V 5.4909.843.831.733.83.7-36.20.01.046.234.174.054.0-27.8-19.9V 6.4059.845.532.635.04.1-36.30.01.049.236.374.054.0-24.8-17.7V 7.3209.844.832.536.24.4-36.30.01.050.137.874.054.0-23.9-16.2V 8.2359.843.630.537.54.8-35.70.01.051.138.074.054.0-22.9-16.0V 9.1509.842.030.438.85.1-35.30.01.051.539.974.054.0-22.5-14.1V 1.8309.849.740.428.11.6-36.40.01.043.934.674.054.0-30.1-19.4H, 2nd har. 2.7459.845.532.430.22.4-36.30.01.042.729.674.054.0-31.3-24.4H 3.6609.848.035.031.92.9-36.20.01.047.634.674.054.0-26.4-19.4H 4.5759.844.131.533.03.3-36.10.01.045.332.674.054.0-28.7-21.4H 5.4909.844.931.733.83.7-36.20.01.0…

Text truncated - open the document above for the full version.

561F Monterey Road Morgan Hill, CA 95037, U.S.A. Tel: (408) 463-0885 Fax:(408) 463-0888 Data#: 12File#: Tom042903.EMIDate: 04-30-2003 Time: 11:52:57 Trace: 11 Ref Trace: Condition: FCC CLASS-B 3m CHAMBER 030306 1185 VERTICAL Company : ALVARION EUT Description : SU-I-900 Model Number : SU-I-900, FCC ID LKT-ASU-900 Test Configurtion: EUT and Support Equipment Test Target : FCC Class B Mode of Operation: TX Page: 1 Read Probe Cable Preamp Limit Over Freq Level Factor Loss Factor Level Line Limit Remark _________ ______ ______ ______ ______ ______ ______ ______ ______ MHz dBuV dB dB dB dBuV/m dBuV/m dB 1 34.590 13.76 16.92 0.59 0.00 31.27 40.00 -8.73 Peak 2 37.480 18.39 16.70 0.58 0.00 35.67 40.00 -4.33 Peak 3 124.180 24.10 10.16 1.06 0.00 35.32 43.50 -8.18 Peak 4 139.990 27.23 8.86 1.13 0.00 37.21 43.50 -6.29 Peak 5 141.690 25.03 8.73 1.13 0.00 34.89 43.50 -8.61 Peak 6 142.880 24.87 8.64 1.13 0.00 34.64 43.…
