PHOTOS : BreezeMAX 2300 system Base station ODU Model: BMAX-BST-AU-ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 Photo1. Basic unit PCB open cover CS Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo2. Basic unit PCB CS Photo3. Basic unit PCB PS Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo4. Power amplifier PCB, CS. Photo5. Power amplifier PCB CS Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo6. Power amplifier PCB PS Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo7 Power amplifier PCB , open cover CS Photo 8. Cavity filter top view Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo9. Cavity filter side view Photo10 . cavity filter bottom view Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo11. Cavity filter Out connector Photo12 . Power amplifier in case with open cover Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo13 . IF Connector TNC side Photo14. From left: cavity filter, open case w/power amplifier PCB, Basic unit PCB, Power amplifier PCB Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo15 Power amplifier , open case Photo16. ODU external view Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo17. ODU open cover , right side Power amplifier Photo 18. ODU open cover, left side Basic unit PCB , right side cavity filter and power amplifier PCB Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com Photo19. ODU , bottom view Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com

Internal Photos

Parts List/Tune Up Info

Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com 5/10/06 BreezeMAX 2300 system FCC ID: LKT-BMAX-BA23 FCC ID: LKT-BMAX-SU23 FCC ID: LKT-BMAX-SI23 Frequency and power determination before shipment: Before product shipment from the factory, the units pass automatic calibration sequence test where the unit is calibrated (including power out) and frequency is tested. Base station installation. The user configures the unit according to licensed frequencies( user may have several frequencies) Subscriber station transmits only when Base station is detected and adjusts the frequency to the Base station transmission.

RF Exposure Info

Sheet1 Alvarion Ltd.FCC ID: LKT-BMAX-BA232.3 GHz Base Station Calculate mW/cm2 here. Enter frequency in MHz: RF Hazard Distance Calculation Calculation of Limits from 1.1310 Table 1 ControAve 6 mW/cm2 from Table1: 1.00 F(MHz) Actual F, MHz Occ, 0.3-3 0.5 10 Max RF Powe TX Antenna MPE distance S, mW/cm@ Comment 3.0 - 30.0 5 18 P, dBm G, dBi cm at 20 cm 30.0-300 55 1 300-1500 902 3 36.10 16.50 120.3 36.20 Outdoor mount 1500-100000 5555 5 Enter P(mW) Equivalent dBm Enter dBm Equiva Basis of Calculations: 895.4 29.52 29.52 E^2/3770 = S, mW/cm2E, V/m = (Pwatts*Ggain*30)^.5/d, metersd = ((Pwatts*G*30)/3770*S))^0.5 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) S@20cm = 20 log (MPE dist/20cm)NOTE: For mobile or fixed location transmitters, minimum separation distance is for FCC compliance is 20 cm, even if calculations indicate MPE distance is less Page 1

Test Report

Test Report No. 8612329133 For ALVARION Ltd. Equipment Under Test: BreezeMAX 2300 Broadband Wireless Access System Base station (AU) From The Standards Institution Of Israel Industry Division Electronics & Telematics Laboratory EMC Section Certificate No. 1487-01 Test report No: 8612329133 Page 2 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 Table of Contents 1 Applicant information......................................................................... 3 2 Test performance...............................................................................3 3 Summary of test................................................................................4 4 EUT description.................................................................................5 4.1 General description........................................................................5 4.2 EUT test configuration............................................................................6 5 Test result.......................................................................................7 5.1 Transmitter characteristics............................................................7 5.1.1 Occupied Bandwidth ....................................................................7 5.1.2 Peak output power ...................................................................... 10 5.1.3 Spurious emissions at antenna terminal.............................................. 13 5.1.4 Spurious emissions radiated...........................................................38 5.1.5 Frequency stability...................................................................... 54 5.2 Unintentional radiated emissions test § 15.109...................................65 5.3 Conducted emissions test §§ 15.107..................................................67 Appendix A Photographs.......................................................................69 Appendix B Test equipment used for test....................................................71 Appendix C General information..............................................................75 Test report No: 8612329133 Page 3 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 1 Applicant information Company: Alvarion Ltd. Address: 21A Habarzel str, Tel-Aviv, 69710, Israel The date of test: May –June 2006 Equipment under test information Test items: Base station BreezeMAX 2300 Manufacturer: Alvarion Ltd Model: BMAX-BST-AU-ODU-HP-2.3 Equipment serial number: NA GPS receiver and antenna Model: BMAX-GPS-OGR GPS adaptor Model: BMAX-GPS-IGA 2 Test performance Location: SII EMC Section Purpose of test: Apparatus compliance verification in accordance with emission requirements Test specifications: 47CFR part 15, part 27, part 2 §§ 2.1049, 2.1053, part 1 §1.1310 This Test Report contains 75 pages and may be used only in full. This Test Report applies only to the specimen tested and may not be applied to other specimens of the same product. Test report No: 8612329133 Page 4 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 3 Summary of test: The EUT was found to be in compliance with requirements of: 47CFR Part 15, part 27, and part 2 §§ 27.50, 27.53, 27.54, 2.1055, 15.107, and 15.109 Parameter Subclasses Transmitter characteristics Occupied bandwidth 2.1049 Peak output power 27.50 Spurious emissions at antenna terminal 27.53 Spurious emissions radiated 27.53 Frequency stability 27.54 Unintentional radiation Conducted emissions 15.107 class B Radiated emissions 15.109 class A Test performed by: Mr. Michael Feldman test technician Test report prepared by: Mr. Michael Feldman test technician Test report approved by: Mr. Yuri Rozenberg. Head of EMC Branch Test report No: 8612329133 Page 5 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 4. Equipment Under Test description *The customer provided description. 4.1 General description BreezeMAX 2300 is Alvarion’s WiMAX platform for the licensed 2.3 GHz WCS frequency band. It is digital modulated TDD system operating in the 2300MHz up to 2360MHz band with OFDM modulation. The Base station -AU outdoor unit contain the radio {Basic + HPA} and digital control section unit. The AU comprises an Indoor Unit (IDU) and an Outdoor Unit (ODU). The AU-IDU module connects to the AU-ODU via an Intermediate Frequency (IF) cable. The IF cable carries full duplex data, control and management signals between the AU-IDU and the AU-ODU, as well as power (48 VDC) and 64 MHz synchronization reference clock from the AU-IDU to the AU-ODU. EUT technical characteristics Transmitter technical characteristics. Note Stand-alone/fixed use Assigned frequency range 2305 – 2320 MHz and 2345 – 2360 MHz Operating frequency range 2307.5 MHz, 2312.5 MHz, 2352.5 MHz, 2357.5 MHz RF channel spacing 5 MHz Maximum rated output power 40 dBm At transmitter 50 Ω RF output connector Antenna connection Standard connector: N-TYPE Professional installation Transmitter 99% power bandwidth 5 MHz Type of modulation BPSK, 4QAM, 16QAM, 64QAM Type of multiplexing OFDM Modulating test signal (baseband) PRBS Maximum transmitter duty cycle in normal use 50 % Transmitter duty cycle supplied for test 100 % Antenna information Type Manufacturer Model Gain Sector TELSA 723214 17 dBi Sector CUSHCRAFT J23017V00-60N 16.5 dBi Test report No: 8612329133 Page 6 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 4.2 EUT test configuration Coax cable Fig. 1 Base station test setup Outdoor unit AU-ODU Indoor Unit AU-IDU 48VDC P.S Test report No: 8612329133 Page 7 of 75 Pages Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU- ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 5 Test results 5.1 Transmitter c…

Text truncated - open the document above for the full version.

Test Report

27 September 2006 To Alvarion Ltd Att. Avner Ruta Dear Avner, According to your request per radio Test reports 8612337013, 8612329133 and 8612337012 we would like to inform you that: Radiated emissions tests according to part 27.53 were performed by substitution method. The limit on the plots is limit EIRP converted to field strength limit at relevant distance and correlated by substitution procedure. For example: EIRP limit 43 + 10*log P = -13 dBm was converted to 82.2 dBμV/m field strength limit at 3m test distance. In bands were spurious emissions peaks were found below limit close than 10 dB test result was got by substitution method. Best regards. Name: Eng. Yuri Rozenberg Position:Head of EMC Branch

Test Report

Title: BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU-ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 Test report: BMAX-2300-AU- ODU Page 1 of 1 Date of issue: September 2006 Alvarion Ltd 21A HaBarzel Street Tel Aviv 69710 ISRAEL Tel: + 972-3-6456262 Fax: + 972-3-6456290 www.alvarion.com Frequency Stability FCC 2.1055(b) Nominal voltage=115VAC BMAX –AU-ODU-HP-2.3 Temperature Extreme Voltage/VAC Frequency Low/MHz Frequency High/MHz 97.75 2307.497750 2357.497710 -30ºC 132.25 2307.497760 2357.497720 97.75 2307.497900 2357.497850 -20ºC 132.25 2307.497890 2357.497860 97.75 2307.497960 2357.497900 -10ºC 132.25 2307.497970 2357.497890 97.75 2307.497990 2357.497950 0ºC 132.25 2307.497980 2357.497950 97.75 2307.497880 2357.497860 10ºC 132.25 2307.497890 2357.497850 97.75 2307.498000 2357.497960 20ºC 132.25 2307.498000 2357.497960 97.75 2307.498000 2357.497960 30ºC 132.25 2307.498000 2357.497960 97.75 2307.498010 2357.497990 40ºC 132.25 2307.498020 2357.498000 97.75 2307.497990 2357.497960 50ºC 132.25 2307.498000 2357.497960

Test Setup Photos

Aug6/06 BreezeMAX2300 Broadband Wireless Access System Model: BMAX-BST-AU-ODU-HP-2.3 FCC ID: LKT-BMAX-BA23 Test setup: AU ODU

Contact Information

Applicant

Gennady Furmanov(Senior HW Engineer)

[email protected]972-3-7674222Fax: 972-3-7674491

Test Firm

The Standards Institution of IsraelYuri Rozenberg

[email protected]972-3-6467800Fax: 972-3-6467779

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	27	2.35 GHz - 2.36 GHz	4 W	4M77W1D	2000 Hz

Confidentiality

Long Term

Grant Notes

Power listed is conducted. Professional installation is required. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures, must not be collocated or operating in conjunction with any other antenna or transmitter and provide a minimum 2 meter separation to all persons. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
