LKT-EXTR-CPE-49HWiMAX subscriber unit transceiver

BreezeMAX ® PRO 5000 CPE Product Manual Software Version 1.5 April 2010 P/N 215643 Document History BreezeMAX PRO 5000 CPEii Product Manual Document History TopicDescriptionDate Issued First ReleaseNew Product ManualSW Version 4.6,  July 2009 Ethernet CS displayUpdated the Service Parameters pageSW Version x.x, September 2009 New IDU power supply unit XTRM-SU-IDU-1D Added specifications and informationSW Version 1.2,  October 2009 “Service Parameters” on page 79 Removed the Modify optionSW Version 1.2,  October 2009 “User Registration” on page 60 Added EAP-AKA to the screenSW Version 1.2,  October 2009 “Radio Parameters” on page 67 Added “ATPC Parameters” on page 72SW Version 1.2,  October 2009 “User Registration” on page 60 Added default username and password.SW Version 1.5,  January 2010 “ATPC Parameters” on page 72  Added a note that the DHCP Client can be set to disable only in ETH-CS service. The upload procedure of a country codes file (country_codes.xml) was added: The country codes file can be uploaded to the CPE using the Configuration Control menu. A new field was added to the Show parameters: Current Country Code Data Country codes changed SW Version 1.5,  January 2010 “Unit Control Parameters” on page 47 Added a new page: “Licences” on page 56 SW Version 1.5,  January 2010 DHCP Client Configuration pageMoved the DHCP Client Configuration page from Radio Parameters to Management Parameters. SW Version 1.5,  January 2010 “Parameters Summary” on page 85 Updated latest parameters: Registration default username and password, Licences and AM&TM SW Version 1.5,  January 2010 General Added information on models with external antennas. Replaced all screenshots SW Version 1.5,  March 2010 Document History BreezeMAX PRO 5000 CPEiii Product Manual 5 GHz Integral Antenna in Table 1-1 15°AZ x 15°EL instead of 20°SW Version 1.5,  March 2010 Table 1-5  Allocation of IP parameters: Removed LAN-Configurable, added options 66, 67 Configuration Upload/Download: added TFTP Authentication: Removed TLS SW Version 1.5,  March 2010 TM/PM Files ControlRemovedSW Version 1.5,  March 2010 “Aligning the PRO CPE’s External Antenna” on page 39 New sectionSW Version 1.5,  March 2010 Integratiion TimeRemovedSW Version 1.5,  March 2010 “Configuration Control” on page 53 New functionsSW Version 1.5,  March 2010 “Licences” on page 56New sectionSW Version 1.5,  March 2010 “User Registration” on page 60 RevisedSW Version 1.5,  March 2010 “BST/AU Parameters” on page 63 RevisedSW Version 1.5,  March 2010 “ATPC” on page 73Added section “Country Codes” on page 73 SW Version 1.5,  March 2010 TopicDescriptionDate Issued Legal Rights BreezeMAX PRO 5000 CPEiv Product Manual Legal Rights © Copyright 2010 Alvarion Ltd. All rights reserved. The material contained herein is proprietary, privileged, and confidential and owned by Alvarion or its third party licensors. No disclosure thereof shall be made to third parties without the express written permission of Alvarion Ltd. Alvarion Ltd. reserves the right to alter the equipment specifications and descriptions in this publication without prior notice. No part of this publication shall be deemed to be part of any contract or warranty unless specifically incorporated by reference into such contract or warranty. Trade Names Alvarion ® , BreezeCOM ® , WALKair ® , WALKnet ® , BreezeNET ® , BreezeACCESS ® , BreezeLINK ® , BreezeMAX ® , BreezeLITE ® , BreezePHONE ® , 4Motion ® , BreezeCONFIG ™ and/or other products and/or services referenced here in are either registered trademarks, trademarks or service marks of Alvarion Ltd. All other names are or may be the trademarks of their respective owners. “WiMAX Forum” is a registered trademark of the WiMAX Forum. “WiMAX,” the WiMAX Forum logo, “WiMAX Forum Certified,” and the WiMAX Forum Certified logo are trademarks of the WiMAX Forum. Statement of Conditions The information contained in this manual is subject to change without notice. Alvarion Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or equipment supplied with it. Warranties and Disclaimers All Alvarion Ltd. ("Alvarion") products purchased from Alvarion or through any of Alvarion's authorized resellers are subject to the following warranty and product liability terms and conditions. Exclusive Warranty (a) Alvarion warrants that the Product hardware it supplies and the tangible media on which any software is installed, under normal use and conditions, will be free from significant defects in materials and workmanship for a period of fourteen (14) months from the date of shipment of a given Product to Purchaser (the "Warranty Period"). Alvarion will, at its sole option and as Purchaser's sole remedy, repair or replace any defective Product in accordance with Alvarion' standard R&R procedure. Legal Rights BreezeMAX PRO 5000 CPEv Product Manual (b) With respect to the Firmware, Alvarion warrants the correct functionality according to the attached documentation, for a period of fourteen (14) month from invoice date (the "Warranty Period")". During the Warranty Period, Alvarion may release to its Customers firmware updates, which include additional performance improvements and/or bug fixes, upon availability (the "Warranty"). Bug fixes, temporary patches and/or workarounds may be supplied as Firmware updates. Additional hardware, if required, to install or use Firmware updates must be purchased by the Customer. Alvarion will be obligated to support solely the two (2) most recent Software major releases. ALVARION SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY PURCHASER'S OR ANY THIRD PERSON'S MISUSE, NEGLIGENCE, IMPROPER INSTALLATION OR IMPROPER TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED US…

Text truncated - open the document above for the full version.

tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 Compliance Certification Services 15 June 2010 47173 Benicia Street Fremont CA 94538 Attention: Application Examiner Reviewing Engineer RE: Request for confidentiality per FCC Rule Sections 0.457 and 0.459 Applicant: Alvarion Ltd. Description: FCC 15.247/90Y Dual Band WiMAX CPE radio FCC ID: LKT-EXTR-CPE-49H To whom it may concern, Request is hereby submitted, on behalf of my client Alvarion Ltd. to permanently withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report shall be kept confidential: Operational Description Schematic Block Diagram Parts List/BOM Rationale for request for confidentiality: Alvarion has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely, THOMAS N. COKENIAS EMC Consultant/Agent for Alvarion Ltd.

tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 CCS 15 June 2010 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner Reviewing Engineer Applicant: Alvarion Ltd. Description: FCC 15.247/90Y Dual Band WiMAX CPE radio FCC ID: LKT-EXTR-CPE-49H To whom it may concern, The referenced application is a dual band subscriber unit operating under Part 15 and Part 90 of FCC Rules. A product with the same electronics is sold under the FCC ID: LKT-EXTR-CPE-58. The radio is professionally installed. If you have questions or need further information, please contact the undersigned. Sincerely, THOMAS N. COKENIAS EMC Consultant/Agent for Alvarion Ltd.

Breez eMAX Extreme Base statio n FCC ID:L KT-EXTR- 58 Photo1. External view Label location Photo2. Connectors view

Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com LKT-EXTR-CPE-49 LKT-EXTR-CPE-50 CPE housing modification Alvarion Ltd. BreezeCOM and Floware unite 21a HaBarzel St. Tel Aviv, 69710 Israel Main Line / Fax: 972 3 645 6262 / 6222 www.alvarion.com

LABEL AND LABEL PLACEMENT Alvarion Ltd. FCC ID: LKT-EXTR-CPE-49H Alvarion Ltd. FCC ID: LKT-EXTR-CPE-49H This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference than may cause undesired operation Breez eMAX Extreme Base statio n FCC ID:L KT-EXTR- 58 Photo1. External view Label location

Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 7 photographs Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 2 of 8 Photograph No.1 BreezeMAX Extreme 5GHz CPE internal view with integral antenna Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 3 of 8 Photograph No.2 BreezeMAX Extreme 5GHz CPE internal view Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 4 of 8 Photograph No.3 Radio module printed circuit board front view Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 5 of 8 Photograph No.4 RF module PCB second side view Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 6 of 8 Photograph No.5 RF module second side without shield Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 7 of 8 Photograph No.6 Main PCB front view Alvarion Ltd. FCC ID:LKT-EXTR-CPE-49 Page 8 of 8 Photograph No.7 Main PCB second side view

Breez eMAX Extreme Base statio n FCC ID:L KT-EXTR- 58 Photo1. External view Label location Photo2. Connectors view R a d i o 1 D i g i t a l c a r d Photo3. Top view, m odules with covers Radio2 Photo4. view with Internal antenna assem b led I n t e r n a l a n t e n n a Photo5. Internal antenna Photo6 View with one radio assem b led Photo7 . Digital card PC B view Photo8. Digital card and radio with RF covers removed Photo9. Digital card and two radio m odules CS view Photo10 Digital card CS view Photo11 . Radio m odule CS view Photo12 Radio m odule PS view

Test Report No. 9012332799 Applicant: Alvarion Ltd Equipment Under Test (EUT): BreezeMAX Broadband Wireless Access BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A From The Standards Institution Of Israel Industry Division Telematics Laboratory EMC Section ACLASS Accreditation Services Certificate Number: AT-1359 Test report N: 9012332799 Page 1 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H Table of contents 1. Applicant information 2 2. Test performance 2 3. Summary of test 3 4. Equipment under test description. 4 4.1 General description 4 5. Environmental evaluation and exposure limit according to FCC part 1, §1.1307, §1.1310 5 6. EUT test configuration 5 7. Test results 6 7.1 Transmitter characteristics 6 7.1.1 Peak transmit power test according to §90.1215(a). 6 7.1.2 Peak power spectral density test according to §90.1215(a). 11 7.1.3 Power spectral density mask according to §90.210(m). 12 7.1.4 Undesired conducted emissions test according to § 90.210 m 15 7.1.5 Undesired radiated emissions test according to § 90.210 (m). 23 7.1.6 Ratio of the peak excursion per part 90.1215(e) 37 7.1.7 Frequency stability according to § 90.213 41 8. APPENDIX A 42 9. APPENDIX B 44 10. APPENDIX C 49 Test report N: 9012332799 Page 2 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H 1. Applicant information Applicant: Alvarion Ltd Address: 21A Habarzel str, Tel-Aviv, 69710, Israel Sample for test selected by: The customer The date of tests: 9, 11 May, 15, 20-21 June 2010. Equipment under test information Description of Equipment Under Test (EUT ): BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A Serial Number: NA Manufactured by: Alvarion Ltd 2. Test performance Location: SII EMC Section Purpose of test: Apparatus compliance verification in accordance with emission requirements Test specifications: 47 CFR parts 90. 210 – 90. 215 part 1 §1.1310 Reference Documents: CFR 47 FCC: Rules and Regulations; Part 15. “Radio frequency devices”; Part. 90. Private land mobile radio services. This Test Report contains 49 pages and may be used only in full. This Test Report applies only to the specimen tested and may not be applied to other specimens of the same product. Test report N: 9012332799 Page 3 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H 3. Summary of test The EUT was found to be in compliance with requirements of: 47CFR Part 90, §§ 90.210, 90.213 and 90.1215. Transmitter characteristics Subclasses Peak transmitter power 90.1215(a) Peak power spectral density 90.1215(a) Power spectral density mask 90.210(m) Undesired conducted emissions test 90.210 m Undesired radiated emissions test 90.210 m Ratio of the peak excursion test 90.1215(e) Frequency stability test 90.213 Electronics and Telematics Laboratory 22 June 2010 Test performed by: Mr. Michael Feldman Test technician Test report approved by: Mr. Yuri Rozenberg. Head of EMC Branch Test report N: 9012332799 Page 4 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H 4. Equipment under test description. *The customer provided description. 4.1 General description BreezeMAX Extreme 5x is a high capacity, IP services oriented Broadband Wireless Access system. BreezeMAX Extreme 5x is digital modulated TDD system operating in the 4900MHz up to 5950MHz band. The system contains a Base station unit and a Subscriber unit. Subscriber unit configuration: The basic system configuration is a two-box configuration that contains Indoor unit that contains a power supply and an Ethernet 10/100BaseT (RJ 45) interface. Outdoor unit containing the entire radio and digital section . Radio Input/Output is connected to two N type connectors , TX/RX and RX allowing connection to dual port antenna . A single CAT5 cable connecting the indoor and outdoor unit serves for carrying the data as well as for transferring power, management and control signals. The subscriber indoor unit is a single power supply (55VDC) and Ethernet 10/100BaseT (RJ 45) interface . EUT technical characteristics Transmitter technical characteristics. Note Stand-alone/fixed use Assigned frequency range 4940 MHz – 4990 MHz 4942.5 MHz – 4987.5 MHz 5 MHz EBW 4945 MHz – 4985 MHz 10 MHz EBW RF channel spacing 5/10 MHz Antenna connection Internal SMA connector. Type of modulation QPSK, 4QAM, 16QAM, 64QAM Type of multiplexing OFDM Modulating test signal (baseband) PRBS Antenna information Type Manufacturer Model Gain, dBi Internal antenna, dual slant Laird Technologies AN1417-02 17 Test report N: 9012332799 Page 5 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H 5. Environmental evaluation and exposure limit according to FCC part 1, §1.1307, §1.1310 Limit for power density for general population/uncontrolled exposure is 1(mW/cm 2 ) or 10 (W/m 2 ). The power density calculation is S = (Pt /4π r 2 ). Where: Pt - The transmitted power (EIRP) (mW) r - The distance from the unit. (cm) The limit 1(mW/cm 2 ) can be calculated from the above based on the following data: Pt- the transmitted power whish is equal to the peak output power 23.5 dBm plus external antenna gain 17 dBi. The maximum peak EIRP = 40.5 dBm = 11220 mW Maximum allowed distance “r”, where RF exposure limits may not be exceeded, r = SQRT (11220/4π) and is more than 30 cm from the antenna main lobe. 6. EUT test configuration BM-XTRM-CPE-4.9 (ODU) AC/DC P.S (IDU) AC power lineETH signal line Fig. 1. EUT block diagram. Test report N: 9012332799 Page 6 of 49 Title: BreezeMax Extreme CPE System 5.x Model: XTRM-SU-OD-1D-4.9-2-A FCC ID: LKT-EXTR-CPE-49H 7. Test results 7.1 Transmitter characteristics 7.1.1 Peak transmit power test according to §90.1215(a). Method of measurement FCC part 90.1215 (c). Operating Frequency Range 4942.5 – 4987.5 MHz Ambient Temperature 22 0 C Relative Humidit…

Text truncated - open the document above for the full version.
