BreezeNET PRO.11 Series Outdoor Bridge User’s Guide (for models using AMP2400S-250/500) October, 2000 Cat. No. 213034 Revision 2 Disclaimer: The diagrams in this manual are for illustrative purposes only. They should not be confused with the transceiver operating in a standalone mode. When these diagrams are in use, the transceiver will be installed in conjunction with amp model AMP-2400S-250/500 and the antennas listed in Table 1. © 2000 by BreezeCOM Ltd. All rights reserved. No part of this publication may be reproduced in any material form without the written permission of the copyright owner. Trade Names BreezeNET and BreezeLINK are trade names of BreezeCOM Ltd. Other brand and product names are registered trademarks or trademarks of their respective companies. Statement of Conditions The information contained in this manual is subject to change without notice. BreezeCOM Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or equipment supplied with it. Warranty In the following warranty text, “the Company” shall mean: - BreezeCOM Inc., for products located in the USA. - BreezeCOM Ltd., for products located outside the USA. This BreezeNET product is warranted against defects in material and workmanship for a period of one year. During this warranty period the Company will, at its option, either repair or replace products that prove to be defective. For warranty service or repair, the product must be returned to a service facility designated by the Company. Authorization to return products must be obtained prior to shipment. The buyer shall pay all shipping charges to the Company and the Company shall pay shipping charges to return the product to the buyer. The Company warrants that the firmware designed by it for use with the unit will execute its programming instructions when properly installed on the unit. The Company does not warrant that the operation of the unit or firmware will be uninterrupted or error-free. Limitation of Warranty The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by the buyer, buyer supplied interfacing, unauthorized modification or misuse, operation outside of the environmental specifications for the product, or improper site preparation or maintenance. No other warranty is expressed or implied. The Company specifically disclaims the implied warranties of merchantability and fitness for any particular purpose. Electronic Emission Notices This device complies with Part 15 of the FCC rules, ETSI 300-328, UL, UL/C, TUV/GS, and CE. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. "Professional Installers Only : Detached antennas should be installed ONLY by experienced antenna installation professionals who arefamiliar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void the BreezeNET product warranty and may expose the end user to excessive Radio Frequency hazard that may bring legal and financial liabilities." "Regulations regarding maximum antenna gains, amplifier power gain, and maximum permissible expose vary from country to country. It is the responsibility of the end user to operate within the limits of these regulations and to ensure that only professional installers install this device that are aware of these regulations and trained or recommended by Breezecom, as well. " FCC Radiation Exposure Statement i) This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment when installed as directed. This equipment should be installed and operated with fix-mounted antennas that are installed with a minimum of 2 meters of separation distance between the antenna and all persons body during normal operation and the antennas as shown below: Antenna Type Gain (dBi) EIRP (mW) Amp Peak output Power (mW) Minimum RF Exposure Separation Distance (m) Uni Grid 24 24 831.8 208.9 2 Uni Patch 16 16 446.7 208.9 2 Uni Patch 16 16 955.0 446.7 2 Uni Patch 11 11 309.0 208.9 2 Uni Patch 11 11 660.7 446.7 2 Uni Patch 9 9 263.0 208.9 2 Uni Patch 9 9 562.3 446.7 2 Omni 8 8 1318.3 208.9 2 Omni 8 8 2818.4 446.7 2 WARNING: It is the responsibility of the professional installer to ensure that when using the outdoor antenna kits in the United States (or where FCC rules apply), only these antenna configurations shown in the table in section 1.4 are used. The use of any antenna other than those listed is expressly forbidden in accordance to FCC rules CFR47 part 15.204.Information to User Any changes or modifications of equipment not expressly approved by the manufacturer could void the user’s authority to operate the equipment and the company’s warranty. CONTACTING BREEZECOM TECHNICAL SUPPORT Should you need assistance beyond the scope of this guide, please contact your local BreezeCOM reseller or distributor. If they cannot solve your problem, feel free to contact the BreezeCOM Technical Support Department. The support representatives can assist you in solving any problems that cannot be solved by your reseller. When requesting support, please have the following items available: • Configuration of the system, including models of the BreezeCOM equipment used. • Antenna type and cable lengths. • Site information such as, possible radio path problems (trees, machines, and buildings). • Distance between devices. • Configuration, statistic counters, and error messages, as seen on the monitor. • Description of problems encountered. To contact BreezeCOM Technical Support, refer to the Technical Support page of the BreezeCOM website: www.breezecom.com Introduction To The BreezeNET PRO.11 Series BreezeNET PRO.11 Series 1-1 User’s Gui…

Text truncated - open the document above for the full version.

Catalog BreezeNET ® Model D Antenna Kits ModelAnt. Gain † Kit Gain ‡ Dispersion MountingDimensionsCableKit Ideal Order No.(Oriented verticallyWall MastH x W x DLengthContains:for: as pictured) OMNI-66 dBi5 dBi360° H/26° VS013" x 0.75"4-ftOMNI-6 AntennaExtending indoor range 872108TubularMounting Hardwareof access points and 4-ft Cable Assemblystation adapters OMNI-7.2 7.2 dBi6 dBi360° H/22° VSS16" x 0.75"20-ftOMNI-7.2 AntennaEstablishing 360° 872914TubularMounting Hardwarecoverage for outdoor 20-ft Cable Assemblymultipoint links UNI-8.5 8.5 dBi6 dBi75°H/60° VSN/A4" x 3.7" x 1.2"8-ftUNI-8.5 Antenna Extending indoor 872109Mounting Hardwarerange of access points 8-ft Cableand/or station adapters UNI-8.5Ext 8.5 dBi6.5 dBi75°H/60° VSO4" x 3.7" x 1.2"8-ftUNI-8.5 AntennaShort range outdoor 872909Mounting Hardwaremultipoint links 8-ft Cable Assembly UNI-11P-75 11 dBi9 dBi75°H/28° VOS11" x 7.5" x 3.5"30-ftUNI-11P-75 AntennaISPs, school districts, and 872917Mounting Hardwarecampus area networks requir- 30-ft Cable Assemblying wide dispersion patterns UNI-13P 13 dBi11 dBi46°H/28° VOS11" x 7.5" x 3.5"20-ftUNI-13P Antenna Medium range outdoor 872913Mounting Hardwaremultipoint links 20-ft Cable Assembly UNI-16P 16 dBi14 dBi28°H/28° VOS11" x 11" x 3.5"30-ftUNI-16P Antenna Medium to long range out- 872916Mounting Hardwaredoor multipoint links requir- 30-ft Cable Assemblying compact form factors UNI-18 18 dBi15 dBi12°H/14° VOS16" x 20" X 15"30-ftUNI-18 Antenna Long range outdoor 872918Mounting Hardwarepoint-to-point and 30-ft Cable Assemblymultipoint links UNI-24 24 dBi19 dBi6° H/10° VOS24" x 36" x 15"50-ftUNI-24 AntennaLong range outdoor 872924Mounting Hardwarepoint-to-point links 50-ft Cable Assembly † Antenna Gain is the gain of the antenna without the cable. ‡ Kit Gain is the actual gain of the antenna kit as it is shipped from BreezeCOM. O = Optional S = Standard Omni-2 Uni-11P-75 & Uni-13P Omni-6 Uni-16P Omni-7.2 Uni-18 Uni-8.5 & Uni-8.5Ext Uni-24 Products Accessories BreezeCOM’s BreezeNET ® Model D Antenna Kits offer unparalleled flexibility and the widest range of configurations available today for building-to-building and in- building wireless networking applications. This comprehensive line of omni- and uni- directional antennas can be mixed and matched to create point-to-point and multipoint LAN-to-LAN connections up to eight miles apart. By choosing the optimum gain and dispersion patterns from BreezeNET’s extensive line of detachable antennas, you can set up high performance network links for almost any application including ISP connections, and industrial, educational, health care, and retail networks, to name just a few. Like all BreezeNET products, antenna installation is a breeze, thanks to small form factors, light weight, and low wind resistance. Easy to use mounting hardware fits a wide variety of masts and may also be attached to walls and ceilings, simplifying installation, while saving both time and money for value added resellers, systems integrators, and end users. A wide range of accessories, including extension cables, lightning arrestors, and amplifiers are available to accommodate any type of outdoor or indoor environment. ModelDescriptionApplication Order No. AL-1In-line lightning arrestor with 5-ft Recommended for ALL outdoor 872905extension cable, wall mount bracketantennas, helps prevent damage (requires ground strap)due to nearby lightning strikes SPF-1In-line band pass filterRecommended for higher gain 872911antennas, reduces out-of-band interference and emissions LNA-10 Low Noise Receive Pre-AmplifierUse with receiveantennas of any 872219gain, provides a 5 dB boost LNA-10Same as above, except 240 VACUse with receiveantennas of any 872249gain, provides a 5 dB boost EXT-10 87291010-ft LMR600 Extension CableUse instead of, or in addition to EXT-20 87292020-ft LMR600 Extension Cablecable provided with antennas EXT-30 87293030-ft LMR 600 Extension Cable EXT-50 87295050-ft LMR 600 Extension Cable EXT-70 87297070-ft LMR 600 Extension Cable EXT-100 8729100100-ft LMR 600 Extension Cable EXT-150 8729150150-ft LMR 600 Extension Cable EXT-200 8729200200-ft LMR 600 Extension Cable BR-WM6 Wall or mast mount bracket for one Enables multiple antennas to be 872241or two OMNI-6, OMNI-7.2, UNI-8.5mounted side-by-side BR-WM12 Wall or mast mount bracket for oneEnables multiple antennas to be 872156or two UNI-18, UNI-24 mounted side-by-side BR-WMAST Wall mount for 12" mast for use withEnables a single mast mount 872901any mast-mount antennaantenna to be mounted on a parapet, wall or under eaves AL-1 EXT-10 thru EXT-200 SPF-1 BR-WM6 LNA-10 BR-WM12 BR-WMAST BreezeCOM is a leader in the development and production of wireless communica- tions products for telecommunications, data communications and wireless LAN applications. Our high performance products use frequency-hopping, spread- spectrum radio technology and operate in the license-free 2.4 GHz ISM (industrial, scientific and medical) band. Already proven in building-to-building, in-building and mobile applications, BreezeCOM’s BreezeNET product line is up to three times faster than the competition, and offers superior range—up to 8 miles outdoors, 600-ft indoors and at roaming speeds of up to 50 mph. Software upgrade- able to the new 802.11 standard and compatible with 802.3 Ethernet, BreezeNET products are extremely reliable, easy to install and offer an exceptionally cost-effective way to add connectivity in your organization. Visit us on the web: http://www.breezecom.com Or callBreezeCOM ® Phone: (760) 431-9880 Fax: (760) 431-2595 BreezeCOM, Inc. 2195 Faraday Avenue, Suite A Carlsbad, CA 92008 © 1998 BreezeCOM, Inc BreezeCOM and BreezeNET are registered trademarks of BreezeCom, Inc. and trademarks of BreezeCom, Ltd. All other brand and product names are registered trademarks or trademarks of their respective companies. BreezeCom does not take responsibility for any damages incurred due to technical inaccuracies in this document. Conten…

Text truncated - open the document above for the full version.

BreezeCOM BreezeNet Radio Board Description Page 1 of 19 BreezeNet Functional Description and Block Diagram Description AP-10D, AP-10 Access Point; SA-10D, SA-10 Station Adapter and WB-10D, WB-10 Wireless Bridge. 1.Functional Description. These devices are designed to operate under IEEE 802.11 standard (Frequency Hopping Spread Spectrum). The hardware of the AP-10, AP-10D, SA-10, SA-10D, WB-10, WB-10D is identical. All products have integrated antennas implemented in two ways: “D” models have non-standard interface for connection with antennas, non”D” models have a fixed integral antennas which require disassembly of the unit in order to be removed. A list of utilized antennas is supplied. 2.Block Description. The device includes 3 main parts: RF part. Baseband part Digital part The device consists of a single board that includes the following sections: 1. A Radio Transceiver that transmits and receives the radio signals. 2. A Modem that handles the modulation/demodulation tasks. 3. A Controller that handles the protocol and the ethernet port. The block diagram of device is shown in Fig.1. BreezeCOM BreezeNet Radio Board Description Page 2 of 19 Antenna Section + LED's RF Transceive r Analog I/F MODEM BBBB ANT1 ANT2 Control Bus System Bus I/O DRAM Bank's FLASH CPU 32 CPM Serial Bus LIU Ethernet Baseband and Radio Parts E2 DC Section ControllerController DownLoad Conn. Monitor Ethernet DC Digital Part Fig.1.Block Diagram of Device. 3.Block Diagram of RF Part. 3.1The RF part has 2 main functions: 1. Modulate and transmit analog data. 2. Receive and demodulate the RF signals and forward these signals to the Baseband processor in analog form. The block diagram of the radio is shown in Fig. 2. 3.2Oscillators. There are three RF oscillators on the RF board: 1. Tx VCO (Modulator), which continuously operates at 880 MHz, and in transmit mode is divided by two; 2. Rx VCO, serves as LO for the second conversion, Operates at 463 MHz; 3. Hopping synthesizer, Operate in the frequency range of 1962 MHz to 2040 MHz, Step size is 1 MHz. There is also a Reference Oscillator that operating at 40 MHz. After division by 2 its signal is used as reference for all 3 VCO’s. All 3 synthesizers are frequency locked by use of PLL. 3.3Transmit Path. BreezeCOM BreezeNet Radio Board Description Page 3 of 19 The transmit path consists of a modulator operating at twice the IF frequency, Hopping VCO, Up converter, PA and Diversity switch. In transmit mode the divider is operated and thus enabling the division of the modulator by 2. This signal is upconverted by mixing it with the hopping signal that operates as LO. The mixed signal that is now in the 2.4 GHz band is filtered and fed to the PA, filtered again and through the diversity switch feeds the antenna. The modulating signal is a 2, 4 or 8 levels analog signal. 3.4Receive Path. The received signal is received in any of the antennas, selected by the diversity switch, filtered and transferred to the LNA, filtered again and down converted by mixing the received signal with the hopping synthesizer. The product has a 440 MHz IF where the signal is filtered and down converted to 23 MHz where it is demodulated into baseband signal. The baseband signal is filtered and transferred to the baseband processor. The output signal is a 2, 4, or 8 levels analog signal with 0.5 MHz bandwidth. P/FLPFP/FLPF P/FLPF /2 20 MHz Rx Out Tx In 440 MHz 880 MHz 23 MHz Fig.2. Radio Part Block Diagram BreezeCOM BreezeNet Radio Board Description Page 4 of 19 4.Block Diagram of Baseband Part. Baseband Part consists of Modem and Analog interface for Radio (see Fig.1). The Modem chip (BOORI) is the system master clock distributor (see Fig.3). It is running from 40MHz Crystal Oscillator Circuit (+/- 10ppm tolerance and +/- 4ppm stability ). R _CLK1 default frequency is 4MHz which is division by 2.5 and 4 from the 40MHz clock. R_CLK1 R_CLK2 EXT_CLK20_40 BOORI 40MHz CLK_4M Ethernet 20MHz reference clock 68360 PLL Input Radio 20Mhz reference clock N.C DF.F Clk Div by 2 CLK_20M Oscil. circuit Fig.3. Clock Distribution 5.Block Diagram of Digital Part. The Digital Part consist of (see Fig.1):  CPU 31Mhz MC68EN360 controller (QUICC);  Memory 16/32Mbit 16 bits bus width sector erase Flash with 64kB uniform sectors; Additional 64kB E^2PROM; BreezeCOM BreezeNet Radio Board Description Page 5 of 19 DRAM banks; 48 bits MAC address serial ROM (BreezeCom customized special regitry);  I/O Ports 24 bits off-QUICC Input/Output ports; 8 SMD miniature DIP switches and 8 hard jumpers for software and hardware configurations and versions.  Monitor Ports 3 wires miniature connector 2 on-PCB test pads (optionally, for BOORI debugging) RS232 Transceiver  Ethernet (see Fig.4) 1 10BaseT port; Motorola compatible Ethernet transceiver; 10BaseT Analog interface for 1 port. QUICC Lxt901 or EEST Additional C.M.C SCC1 Ethernet Port LIU- Ethernet LPF LPF LPF LPF Analog Interface AP / SA Cross LOOP LINK Activity / Link 20MHz Fig.4. Ethernet Interface Block Diagram BreezeCOM BreezeNet Radio Board Description Page 6 of 19 BreezeNet Functional Description and Block Diagram Description SA-40D, SA-40 Four Port Adapter 1.Functional Description. These devices are designed to operate under IEEE 802.11 standard (Frequency Hopping Spread Spectrum). The hardware of the SA-40, SA-40D is identical. All products have integrated antennas implemented in two ways: “D” models have non-standard interface for connection with antennas, non”D” models have a fixed integral antennas which require disassembly of the unit in order to be removed. A list of utilized antennas is supplied. The SA-40(D) is based on the hardware and software of the SA-10(D). RF and Baseband parts of SA-40(D) and SA-10(D) are identical, however digital part of SA-40(D) has some additional hardware options for 4 ports Ethernet. The software of SA-40(D) is identical to SA-10. 2.Block Description. The device includes 3 main parts: RF part. Baseband part Digital part The device c…

Text truncated - open the document above for the full version.

October 4, 2000 RE: Breezecom LTD. LKTEAP-11AMP Desmond, 1.) The Confidentiality letter is not appropriate. No test data including plots can be held confidential. 2.) The photographs must be separated into inside views and exterior views. This is required by FCC. 3.) The labels are not readable on the label photographs. 4.) The site photos at four per page are too small to be useful. 5.) RF Exposure information should be broken out as a separate file. 6.) I would like to suggest that in the future the MS-DOS filenames should contain the section number of the report. This will save me time in the review process. As an example, rename various extracted files to: a. 200238_Breezecom_Product_ Description_section8.pdf b. 200238_Breezecom_Plots_section13a.pdf c. 200238_Breezecom_Plots_section13b.pdf 7.) Please provide evidence of 15.203 connector requirements if equipment can be used without Teletronics 2400S. Has the Breezcom by itself been Certified previously? 8.) Please confirm if all installations will use the 30’ or greater cable listed in Section 3.2. The manual section 0.1, 0.4 and 8.37 appears to indicate a cable of just 10” could be used. Also note that the last sentence of 3.2 indicates there is a column labeled “Radio Power”: It is not apparent what column is this on the table. 9.) RF Power Output is listed as a maximum of +26.5dBm. Rules specify that RF output must be reduced 1dB below the one-watt limit for every three dB of antenna gain above 6dBi. For the +24dB gain antenna, this means a reduction of [(24-6) / 3], or 4 dB. The maximum conducted power that should be conducted to the antenna is then +26 dBm. Table in 3.2.2 appears to show failing data. 10.) In Section7, please indicate how 15.204(b) bi-directional module will be labeled. 11.) The product description appears to refer exclusively to the 15.204 (b) transmission system. It does not include anything about the Breezcom transceiver. Is this appropriate? 12.) The language of page 0.6 of the manual could be interpreted to permit indoor installations. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal pursuant to Section 2.917(c). Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not reply to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must attach your answers to email correspondence. Reply to the examiner at the email address shown below. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. William H. Graff Examining Engineer Vice President of Engineering AmericanTCB, Inc. 6731 Whittier Avenue McLean, VA 22101 Ph: (703) 847-4700 FAX: (703) 847-6888

Electro Magnetic Interference Testing and Engineering Wireless Testing, Electrical Safety Testing, PCB Designs, and Hardware Design Engineering 360 Herndon Parkway, Suite 1400, Herndon, VA 20170 Tel: 703-689-0368, Fax: 703-689-2056 To: Mr. William H. Graff, NARTE Certified October 4, 2000 Vice President of Engineering AmericanTCB, Inc. 6731 Whittier Avenue McLean, VA 22101 RE: Breezecom FCC ID: LKTEAP-11AMP Dear Graff, In response to your letter dated 10-4-00 the following are answers to your questions. 1. Corrected and uploaded as new1_new1_Confidential_letter.pdf 2. Corrected and uploaded as new1_ 2000283_Breezecom_External_Pictures.pdf and new1_2000283_Breezecom_Internal_Pictures.pdf. 3. Corrected and uploaded as new1_200238_breezecom_label.pdf 4. Corrected and uploaded as new1_Measurement_Photos.PDF 5. Corrected and uploaded as new1_2000283_Breezecom_RF_Exposure.pdf 6. We will adhere to this new naming convention in the future. 7. The EUT will be sold as a separate system only. The transceiver unit was originally certified under FCC ID: LKTE AP-10N 8. Corrected and uploaded as new1_2000283_Breezecom_Report.pdf. The 30’ and radio power text were a left-over text from the boiler plate report used to prepare this application. 9. The 24 dBi gain antenna is not support using the 500 mW (26.5 dBm) AMP. There are no failing data. See report and manual. 10. The Transceiver unit will contain the FCC ID label. Model numbers will be affixed to the Amplifier and DC power injector. 11. Corrected and uploaded as new1_2000283_Breezecom_Product_Description.pdf. See functional description file. 12. Corrected and uploaded as new1_Manual1_BRZN11.pdf If you need any further information please call. Desmond A. Fraser President

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 78 of 106 14 EXTERNAL EUT PICTURES AMPLIFIER (TOP VIEW AMPLIFIER (BOTTOM VIEW) 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 79 of 106 AMPLIFIER (LEFT SIDE VIEW) AMPLIFIER (RIGHT SIDE VIEW) 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 80 of 106 AMPLIFIER FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 81 of 106 DC POWER INJECTOR TOP VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 82 of 106 DC POWER INJECTOR BOTTOM VIWE DC POWER INJECTOR REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 83 of 106 DC POWER INJECTOR FRONT VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 84 of 106 RADIO TRANSCEIVER HOUSING AND RF BOARD COMPONENT SIDE WITH SHIELD 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 85 of 106 RADIO TRANSCEIVER UNIT RIGHT AND LEFT SIDE VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 86 of 106 RADIO TRANSCEIVER UNIT FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 87 of 106 RADIO TRANSCEIVER UNIT TOP AND BOTTOM VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 88 of 106 SERIAL INTERFACE CABLE Low loss cables 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 89 of 106 AMP AC/DC POWER SUPPLY FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 90 of 106 Transceiver power supply front and rear view 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 91 of 106 power cable to transceiver supply 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 92 of 106 24 UNI DIRECTIONAL ANTENNA FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 93 of 106 OMNI-8 OMNI DIRECTIONAL ANTENNA 250 Feet low loss cable 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 94 of 106 PATCH-16 DIRECTIONAL ANTENNA FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 95 of 106 PATCH-11 DIRECTIONAL ANTENNA FRONT AND REAR VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 96 of 106 UNI-9 UNI DIRECTIONAL ANTENNA FRONT AND REAR VIEW

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 36 of 106 7 LABEL PLACEMENT 7.1 FCC L ABEL 7.2 L OCATION OF L ABEL ON

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 97 of 106 15 INTERNAL EUT PICTURES AMPLIFIER COMPONENT AND SOLDER SIDE 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 98 of 106 AMPLIFIER PCB INSIDE CHASSIS AMPLIFIER INSIDE CHASSIS AND BOTTOM CHASSIS 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 99 of 106 AMPLIFIER TOP COVER DC POWER INJECTOR INSIDE CHASSIS VIEW 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 100 of 106 DC POWER INJECTOR COVER Dc Power Inject Inside Case DC Power component side 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 101 of 106 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 102 of 106 DC Power solder side 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 103 of 106 TRANSCEIVER INTERFACE PCB COMPONENT AND SOLDER SIDE 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 104 of 106 Transceiver PCB shields Misc antenna mounting brackets

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 37 of 106 8 PRODUCT DESCRIPTION 8.1 G ENERAL P RODUCT D ESCRIPTION AMP2400SS is a new bi-dire cti onal antenna-mount amplifier that consists of an intell igent algorit hm and Automati c Gain Controlled (AGC) circuits to maintain the output power and prevent transmit signal saturation. The input transmit power level is sensed by the Radio Frequency (RF) sensor and the gain is automatically adjusted to minimize the signal distortion so that the desired signal quality can be assured. Thus full RF output is delivered at wide input range (2mW to 200mW). Due to these advance features any cable length between 10 inch and 250 foot can be used a part of FCC certified setup without compromising the signal strength. The built-in attenuator triggers and controls the input signal when the power increases a certain threshold. Thus the amplifier never goes to saturation and stays in linear operating mode at all input levels to a maximum of 23 dBm. The temperature compensatory circuitry further compensates for any changes to the signal due to temperature variations. Each Amplifier Kit Includes: • Bi-directional Amplifier, AMP2400S-250 or AMP2400S-500 • DC Power Injector • 5ft. LMR-400 cable (N-male to N-female) • 2 N-male to N-male adapters • 100/250 VAC to 7.5VDC Power Supply • Stainless Steel U-Bolt and mounting hardware • Vapor wrap coaxial connector sealing tape • Installation Manual 8.2 S PECIFICATIONS Operating Range 2400 ~ 2500 MHz Operating Mode Bi-directional TDD Transmit Output Power +27. dBm at the output connector (500mW) Transmit Input Power 0 dB min, 23 dB max. Transmit Gain Automatically adjusts up to 26dB Receive Gain 14 dB Frequency Flatness ±1.0 dB Noise Figure 3.5 dB Lightening Protection Direct DC ground at antenna port DC Surge Protection At 7.5 V DC input LED indicators on Amp Tx: Green, Rx: Red Operating Temperature -40 °C ~ + 70 °C Power Supply 7.5 V DC at 0.7 amp RF Connectors Type N, Female 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Page 38 of 106 8.3 P RODUCT D ESCRIPTION FOR THE DC P OWER I NJECTOR “TO DC Injector” Connection This “N” Female connector is connected to the DC Power Injector via the transmission cable DC Power Injector Connections and Indicators A DC Power Injector is an in-line device which “injects” the DC power necessary to operate the amplifier onto a transmission line. This allows the cable to carry both RF signals and DC power to the mast-mounted amplifier. LED Green LED indicates DC power on. “To Radio” Connection: This “N” Female connector is connected to the radio modem via a short jumper RF cable. “To Amplifier” Connection: This “N” Female connector connects to the amplifier on the mast via the transmission cable. 12 VDC: DC power input for the injector with standard 2.5mm barrel jack. +7.5VDC should be applied with center positive. For product description of the TU refer to "funtional_description_block-diagram file.
