LLM007WL11000-2Wireless LAN Card

W W L L 1 1 1 1 0 0 0 0 0 0 Wireless LAN PCMCIA Adapter USER MANUAL Version 0.9.2, February 16, 2000 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and receiver. ! Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ! Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. This device requires a radio license, unless it (including antenna ) is installed totally inside a building. (User must obtain this license from Industry Canada ). Printed in Taiwan 3 Contents Chapter 1 About the WL11000 PCMCIA Card ........................................................... 4 1-1 Features .............................................................................................................................................. 4 1-2 Applications ......................................................................................................................................... 4 1-3 Product Kit ........................................................................................................................................... 5 Chapter 2 Network Configuration and Planning ...................................................... 6 2-1 Network Topology................................................................................................................................ 6 2-2 Roaming .............................................................................................................................................. 8 Chapter 3 Adapter Installation and Configuration – Windows ® 98 ......................... 9 3-1 System Requirements ......................................................................................................................... 9 3-2 Inserting the Adapter ........................................................................................................................... 9 3-3 WL11000 Driver Installation -Windows ® 98 ....................................................................................... 10 3-4 Adapter Configuration – Windows ® 98............................................................................................... 13 3-5 Protocol Installation – Windows ® 98 .................................................................................................. 19 3-6 WL11000 Setup for Windows NT 4.0 ................................................................................................ 24 Chapter 4 Installing and Navigating the PRISM Configuration Utility .................. 28 4-1 PRISM Configuration Utility - Installation........................................................................................... 28 4-2 PRISM Configuration Utility- Navigation ............................................................................................ 31 Appendix A Troubleshooting................................................................................... 36 Appendix B Glossary................................................................................................ 38 4 Chapter 1 About the WL11000 PCMCIA Card The WL11000 IEEE 802.11 PCMCIA PC Card is compatible with any standard, notebook computer Type II or Type III PCMCIA slot. As a Plug-and-Play device, Windows 95/98 will automatically recognize the WL11000 PCMC…

Text truncated - open the document above for the full version.

W W L L 1 1 1 1 0 0 0 0 0 0 Wireless LAN PCMCIA Adapter USER MANUAL Version 0.9.2, February 16, 2000 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and receiver. ! Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ! Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. This device requires a radio license, unless it (including antenna ) is installed totally inside a building. (User must obtain this license from Industry Canada ). Printed in Taiwan 3 Contents Chapter 1 About the WL11000 PCMCIA Card ........................................................... 4 1-1 Features .............................................................................................................................................. 4 1-2 Applications ......................................................................................................................................... 4 1-3 Product Kit ........................................................................................................................................... 5 Chapter 2 Network Configuration and Planning ...................................................... 6 2-1 Network Topology................................................................................................................................ 6 2-2 Roaming .............................................................................................................................................. 8 Chapter 3 Adapter Installation and Configuration – Windows ® 98 ......................... 9 3-1 System Requirements ......................................................................................................................... 9 3-2 Inserting the Adapter ........................................................................................................................... 9 3-3 WL11000 Driver Installation -Windows ® 98 ....................................................................................... 10 3-4 Adapter Configuration – Windows ® 98............................................................................................... 13 3-5 Protocol Installation – Windows ® 98 .................................................................................................. 19 3-6 WL11000 Setup for Windows NT 4.0 ................................................................................................ 24 Chapter 4 Installing and Navigating the PRISM Configuration Utility .................. 28 4-1 PRISM Configuration Utility - Installation........................................................................................... 28 4-2 PRISM Configuration Utility- Navigation ............................................................................................ 31 Appendix A Troubleshooting................................................................................... 36 Appendix B Glossary................................................................................................ 38 4 Chapter 1 About the WL11000 PCMCIA Card The WL11000 IEEE 802.11 PCMCIA PC Card is compatible with any standard, notebook computer Type II or Type III PCMCIA slot. As a Plug-and-Play device, Windows 95/98 will automatically recognize the WL11000 PCMC…

Text truncated - open the document above for the full version.




















WL11000-2 FCC ID label: 1. The FCC ID label will paste in the bottom side of the product.( See figure below)

WL11000-2 FCC ID label: 1. The FCC ID label will paste in the bottom side of the product.( See figure below)

RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the total power input to the antenna is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r) 2 where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 and 78% RH 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are : WL11000-2-D : 3.4 dBi or 2.19 (numeric) WL11000-2-M : -0.48 dBi or 0.895 (numeric) WL11000-2-P : 1.45 dBi or 1.396 (numeric) Gain 2.19 has been chosen to calculated RF exposure distance. 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241227.612.19 6243722.491.98 11246219.501.84 Under the condition of normal use, more than 2.19 cm separation distance between user and the antenna is kept, So, the SAR measurement is not required.





                                                           !   "                     #$ %  &$ '#%&(   )** ++,+-              )  . * ').*("  $               )        $     "        "    "  #%&             "        "
-     /
-            $           0"            .  )**++,+-1                      $  2 '3)(     ++,-4'(
  5!#!0)63#.7!#8#%&3#!00!95&&7%6083&'#%&( )  3  '#( &  )  0 ':;( # )  0 '.;( % <  '/;
( .   '  ( !"  #  $  ,--2+=-->>);,--? +=--2+--"--->>=? %"  &'  $(    ,--2+=-->>);+=--? +=--2+--"--->>+-,- )@)  # )   )      1%@'% A(;'AA
(  %@   /;
% @      / @       %@,++? 3@               % #%&"+/;
!   $             "     "        #%&   3 1<B* "Field and Wave Electromagnetics"0  & " % ?-"& '++2+,,( *(+# ,        #     &8        "
  -+
    $     ) . *









AA BB CC DD EE 4 4 3 3 2 2 1 1 1/4 W, 50R Ant 11m-2 T2.0 DUAL PATCH T2.0 Eumitcom Technology Inc. WL-ANT-PAT A 11 Thursday, August 03, 2000 TitleSize Document Number Rev Date: Sheet of D1BAR63-03W D2BAR63-03W ANT1PCB ANTENNA ANT2PCB ANTENNA R21K 1 2 J1 MMCX(MALE) 1 2 3 G1 S G2 L2 1.2NH L11.2NH C1 2.2PF C310PF C210PF

VS2* (NOT CONNECTED) PCMCIA 3.3 VOLT LOW TAGE KEYED GEN_MODE DIGITAL GROUND ANALOG GROUND 10981112131415 34567 89 128K*8SRAM 128K*8SRAM 2 413 128K*8SRAM 0 0 1 13 3 2 28 8 4 45 56 67 79 9 10 1011 1112 1213 1314 1415 15 11109876532014 T9 89101112131415 01234567810911121314151617 01245637 31 0 4 NC NC NCNCNCNCNC 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 S_CLKS_DATACSBPE1LE_IFSCLK_RF_IFLEDILE_RFSD_RF_IFPA_PEPE2MD_RDYCCACAL_ENTX_PERX_PERESET_BB*T/R_SW* SHEET 3 ANALOG/RF POWERPLANDDIGITAL POWERPLAND LOCATED CLOSE TO MAC AND SRAM DIGITALGROUND T10 ANALOG AND DIGITAL GROUND CL OSE TO CONNECTOR P1 NOTE:HRESET IS ACTIVE HIGH AND TIEO HIGH INTERNALLY IN THO H FA3841 0 CONNECTAGND TO DGNDHERE SHEET 4SHEET 2SHEET 2SHEET 2SHEET 2,3,4SHEET 2SHEET 2SHEET 2SHEET 2SHEET 3,4SHEET 3SHEET 4SHEET 3,4SHEET 3,4SHEET 4SHEET 3,4SHEET 2SHEET 2SHEET 3SHEET 2SHEET 2SHEET 2SHEET 4 WL-SCH-WL11000-2-3V T 2 Eumitcom Technology Inc. W L11000-2 Custom 14 Thursday, August 03, 2000 TitleSize Document Number Rev Date: Sheet of MOD* MA0(MWEH*)RAMCS* RAMCS* MOE* MOE* HD15 HD5 HD10 HD2HD0 MOE* HD0 HD2 HD11HD12 HD1 HD9HD7 HD3 HD14 NVCS HD3HD1 MWEL* HD9 HD13 MWEL* HD4 HD7 HD13 HD14 HD6 HD11 HD10 HD6 HD8 HD4 MWEL* HD5 RAMCS HD8 HD12 HD15 NVCS* MEM CTRL [4..0] MEM CTRL [4..0] MA [17..0] HA[9..0] HA1 HA5 HA1HA4 HA9 HA2 HA6 HA0 HA7 HA8HA7 HA4 HA3 HA5 HA8 HA[9..0] HA6HA3HA0HA9 HA[9..0] HA2 HA[9..0] MA17 MA4 MA16MA15 MA[17..0] MA3 MA4 MA7MA14 MA1 MA12 MA9MA8 MA[0..17] MA11MA9 MA2 MA5 MA13MA16 MA5 MA7 MA13 MA17 MA12MA3MA10 MA11 MA11 MA15 MA0 MA14 MA13 MA12 MA10 MA4 MA16 MA6 MA[7..0] MA9 MA7 MA1 MA15 MA17 MA8 MA0 MA[7..0] MA3MA10MA14 MA8 MA8 MA9MA0 MA5MA7 MA1 MA6 MA5 MA12 MA2 MA16 MA1 MA6 MA6 MA3 MA4 MA2 MA2 MA15 MA10 MA11 MA14 MA13 MA[17..0] MEM CTRL [4..0] MEM CTRL [4..0] HD[1 5..0] HD[15..0] MEM CTRL [4..0] MD13 MD15MD14 MD[15..0] MD15 MD9 MD10 MD14 MD[15..0] MD4 MD4 MD6MD4MD3 MD[0..7] MD7MD1MD0 MD11 MD3 MD8 MD0 MD6 MD[15..0] MD13 MD11 MD[15..0] MD7MD1MD2 MD9 MD4MD5 MD10MD14 MD0 MD6MD3 MD10MD2 MD2 MD12 MD12 MD1 MD0 MD6 MD2 MD12 MD[15..0] MD13 MD7 MD5 MD15 MD5 MD1 MD[15..0] MD[15..0] MD5 MD8MD9 MD[15..0] MD8 MD7 MD3 MD11 HINPACK* HC2 HREG* HC3 HRESET HC0 HWE* HC8 HIREO* HC4 HIOWR* HC6 HSTSCHG* HC1 HSTSCHG* HC1 HIORD* HC7 HRESET* HC0 HWE* HC8 HWAIT* HC5 HCE2* HC10 HIREQ* HC4 HC10 HC[11..0] HC[11..0] HC11 HCE* HC9 HC9 HIOR* HC7 HIOWR* HC6 HCE2* HC[11..0] HREG* HC3 HCE1*HOE* HCE1* HC11 HWAIT* HC5 HINPACK* HC2 P1-51-VCC2 P1-33-IOIS16*ASSEPIED OSI* +3.3V VCCS VCCS VCCS VH VCCS VCCS VCCS VCCS U2 AM29LV010B 1011 54 12 1 31 23 13141516171819203032 7 292827262523222196 824 A16A15A14A13A12A11A10A9A8A7A6A5A4A3A2A1A0CEOEWE DO7DO6DO5DO4DO3DO2DO1DO0 NCNC VCCVSS P1PCMCIA 68X1 1234567891011121314151617181920212223242526272829303132333435363738394041424344454647484950515253545556575859606162636465666867 GND1 D3D4D5D6D7 CE1* A10 OE* A11 A9A8 A13A14 WE*/PGM* IREQ* VCC1 VPP1 A16A15A12 A7A6A5A4A3A2A1A0 D0D1D2 IOIS16* GND2GND3 CD1* D11D12D13D14D15 CE2* RFSH IORD* IOWR* A17A18A19A20A21 VCC2 VPP2 A22A23A24A25 RFU RESET WAIT* INPACK* REG* SPKR STSCHG* D8D9 D10 GND4 CD2* U4 1562LV1024LL 10 7 11 4 12 1 31 23 1314151617 9 32 6 30 5 201918 21222325262728 824 29 A16A15A14A13A12A11A10A9A8A7A6A5A4A3NCOE CD2CD1WEA0A1A2 I/O0I/O1I/O2I/O3I/O4I/O5I/O6 VCCGND I/O7 U1 1562LV1024LL 10 7 11 4 12 1 31 23 1314151617 9 32 6 30 5 201918 21222325262728 824 29 A16A15A14A13A12A11A10A9A8A7A6A5A4A3NCOE CD2CD1WEA0A1A2 I/O0I/O1I/O2I/O3I/O4I/O5I/O6 VCCGND I/O7 U3 HFA3841 72737475767778798081848586878889909192616059 621031303229658 707154555657586869 73534336364212223152726284312115150494847464544 101 100 99 6 5 4 3 2 96 95 94 128 127 126 125 123 106 107 108 109 110 111 112 113 117 118 1 122 121 116 120 119 114 102 103 16 36 104 13 37 42 52 67 82 97 115 24 14 25 39 53 66 83 98 124 9 41 93 105 17 18 19 20 40 38 MA0MA1MA2MA3MA4MA5MA6MA7MA8MA9MA10MA11MA12MA13MA14MA15MA16MA17MA18MD0MD1MD2 TRST TCLKIN PJ0PJ1PJ2PJ3PJ4PJ5 MOE MWECMD7MD6MD5MD4MD3NVCSRAMCS PJ6 PK0PK1PK2PK3PK4PK5PK6PK7 PL0PL1PL2PL3PL4PL5PL6 MD8MD9 MD10MD11MD12MD13MD14MD15 MD0 MD1 MD2 MD3 MD4 MD5 MD6 MD7 MD8 MD9 MD10 MD11 MD12 MD13 MD14 MD15 HA0 HA1 HA2 HA3 HA4 HA5 HA6 HA7 HA8 HA9 HCE1 HCE2 HOE HWE HIOR HIOWR HIREO HREG HINPACK RESET HSTSCHG HWAIT VSS_CORE3 VSS_CORE3 VSS_IO3 VSS_IO3 VSS_IO3 VSS_IO3 VSS_IO3 VSS_IO3 VSS_-CORE3 VCC_CORE3 VCC_CORE3 VCC_CORE3 VCC_CORE3 VCC_IO3 VCC_IO3 VCC_IO3 VCC_IO3 PJ7 XTALO PL7 VCC_IO5 TXD TXC RXD RXC XTALI CLKOUT R3470 12 D5 LED 12 R14560 R721K 12 + C910UF 12 C310.1UF 12 C14 0.1UF 12 C810.1UF 12 + C3410UF 12 L17HMZ 201209T300Y-P 1 2 L3HMZ 201209T300Y-P 1 2 + C10210UF 12 C20 0.1UF 12 C210.1UF 12 C100.1UF 12 C50.1UF 12 C2 0.1UF 12 C3 0.1UF 12 C190.1UF 12 C80.1UF 12 C4 0.1UF 12 C60.1UF 1 2 C70.1UF 1 2 C10.1UF 1 2 R7922K R7822K R622K D1 MA25D10 R747K R847K R21 47K R1222K R422K R222K R122K R26 47K R17 47K R9 47 K R1622K R185.62K R425.62K R11 47K R10 47K R5 47 K CCA MD_RDY SD_RF_IF S_DATA CSB PE1 LE_IF LE_RFSCLK_RF_IFPA_PEPE2CAL_ENTX_PERX_PERESET_BB*T/R_SW* GEN_MODE GEN_MODE S_CLK TX_CLKRX_DATAT/R SWTX_DATARADIO_PD 44MHz_REF RX_CLK T2.0 Rev F AA BB CC DD EE 4321 SMD_23X24 mil-PAD T8T7T6T5T4T3T2T1 NC DIGITAL ANALOG SHEET 1SHEET 1SHEET 3SHEET 3SHEET 3SHEET 3SHEET 3 SHEET 1,3 SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 1SHEET 4 SHEET 4SHEET 4SHEET 4SHEET 3SHEET 3SHEET 3SHEET 3SHEET 3SHEET 3SHEET 3 NO POP WL-SCH-WL11000-2-3V T2.0 Eumitcom Technology Inc. WL11000-2 Custom 24 Thursday, August 03, 2000 TitleSize Document Number Rev Date: Sheet of U5-21-IRDF U5-10-I IN+ COMPCAP2 U5-27-COMPRES2 U5-33-COMPCAP1 /ANT_SEL ANT_SEL RX_RF_AGC MCLK U5-41-BYP TEST0TEST1 TEST2 TEST3 TEST4 TEST5 TEST6 TEST7 TEST0 TEST2TEST1 TEST6 TEST3 TEST5 TEST4 TEST[7..0] TEST[7..0] TEST7 TEST[7..0] U5-32-COMPRES1 U5-14-Q IN- U5-11-I IN- U5-5-/RW VCCS +3.3V R1310K C180.1UFC290.1UF C139 0.01UF C140 0.01UF R29 0 R23 0 R19 0 C36 0.1UF C350.1UF C26 0.1UF C300.1UF C320.1UF R3212.1K R20560 R28619 R30976 C130.1UF C17 0.1UF R3319.1K C25 1000PF C120.1UF + C1110UF + C1510UF R27 0 U5 HFA3861 13 20 456789 1011 2 141312 40393837363…

Text truncated - open the document above for the full version.

AA BB CC DD EE 4 4 3 3 2 2 1 1 1/4 W, 50R Ant 11m-1 T3.0 DUAL DIPOLE T3.0 Eumitcom Technology Inc WL-ANT-DI A 11 Thursday, August 03, 2000 TitleSize Document Number Rev Date: Sheet of C310PF D1BAR63-03W D2BAR63-03W R11K 1 2 U3MMCX(FEMALE) 1 2 IN GND U2MMCX(FEMALE) 1 2 IN GND U1 MMCX(MALE) 1 2 3 G1 S G2 C1 1PF C410PF

RF89070613Page 1/99 FCC ID:LLM007WL11000-2 Issued Date: August 8, 2000 REPORT NO:RF89070613 PRODUCT:Wireless LAN Card MODEL NO:WL11000-2-D, WL11000-2-P, WL11000-2-M SERIAL NO:N/A CLIENT:Eumitcom Technology Inc. ADDRESS:2F, No. 2, Li Hsin Rd., Science-Based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation (ADT Corp.) OFFICE ADDRESS:11F, No. 1, Sec. 4, Nan-King East Rd., Taipei, Taiwan, R.O.C. LABORATORY ADDRESS:No. 47, 14 Ling, Chia Pau Tsuen, Lin Kou Hsian, Taipei Hsien, Taiwan, R.O.C. TEST STANDARD:47CFR Part 15, Subpart C (15.247) & Subpart B TEST DATE:July 5, 2000 TEST RESULT:Pass This test report consists of 99 pages in total. This test report is the property of ADT Corp. and shall not be reproduced, except in full, without the written consent of ADT. ADT hereby returns all rights in data to the client for legal use by the client. The test results contained in this report apply only to the samples tested. Accredited Laboratory RF89070613Page 2/99 FCC ID:LLM007WL11000-2 Issued Date: August 8, 2000 TABLE OF CONTENTS 1CERTIFICATION...............................................................................................4 2SUMMARY OF TEST RESULTS........................................................................5 3DECLARATION OF COMPLIANCE WITH SUBPART B.......................................6 4GENERAL INFORMATION................................................................................7 4.1GENERAL DESCRIPTION OF EUT.................................................................................................................7 4.2DESCRIPTION OF TEST MODE.......................................................................................................................8 4.3TEST METHODOLOGY...................................................................................................................................8 4.4SUPPORT UNITS LIST....................................................................................................................................9 4.5CONFIGURATION OF SYSTEM UNDER TEST.................................................................................................9 5GENERAL INFORMATION OF TEST FACILITY................................................10 5.1TEST LAB....................................................................................................................................................10 5.2CALIBRATION INTERVAL.............................................................................................................................10 6TEST PROCEDURES AND TEST RESULTS.....................................................11 6.1CONDUCTED EMISSION MEASUREMENT...................................................................................................11 6.1.1Test Instruments..........................................................................................................................11 6.1.2Test Procedure............................................................................................................................11 6.1.3 Test Setup.....................................................................................................................................12 6.1.4 Photograph of Test Setup............................................................................................................13 6.1.5EUT Operating condition..........................................................................................................14 6.1.6Climate Condition......................................................................................................................14 6.1.7Test Results.................................................................................................................................15 6.26DB BANDWIDTH MEASUREMENT............................................................................................................24 6.2.1Test Instruments..........................................................................................................................24 6.2.2Test Procedure............................................................................................................................24 6.2.3Test Setup....................................................................................................................................24 6.2.4EUT Operating Condition.........................................................................................................24 6.2.5Climate Condition......................................................................................................................25 6.2.6Test Results.................................................................................................................................25 6.3MAXIMUM PEAK OUTPUT POWER AND RF EXPOSURE MEASUREMENT.................................................29 6.3.1Test Instruments..........................................................................................................................29 6.3.2Test Procedures...........................................................…

Text truncated - open the document above for the full version.
